Eaton 9E1000I, 1000VA 800W, IEC

Accessories included - UPS USB cable Serial cable Quick start guide Safety instructions
ACoutletsquantity - 4 AC outlet(s)
ACoutlettypes - IEC 320
Active power - 800 W
Apparent power - 1000 VA
AutomaticVoltageRegulationAVR -
Backup time (100% load) - 5 min
Battery -
Batterycapacity -
Battery capacity - 9 Ah
Batterytechnology -
Batteryvoltage -
Cablesincluded -
Category - Root/Accessories | Exploitation/Power supply/UPSs and power strips/UPSs
Category Code - UPW
Certificates - IEC/EN 62040-1 IEC/EN 62040-2 CE EAC TUV
Chassis type - Tower
Code - 9E1000I
Color - Black
Depth - 144 mm
Description - Eaton 9E UPS, 1000 VA, 800 W, input: C14, output: 4 x C13, tower
Description - The Eaton 9E is an online double-conversion power protection at an affordable price with compact yet robust construction. This UPS an ideal choice for industrial, medical and information technology (IT) applications and telecommunications.
Design -
Design > Form factor - Tower
Designation - CE+WEEE
Desktop/pedestal Mounting Type - Yes
dimension depth - 440 mm
dimension height - 335 mm
Dimensions - 356 x 228 x 144 mm
Dimensions - 356 x 228 x 144 mm
dimension weight - 11000 g
dimension width - 240 mm
Displaytype -
EAN - 786689166564
ean - 786689166564
Eans - 786689166564
Efficiency - 91%
Environment requirements - Operating temperature: 0 to 40°C Relative humidity: 0-95%, non-condensing Altitude: 3,000 m
Features -
Filters / protection - Overdischarge
Formfactor -
guarantee - 24
guarantee_type - external
Heatdissipation -
Height - 356 mm
HighLights -
Hotswapbattery -
I/O connectors - 1 x RS-232 (COM)
I/O connectors - 1 x USB (Type B)
Inputfrequency - 50/60 Hz
Inputoperationvoltagemax - 300 V
Inputoperationvoltagemin - 100 V
Input ports - Single, IEC320 C14
Input power ports - IEC-C14
Link - https://www.eaton.com/za/en-gb/skuPage.9E1000I.html
LongDesc -
ManufDatasheet - https://www.tdbaltic.ee/leaflets/EATON/9E1000I.pdf
Name - Eaton 9E1000I
Name - Eaton | OnLine UPS | 9E1000I | 1000 VA | 800 W | C14
name - UPS 9E 1000 VA 800 W 9E1000I
Networkcardslot -
No. of batteries - 2
Noiselevel - 37 dB
Numberofbatterycells -
Numberofinputphases -
Numberofoutputphases -
Number of phases input - 1 (230V)
Operatingaltitude -
OperatingrelativehumidityHH -
OperatingtemperatureTT - 0 - 40 °C
Operationalconditions -
Other features - Slot for optional communication card: Network-M2, ModBus-MS or Relay-MS
Outputfrequency - 50/60 Hz
Outputoperationvoltagemax - 240 V
Outputoperationvoltagemin - 208 V
Outputpower - 800 W
Outputpowercapacity - 1 kVA
Output power capacity, VA - 1000 VA
Output power capacity, W - 800 Watts
Output power connector type - IEC 320 C13
Output power ports - 4 x IEC-C13
Package features > Classification of battery - CL126:NE:2016-12-09
Package features > Composition of battery - CL127:KT:2016-12-09
Package features > Embeeded battery - Yes
Package features > Gross depth (mm) - 240.00 mm
Package features > Gross height (mm) - 330.00 mm
Package features > Gross width (mm) - 435.00 mm
Package features > Packing quantity - 1.00 pc(s)
Package features > Palette Qty - 50 pc(s)
Package features > Paper/Pasteboard - 900.00 g
Package features > Plastic (No PET) - 100.00 g
Package features > Tare weight (kg) - 1.00 kg
Package features > TI weight (kg) - 8.00 kg
Package features > Type of battery - Battery
Package features > Volume (m3) - 0.03 m³
Package features > WEE classification - CL109:6:2017-04-01
Package features > WEEE tax - Yes
Packagingcontent -
PDF - https://www.blobs.lt/products/9/0/4/1/8/3/31ede873171b3bceea52837e04484234/original.pdf
Performance > Capacity - 1000 VA
Performance > UPS topology - On line
Performance > Waveform - Sine wave
Ports & interfaces > Power plug - C14
Portsinterfaces -
Powerfactor -
Powerplug - C13 coupler
ProdDesc - Eaton 9E 1000i
producer - Eaton
Producer - Eaton
ProducerCode - 9E1000I
Producer product family - OnLine UPS
Producer product name - 9E1000I
Productcolour -
Productcondition - Original
ProductHighLights -

• Get clear information on the UPS’ status and measurements (load level, battery level, input/output voltage and frequency) on a single screen with the new LCD interface

Product Net Weight - 9.5 kg
ProductPicture - https://www.tdbaltic.ee/images/products/EATON/9E1000I_1.jpg
ProductPicture1 - https://www.tdbaltic.ee/images/products/EATON/9E1000I_2.jpg
ProductPicture2 - https://www.tdbaltic.ee/images/products/EATON/9E1000I_3.jpg
ProductPicture3 - https://www.tdbaltic.ee/images/products/EATON/9E1000I_4.jpg
ProductPicture4 - https://www.tdbaltic.ee/images/products/EATON/9E1000I_5.jpg
ProductPicture5 - https://www.tdbaltic.ee/images/products/EATON/9E1000I_6.jpg
Quickinstallationguide -
Rackmountkit -
RS232 Communication ports - 1
RS232ports - 1
Serialinterface - Yes
Serialinterfacetype - RS-232
Serialportsquantity - 1
ShortDescription - Zasilacz awaryjny 9E1000I UPS Online 1000 VA / 900W
Software - Intelligent Power Editions
Special functions - Double conversion topology Continuously monitors power supply conditions and regulates voltage and frequency Internal bypass ensures continuous operation in the event of a UPS failure LCD display showing status and measurements in real time Compatibility with virtual environments (VMware, Hyper-V, Citrix Xen, Redhat) Automatic battery test
Technical details > Capacity - 800 W
Technical details > Gross weight - 11.00 kg
Technical details > Net weight - 10.00 kg
Technical details > Other features - Easily communicate with the UPS through USB, RS232 serial or over the network with the optional network card (Network-M2). Relay cards or ModBus cards are also available. Output 4xC13
Technical details > Producer - Eaton
The shape of the output voltage - Full sine wave
Topology - OnLine DoubleConvertion
Typicalbackuptimeathalfload - 12 min
Unit Box Height - 0.325
Unit Box Length - 0.43
Unit Box Width - 0.24
Unit Calculated Volume - 0.03354 cubm
Unit Calculated Weight - 10.7 kg
Units per Shipping Box - 1
UPS Architecture - on-line double conversion
UPStopology - Double-conversion (Online)
USB Communication ports - 1
USBport - Yes
USBporttype -
Vendor Homepage - powerquality.eaton.com/9E1000I.aspx?cx=61
vendpn - 9E1000I
Video -
Voltage - 12 V
Warranty - 12 months
Warranty - 24 months
Warranty - 36
Warranty - 36 month(s)
Warrantyandmisc -
Waveform -
Weight - 9.5 kg
Weight - 9.5 kg
Weightdimensions -
Width - 228 mm
