Brand - Dahua Technology
BrandPartCode - DH-PFS3006-4ET-60-V2
Category - Network Switches
Category Code - SWI
Data transmission - Forwarding rate - 0.89 Mpps
Data transmission - MAC address table - 2000 entries
Data transmission - Packet buffer memory - 1 MB
Data transmission - Switching capacity - 1.8 Gbit/s
Description - 6-Port 10/100Mbps Unmanaged Desktop Switch with 4 PoE Ports > Layer two commercial switch > Supports IEEE802.3, IEEE802.3u, IEEE802.3ab and IEEE802.3x standards > MDI/MDIX self-adaptation > RJ-45 port supports 10/100 Mbps self-adaptation, and confirms to 802.3at, and 802.3af power supply standards > Port 1 supports Hi-PoE 60W power supply > 250 m PoE power supply > Wall mounting and mechanical anti-thef > 53V DC power supply > Supports PoE watchdog > Port 1–4: 4 × RJ-45 10/100 M (PoE); Port 5–6: 2 × RJ-45 10/100 M (uplink) > PoE Power: 60W
Design - Housing material - Metal
Design - LED indicators - Yes
Design - Product colour - Black
Design - Rack mounting - No
Design - Stackable - No
Design - Wall mountable - Yes
Dimensions - 130 mm × 85 mm × 26 mm
Forwarding rate - 1 Mpps
GTIN - 6923172500717
LongDesc -
LongProductName - 6-Port 10/100Mbps Unmanaged Desktop Switch with 4 PoE Ports
LongSummaryDescription - Dahua Technology PFS3006-4ET-60. Switch type: Unmanaged, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Fast Ethernet (10/100), Basic switching RJ-45 Ethernet ports quantity: 6. MAC address table: 2000 entries, Switching capacity: 1.8 Gbit/s. DC input voltage: 53 V. Power connector: DC-in jack. Power over Ethernet (PoE). Wall mountable
Management features - Switch layer - L2
Management features - Switch type - Unmanaged
Model name - PFS3006-4ET-60
Network - 10G support - No
Network - Auto MDI/MDI-X - Yes
Network - Ethernet LAN data rates - 10,100 Mbit/s
Operational conditions - Operating relative humidity (H-H) - 5 - 95%
Operational conditions - Operating temperature (T-T) - -10 - 55 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 95%
Operational conditions - Storage temperature (T-T) - -20 - 70 °C
Packaging content - Manual - Yes
Packaging data - Package depth - 239 mm
Packaging data - Package height - 77 mm
Packaging data - Package weight - 900 g
Packaging data - Package width - 267 mm
PoE ports - 4
PoE power budget - 60 Watts
Ports & interfaces - Basic switching RJ-45 Ethernet ports quantity - 6
Ports & interfaces - Basic switching RJ-45 Ethernet ports type - Fast Ethernet (10/100)
Ports & interfaces - Fast Ethernet (copper) ports quantity - 6
Ports & interfaces - Power connector - DC-in jack
Power - DC input voltage - 53 V
Power - Power source - DC
Power - Power supply included - Yes
Power over Ethernet (PoE) - Power over Ethernet (PoE) - Yes
Power over Ethernet (PoE) - Power over Ethernet (PoE) ports quantity - 4
Power over Ethernet (PoE) - Total Power over Ethernet (PoE) budget - 60 W
Primary port count - 4
ProductName - PFS3006-4ET-60
Product Net Weight - 0 kg
ShortSummaryDescription - Dahua Technology PFS3006-4ET-60, Unmanaged, L2, Fast Ethernet (10/100), Power over Ethernet (PoE), Wall mountable
Switching capacity - 2 Gbps
Switch type - L2
Title - Dahua Technology PFS3006-4ET-60 Unmanaged L2 Fast Ethernet (10/100) Power over Ethernet (PoE) Black
Unit Box Height - 0.24
Unit Box Length - 0.265
Unit Box Width - 0.08
Unit Calculated Volume - 0 cubm
Unit Calculated Weight - 1 kg
Units per Shipping Box - 1
URL - https://www.dahuasecurity.com/products/productDetail/15551
Vendor Homepage - www.dahuasecurity.com/ceen/products/All-Products/Transmission/PoE-Switches/Desktop-PoE-Switch/PFS3006-4ET-60
Warranty - 36 months
WarrantyInfo -
Weight & dimensions - Depth - 85 mm
Weight & dimensions - Height - 26 mm
Weight & dimensions - Weight - 300 g
Weight & dimensions - Width - 130 mm
