Accessories included - TL-MR105 Power supply with 1.5m cable RJ45 Ethernet cable Quick installation guide
Aero2 support - No
Antenna - Built-in
Antenna - Detachable external
Antenna - Antenna design - Internal
Brand - TP-Link
BrandPartCode - TL-MR105
Card reader - None
Category - Wireless Routers
Certificates - CE, RoHS
Certificates - Compliance certificates - CE, RoHS
Code - TL-MR105
Color - White
Data transmission - HSPA+
Data transmission - LTE
Data transmission - UMTS
Description - TL-MR105 4G LTE Wireless N Router 300Mbps 4G LTE Support Share your internet connection with up to 32 devices and enjoy download speeds of up to 150Mbps Insert a nanoSIM card and go Forget about the tedious setup process. SIM card compatibility has been confirmed by years of field testing in over 100 countries Wi-Fi Router Mode Connect an Ethernet cable to the LAN/WAN port and use a wired connection when there is no 4G network available
Design - Product colour - White
Design - Product type - Tabletop router
Designation - CE+WEEE
dimensionalWeight - 728
dimension depth - 5 mm
dimension height - 200 mm
Dimensions - 174 × 130 × 60 mm
dimension weight - 560 g
dimension width - 260 mm
EAN - 4895252503371
ean - 4895252503371
Environment requirements - Permissible operating temperature: 0~40 degrees Celsius Permissible air humidity: 10%~90%, non-condensing Permissible storage humidity: 5%~90%, non-condensing
GTIN - 4895252503388
guarantee - 36
guarantee_type - normal
I/O ports - 1 x 10/100 Mbit/s
I/O ports - 1 x 10/100 Mbit/s LAN / WAN (Combo)
I/O ports - 1 x SIM card slot
LongDesc - Enjoy 4G LTE SharingWherever You Want300 Mbps Wireless N 4G LTE RouterNo Configuration Needed Simply Plug and Play!With an integrated 4G LTE modem and a built-in SIM card slot, all you need to do is inserting a nano SIM card and turning on the router. It has never been easier than enjoy a fast, stable Wi-Fi on 4G LTE network.Share Your 4G LTE NetworkTake full advantage of your cutting-edge 4G LTE network to download speed up to 150 Mbps. Share your 4G LTE network with multiple Wi-Fi devices and enjoy uninterrupted HD movies, rapid file downloads, and smooth video chats. Fully compatible with FDD-LTE and TDD-LTE to work with most service providers worldwide.Advanced Software Functions Help You Enhance Your Network Safety and EffectivenessRobust Parental ControlsIf you want to block harmful websites, set surfing time limits, check which sites your kids are using or just pause the internet, you can do it all.Guest NetworkIt provides separate Wi-Fi access for guests while securing the whole network.Wi-Fi Where You Need ItEnjoy unconstrained convenience and versatility. TL-MR105 has been tested in the field for years to ensure universal compatibility with 2 internal LTE antennas to deliver a smooth connection. Simply plug in a nano SIM card and power on this elegant piece of device to utilize fast and stable Wi-Fi, whether you’re at home or working remotely.Reliable Access for Up to 32 Devices SimultaneouslyEasily share a 3G/4G connection with up to 32 wireless devices, such as phones, tablets, and laptops, at the same time. 2 LAN ports stand ready to provide internet for wired devices like desktop computers.
LongProductName - 2.4 GHz, 300 Mbps, IEEE 802.11b/g/n, 1x 10/100Mbps LAN, 1x 10/100Mbps LAN/WAN, Nano SIM Card Slot, 174×130×60 mm
LongSummaryDescription - TP-Link 300 Mbps Wireless N 4G LTE Router. WAN connection type: RJ-45. Wi-Fi band: Single-band (2.4 GHz), Top Wi-Fi standard: Wi-Fi 4 (802.11n), WLAN data transfer rate (max): 300 Mbit/s. Ethernet LAN interface type: Fast Ethernet, Ethernet LAN data rates: 10,100 Mbit/s. Mobile network generation: 4G, 3G standards: DC-HSPA+, HSDPA, HSPA, UMTS, 4G standard: LTE-TDD & LTE-FDD. Security algorithms: 64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK, Firewall security: IPv4 SPI Firewall
LTE network - 800 MHz
LTE network - 850 MHz
LTE network - 900 MHz
LTE network - 1800 MHz
LTE network - 1900 MHz
LTE network - 2100 MHz
LTE network - 2300 MHz
LTE network - 2500 MHz
LTE network - 2600 MHz
Management, monitoring, configuration -
Management features - Reset button - Yes
Management features - WPS push button - Yes
Mobile network - 3G standards - DC-HSPA+
Mobile network - 3G standards - DC-HSPA+, HSDPA, HSPA, UMTS
Mobile network - 3G standards - HSDPA
Mobile network - 3G standards - HSPA
Mobile network - 3G standards - UMTS
Mobile network - 4G bands supported - 800
Mobile network - 4G bands supported - 800,850,900,1800,2100,2300,2500,2600 MHz
Mobile network - 4G bands supported - 850
Mobile network - 4G bands supported - 900
Mobile network - 4G bands supported - 1800
Mobile network - 4G bands supported - 2100
Mobile network - 4G bands supported - 2300
Mobile network - 4G bands supported - 2500
Mobile network - 4G bands supported - 2600 MHz
Mobile network - 4G standard - LTE-TDD & LTE-FDD
Mobile network - Mobile network generation - 4G
Mobile network - SIM card type - NanoSIM
Model - MR105
name - Router Archer MR105 4G LTE N300
Name - TP-LINK TL-MR105 300Mbps Wireless N 4G LTE Router
Network - Dynamic DNS (DDNS) - Yes
Network - Ethernet LAN - Yes
Network - Ethernet LAN data rates - 10
Network - Ethernet LAN data rates - 10,100 Mbit/s
Network - Ethernet LAN data rates - 100
Network - Ethernet LAN interface type - Fast Ethernet
Network - Number of guest networks (2.4 GHz) - 1
Network - Port forwarding - Yes
Network - Port triggering - Yes
Number of antennas - 6
Operating frequency - 2,4 GHz
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 90%
Other features -
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 280.00 mm
Package features > Gross height (mm) - 100.00 mm
Package features > Gross width (mm) - 150.00 mm
Package features > Packing quantity - 1.00 pc(s)
Package features > Palette Qty - 333 pc(s)
Package features > Paper/Pasteboard - 190.00 g
Package features > Plastic (No PET) - 10.00 g
Package features > Tare weight (kg) - 0.20 kg
Package features > Volume (m3) - 0.00 m³
Package features > WEE classification - CL109:5:2017-04-01
Package features > WEEE tax - Yes
Packaging content - Cables included - LAN (RJ-45)
Packaging content - Quick installation guide - Yes
Packaging data - Package type - Box
Ports & interfaces - DC-in jack - Yes
Ports & interfaces - Ethernet LAN (RJ-45) ports - 2
Ports & interfaces - USB port - No
Power - Power source type - DC
Power supply - 9V/0,85A
producer - TP-LINK
producerCode - TL-MR105
ProductName - 300 Mbps Wireless N 4G LTE Router
productName - TP-Link 300 Mbps Wireless N 4G LTE Router
productSize - Normal
Protocols - DHCP client - Yes
Protocols - DHCP server - Yes
Protocols - Universal Plug and Play (UPnP) - Yes
Security - Wireless Security: 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK encryption
Security - DMZ support - Yes
Security - Firewall - Yes
Security - Firewall security - IPv4 SPI Firewall
Security - Guest access - Yes
Security - Security algorithms - 64-bit WEP
Security - Security algorithms - 64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Security - Security algorithms - 128-bit WEP
Security - Security algorithms - WPA
Security - Security algorithms - WPA-PSK
Security - Security algorithms - WPA2
Security - Security algorithms - WPA2-PSK
ShortSummaryDescription - TP-Link 300 Mbps Wireless N 4G LTE Router, Wi-Fi 4 (802.11n), Single-band (2.4 GHz), Ethernet LAN, 4G, White, Tabletop router
SIM card - Nano
sizeX - 70
sizeY - 200
sizeZ - 260
Software -
Special functions -
Standards - 802.11b
Standards - 802.11g
Standards - 802.11n
Standards - IPv4
Standards - IPv6
Sustainability - Sustainability certificates - CE
Sustainability - Sustainability certificates - RoHS
Sustainability - Sustainability compliance - Yes
System Requirements - Internet Explorer 11+, Firefox 12.0, Chrome 20.0, Safari 4.0 or other browser with JavaScript enabled
Technical details > Gross weight - 3.00 kg
Technical details > Net weight - 2.80 kg
Technical details > Producer - TP-LINK
Title - TP-Link 300 Mbps Wireless N 4G LTE Router
Type - GSM 3G/4G
UMTS network - 850 MHz
UMTS network - 900 MHz
UMTS network - 2100 MHz
URL - https://www.tp-link.com/uk/home-networking/3g-4g-router/tl-mr105/
vendpn - TL-MR105
WAN connection - Ethernet WAN - Yes
WAN connection - SIM card slot - Yes
WAN connection - WAN connection type - RJ-45
Warranty - 36
Warranty - 36 month(s)
WarrantyInfo -
warrantyLength - 36
warrantyType - G
weight - 550
Weight & dimensions - Depth - 130 mm
Weight & dimensions - Height - 60 mm
Weight & dimensions - Width - 174 mm
Wireless LAN features - Top Wi-Fi standard - Wi-Fi 4 (802.11n)
Wireless LAN features - Wi-Fi band - Single-band (2.4 GHz)
Wireless LAN features - Wi-Fi standards - 802.11b
Wireless LAN features - Wi-Fi standards - 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Wireless LAN features - Wi-Fi standards - 802.11g
Wireless LAN features - Wi-Fi standards - Wi-Fi 4 (802.11n)
Wireless LAN features - WLAN data transfer rate (first band) - 300 Mbit/s
Wireless LAN features - WLAN data transfer rate (max) - 300 Mbit/s
