Eaton 5P1150IG2, 1150VA 920W, IEC

Picture may differ from actual product, there can be accessories and parts not supplied with the actual product.
ID: 1124790 Product code: 5P1150IG2
In stock 1 units
Warranty: 2 years
656.05 €
Ready for dispatch
on Thursday, 19.06.2025
starting from 1.99 €
Delivery options
  • Omniva parcel machine
    Within 1-2 working days
    1.99 €
  • SmartPosti parcel terminal
    Within 1-2 working days
    1.99 €
  • Delivery by courier to the address
    Within 1-2 working days
    5.99 €
Main product parameters All parameters
  • Battery capacity (VA): 1150 VA
  • Output power (W): 920
Display characteristics
Display : Ir
Basic information
Battery capacity (VA) 1150 VA
The capacity of the battery pack is the index of the long-term operation of the UPS device without a permanent power supply source. This parameter applies to a UPS device with a fully charged battery pack. If you want to verify how big capacity is required for your computer equipment visit www.apc.ru where you will find the UPS capacity determination configuration tool.
Battery type : Nav norādīts
Charging time (hours) : Not specified
Output power (W) : 920
Ports and equipment
Number of nests (total) : 8
Number of sockets (Battery Backup) : Eight Core
RJ-45 : 0
Socket type : IEC320
USB : 0
More detailed specification
Additional information in manufacturers website Eaton 5P1150IG2, 1150VA 920W, IEC
Alarm - -
ARTIKEL1 - EATON 5P 1150I G2
ARTIKEL2 -
BatteryType - Lead-acid maintenance-free (replaceable)
Breite - 0
Category Code - UPW
Code - 5P1150IG2
Color - Black/Silver
Colour - Black / Silver
ControlPanel - Multilingual graphical LCD display
Depth - 345 mm
Description - Eaton 5P Gen2 UPS, 1150 VA, 920 W, Input: C14, Outputs: (8) C13, Tower.
Desktop/pedestal Mounting Type - Yes
Dimensions - 150 x 233 x 345mm
EAN - 3553340710278
EANCode - 3553340710278
FormFactor - Tower
Full Description Line - 920 Watts|1150 VA|Topology LineInteractive|Input ports Single, IEC320 C14|1xRS232|1xUSB|Desktop/pedestal|Colour Black / Silver
Gewicht - 12.6
GrossWeight - 12.5 kg
GRUPPE1 - Power Protection
GRUPPE2 - UPS (Uninterruptable Power Supply)
Height - 230 mm
HERSTELLER - EATON
Hoehe - 0
HSTNUMMER - 5P1150IG2
InputConnections - C14
InputFrequency -
  • 47-70 Hz (50 Hz system)
  • 56.5-70 Hz (60 Hz system)
  • 40 Hz in low sensitivity mode

    • Input ports - Single, IEC320 C14
    InputVoltage - 160-294 V (adjustable to 150 V-294 V)
    InterfacePorts -
  • USB port (HID compliant)
  • Serial port (RS232)
  • Mini-terminal block for remote On/Off and Remote Power Off
  • Dry contacts (2 outputs, optocoupler, RJ)

    • Laenge - 0
    Link - https://www.eaton.com/lt/lt-lt/skuPage.5P1150IG2.html
    LongDesc -
    MANUFDATASHEET - https://www.eaton.com/lt/lt-lt/skuPage.5P1150IG2.html
    Model - 5P Gen2
    Name - Eaton 5P Gen2 UPS | 5P1150IG2 | 1150 VA | 920 W
    Other features > Dimensions (WxDxH) - 150 x 345 x 233 mm
    Other features > Special features - Input: C14, Outputs: (8) C13
    OutputConnections - 8x C13
    OutputFrequency - 50-60 Hz
    Output power capacity, VA - 1150 VA
    Output power capacity, W - 920 Watts
    OutputVoltage - 230V default (200/208/220/230/240V)
    PackageContents -
  • USB cable
  • 2x IEC-IEC cables
  • Quickstart guide
  • Safety instructions

    • Package features > Classification of battery - CL126:NE:2016-12-09
    Package features > Composition of battery - CL127:KT:2016-12-09
    Package features > Embeeded battery - Yes
    Package features > Gross depth (mm) - 235.00 mm
    Package features > Gross height (mm) - 325.00 mm
    Package features > Gross width (mm) - 435.00 mm
    Package features > Packing quantity - 1.00 pc(s)
    Package features > Palette Qty - 26 pc(s)
    Package features > Paper/Pasteboard - 1000.00 g
    Package features > Plastic (No PET) - 400.00 g
    Package features > Tare weight (kg) - 1.40 kg
    Package features > TI weight (kg) - 10.00 kg
    Package features > Type of battery - Accumulator
    Package features > Volume (m3) - 0.03 m³
    Package features > WEE classification - CL109:5:2017-04-01
    Package features > WEEE tax - Yes
    Performance > Capacity - 1150 VA
    Performance > UPS topology - Line-Interactive
    PowerVAW - 1150 VA
    PowerW - 920 W
    ProdDesc - Eaton 5P 1150i G2
    Product Net Weight - 11 kg
    ProductPicture - http://www.tdbaltic.ee/images/ds4/5P1550IG2-01.jpg
    ProductPicture2 -
    ProductPicture3 -
    ProductPicture4 -
    RechargeTime - -
    RJ45 - -
    RS232 Communication ports - 1
    Runtime - 11/3
    Shipping Box Depth Shipping/Package Box Dimensions - 23.5 cm
    Shipping Box Height Shipping/Package Box Dimensions - 32.5 cm
    Shipping Box Weight Shipping/Package Box Dimensions - 12.4 kg
    Shipping Box Width Shipping/Package Box Dimensions - 43.5 cm
    SmartSlot - -
    Stck_Kart - 1
    Stck_Pal - 8
    Storno - Y
    Technical details > Capacity - 920 W
    Technical details > Gross weight - 12.40 kg
    Technical details > Net weight - 11.00 kg
    Technical details > Producer - Eaton
    Technical details > Producer product family - 5P Gen2 UPS
    Technical details > Producer product name - 5P1150IG2
    Topology - LineInteractive
    Topology - Line interactive
    Unit Calculated Volume - 0.03322 cubm
    Unit Calculated Weight - 12.4 kg
    Units per Shipping Box - 1
    USB - Yes
    USB Communication ports - 1
    Vendor Homepage - www.eaton.com/bg/en-gb/skuPage.5P1150IG2.html
    Warranty - 2 years
    Warranty - 24 months
    Warranty - 36
    Warranty - 36 month(s)
    WaveformType - Sine wave
    Weight - 11 kg
    Width - 150 mm
    656.05 €
    Eaton 5P1150IG2, 1150VA 920W, IEC
