10/100/1000M LAN Ports - 4
Accessories included -
Antenna - Built-in
Antenna - Antenna gain level (max) - 4.7 dBi
Antenna - Antenna type - Internal
Antenna gain - 7 dBi
Antenna Gain - 27 dB
ARTIKEL1 - AX3000 WI-FI 6 ACCESS POINT
ARTIKEL2 - DESKTOP DUAL-BAND
Brand - TP-Link
BrandPartCode - EAP650-DESKTOP
Breite - 0
Category - Wireless Access Points
Category 1 - Netzwerk
Category 2 - Accesspoints
Category Code - WAP
Certificates - CE, FCC, RoHS, IC
Certificates - Certification - CE, FCC, RoHS, IC
Code - EAP650-Desktop
Color - White
Colour - White
Data transmission speed - 3000 Mbps
Description - Błyskawicznie szybkie prędkości WiFi 6 AX3000: 574 Mb/s w paśmie 2,4 GHz oraz 2402 Mb/s w paśmie 5 GHz, co łącznie daje 2976 Mb/s. Wiele portów Gigabit: Możliwość podłączenia wielu urządzeń dzięki 4 gigabitowym portom Ethernet. Wygodne wdrożenie: Obsługuje zarówno zasilanie PoE++ 802.3bt, jak i zasilacz DC (w zestawie), co umożliwia szybkie i łatwe wdrożenie. Bez konieczności instalacji: Obsługuje instalację na biurku bez potrzeby dodatkowej konfiguracji. Wysoka elastyczność: Oferuje elastyczne opcje montażu zarówno na biurku, jak i na ścianie. Płynne działanie dzięki bezproblemowemu roamingowi: Użytkownicy mogą cieszyć się nieprzerwanym strumieniowaniem, ponieważ ich urządzenia płynnie przełączają się między punktami dostępowymi. Scentralizowane zarządzanie w chmurze: Integracja z platformą Omada SDN umożliwia scentralizowane zarządzanie.
Description - Omada AX3000 Desktop Wi-Fi 6 Access Point Blazing-Fast AX3000 WiFi 6 Speeds: 574 Mbps on 2.4 GHz and 2402 Mbps on 5GHz totals 2976 Mbps WiFi speeds. Multiple Gigabit Ports: Connect multiple devices with 4× Gigabit Ethernet Ports. Convenient Deployment: Supports both 802.3bt PoE++ and DC (adapter included) for easy and quick deployment. No Installation needed:Supports desktop installation without the need for additional setup. High Flexibility: Provide flexible installation solutions for both desktop and wall mounting. Stay Smooth with Seamless Roaming: Users can enjoy seamless streaming across the property with their devices switching effortlessly between access points.§ Centralized Cloud Management: Integrates with the Omada SDN platform for Centralized Management.
Design - LED indicators - Yes
Design - Placement - Table
Design - Product colour - White
Design - Reset button - Yes
Designation - CE+WEEE
dimensionalWeight - 756
dimension depth - 95 mm
dimension height - 205 mm
Dimensions - 175 × 140 × 33 mm
dimension weight - 930 g
dimension width - 175 mm
EAN - 8885020623734
ean - 8885020623734
EANCode - 8885020623734
Environment requirements - Temperatura robocza: 0-40 stopni Celsjusza Temperatura przechowywania: -40-70 stopni Celsjusza Wilgotność robocza: 10-90% RH, bez kondensacji Wilgotność przechowywania: 5-90% RH, bez kondensacji
Features - 2.4 GHz - Yes
Features - 5 GHz - Yes
Features - 6 GHz - No
Features - Airtime Fairness (ATF) - Yes
Features - Band steering - Yes
Features - BeamForming - Yes
Features - Channel bandwidth - 160 MHz
Features - Ethernet LAN data rates - 1000 Mbit/s
Features - Load balancing - Yes
Features - Maximum data transfer rate - 2976 Mbit/s
Features - Maximum data transfer rate (2.4 GHz) - 574 Mbit/s
Features - Maximum data transfer rate (5 GHz) - 2402 Mbit/s
Features - MIMO - Yes
Features - MIMO type - Multi User MIMO
Features - Networking standards - IEEE 802.3af
Features - Networking standards - IEEE 802.3af, IEEE 802.3bt
Features - Networking standards - IEEE 802.3bt
Features - Quality of Service (QoS) support - Yes
Features - Rate limiting - Yes
Features - Transmitting power (CE) - 20 - 29 dBm
Features - Transmitting power (FCC) - 26 - 27 dBm
Features - VLAN support - Yes
Features > MU-MiMO - Yes
Gewicht - 0
Gross Weight Kg - 0,25
GRUPPE1 - Network
GRUPPE2 - Wireless Lan Ap
GTIN - 1210002605939
GTIN - 8885020623734
guarantee - 60
guarantee_type - normal
HERSTELLER - TP-LINK
Hoehe - 0
HSTNUMMER - EAP650-DESKTOP
I/O ports - 1 x FXS (RJ-11)
I/O ports - 4 x 10/100/1000 Mbit/s
Laenge - 0
Link - https://www.omadanetworks.com/my/business-networking/omada-wifi-desktop/eap650-desktop/
LongDesc -
LongProductName - EAP650-Desktop Omada AX3000 Desktop Wi-Fi 6 Access Point
LongSummaryDescription - TP-Link EAP650-DESKTOP. 2.4 GHz, 5 GHz, Maximum data transfer rate: 2976 Mbit/s. Security algorithms: 802.1x RADIUS, SNMP, SNMPv2, SNMPv3, SSH, WPA-Enterprise, WPA-Personal, WPA2-Enterprise,.... Ethernet LAN data rates: 1000 Mbit/s. Power over Ethernet (PoE). Product colour: White. Power consumption (max): 17.3 W
Management, monitoring, configuration -
Management features - Management platform - Omada
Management features - Syslog - Yes
Management features - Web-based management - Yes
Manufacturer - TP-Link
Manufacturer Code - EAP650-DESKTOP
Manufacturer Name - TP-LINK
Model name - EAP650-Desktop
MPN - EAP650-Desktop(EU)
name - EAP650-Desktop Access Point Omada AX3000 Desktop Dual Band Wi-Fi 6
Name - TP-LINK Omada AX3000 Desktop Wi-Fi 6 Access Point | EAP650-Desktop | 802.11ax | 2402 Mbit/s | Ethernet LAN (RJ-45) ports 4 | MU-MiMO Yes | PoE in
Name - TP-Link Omada WL-AP Access Point EAP650 Desktop (AX3000)
Network architecture - GigabitEthernet
Network Device Type - Wireless Access Point
Networking > Wi-Fi - Yes
Networking > Wi-Fi standards - 802.11 a/b/g/n/ac/ax
Number of antennas - 5
Operating frequency - 2,4 GHz
Operating frequency - 5 GHz
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 90%
Operational conditions - Storage temperature (T-T) - -40 - 70 °C
Other features -
Other features - Wireless standard - IEEE 802.11 a/b/g/n/ac/ax
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 209.00 mm
Package features > Gross height (mm) - 97.00 mm
Package features > Gross width (mm) - 177.00 mm
Package features > Packing quantity - 1.00 pc(s)
Package features > Palette Qty - 482 pc(s)
Package features > Paper/Pasteboard - 90.00 g
Package features > Plastic (No PET) - 10.00 g
Package features > Tare weight (kg) - 0.10 kg
Package features > Volume (m3) - 0.00 m³
Package features > WEE classification - CL109:5:2017-04-01
Package features > WEEE tax - Yes
Packaging content - Quantity per pack - 1 pc(s)
Performance - Compatible operating systems - Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Windows11, Linux
Performance > Ethernet LAN data rates - 2402 Mbit/s
Ports & interfaces - Ethernet LAN (RJ-45) ports - 4
Ports & interfaces > Ethernet LAN (RJ-45) ports - 4
Ports & interfaces > POE - PoE in
Power - DC voltage range - 12 V
Power - Input current - 1.5 A
Power - Power consumption (max) - 17.3 W
Power - Power over Ethernet (PoE) - Yes
Power supply - 802.3 af/at/bt PoE lub 12 V/1,5 A DC *PoE Out wymaga zasilania PoE 802.3at/bt
producer - TP-LINK
producerCode - EAP650-Desktop
ProductName - EAP650-DESKTOP
productName - TP-Link EAP650-DESKTOP wireless access point 2976 Mbit/s White Power over Ethernet (PoE)
Product Net Weight - 0 kg
productSize - Normal
Security - WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise
Security - Access Control List (ACL) - Yes
Security - Number of SSID supported - 16
Security - Security algorithms - 802.1x RADIUS
Security - Security algorithms - 802.1x RADIUS, SNMP, SNMPv2, SNMPv3, SSH, WPA-Enterprise, WPA-Personal, WPA2-Enterprise, WPA2-Personal, WPA3-Enterprise, WPA3-Personal
Security - Security algorithms - SNMP
Security - Security algorithms - SNMPv2
Security - Security algorithms - SNMPv3
Security - Security algorithms - SSH
Security - Security algorithms - WPA-Enterprise
Security - Security algorithms - WPA-Personal
Security - Security algorithms - WPA2-Enterprise
Security - Security algorithms - WPA2-Personal
Security - Security algorithms - WPA3-Enterprise
Security - Security algorithms - WPA3-Personal
Security - Service Set Identifier (SSID) features - Multiple SSIDs
Series - Omada
Short description - TP-LINK WLAN AX3000 Access Point Dualband EAP650-Desktop
ShortSummaryDescription - TP-Link EAP650-DESKTOP, 2.4 GHz, 5 GHz, 2976 Mbit/s, 802.1x RADIUS, SNMP, SNMPv2, SNMPv3, SSH, WPA-Enterprise, WPA-Personal, WPA2-Enterprise,..., 1000 Mbit/s
sizeX - 210
sizeY - 180
sizeZ - 100
Software -
Special functions -
Standards - 802.3af
Standards - 802.3at
Standards - 802.3bt
Standards - 802.11a
Standards - 802.11ac
Standards - 802.11ax
Standards - 802.11b
Standards - 802.11g
Standards - 802.11n
Stck_Kart - 9998
Stck_Pal - 0
Storno - Y
System Requirements -
Technical details > Gross weight - 0.96 kg
Technical details > Net weight - 0.86 kg
Technical details > Producer - TP-LINK
Technical details > Producer product family - Omada AX3000 Desktop Wi-Fi 6 Access Point
Technical details > Producer product name - EAP650-Desktop
Title - TP-Link EAP650-DESKTOP wireless access point 2976 Mbit/s White Power over Ethernet (PoE)
Unit Box Height - 0.095
Unit Box Length - 0.21
Unit Box Width - 0.175
Unit Calculated Volume - 0 cubm
Unit Calculated Weight - 1 kg
Units per Shipping Box - 1
URL - https://www.omadanetworks.com/my/business-networking/omada-wifi-desktop/eap650-desktop/
Vendor Homepage - www.omadanetworks.com/my/business-networking/omada-wifi-desktop/eap650-desktop/
vendpn - EAP650-Desktop
Warranty - 60
Warranty - 60 month(s)
Warranty - 60 months
WarrantyInfo -
warrantyLength - 60
warrantyType - G
Weight - 0.952
Weight - 452 g
weight - 920
Weight & dimensions - Depth - 33 mm
Weight & dimensions - Height - 175 mm
Weight & dimensions - Weight - 452 g
Weight & dimensions - Width - 140 mm
Wi-Fi 6 Network standard - Yes
Wireless Frequency Range - 2.4 GHz and 5 GHz
Wireless LAN features > Wi-Fi band - 802.11ax
