Philips 10BDL5051T, 10.1"

Accessories included - AC adapter Quick start guide (x1) USB-A to USB-C cable HDMI cable
ACinputfrequency -
ACinputvoltage -
ARTIKEL1 - 10BDL5051T 10IN 1280X800
ARTIKEL2 - 350CD/M2 16:10 ANDROID 13 HDMI
Aspect ratio - 16:10
Audio -
Audio - Built-in speaker(s) - Yes
Audio - Number of built-in speakers - 2
Audio - RMS rated power - 3 W
Audioformatssupported -
Auto Pivot - No
Batteriesincluded -
Bluetooth - Yes
Bluetooth version - 5.0
Brand - Philips
BrandPartCode - 10BDL3351T/00
BrandPartCode - 10BDL5051T/00
Breite - 0.28
Brightness - 350 cd/m²
Built-in speakers - Yes
Builtinspeakers - Yes
Cable lock slot - Kensington
Cablesincluded - HDMI, USB Type-A to USB Type-C
Category - Signage Displays
Certificates - CB
Certificates - CE
Certificates - ETL
Certificates - FCC Class A
Certificates - RoHS
Certificates - Certification - CB
CE
RoHS
FCC, Classe A
ETL
Certification - CE
FCC, Class A
RoHS
CB
ETL
Color - Black
Computersystem - Yes
Computer system - Built-in processor - Yes
Computer system - Computer system - Yes
Computer system - Internal memory - 2 GB
Computer system - Internal storage capacity - 16 GB
Computer system - Operating system installed - Android
Computer system - Operating system version - 13
Computer system - Processor manufacturer - Rockchip
Computer system - Processor model - RK3568
Connections - Audio (3.5mm)
Connections - Ethernet (RJ-45)
Connections - HDMI out
Connections - micro SD
Connections - USB-A (USB 2.0)
Connections - USB-C
Contrast ratio (typical) - 1000:1
Contrastratiodynamic -
Contrastratiotypical - 1000:1
Depth - 24.75 mm
Description - Just the lightest touch is all it takes.
This ultra-clear, multi-touch smart display is ideal for situations where space is at a premium: from booking a room and finding your way to displaying ads. Power over Ethernet technology allows you to place the display anywhere, while the Android SoC enables versatile solutions.
Wave-enabled PPDS for remote display management and control
Your Wave-enabled PPDS display allows you to remotely manage and maintain it anywhere, anytime. This evolving cloud platform gives you complete control, with simplified installation and configuration, display monitoring and control, firmware updates, central content management, and power scheduling. You save time, energy, and environmental impact.
Built-in camera and speakers
The built-in camera and speakers make this small touchscreen a truly versatile, intelligent solution. Use it for retail audience measurement, customer analytics, and more. Harness the power of AI-powered Android apps to display content tailored to your audience. Or simply use the screen for video conferencing.
Stream content and play it instantly
Save and play content without a constant external player. The Philips professional monitor features internal memory, allowing you to stream media to the monitor for instant playback. The internal memory also acts as a cache for online streaming.
Plug & Play Multi-Touch Screen with 10-Point Touch
Philips professional Android displays are flexible and secure, optimized for native Android apps and the easy installation of web apps and software directly on the display. Everything can be controlled via an internet connection.
Android: Launch your own app or choose your favorite app to run
Thanks to the monitor's Android operating system, you can work with the world's most advanced operating system and save your own app directly on the monitor. You can also choose an app from the extensive Android app library and play content from it. Using the built-in task scheduler, you can schedule app usage and content playback based on customers and the time of day, and with the automatic orientation feature, displaying content in portrait or landscape orientation is as easy as turning on the monitor.
Near Field Communication (NFC) Ensures Security
NFC (Near Field Communication) offers secure authentication and access control, enhancing security through encrypted data transfer. Touchless operation minimizes the risk of unauthorized access or data interception, ensuring reliable display security.
Description - PHILIPS 10BDL5051T 10" MULTITOUCH DISPLAY WXGA POE ANDROID 13 SOC CAMERA NFC
Design -
Design - Bezel width (bottom) - 1.4 cm
Design - Bezel width (side) - 2.2 cm
Design - Bezel width (top) - 2.2 cm
Design - Mounting type - Wall
Design - Orientation - Horizontal/Vertical
Design - Panel mounting interface - 75 x 75 mm
Design - Placement supported - Indoor
Design - Product colour - Black
Design - Product design - Digital signage flat panel
Design - Product design - Interactive flat panel
Design - Screen shape - Flat
Design - VESA mounting - Yes
Designation - CE+WEEE
dimension depth - 290 mm
dimension height - 110 mm
Dimensions W x D x H, mm - 262 x 24.75 x 164
dimension weight - 2000 g
dimension width - 330 mm
Display -
Display - Contrast ratio (typical) - 1000:1
Display - Display brightness - 350 cd/m²
Display - Display diagonal - 25.6 cm (10.1")
Display - Display diagonal (metric) - 25.6 cm
Display - Display number of colours - 16.7 million colours
Display - Display resolution - 1280 x 800 pixels
Display - Display technology - LCD
Display - Frame width - 22 (L/R) 14 (T/B)
Display - Glass thickness - 0.7 mm
Display - HD type - WXGA
Display - Multi-touch - Yes
Display - Native aspect ratio - 16:10
Display - Number of displays - 1
Display - Number of simultaneous touchpoints - 10
Display - Response time - 35 ms
Display - Touchscreen - Yes
Display - Touchscreen technology - Projected capacitive system
Display - Viewing angle, horizontal - 160°
Display - Viewing angle, vertical - 160°
Displaybrightness - 350 cd/m²
Display brightness, cd/m² - 350
Displaydepth - 24.8 mm
Displaydiagonal - 25.6 cm (10.1")
Display diagonal, " - 10.1
Displayheight - 164 mm
Displaynumberofcolours - 16.7 million colours
DisplayPortsin -
DisplayPortsout -
DisplayPortsquantity -
Displayresolution - 1280 x 800 pixels
Display resolution, pixels - 1280 x 800
Display surface - Matt
Displaytechnology - LCD
Displayweight - 800 g
Displaywidth - 262 mm
DVIIportsquantity -
DVIport - No
ean - 810112790849
EANCode - 8712581806132
Energy class - not applicable
EnergyconsumptionSDRper1000hou -
EnergyefficiencyclassSDR -
Energyefficiencyscale -
EthernetLAN - Yes
EthernetLANRJ45ports - 1
EUEnergyLabel -
Features - Wall mountable - Yes
Gewicht - 1.67
GRUPPE1 - Displays
GRUPPE2 - Lcd Touchscreen
GTIN - 8712581804190
GTIN - 8712581806132
guarantee - 36
guarantee_type - external
Hazerate -
HDMIinputportsquantity -
HDMIoutputportsquantity - 1
HDMIportsquantity - 1
HDMIversion -
HDtype - WXGA
Height - 110.000000
Height - 164 mm
Height adjustment - No
HERSTELLER - PHILIPS
HighLights -
Hoehe - 0.11
HSTNUMMER - 10BDL5051T/00
I/O connectors - 1 x 3,5 mm minijack
I/O connectors - 1 x HDMI
I/O connectors - 1 x MicroSD card slot
I/O connectors - 1 x RJ-45 LAN
I/O connectors - 1 x USB (Type C)
I/O connectors - 1 x USB 2.0
Imageformatssupported -
Internal memory - 2 GB
Internal player - Yes
Laenge - 0.34
Length - 340.000000
LongDesc -
LongDesc - PPDS Wave-ready for remote display management and controlYour PPDS Wave-ready display enables you to manage and maintain this device remotely, wherever you are, whenever you choose. This evolutionary cloud platform puts you fully in control, with simplified installation and setup, monitoring and controlling displays, upgrading firmware, managing central content needs and setting power schedules — saving you time, energy and environmental impact.Built-in camera and speakersThe built-in camera and speakers make this small touchscreen a truly versatile smart solution. Use it for retail audience measurement, footfall analytics and more. Harness the power of Android AI apps to show targeted content. Or simply use your display for video conferencing.Internal memory. Upload content for instant playSave and play content without the need for a permanent external player. Your Philips Professional Display has an internal memory, which allows you to upload media into the display for instant playback. The internal memory also functions as a cache for online streaming.Plug-and-play 10-point multi-touch displayAndroid-powered Philips professional displays are flexible and secure, optimised for native Android apps and the easy installation of web apps and software directly on the display. All controlled via an Internet connection.Android: Run your own app or choose your favourite app to runWith Android OS integrated into the display, you can work with the most developed OS on the planet and save your own app directly into the display. Or, choose from the large library of Android apps and play content from there. With the built-in scheduler, you can daypart your apps and content based on your customer and time of day. With the auto-orientation feature, showing content in portrait or landscape is as simple as turning the display.Near-Field Communication (NFC) for securityNFC (Near Field Communication) offers secure authentication and access control, enhancing security with encrypted data transfer. Its contactless operation minimises the risk of unauthorised access or data interception, ensuring reliable security of the displays.
LongProductName - 10.1", 1280 x 800, 2/16 GB, Rockchip RK3568, Wi-Fi 5, Bluetooth 5.0, LAN, NFC, microSD, VESA, Android 13
LongSummaryDescription - Philips 10BDL3351T/00. Product design: Interactive flat panel. Display diagonal: 25.6 cm (10.1"), Display resolution: 1280 x 800 pixels, Display brightness: 350 cd/m², Touchscreen. Wi-Fi. Operating hours (hours/days): 24/7. Operating system installed: Android. Product colour: Black
LongSummaryDescription - Philips Signage Solutions 10BDL5051T/00. Product design: Digital signage flat panel. Display diagonal: 25.6 cm (10.1"), Display technology: LCD, Display resolution: 1280 x 800 pixels, Display brightness: 350 cd/m², HD type: WXGA, Touchscreen. Wi-Fi. Operating hours (hours/days): 24/7. Operating system installed: Android. Product colour: Black
Manufacturer - Philips
ManufacturerPartNumber - 10BDL5051T/00
ManufDatasheet - https://www.tdbaltic.ee/leaflets/PHILIPS/10BDL5051T00.pdf
Model - 10BDL5051T/00
name - 10BDL5051T 10-inch Touch Display
Nativerefreshrate -
Numberofbuiltinspeakers - 2
Number of colors - 16,7 mln
Operatinghourshoursdays - 24/7
OperatingrelativehumidityHH - 30 - 80%
Operating system provided - Android 13.0
Operating temperature range (T-T), °C - 0 - 40
OperatingtemperatureTT - 0 - 40 °C
Operationalconditions -
Operational conditions - Operating relative humidity (H-H) - 30 - 80%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 10 - 85%
Operational conditions - Storage temperature (T-T) - -10 - 60 °C
Operation time - 24/7
Optional accessory -
Orientation - Horizontal/Vertical
Other features -
Other features - Bluetooth - Yes
Other features - Bluetooth version - 5.0
Packagingcontent -
Packaging content - Cables included - HDMI, USB Type-A to USB Type-C
Packaging content - Power adapter included - Yes
Panellife -
Panelmountinginterface - 75 x 75 mm
Paneltype -
Performance -
Performance - Mean time between failures (MTBF) - 30000 h
Performance - Number of OSD languages - 18
Performance - On Screen Display (OSD) - Yes
Performance - On Screen Display (OSD) languages - Arabic, Simplified Chinese, Traditional Chinese, Danish, German, Dutch, English, Spanish, Finnish, French, Italian, Japanese, Norwegian, Polish, Portuguese, Russian, Swedish, Turkish
Performance - On Screen Display (OSD) languages - Arabic, Simplified Chinese, Traditional Chinese, Danish, German, English, Finnish, French, Italian, Japanese, Norwegian, Polish, Portuguese, Russian, Swedish, Turkish
Performance - Operating hours (hours/days) - 24/7
Performance - Purpose - Commercial
PeriodofWarranty - 3 Y
Pivot - Yes
Pixelpitch -
Placementsupported - Indoor
Ports & interfaces - Card reader integrated - Yes
Ports & interfaces - Compatible memory cards - MicroSD (TransFlash)
Ports & interfaces - DC-in jack - Yes
Ports & interfaces - DVI port - No
Ports & interfaces - Ethernet LAN - Yes
Ports & interfaces - Ethernet LAN (RJ-45) ports - 1
Ports & interfaces - HDMI output ports quantity - 1
Ports & interfaces - HDMI ports quantity - 1
Ports & interfaces - USB connector type - USB Type-A, USB Type-C
Ports & interfaces - USB connector type - USB Type-C
Ports & interfaces - USB port - Yes
Ports & interfaces - USB ports quantity - 3
Ports & interfaces - USB version - 2.0
Ports & interfaces - Wi-Fi - Yes
Ports & interfaces - Wi-Fi standards - 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Portsinterfaces -
Power -
Power - Input voltage - 12 V
Power - Power consumption (max) - 13 W
Power - Power consumption (max) - 18 W
Power - Power consumption (standby) - 0.5 W
Power - Power consumption (typical) - 4 W
Power consumption - 4 W
Power consumption (max.), W - 18
Power consumption (standby), W - 0.5
Power consumption, W - 4
Powerconsumptionstandby - 0.5 W
Powerconsumptiontypical - 4 W
ProdDesc - 10” P-CAP, Android 13, POE, WiFi, NFC, mainstream
producer - Philips
Productcolour - Black
Productcondition - Original
Productdesign - Digital signage flat panel
ProductHighLights -

• 10"
• Powered by Android
• Multi-touch

ProductName - 10BDL3351T/00
ProductName - 10BDL5051T/00
ProductPicture - https://www.tdbaltic.ee/images/products/PHILIPS/10BDL5051T00_1.jpg
ProductPicture1 -
ProductPicture2 -
ProductPicture3 -
ProductPicture4 -
ProductPicture5 -
Purpose - Commercial
Remotecontrolincluded -
RemoteIRinput -
RemoteIRoutput -
Resolution - 1280 x 800 (WXGA)
Responsetime - 35 ms
Response time - 35 ms
Response time, ms - 35
RMSratedpower - 3 W
RS232C -
Screen size (diag.) - 10.1''
ShortSummaryDescription - Philips 10BDL3351T/00, Interactive flat panel, 25.6 cm (10.1"), 1280 x 800 pixels, Wi-Fi, 24/7
ShortSummaryDescription - Philips Signage Solutions 10BDL5051T/00, Digital signage flat panel, 25.6 cm (10.1"), LCD, 1280 x 800 pixels, Wi-Fi, 24/7
Speaker power, W - 2 x 1.5
Speakers built-in - Yes
Static contrast - 1 000:1
Stck_Kart - 8
Stck_Pal - 0
StoragerelativehumidityHH - 10 - 85%
StoragetemperatureTT - -10 - 60 °C
Storno - N
Technical details - Compliance certificates - CB, CE, ETL, Federal Communications Commission (FCC), RoHS
Technical details - Warranty period - 3 year(s)
Title - Philips 10BDL3351T/00 Signage Display Interactive flat panel 25.6 cm (10.1") Wi-Fi 350 cd/m² Black Touchscreen Built-in processor Android 24/7
Title - Philips Signage Solutions 10BDL5051T/00 Signage Display Digital signage flat panel 25.6 cm (10.1") LCD Wi-Fi 350 cd/m² WXGA Black Touchscreen Built-in processor Android 24/7
Total storage capacity - 16 GB
Touch screen - Yes
Touch sensitive screen - Yes
Transreflective technology - LED
TV tuner built-in - No
URL - https://www.philips.co.uk/p-p/10BDL5051T_00/signage-solutions-multi-touch-display
USBport - Yes
USBportsquantity - 3
USBversion -
vendpn - 10BDL5051T/00
VESA-standard, mm - 75 x 75
VESAmounting - Yes
Videoformatssupported -
Viewing angle, horizontal - 160 °
Viewing angle, horizontal, ° - 160
Viewing angle, vertical - 160 °
Viewing angle, vertical, ° - 160
Viewinganglehorizontal - 160°
Viewinganglevertical - 160°
Warranty -
Warranty - 36 months
Warrantyandmisc -
WarrantyInfo - 3 years
Web camera - None
Weight - 0.8 kg
Weight - 1.650000
Weight & dimensions - Display depth - 24.8 mm
Weight & dimensions - Display height - 164 mm
Weight & dimensions - Display weight - 800 g
Weight & dimensions - Display width - 262 mm
Weight, kg - 0.8
Weightdimensions -
Wi-Fi - Yes
Width - 262 mm
Width - 280.000000
WiFi - Yes
WLAN type - 802.11 ac/a/b/g/n
