LG 75UH5N-M

600 mm x 400 mm VESA mounting interface - Yes
Audio - Built-in speaker(s) - Yes
Audio-In Input/Output connectors - 1
Audio-Out Input/Output connectors - 1
Audio - RMS rated power - 20 W
Brand - LG
BrandPartCode - 75UH5N-M
Brightness - 500
Category - Signage Displays
Category Code - LCD
Colour - Black
Computer system - Computer system - Yes
Computer system - Computer system type - System on Chip (SoC)
Computer system - Internal memory - 16 GB
Computer system - Operating system installed - WebOS
Computer system - Operating system version - 6.0
Contrast - 1200:1
Depth Product Dimensions - 30 mm
Description - Resolution : 3,840 × 2,160 (UHD) Brightness : 500 nits (Typ.) Surface Treatment (Haze) : 25% Bezel Width : 12.9 mm
Design - Bezel width (bottom) - 1.29 cm
Design - Orientation - Horizontal
Design - Panel mounting interface - 600 x 400 mm
Design - Placement supported - Indoor
Design - Product colour - Black
Design - Product design - Digital signage flat panel
Design - VESA mounting - Yes
Display - Colour depth - 8 bit
Display - Colour gamut - 95%
Display - Contrast ratio (dynamic) - 1000000:1
Display - Contrast ratio (typical) - 1200:1
Display - Display brightness - 500 cd/m²
Display - Display diagonal - 190.5 cm (75")
Display - Display number of colours - 1.07 billion colours
Display - Display resolution - 3840 x 2160 pixels
Display - Display technology - LED
Display - Haze rate - 25%
Display - HD type - 4K Ultra HD
Display - LED backlight - Yes
Display - LED backlighting type - Edge-LED
Display - Native aspect ratio - 16:9
Display - Native refresh rate - 60 Hz
Display - Panel life - 50000 h
Display - Panel type - ADS
Display - Response time - 8 ms
Display - Touchscreen - No
Display - Viewing angle, horizontal - 178°
Display - Viewing angle, vertical - 178°
DVI-D Input/Output connectors - 1
Dynamic contrast (DCR) - 1000000:1
Features - Heat dissipation (max) - 843 BTU/h
HDMI Input/Output connectors - 3
Height Product Dimensions - 959 mm
LongDesc - Large UHD Signage Display with Slim DesignEye-catching Large ScreenA large screen effectively captures people's attention. Especially, 75-inch model supports 60Hz, enabling smooth content operation.Sturdy Design with Fire Flame ResistanceThe outer cover of the product is designed to effectively resist fire flame spread, making the product a great fit for installation in public spaces.* Based on third party testing, the case top and back cover of the product are classified Class A1 (case top) and A2 (back cover) under EN13501-1, Class 1 under BS476 Part 7.Slim Depth with Even BezelDespite its large screen, UH5N-M boasts a slim depth, which is advantageous for interior design. To avoid visual issues when adjusting to portrait mode, the bezel maintains uniform thickness on all four sides, providing even symmetry on the top, bottom, left, and right. Therefore, it is a model suitable for various styling options.Versatile Operation with Multi-USBWith support for two USB ports, UH5N-M offers versatile usage options. For example, operating content on the screen while simultaneously using other connected devices is possible. This includes convenient tasks like downloading PPT files from external storage devices while using a mouse or keyboard during a meeting.High Resolution DisplayIt offers a resolution that is four times higher than FHD, satisfying customers visually. Additionally, the anti-glare coating on the screen reduces screen reflection in bright lighting environments, increasing visibility and legibility, providing customers with a comfortable screen.Convenient webOS PlatformThe UH5N-M is equipped with a high-performance SoC that allows for multiple tasks to be performed without a separate media player. The webOS platform provides app development tools with an intuitive UI that enhances user convenience, enabling easy connection with external sensors and webOS partner apps to create an SI-friendly environment.Durability that Provides ReliabilityOptimized for business environments, the UH5N-M is protected against rust and dust with conformal coating and IP5x certification, allowing for stable operation.Enhanced Security FeaturesThe UH5N-M provides advanced security features, including LG's Enhanced Kernel Protection (EKP) technology, protecting important data from external access or attacks. LG UHD Signage also holds reliable certifications in the field of information security, maintaining customers' data and businesses securely. For example, this model is ISO/IEC 15408 Common Criteria EAL2 Certified.SuperSign SolutionsSuperSign is an integrated and intuitive content management solution for creative and organized digital signage content in your space, connecting customers to a range of services with convenient user experiences. There are a variety of versions such as SuperSign Cloud, so discover and enjoy the version that best fits you.
LongProductName - 75", 4K UHD (3840 x 2160), ADS 500 nit, 8 ms, IP5X, Wi-Fi, webOS 6.0
LongSummaryDescription - LG 75UH5N-M. Product design: Digital signage flat panel. Display diagonal: 190.5 cm (75"), Display technology: LED, Display resolution: 3840 x 2160 pixels, Display brightness: 500 cd/m², HD type: 4K Ultra HD. Wi-Fi. Operating hours (hours/days): 24/7. Operating system installed: WebOS. Product colour: Black
Model - 75UH5N-M
Model name - 75UH5N-M
Native resolution - 3840x2160
Operational conditions - Operating relative humidity (H-H) - 10 - 80%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operation time hours/day - 24/7
Other features - Audio output - 1
Other features - Plug and Play - Yes
Packaging content - Batteries included - Yes
Packaging content - Cables included - AC, Phone
Packaging content - Remote control included - Yes
Packaging data - Package depth - 200 mm
Packaging data - Package height - 1115 mm
Packaging data - Package weight - 44 kg
Packaging data - Package width - 1820 mm
Performance - Automatic brightness control - Yes
Performance - HDCP - Yes
Performance - HDCP version - 1.4/2.2/2.3
Performance - International Protection (IP) code - IP5X
Performance - On Screen Display (OSD) - Yes
Performance - Operating hours (hours/days) - 24/7
Performance - Purpose - Universal
Ports & interfaces - DisplayPorts quantity - 1
Ports & interfaces - DVI port - No
Ports & interfaces - Ethernet LAN - Yes
Ports & interfaces - Ethernet LAN (RJ-45) ports - 1
Ports & interfaces - HDMI input ports quantity - 3
Ports & interfaces - HDMI ports quantity - 3
Ports & interfaces - Remote (IR) input - 1
Ports & interfaces - RS-232C - Yes
Ports & interfaces - USB connector type - USB Type-A
Ports & interfaces - USB port - Yes
Ports & interfaces - USB ports quantity - 2
Ports & interfaces - USB version - 2.0
Ports & interfaces - Wi-Fi - Yes
Power - AC input frequency - 50-60 Hz
Power - AC input voltage - 100-240 V
Power - Heat dissipation - 546 BTU/h
Power - Power consumption (max) - 247 W
Power - Power consumption (standby) - 0.5 W
Power - Power consumption (typical) - 160 W
Power supply - Inbuilt
ProductName - 75UH5N-M
Product Net Weight - 36 kg
Refresh rate - 60Hz
Response time - 8 ms
RJ45 Input/Output connectors - 1
RS232 Input/Output connectors - 2
Screen form factor - 16:9
Screen size - 75"
ShortSummaryDescription - LG 75UH5N-M, Digital signage flat panel, 190.5 cm (75"), LED, 3840 x 2160 pixels, Wi-Fi, 24/7
Speakers - Yes
Technical details - Real Time Clock (RTC) - Yes
Title - LG 75UH5N-M Signage Display Digital signage flat panel 190.5 cm (75") LED Wi-Fi 500 cd/m² 4K Ultra HD Black WebOS 24/7
Unit Box Height - 0.2
Unit Box Length - 1.82
Unit Box Width - 1.12
Unit Calculated Volume - 0 cubm
Unit Calculated Weight - 44 kg
URL - https://www.lg.com/global/business/digital-signage/lg-75uh5n-m
USB 2.0 Input/Output connectors - 2
Vendor Homepage - www.lg.com/global/business/digital-signage/lg-75uh5n-m
Viewing angle horizontal - 178 degrees
Viewing angle vertical - 178 degrees
Warranty - 36 months
WarrantyInfo -
Weight & dimensions - Display depth - 29.7 mm
Weight & dimensions - Display height - 958.7 mm
Weight & dimensions - Display weight - 35.7 kg
Weight & dimensions - Display width - 1679.5 mm
Width Product Dimensions - 1680 mm
