Mercusys WRL ROUTER 1167MBPS 1000M/4PORT AC12

3G/4G USB modem compatibility WAN connection - No
3G Mobile network - No
4G Mobile network - No
5G Mobile network - No
AC adapter included Packaging content - Yes
Access Control List (ACL) Security - Yes
Antenna > Antenna type - 4xFixed
Antenna design Antenna - External
Antenna gain level (max) Antenna - 5 dBi
Antennas quantity Antenna - 4
Cables included Packaging content - LAN (RJ-45)
Cabling technology Network - 10/100Base-T(X)
Category - Root/Electronics/Networks and communication/Routers
Category Code - WRO
Cechy podstawowe: Zarządzanie - WWW
Certification Certificates - CE, ROHS
Code - AC12
Dane techniczne: Funkcje urządzenia - router DSL
Dane techniczne: Gwarancja - 3 lata w serwisie zewnętrznym
Dane techniczne: Producent - Mercusys
Dane techniczne: Standard - Wi-Fi 5 (802.11a/b/g/n/ac)
Dane techniczne: Tryb pracy - bridge
Dane techniczne: Tryb pracy - router
Dane techniczne: Zastosowanie - domowy
Depth Weight & dimensions - 140 mm
Description - Faster Access to a More Colorful Life
AC1200 Dual Band Wireless Router
AC12 Blazing-Fast Everyday Wi-Fi
Complying with the powerful 802.11ac standard, AC12 delivers a blazing-fast Wi-Fi speed of up to 1200Mbps, which is 3x faster than the speed of the previous 802.11n standard. AC12 lets your home devices achieve their optimal Wi-Fi performance. It is the superior choice for providing faster, stronger Wi-Fi over your home or office. Concurrent Dual Band Connections
AC12 provides simultaneous dual-band Wi-Fi signals. The 2.4GHz band delivers 300Mbps Wi-Fi for everyday activities like surfing the internet and sending emails. The crystal 5GHz band reaches 867Mbps so you can game online and stream in HD simultaneously. Both bands work at the same time to meet the needs of multiple tasks on different devices. Strong Signal,
Great Coverage
Four external 5dBi antennas powered with advanced antenna technology provide users with larger wireless coverage and wireless signal intensity throughout your large home or office, making weak, dropped connections a thing of the past. Superior Online Experience with IPv6 & IPTV
Compatible with IPv6, AC12 allows you to enjoy IPv6 services provided by ISP
and visit IPv6 websites. IPTV supports IGMP Proxy/Snooping, Bridge and Tag VLAN to optimize IPTV
streaming for high network efficiency and superior online experience. Easy Three-Step Installation
With no need for complicated configuration, you can simply follow the step-by-step instructions on the intuitive webpage to set up your AC12 in minutes.
- 1. Create a unique login password
- 2. Choose your internet service and enter the required information
- 3. Set your wireless network name ( SSID ) and passwordSupports 802.11ac standard - the next generation of Wi-FiEnjoy smooth online gaming and video streaming with dual band 1200Mbps Wi-Fi4 External Antennas Greatly Expand Wireless CoverageGuest Network Access provides secure Wi-Fi access for guests sharing your home or office networkEasy installation - intuitive webpage guides you through the setup process in minutes
Design > Colour of product - Black
DHCP client Protocols - Yes
DHCP server Protocols - Yes
DSL WAN WAN connection - No
Dynamic DNS (DDNS) Network - Yes
EAN - 6957939000479
Eans - 6957939000479
Ethernet LAN (RJ-45) ports Ports & interfaces - 4
Ethernet LAN data rates Network - 10,100 Mbit/s
Ethernet LAN interface type Network - Fast Ethernet
Ethernet LAN Network - Yes
Ethernet WAN WAN connection - Yes
Features > Mesh Support - No
Features > Mobile Broadband - No mobile broadband
Features > MU-MiMO - No
Firewall Security - Yes
Guest access Security - Yes
Height Weight & dimensions - 32 mm
IP address filtering Security - Yes
Link - https://www.mercusys.com/en/product/details/ac12
MAC address filtering Security - Yes
Memory card slot(s) Ports & interfaces - No
Model name - AC12
Name - Mercusys AC12
Name - Mercusys | AC1200 Dual Band Wireless Router | AC12 | 802.11ac | 300+867 Mbit/s | 10/100 Mbit/s | Ethernet LAN (RJ-45) ports 3 | Mesh Support No | MU-MiMO No | No mobile broadband | Antenna type 4xFixed | No
Networking standards Network - IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Operating relative humidity (H-H) Operational conditions - 10 - 90%
Operating temperature (T-T) Operational conditions - 0 - 40 °C
Other features > Ethernet LAN (RJ-45) ports - 3
Other features > USB ports quantity - No
Output current Power - 0.85 A
Output voltage Power - 9 V
Package depth Packaging data - 288 mm
Package features > Classification of battery - CL126:NE:2016-12-09
Package features > Composition of battery - CL127:KT:2016-12-09
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 380 mm
Package features > Gross depth master carton - 600 mm
Package features > Gross height (mm) - 290 mm
Package features > Gross height master carton - 360 mm
Package features > Gross width (mm) - 65 mm
Package features > Gross width master carton - 395 mm
Package features > Net weight master carton - 6.85 kg
Package features > Packing quantity - 10 pc(s)
Package features > Palette Qty - 200 pc(s)
Package features > Paper/Pasteboard - 360.00 g
Package features > Plastic (No PET) - 90.00 g
Package features > Tare weight (kg) - 0.45 kg
Package features > Tare weight master carton - 1.45 kg
Package features > TI weight (kg) - 0.15 kg
Package features > Type of battery - Accumulator
Package features > Volume (m3) - 0.007163 m³
Package features > WEE classification - CL109:5:2017-04-01
Package features > WEEE tax - Yes
Package height Packaging data - 66 mm
Package weight Packaging data - 640 g
Package width Packaging data - 382 mm
Performance > Ethernet LAN data rates - 10/100 Mbit/s
Performance > Wi-Fi data rate (max) - 300+867 Mbit/s
Port forwarding Network - Yes
Ports & interfaces > WAN connection - 1*10/100Mbps WAN Port
Power source type Power - AC
Pozostałe cechy: Akcesoria - zasilacz | kabel sieciowy | instrukcja
Pozostałe cechy: Dodatkowe informacje - sieć gość
Pozostałe cechy: Rodzaj anteny - zewnętrzna (4 x 5dBi)
Pozostałe cechy: Wymiary - 220 x 140 x 32 mm
Pozostałe cechy: Zasilanie - zasilacz AC
Praca bezprzewodowa: Częstotliwość - 2.4 GHz
Praca bezprzewodowa: Częstotliwość - 5 GHz
Praca bezprzewodowa: Szybkość dla 2.4 GHz - 300 Mbps
Praca bezprzewodowa: Szybkość dla 5 GHz - 867 Mbps
Praca bezprzewodowa: Szyfrowanie - WPA-PSK
Praca bezprzewodowa: Szyfrowanie - WPA2-PSK
Praca przewodowa: Interfejsy LAN - RJ-45
Praca przewodowa: Interfejsy WAN - 1 x 10/100 Mb/s
Praca przewodowa: Liczba portów LAN 10/100 - 4 szt.
Praca przewodowa: Liczba portów WAN - 1 szt.
Praca przewodowa: Złącza - 1 x RJ45 (LAN/WAN)
Praca przewodowa: Złącza - 4 x RJ45
Producent: Nazwa producenta / importera - Mercusys
TP-LINK Polska Sp. z o.o.
Ożarowska 40/42
05-850 Duchnice

Producer - Mercusys
ProducerCode - AC12
Producer product family - AC1200 Dual Band Wireless Router
Producer product name - AC12
Product colour Design - Black
Product type Design - Tabletop router
Quick installation guide Packaging content - Yes
Reset button Management features - Yes
Security algorithms Security - WPA-PSK, WPA2-PSK
ShortDescription - Obsługa standardu 802.11ac - nowej generacji połączeń bezprzewodowych
SIM card slot WAN connection - No
Storage relative humidity (H-H) Operational conditions - 5 - 90%
Storage temperature (T-T) Operational conditions - -40 - 70 °C
Summary - Mercusys AC1200 Dual Band Wireless Router. Wi-Fi band: Dual-band (2.4 GHz / 5 GHz), Top Wi-Fi standard: Wi-Fi 5 (802.11ac), WLAN data transfer rate (max): 867 Mbit/s. Ethernet LAN interface type: Fast Ethernet, Ethernet LAN data rates: 10,100 Mbit/s, Cabling technology: 10/100Base-T(X). Security algorithms: WPA-PSK, WPA2-PSK. Product type: Tabletop router, Product colour: Black. Certification: CE, ROHS
Technical details > Gross weight - 0.685 kg
Technical details > Net weight - 0.235 kg
Technical details > Producer - Mercusys
Top Wi-Fi standard Wireless LAN features - Wi-Fi 5 (802.11ac)
Unit Box Height - 0.07
Unit Box Length - 0.38
Unit Box Width - 0.29
Unit Calculated Volume - 0.007714 cubm
Unit Calculated Weight - 0.77 kg
Units per Shipping Box - 1
USB port Ports & interfaces - No
Vendor Homepage - https://www.mercusys.com/uk/product/details/ac12
Warranty - 24
Warranty - 24 month(s)
Warranty - 36 months
Web-based management Management features - Yes
Wi-Fi band Wireless LAN features - Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards Wireless LAN features - 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Width Weight & dimensions - 222 mm
Wireless LAN features > Wi-Fi band - 802.11ac
WLAN data transfer rate (max) Wireless LAN features - 867 Mbit/s
