AC adapter output voltage Power - 12 V
Backlight type Display - Edge LED
Bezel width (bottom) Weight & dimensions - 15.2 mm
Bezel width (side) Weight & dimensions - 3.3 mm
Bezel width (top) Weight & dimensions - 3.3 mm
Brand - Dahua Technology
BrandPartCode - DHI-LM22-A200Y
Built-in camera Multimedia - No
Built-in speaker(s) Multimedia - No
Built-in USB hub Ports & interfaces - No
Category - Computer Monitors
Category Code - LC3
CnCode - 85285210
Colour depth Display - 8 bit
Colour gamut standard Display - NTSC
Compliance certificates Other features - CE/Electromagnetic Compatibility (EMC)/Low Voltage Directive (LVD)
Contrast ratio (typical) Display - 3000:1
Current rating Power - 2 A
Data Sheet (Link) Energy Efficiency - https://eprel.ec.europa.eu/api/product/2139333/fiches?language=EN
Depth (without stand) Weight & dimensions - 41.2 mm
Description - Ultra-narrow bezel , elegant appearance, plastic base178°H/178°V extra-wide viewing angle for overall viewing performanceHigh fidelity digital processing for a brilliant and vivid videoSupport multiple signal inputs such as HDMI, VGA100Hz high refresh rate, eliminates picture lagging
Design - Detachable stand - Yes
Design - Feet colour - Black
Design - Frameless design - Yes
Design - Front bezel colour - Black
Design - Product colour - Black
Detachable stand Design - Yes
Display - Backlight type - Edge LED
Display - Colour depth - 8 bit
Display - Colour gamut standard - NTSC
Display - Contrast ratio (typical) - 3000:1
Display - Display brightness (typical) - 250 cd/m²
Display - Display diagonal - 54.5 cm (21.4")
Display - Display diagonal (metric) - 56 cm
Display - Display resolution - 1920 x 1080 pixels
Display - Display technology - LED
Display - HD type - Full HD
Display - LED backlight - Yes
Display - Maximum refresh rate - 100 Hz
Display - Native aspect ratio - 16:9
Display - NTSC coverage (typical) - 72%
Display - Panel type - VA
Display - Response time - 10 ms
Display - Screen shape - Flat
Display - Touchscreen - No
Display - Viewing angle, horizontal - 178°
Display - Viewing angle, vertical - 178°
Display brightness (typical) Display - 250 cd/m²
Display diagonal (metric) Display - 56 cm
Display diagonal Display - 21.45 "
Display resolution Display - 1920 x 1080 pixels
Display technology Display - LED
Energy consumption (SDR) per 1000 hours Power - 15 kWh
Energy efficiency class (SDR) Power - E
Energy efficiency class Energy Efficiency - E
EPREL Registration Number Energy Efficiency - 2139333
EPREL Version Number Energy Efficiency - 1
Ergonomics - Height adjustment - No
Ergonomics - Panel mounting interface - 75 x 75 mm
Ergonomics - Plug and Play - Yes
Ergonomics - Tilt adjustment - Yes
Ergonomics - Tilt angle range - -5 - 15°
Ergonomics - VESA mounting - Yes
Ergonomics - Wall mountable - Yes
Feet colour Design - Black
Frameless design Design - Yes
Front bezel colour Design - Black
HDMI Ports & interfaces - Yes
HD type Display - Full HD
Headphone out Ports & interfaces - No
Height (without stand) Weight & dimensions - 284 mm
Height adjustment Ergonomics - No
LED backlight Display - Yes
LongDesc -
LongProductName - 21.45" FHD ELED, VA, 16:9, 100 Hz, 10 ms, 250 cd/m², 3000:1, VGA, HDMI, 12 VDC, 2 A, 2.05 kg
LongSummaryDescription - Dahua Technology LM22-A200Y. Display diagonal: 54.5 cm (21.4"), Display resolution: 1920 x 1080 pixels, HD type: Full HD, Display technology: LED, Response time: 10 ms, Native aspect ratio: 16:9, Viewing angle, horizontal: 178°, Viewing angle, vertical: 178°. VESA mounting. Product colour: Black
Maximum refresh rate Display - 100 Hz
Mean time between failures (MTBF) Other features - 30000 h
Multimedia - Built-in camera - No
Multimedia - Built-in speaker(s) - No
Native aspect ratio Display - 16:9
NTSC coverage (typical) Display - 72 %
Operating relative humidity (H-H) Operational conditions - 10 - 90 %
Operating temperature (T-T) Operational conditions - 0 - 40 °C
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 90%
Operational conditions - Storage temperature (T-T) - -20 - 60 °C
Other features - Compliance certificates - CE, Electromagnetic Compatibility (EMC), Low Voltage Directive (LVD)
Other features - Mean time between failures (MTBF) - 30000 h
Package depth Packaging data - 99 mm
Package height Packaging data - 366 mm
Package type Packaging data - Box
Package weight Packaging data - 2860 g
Package width Packaging data - 598 mm
Packaging content - Power adapter included - Yes
Packaging content - Stand included - Yes
Packaging data - Package depth - 99 mm
Packaging data - Package height - 366 mm
Packaging data - Package type - Box
Packaging data - Package weight - 2.86 kg
Packaging data - Package width - 598 mm
Panel mounting interface Ergonomics - 75 x 75 mm
Panel type Display - VA
Plug and Play Ergonomics - Yes
Ports & interfaces - Built-in USB hub - No
Ports & interfaces - HDMI - Yes
Ports & interfaces - Headphone out - No
Ports & interfaces - VGA (D-Sub) ports quantity - 1
Power - AC adapter output voltage - 12 V
Power - Current rating - 2 A
Power - Energy consumption (SDR) per 1000 hours - 15 kWh
Power - Energy efficiency class (SDR) - E
Power - Power consumption (max) - 16 W
Power - Power consumption (standby) - 0.5 W
Power - Power consumption (typical) - 16 W
Power - Power supply type - External
Power adapter included Packaging content - Yes
Power consumption (max) Power - 16 W
Power consumption (standby) Power - 0.5 W
Power consumption (typical) Power - 16 W
Power supply type Power - External
Product colour Design - Black
ProductName - LM22-A200Y
Product Net Weight - 2.05 kg
Response time Display - 10 ms
Screen shape Display - Flat
ShortSummaryDescription - Dahua Technology LM22-A200Y, 54.5 cm (21.4"), 1920 x 1080 pixels, Full HD, LED, 10 ms, Black
Stand included Packaging content - Yes
Storage relative humidity (H-H) Operational conditions - 5 - 90 %
Storage temperature (T-T) Operational conditions - -20 - 60 °C
Summary - Dahua Technology LM22-A200Y. Display diagonal: 54.5 cm (21.4"), Display resolution: 1920 x 1080 pixels, HD type: Full HD, Display technology: LED, Response time: 10 ms, Native aspect ratio: 16:9, Viewing angle, horizontal: 178°, Viewing angle, vertical: 178°. VESA mounting. Product colour: Black
Tilt adjustment Ergonomics - Yes
Tilt angle range Ergonomics - -5 - 15 °
Title - Dahua Technology LM22-A200Y LED display 54.5 cm (21.4") 1920 x 1080 pixels Full HD Black
Touchscreen Display - No
Unit Box Height - 0.37
Unit Box Length - 0.6
Unit Box Width - 0.1
Unit Calculated Volume - 0.0222 cubm
Unit Calculated Weight - 3.06 kg
Units per Pallet - 0
URL - https://www.dahuasecurity.com/search/products?keyword=DHI-LM22-A200Y
Vendor Homepage - https://www.dahuasecurity.com/search/products?keyword=DHI-LM22-A200Y
VESA mounting Ergonomics - Yes
VGA (D-Sub) ports quantity Ports & interfaces - 1
Viewing angle, horizontal Display - 178 °
Viewing angle, vertical Display - 178 °
Wall mountable Ergonomics - Yes
Warranty - 36 months
WarrantyInfo -
Weight & dimensions - Bezel width (bottom) - 1.52 cm
Weight & dimensions - Bezel width (side) - 3.3 mm
Weight & dimensions - Bezel width (top) - 3.3 mm
Weight & dimensions - Depth (without stand) - 41.2 mm
Weight & dimensions - Height (without stand) - 284 mm
Weight & dimensions - Weight (without stand) - 2.05 kg
Weight & dimensions - Width (without stand) - 492.7 mm
Weight (without stand) Weight & dimensions - 2050 g
Width (without stand) Weight & dimensions - 492.7 mm
