LG 55UH5N-M

300 mm x 300 mm VESA mounting interface - Yes
Accessories included -
Aspect ratio - 16:9
Audio - Built-in speaker(s) - Yes
Audio - RMS rated power - 20 W
Auto Pivot - No
Battery - AAA x2
Bluetooth - Yes
Brand - LG
BrandPartCode - 55UH5N-M
Brightness - 500
Brightness - 500 nits
Category - Signage Displays
Category Code - LCD
Certificates - CB
Certificates - Energy Star
Certificates - EPEAT
Certificates - ErP
Certificates - FCC Class B
CnCode CnCode - 85285291
Color - Black
Computer system - Computer system - Yes
Computer system - Computer system type - System on Chip (SoC)
Computer system - Internal memory - 16 GB
Computer system - Operating system installed - WebOS
Computer system - Operating system version - 6.0
Contrast - 1200:1
Data Sheet (Link) - https://eprel.ec.europa.eu/api/product/2194778/fiches?language=EN
Depth - 29.7 mm
Depth Product Dimensions - 29.7 mm
Description - 4K UHD Signage - Resolution : 3,840 × 2,160 (UHD) - Brightness : 500 nits (Typ.) - Bezel Width : 8.9 mm (T/R/L), 12.9 mm (B) - webOS Smart Platform
Description - Wyświetlacz o Wysokiej Rozdzielczości
Oferuje rozdzielczość czterokrotnie wyższą niż Full HD, co zapewnia wyjątkową jakość obrazu i satysfakcję wizualną użytkowników. Dodatkowo, powłoka antyodblaskowa na ekranie ogranicza odbicia światła w jasnym otoczeniu, zwiększając widoczność i czytelność, co przekłada się na komfortowe korzystanie z ekranu. Solidna Konstrukcja Odporna na Ogień
Obudowa zewnętrzna urządzenia została zaprojektowana w taki sposób, aby skutecznie zapobiegać rozprzestrzenianiu się płomieni, co czyni produkt idealnym do instalacji w przestrzeniach publicznych. Wygodna Platforma webOS
Model UH5N-M jest wyposażony w wydajny układ SoC, który umożliwia wykonywanie wielu zadań bez potrzeby stosowania oddzielnego odtwarzacza multimedialnego. Platforma webOS oferuje narzędzia do tworzenia aplikacji oraz intuicyjny interfejs użytkownika, co zwiększa wygodę obsługi. Umożliwia również łatwe podłączanie zewnętrznych czujników oraz aplikacji partnerów webOS, tworząc środowisko przyjazne dla integratorów systemów (SI). Trwałość Gwarantująca Niezawodność
Model UH5N-M został zoptymalizowany z myślą o środowiskach biznesowych i zabezpieczony przed działaniem soli, kurzu, pyłu żelaznego i wilgoci dzięki powłoce ochronnej na płycie zasilania. Dodatkowo, funkcje ukierunkowane na potrzeby użytkownika takie jak klasa szczelności IP5x oraz monitoring wstrząsów zapewniają niezawodność i satysfakcję z użytkowania.
Design - Bezel width (bottom) - 1.29 cm
Design - Bezel width (side) - 8.9 mm
Design - Bezel width (top) - 8.9 mm
Design - Orientation - Horizontal/Vertical
Design - Panel mounting interface - 300 x 300 mm
Design - Placement supported - Indoor
Design - Product colour - Black
Design - Product design - Digital signage flat panel
Design - VESA mounting - Yes
Designation - CE+WEEE
dimension depth - 150 mm
dimension height - 800 mm
dimension weight - 19500 g
dimension width - 1135 mm
Display - Colour depth - 10 bit
Display - Colour gamut - 95%
Display - Contrast ratio (dynamic) - 1000000:1
Display - Contrast ratio (typical) - 1200:1
Display - Display brightness - 500 cd/m²
Display - Display diagonal - 139.7 cm (55")
Display - Display number of colours - 1.07 billion colours
Display - Display resolution - 3840 x 2160 pixels
Display - Display technology - LCD
Display - Haze rate - 25%
Display - HD type - 4K Ultra HD
Display - LED backlight - Yes
Display - LED backlighting type - Edge-LED
Display - Native aspect ratio - 16:9
Display - Native refresh rate - 60 Hz
Display - Panel life - 50000 h
Display - Panel type - IPS
Display - Response time - 8 ms
Display - Touchscreen - No
Display - Viewing angle, horizontal - 178°
Display - Viewing angle, vertical - 178°
Displayable colours - 1070 million
DisplayPort Input/Output connectors - 2
Display surface - Matt
Dynamic contrast - 1 000 000:1
Dynamic contrast (DCR) - 1000000:1
ean - 8806096251911
Energy class - G
Energy consumption, standard - 102.5 kWh/1000h
Energy efficiency class - G
Energy label - Pobierz
EPREL Registration Number - 2.19478e+006
EPREL Version Number - 1
Features - Heat dissipation (max) - 546 BTU/h
Full Description Line - Model 55UH5N-M|55"|Touchscreen|Panel IPS|Resolution 3840x2160|Form factor 16:9|Refresh rate 60|Brightness 500|Contrast 1200:1|Dynamic contrast (DCR) 1000000:1|Response time 8 ms|Horizontal 178 degrees|Vertical 178 degrees|Displayable colours 1070 million|2xHDMI|2xDisplayPort|1xRS232|1xUSB 2.0|1xRJ45|PSU Inbuilt|300 mm x 300 mm|Operation time hours/day 24/7|Included Accessories Remote Controller, Power Cord, QSG, Regulation Book, Phone to RS-232C Gender, Cable Holder (2 ea), AC Cord Holder
GTIN - 8806096251911
guarantee - 36
guarantee_type - external
HDMI Input/Output connectors - 2
Height - 707.2 mm
Height adjustment - No
Height Product Dimensions - 707.2 mm
I/O connectors - 1 x Audio out
I/O connectors - 1 x DisplayPort
I/O connectors - 1 x RJ-45 LAN
I/O connectors - 1 x USB 2.0
I/O connectors - 2 x RS-232 (COM)
I/O connectors - 3 x HDMI
Included Accessories - Remote Controller, Power Cord, QSG, Regulation Book, Phone to RS-232C Gender, Cable Holder (2 ea), AC Cord Holder
Kensington Security Slot - Nie
LongDesc - UHD Signage Display withLG webOS Platform and Advanced SecurityHigh Resolution DisplayIt offers a resolution that is four times higher than FHD, satisfying customers visually. Additionally, the anti-glare coating on the screen reduces screen reflection in bright lighting environments, increasing visibility and legibility, providing customers with a comfortable screen.Sturdy Design with Fire Flame ResistanceThe outer cover of the product is designed to effectively resist fire flame spread, making the product a great fit for installation in public spaces.Convenient webOS PlatformThe UH5N-M is equipped with a high-performance SoC that allows for multiple tasks to be performed without a separate media player. The webOS platform provides app development tools with an intuitive UI that enhances user convenience, enabling easy connection with external sensors and webOS partner apps to create an SI-friendly environment.Design for Space UtilizationDesigned with thin bezels and simple cable management, the UH5N-M saves space. With specialized hidden power inlets, it can be installed close to the wall, leaving only about 13 mm of space with the slim bracket.Durability that Provides ReliabilityOptimized for business environments, the UH5N-M is protected against salt, dust, iron powder and humidity thanks to conformal coating on power board, allowing for stable operation. Also, its customer-centric features, such as IP5x and Shock Monitoring, provide both reliability and satisfaction.Enhanced Security FeaturesThe UH5N-M provides security features, including LG's Enhanced Kernel Protection (EKP) technology, protecting important data from external access or attacks. LG UHD Signage also holds reliable certification in the field of information security, maintaining customers' data and businesses securely. For example, this model is ISO/IEC 15408 Common Criteria EAL2 Certified.SustainabilityWith a commitment to innovation and sustainability, LG is continuously striving to create a better future for manufacturers, consumers, and future generations. With a focus on minimizing waste, maximizing recycling, and efficient power management, LG actively strives for sustainability, obtaining various certifications such as FCC EMC Class B.SuperSign SolutionsSuperSign is an integrated and intuitive content management solution for creative and organized digital signage content in your space, connecting customers to a range of services with convenient user experiences. There are a variety of versions such as SuperSign Cloud, so discover and enjoy the version that best fits you.
LongProductName - 55", 4K UHD (3840 x 2160), IPS, 500 nit, 8 ms, IP5X, SoC, Wi-Fi, PIP, PBP, Pro:Idiom, Beacon, Control Manager, SuperSign CMS, webOS 6.0
LongSummaryDescription - LG 55UH5N-M. Product design: Digital signage flat panel. Display diagonal: 139.7 cm (55"), Display technology: LCD, Display resolution: 3840 x 2160 pixels, Display brightness: 500 cd/m², HD type: 4K Ultra HD. Wi-Fi. Operating hours (hours/days): 24/7. Operating system installed: WebOS. Product colour: Black
Matrix type - Advanced PLS
Model - 55UH5N-M
Model name - 55UH5N-M
name - Monitor 55UH5N-M IPS 500cd/m2 24/7
Native resolution - 3840x2160
Number of colors - 1,07 mld
Operational conditions - Operating relative humidity (H-H) - 10 - 80%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operation time hours/day - 24/7
Optional accessory -
Other features -
Other features - Audio output - 1
Other features - Plug and Play - Yes
Other features - Power consumption (PowerSave) - 72 W
Packaging content - Batteries included - Yes
Packaging content - Cables included - AC, Phone
Packaging content - Remote control included - Yes
Packaging data - Package depth - 161 mm
Packaging data - Package height - 801 mm
Packaging data - Package weight - 20.5 kg
Packaging data - Package width - 1360 mm
Panel type - IPS
Performance - Automatic brightness control - Yes
Performance - HDCP - Yes
Performance - HDCP version - 1.4/2.2/2.3
Performance - International Protection (IP) code - IP5X
Performance - On Screen Display (OSD) - Yes
Performance - Operating hours (hours/days) - 24/7
Performance - Picture-in-Picture - Yes
Performance - Purpose - Universal
Ports & interfaces - DisplayPorts quantity - 1
Ports & interfaces - DVI port - No
Ports & interfaces - Ethernet LAN - Yes
Ports & interfaces - Ethernet LAN (RJ-45) ports - 1
Ports & interfaces - HDMI input ports quantity - 3
Ports & interfaces - HDMI output ports quantity - 1
Ports & interfaces - HDMI ports quantity - 4
Ports & interfaces - Remote (IR) input - 1
Ports & interfaces - RS-232C - Yes
Ports & interfaces - USB connector type - USB Type-A
Ports & interfaces - USB port - Yes
Ports & interfaces - USB ports quantity - 1
Ports & interfaces - USB version - 2.0
Ports & interfaces - Wi-Fi - Yes
Power - AC input frequency - 50-60 Hz
Power - AC input voltage - 100-240 V
Power - Heat dissipation - 351 BTU/h
Power - Power consumption (max) - 160 W
Power - Power consumption (standby) - 0.5 W
Power - Power consumption (typical) - 103 W
Power consumption - 103 W
Power supply - Inbuilt
producer - LG Electronics
ProductName - 55UH5N-M
Product Net Weight - 16.1 kg
Refresh rate - 60
Refresh rate - 60 Hz
Resolution - 3840 x 2160
Response time - 8 ms
Response time - 8 ms
RJ45 Input/Output connectors - 1
RS232 Input/Output connectors - 1
Screen form factor - 16:9
Screen size - 55"
Screen size (diag.) - 55"
Shipping Box Depth Shipping/Package Box Dimensions - 136 cm
Shipping Box Height Shipping/Package Box Dimensions - 15.2 cm
Shipping Box Weight Shipping/Package Box Dimensions - 20.5 kg
Shipping Box Width Shipping/Package Box Dimensions - 81 cm
ShortSummaryDescription - LG 55UH5N-M, Digital signage flat panel, 139.7 cm (55"), LCD, 3840 x 2160 pixels, Wi-Fi, 24/7
Speakers built-in - Yes
Standby consumption - 0.5 Watts
Static contrast - 1 200:1
Technical details - Real Time Clock (RTC) - Yes
Title - LG 55UH5N-M Signage Display Digital signage flat panel 139.7 cm (55") LCD Wi-Fi 500 cd/m² 4K Ultra HD Black WebOS 24/7
Touch screen - No
Touchscreen - Yes
Transreflective technology - LED
TV tuner built-in - No
Unit Box Height - 0.152
Unit Box Length - 1.36
Unit Box Width - 0.81
Unit Calculated Volume Retail box Dimensions - 0.167443 cubm
Unit Calculated Weight - 20.5 kg
Units per Shipping Box - 1
URL - https://www.lg-informationdisplay.com/product/digital-signage/standard/55UH5N-M
USB 2.0 Input/Output connectors - 1
Vendor Homepage - www.lg-informationdisplay.com/product/digital-signage/standard/55UH5N-M
vendpn - 55UH5N-M
VESA - 300 x 300
Viewing angle, horizontal - 178 °
Viewing angle, vertical - 178 °
Viewing angle horizontal - 178 degrees
Viewing angle vertical - 178 degrees
Warranty -
Warranty - 36 months
WarrantyInfo -
Web camera - None
Weight - 16.1 kg
Weight & dimensions - Display depth - 29.7 mm
Weight & dimensions - Display height - 707.2 mm
Weight & dimensions - Display weight - 16.1 kg
Weight & dimensions - Display width - 1231.4 mm
Width - 1231.4 mm
Width Product Dimensions - 1231.4 mm
WiFi - Yes
