AC adapter output voltage Power - 12 V
AMD FreeSync Performance - No
Automatic brightness control Other features - No
Backlight type Display - Edge LED
Bezel width (bottom) Weight & dimensions - 1.82 cm
Bezel width (side) Weight & dimensions - 2.8 mm
Bezel width (top) Weight & dimensions - 2.8 mm
Bluetooth Network - No
Brand - Dahua Technology
BrandPartCode - DHI-LM27-A221Y
Built-in camera Multimedia - No
Built-in speaker(s) Multimedia - No
Built-in USB hub Ports & interfaces - No
Cables included Packaging content - HDMI
Category - Computer Monitors
Category Code - LC3
CnCode - 85285210
Colour depth Display - 6 bit
Colour gamut standard Display - NTSC
Compliance certificates Other features - CE, Electromagnetic Compatibility (EMC), Low Voltage Directive (LVD)
Contrast ratio (typical) Display - 1200:1
Data Sheet (Link) Energy Efficiency - https://eprel.ec.europa.eu/api/product/2452601/fiches?language=EN
Depth (without stand) Weight & dimensions - 49.1 mm
Depth (with stand) Weight & dimensions - 189 mm
Description - Light and cost-effective plastic housingUltra-narrow bezel , elegant appearance, plastic baseSupport multiple signal inputs such as HDMI, VGA144Hz high refresh rate1ms rapid response time
Design - Detachable stand - Yes
Design - Feet colour - Black
Design - Frameless design - No
Design - Housing material - Plastic
Design - Illuminated stand - No
Design - Market positioning - Office
Design - Product colour - Black
Detachable stand Design - Yes
Display - Backlight type - Edge LED
Display - Colour depth - 6 bit
Display - Colour gamut standard - NTSC
Display - Contrast ratio (typical) - 1200:1
Display - Display brightness (typical) - 250 cd/m²
Display - Display diagonal - 68.6 cm (27")
Display - Display diagonal (metric) - 69 cm
Display - Display resolution - 1920 x 1080 pixels
Display - Display technology - LED
Display - Haze rate - 25%
Display - HD type - Full HD
Display - LED backlight - Yes
Display - Maximum refresh rate - 144 Hz
Display - Native aspect ratio - 16:9
Display - NTSC coverage (typical) - 72%
Display - Panel type - IPS
Display - Pixel density - 81.59 ppi
Display - Pixel pitch - 0.3114 x 0.3114 mm
Display - Response time (MPRT) - 1 ms
Display - Screen shape - Flat
Display - Supported graphics resolutions - 1920 x 1080 (HD 1080)
Display - Supported video modes - 1080p
Display - Surface hardness - 3H
Display - Touchscreen - No
Display - Viewable size, horizontal - 59.8 cm
Display - Viewable size, vertical - 33.6 cm
Display - Viewing angle, horizontal - 178°
Display - Viewing angle, vertical - 178°
Display brightness (typical) Display - 250 cd/m²
Display diagonal (metric) Display - 69 cm
Display diagonal Display - 68.6 cm (27")
Display resolution Display - 1920 x 1080 pixels
Display technology Display - LED
E-manual Other features - Yes
Energy consumption (SDR) per 1000 hours Power - 15 kWh
Energy efficiency class (HDR) Power - Not available
Energy efficiency class (SDR) Power - D
Energy efficiency class Energy Efficiency - D
Energy efficiency scale Power - A to G
EPREL Registration Number Energy Efficiency - 2452601
EPREL Version Number Energy Efficiency - 2
Ergonomics - Height adjustment - No
Ergonomics - Panel mounting interface - 100 x 100 mm
Ergonomics - Plug and Play - Yes
Ergonomics - Tilt adjustment - Yes
Ergonomics - Tilt angle range - -5 - 20°
Ergonomics - VESA mounting - Yes
Ergonomics - Wall mountable - Yes
Feet colour Design - Black
Flicker-free technology Performance - Yes
Frameless design Design - No
Haze rate Display - 25%
HDMI Ports & interfaces - Yes
HDMI ports quantity Ports & interfaces - 1
HDMI version Ports & interfaces - 1.4
HD type Display - Full HD
Height (without stand) Weight & dimensions - 364.1 mm
Height (with stand) Weight & dimensions - 455.5 mm
Height adjustment Ergonomics - No
Housing material Design - Plastic
Illuminated stand Design - No
Input current Power - 3 A
LED backlight Display - Yes
LongDesc -
LongProductName - 27", 1920 x 1080 FHD, 144 Hz, IPS, ELED, 16:9, 250 cd/m², 1200:1, MPRT 1 ms, 6 bit + FRC, 3H, VGA, HDMI 1.4, Black
LongSummaryDescription - Dahua Technology LM27-A221Y. Display diagonal: 68.6 cm (27"), Display resolution: 1920 x 1080 pixels, HD type: Full HD, Display technology: LED, Native aspect ratio: 16:9, Viewing angle, horizontal: 178°, Viewing angle, vertical: 178°. VESA mounting. Product colour: Black
Market positioning Design - Office
Maximum refresh rate Display - 144 Hz
Multimedia - Built-in camera - No
Multimedia - Built-in speaker(s) - No
Native aspect ratio Display - 16:9
Network - Bluetooth - No
Network - Wi-Fi - No
NTSC coverage (typical) Display - 72%
NVIDIA G-SYNC Performance - No
Operating relative humidity (H-H) Operational conditions - 10 - 85%
Operating temperature (T-T) Operational conditions - 0 - 40 °C
Operational conditions - Operating relative humidity (H-H) - 10 - 85%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 90%
Operational conditions - Storage temperature (T-T) - -20 - 60 °C
Other features - Automatic brightness control - No
Other features - Compliance certificates - CE, Electromagnetic Compatibility (EMC), Low Voltage Directive (LVD)
Other features - E-manual - Yes
Package depth Packaging data - 118 mm
Package height Packaging data - 450 mm
Package weight Packaging data - 4.7 kg
Package width Packaging data - 678 mm
Packaging content - Cables included - HDMI
Packaging content - Power adapter included - Yes
Packaging content - Quick start guide - Yes
Packaging data - Package depth - 118 mm
Packaging data - Package height - 450 mm
Packaging data - Package weight - 4.7 kg
Packaging data - Package width - 678 mm
Panel mounting interface Ergonomics - 100 x 100 mm
Panel type Display - IPS
Performance - AMD FreeSync - No
Performance - Flicker-free technology - Yes
Performance - NVIDIA G-SYNC - No
Pixel density Display - 81.59 ppi
Pixel pitch Display - 0.3114 x 0.3114 mm
Plug and Play Ergonomics - Yes
Ports & interfaces - Built-in USB hub - No
Ports & interfaces - HDMI - Yes
Ports & interfaces - HDMI ports quantity - 1
Ports & interfaces - HDMI version - 1.4
Ports & interfaces - VGA (D-Sub) ports quantity - 1
Power - AC adapter output voltage - 12 V
Power - Energy consumption (SDR) per 1000 hours - 15 kWh
Power - Energy efficiency class (HDR) - Not available
Power - Energy efficiency class (SDR) - D
Power - Energy efficiency scale - A to G
Power - Input current - 3 A
Power - Power consumption (max) - 28 W
Power - Power consumption (off) - 0.3 W
Power - Power consumption (standby) - 0.5 W
Power - Power consumption (typical) - 27.1 W
Power - Power supply type - External
Power adapter included Packaging content - Yes
Power consumption (max) Power - 28 W
Power consumption (off) Power - 0.3 W
Power consumption (standby) Power - 0.5 W
Power consumption (typical) Power - 27.1 W
Power supply type Power - External
Product colour Design - Black
ProductName - LM27-A221Y
Product Net Weight - 3.4 kg
Quick start guide Packaging content - Yes
Response time (MPRT) Display - 1 ms
Screen shape Display - Flat
ShortSummaryDescription - Dahua Technology LM27-A221Y, 68.6 cm (27"), 1920 x 1080 pixels, Full HD, LED, Black
Storage relative humidity (H-H) Operational conditions - 5 - 90%
Storage temperature (T-T) Operational conditions - -20 - 60 °C
Summary - Dahua Technology LM27-A221Y. Display diagonal: 68.6 cm (27"), Display resolution: 1920 x 1080 pixels, HD type: Full HD, Display technology: LED, Native aspect ratio: 16:9, Viewing angle, horizontal: 178°, Viewing angle, vertical: 178°. VESA mounting. Product colour: Black
Supported graphics resolutions Display - 1920 x 1080 (HD 1080)
Supported video modes Display - 1080p
Surface hardness Display - 3H
Tilt adjustment Ergonomics - Yes
Tilt angle range Ergonomics - -5 - 20°
Title - Dahua Technology LM27-A221Y computer monitor 68.6 cm (27") 1920 x 1080 pixels Full HD LED Black
Touchscreen Display - No
Unit Box Height - 0.445
Unit Box Length - 0.68
Unit Box Width - 0.115
Unit Calculated Volume - 0.0348 cubm
Unit Calculated Weight - 4.79 kg
Units per Pallet - 0
URL - https://www.dahuasecurity.com/fr/products/All-Products/Display--Control/Monitors/Commercial-Series/LM27-A221Y=V1
Vendor Homepage - https://www.dahuasecurity.com/fr/products/All-Products/Display--Control/Monitors/Commercial-Series/LM27-A221Y=V1
VESA mounting Ergonomics - Yes
VGA (D-Sub) ports quantity Ports & interfaces - 1
Viewable size, horizontal Display - 59.8 cm
Viewable size, vertical Display - 33.6 cm
Viewing angle, horizontal Display - 178°
Viewing angle, vertical Display - 178°
Wall mountable Ergonomics - Yes
Warranty - 36 months
WarrantyInfo -
Weight & dimensions - Bezel width (bottom) - 1.82 cm
Weight & dimensions - Bezel width (side) - 2.8 mm
Weight & dimensions - Bezel width (top) - 2.8 mm
Weight & dimensions - Depth (without stand) - 49.1 mm
Weight & dimensions - Depth (with stand) - 189 mm
Weight & dimensions - Height (without stand) - 364.1 mm
Weight & dimensions - Height (with stand) - 455.5 mm
Weight & dimensions - Weight (without stand) - 3.4 kg
Weight & dimensions - Width (without stand) - 615.1 mm
Weight & dimensions - Width (with stand) - 615.1 mm
Weight (without stand) Weight & dimensions - 3.4 kg
Wi-Fi Network - No
Width (without stand) Weight & dimensions - 615.1 mm
Width (with stand) Weight & dimensions - 615.1 mm
