LG 65UH5N-M

300 mm x 300 mm VESA mounting interface - Yes
Audio - Built-in speaker(s) - Yes
Audio-Out Input/Output connectors - 1
Audio - RMS rated power - 20 W
Audio > Built-in speaker(s) - Yes
Battery - AAA x2
Brand - LG
BrandPartCode - 65UH5N-M
Brightness - 500
Category - Signage Displays
Category Code - LCD
Code - 65UH5N-M.AEU
Computer system - Computer system - Yes
Computer system - Computer system type - System on Chip (SoC)
Computer system - Internal memory - 16 GB
Computer system - Operating system installed - WebOS
Computer system - Operating system version - 6.0
Contrast - 1100:1
Data Sheet (Link) Energy Efficiency - https://eprel.ec.europa.eu/api/product/1527487/fiches?language=EN
Depth Product Dimensions - 297 mm
Description - 65UH5N-M Resolution : 3,840 × 2,160 (UHD) Brightness : 500 nits (Typ.) Bezel Width : 8.9 mm (T/R/L), 12.9 mm (B) webOS Smart Platform
Design - Bezel colour - Black
Design - Bezel width (bottom) - 1.29 cm
Design - Bezel width (side) - 8.9 mm
Design - Bezel width (top) - 8.9 mm
Design - Orientation - Horizontal/Vertical
Design - Panel mounting interface - 200 x 200 mm
Design - Placement supported - Indoor
Design - Product colour - Black
Design - Product design - Digital signage flat panel
Design - Screen shape - Flat
Design - VESA mounting - Yes
Design > Colour of product - Black
Design > Producer product family - 4K UHD Signage
Design > VESA mounting - Yes
Design > VESA mounting interfaces - 300x300 mm
Display - Colour depth - 10 bit
Display - Colour gamut - 95%
Display - Contrast ratio (dynamic) - 1000000:1
Display - Contrast ratio (typical) - 1100:1
Display - Display brightness - 500 cd/m²
Display - Display diagonal - 165.1 cm (65")
Display - Display number of colours - 1.07 billion colours
Display - Display resolution - 3840 x 2160 pixels
Display - Display technology - LED
Display - Haze rate - 28%
Display - HD type - 4K Ultra HD
Display - LED backlight - Yes
Display - LED backlighting type - Edge-LED
Display - Native aspect ratio - 16:9
Display - Native refresh rate - 60 Hz
Display - Panel life - 50000 h
Display - Panel type - IPS
Display - Response time - 8 ms
Display - Touchscreen - No
Display - Viewing angle, horizontal - 178°
Display - Viewing angle, vertical - 178°
Display > Display brightness - 500 cd/m²
Display > Placement (L/P) - Landscape/Portrait
Display > Response time - 8 ms
Display > Viewing angle, horizontal - 178 °
Display > Viewing angle, vertical - 178 °
DisplayPort Input/Output connectors - 1
Dynamic contrast (DCR) - 10000000:1
EAN - 8806096398401
Energy consumption, standard - 99.9 kWh/1000h
Energy efficiency class Energy Efficiency - F
EPREL Registration Number Energy Efficiency - 1527487
EPREL Version Number Energy Efficiency - 2
Features - Heat dissipation (max) - 699 BTU/h
GTIN - 0195174098288
GTIN - 195174098288
GTIN - 8806096398401
HDMI Input/Output connectors - 3
Height Product Dimensions - 903 mm
Link - https://eu.lg-informationdisplay.com/product/digital-signage/standard/65UH5N-M
LongDesc - UHD Signage Display withLG webOS Platform and Advanced SecurityHigh Resolution DisplayIt offers a resolution that is four times higher than FHD, satisfying customers visually. Additionally, the anti-glare coating on the screen reduces screen reflection in bright lighting environments, increasing visibility and legibility, providing customers with a comfortable screen.Sturdy Design with Fire Flame ResistanceThe outer cover of the product is designed to effectively resist fire flame spread, making the product a great fit for installation in public spaces.* Based on third party testing, the case top and back cover of the product are classified Class A1 (case top) and A2 (back cover) under EN13501-1, Class 1 under BS476 Part 7.Convenient webOS PlatformThe UH5N-M is equipped with a high-performance SoC that allows for multiple tasks to be performed without a separate media player. The webOS platform provides app development tools with an intuitive UI that enhances user convenience, enabling easy connection with external sensors and webOS partner apps to create an SI-friendly environment.Design for Space UtilizationDesigned with thin bezels and simple cable management, the UH5N-M saves space. With specialized hidden power inlets, it can be installed close to the wall, leaving only about 13 mm of space with the slim bracket.Durability that Provides ReliabilityOptimized for business environments, the UH5N-M is protected against salt, dust, iron powder and humidity thanks to conformal coating on power board, allowing for stable operation. Also, its customer-centric features, such as IP5x and Shock Monitoring, provide both reliability and satisfaction.Enhanced Security FeaturesThe UH5N-M provides security features, including LG's Enhanced Kernel Protection (EKP) technology, protecting important data from external access or attacks. LG UHD Signage also holds reliable certification in the field of information security, maintaining customers' data and businesses securely. For example, this model is ISO/IEC 15408 Common Criteria EAL2 Certified.SustainabilityWith a commitment to innovation and sustainability, LG is continuously striving to create a better future for manufacturers, consumers, and future generations. With a focus on minimizing waste, maximizing recycling, and efficient power management, LG actively strives for sustainability, obtaining various certifications such as FCC EMC Class B.SuperSign SolutionsSuperSign is an integrated and intuitive content management solution for creative and organized digital signage content in your space, connecting customers to a range of services with convenient user experiences. There are a variety of versions such as SuperSign Cloud, so discover and enjoy the version that best fits you.
LongProductName - 65", 4K UHD (3840 x 2160), IPS, 500 nits, 8 ms, 16 : 9, 178 x 178, 50,000 Hrs, Black
LongSummaryDescription - LG 65UH5N-M. Product design: Digital signage flat panel. Display diagonal: 165.1 cm (65"), Display technology: LED, Display resolution: 3840 x 2160 pixels, Display brightness: 500 cd/m², HD type: 4K Ultra HD. Wi-Fi. Operating hours (hours/days): 24/7. Operating system installed: WebOS. Product colour: Black
Model - 65UH5N-M
Name - LG 4K UHD Signage | 65UH5N-M | 65 " | 500 cd/m² | Landscape/Portrait | 24/7 | webOS | 8 ms | 178 ° | 178 °
Native resolution - 3840x2160
Operational conditions - Operating relative humidity (H-H) - 10 - 80%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Other features - Audio output - 1
Other features - Plug and Play - Yes
Other features > Aspect ratio - 16:9
Other features > Resolution - 3840 x 2160
Other features > Signage product family - Digital Signage
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 172.00 mm
Package features > Gross height (mm) - 970.00 mm
Package features > Gross width (mm) - 1600.00 mm
Package features > Packing quantity - 1.00 pc(s)
Package features > Palette Qty - 5 pc(s)
Package features > Paper/Pasteboard - 4960.00 g
Package features > Plastic (No PET) - 1240.00 g
Package features > Tare weight (kg) - 6.20 kg
Package features > Volume (m3) - 0.27 m³
Package features > WEE classification - CL109:2:2017-04-01
Package features > WEEE tax - Yes
Packaging content - Batteries included - Yes
Packaging content - Cables included - Power
Packaging content - Remote control included - Yes
Packaging data - Package depth - 172 mm
Packaging data - Package height - 970 mm
Packaging data - Package weight - 30.4 kg
Packaging data - Package width - 1600 mm
PDF - https://www.blobs.lt/products/3/3/5/4/7/4/04a4e144f859df9ae29937064e3ebcd1/original.pdf
Performance - Automatic brightness control - Yes
Performance - HDCP - Yes
Performance - HDCP version - 1.4/2.2/2.3
Performance - International Protection (IP) code - IP5X
Performance - Operating hours (hours/days) - 24/7
Performance - Purpose - Universal
Ports & interfaces - DisplayPorts quantity - 1
Ports & interfaces - DVI port - No
Ports & interfaces - Ethernet LAN - Yes
Ports & interfaces - Ethernet LAN (RJ-45) ports - 1
Ports & interfaces - HDMI input ports quantity - 3
Ports & interfaces - HDMI ports quantity - 3
Ports & interfaces - Remote (IR) input - 1
Ports & interfaces - RS-232C - Yes
Ports & interfaces - USB connector type - USB Type-A
Ports & interfaces - USB port - Yes
Ports & interfaces - USB ports quantity - 2
Ports & interfaces - USB version - 2.0
Ports & interfaces - Wi-Fi - Yes
Ports & interfaces > HDMI ports quantity - 3
Power - AC input frequency - 50/60 Hz
Power - AC input voltage - 100 - 240 V
Power - Energy consumption (SDR) per 1000 hours - 130 kWh
Power - Energy efficiency class (SDR) - G
Power - Energy efficiency scale - A to G
Power - Heat dissipation - 444 BTU/h
Power - Power consumption (max) - 205 W
Power - Power consumption (standby) - 0.5 W
Power - Power consumption (typical) - 130 W
ProductName - 65UH5N-M
Product Net Weight - 24.2 kg
Refresh rate - 60Hz
Response time - 8 ms
RJ45 Input/Output connectors - 1
Screen form factor - 16:9
Screen size - 65"
ShortSummaryDescription - LG 65UH5N-M, Digital signage flat panel, 165.1 cm (65"), LED, 3840 x 2160 pixels, Wi-Fi, 24/7
Software > Operating system - webOS
Software > Operating system version - 6.0
Standby consumption - 0.5 Watts
Technical details - Real Time Clock (RTC) - Yes
Technical details > Diagonal - 65 "
Technical details > Gross weight - 30.40 kg
Technical details > Net weight - 24.20 kg
Technical details > Operating hours/days - 24/7
Technical details > Producer - LG
Technical details > Producer product name - 65UH5N-M
Title - LG 65UH5N-M Signage Display Digital signage flat panel 165.1 cm (65") LED Wi-Fi 500 cd/m² 4K Ultra HD Black WebOS 24/7
Unit Box Height - 0.96
Unit Box Length - 1.59
Unit Box Width - 0.17
Unit Calculated Volume - 0.259488 cubm
Unit Calculated Weight - 30.4 kg
URL - https://www.lg.com/global/business/digital-signage/lg-65uh5n-m
USB 2.0 Input/Output connectors - 2
Vendor Homepage - www.lg.com/global/business/digital-signage/lg-65uh5n-m
Viewing angle horizontal - 178 degrees
Viewing angle vertical - 178 degrees
Warranty - 36
Warranty - 36 month(s)
Warranty - 36 months
WarrantyInfo -
Weight & dimensions - Display depth - 29.7 mm
Weight & dimensions - Display height - 830.3 mm
Weight & dimensions - Display weight - 24.2 kg
Weight & dimensions - Display width - 1450.3 mm
Width Product Dimensions - 1454 mm
