Brand - Viewsonic
BrandPartCode - PA503W
Category - Data Projectors
Design - Market positioning - Presentation
Design - Placement - Desktop, Ceiling
Design - Product colour - White
Design - Product type - Standard throw projector
Display - Built-in display - No
Features - HDCP - Yes
Features - Interactive - No
Features - Noise level - 31 dB
Features - Noise level (economic mode) - 27 dB
Features - Number of OSD languages - 22
Features - On Screen Display (OSD) - Yes
Features - On Screen Display (OSD) languages - Arabic, Simplified Chinese, Traditional Chinese, Czech, German, Dutch, English, Spanish, Finnish, French, Greek, Indonesian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Swedish, Thai, Turkish, Vietnamese
GTIN - 766907904918
GTIN - 0766907904918
Lens system - Aperture range (F-F) - 2.56 - 2.68
Lens system - Focal length range - 22 - 24.1 mm
Lens system - Focus - Manual
Lens system - Offset - 100%
Lens system - Throw ratio - 1.55-1.7
Lens system - Zoom capability - Yes
Lens system - Zoom ratio - 2.0:1
Light source - Lamp power - 200 W
Light source - Lamps quantity - 1 lamp(s)
Light source - Light source type - Lamp
Light source - Service life of light source - 5000 h
Light source - Service life of light source (economic mode) - 15000 h
Logistics data - Harmonized System (HS) code - 85286200
LongDesc - DescriptionThe ViewSonic PA503W price-performance projector features 3,600 lumens, native WXGA 1280x800 resolution, and an intuitive, user-friendly design. Exclusive SuperColor technology offers a wider color range for lifelike image projection. The PA503w also features extensive connectivity including HDMI, 2 x VGA in, Composite Video, 1 x VGA output, and Audio in/out. An energy-saving SuperEco feature reduces power consumption by up to 70%, and extends the lamp life by up to 10,000 hours. With advanced audiovisual features, flexible connectivity options, and an affordable price, the PA503W is ideal for use in education and small business environments.
LongProductName - 3600 Lumen, DLP, WXGA, 16:9, 30-300", 100-240V, 50/60Hz, 396x110x218mm, 2.2 kg, White
LongSummaryDescription - Viewsonic PA503W. Projector brightness: 3800 ANSI lumens, Projection technology: DMD, Projector native resolution: WXGA (1280x800). Light source type: Lamp, Service life of light source: 5000 h, Service life of light source (economic mode): 15000 h. Focus: Manual, Focal length range: 22 - 24.1 mm, Aperture range (F-F): 2.56 - 2.68. Analog signal format system: NTSC, PAL, SECAM, Supported graphics resolutions: 640 x 480 (VGA), 1920 x 1080 (HD 1080), Supported video modes: 480i, 480p, 576i, 576p, 720p, 1080i, 1080p. Serial interface type: RS-232, HDMI connector type: Full-size
Multimedia - Built-in speaker(s) - Yes
Multimedia - RMS rated power - 2 W
Network - Ethernet LAN - No
Network - Smart TV - No
Network - Wi-Fi - No
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Packaging content - Cables included - AC, VGA
Packaging content - Manual - Yes
Packaging content - Remote control included - Yes
Ports & interfaces - AC (power) in - Yes
Ports & interfaces - Composite video in - 1
Ports & interfaces - DVI port - No
Ports & interfaces - HDMI connector type - Full-size
Ports & interfaces - HDMI ports quantity - 1
Ports & interfaces - HDMI version - 1.4
Ports & interfaces - Mini-USB 2.0 ports quantity - 1
Ports & interfaces - Mobile High-Definition Link (MHL) - No
Ports & interfaces - PC Audio in - Yes
Ports & interfaces - PC Audio out - Yes
Ports & interfaces - Serial interface type - RS-232
Ports & interfaces - VGA (D-Sub) ports quantity - 3
Power - AC input frequency - 50 - 60 Hz
Power - AC input voltage - 100-240 V
Power - Power consumption (standby) - 0.5 W
Power - Power consumption (typical) - 260 W
Power - Power source - AC
ProductName - PA503W
Projector - Contrast ratio (typical) - 22000:1
Projector - Horizontal scan range - 15 - 102 kHz
Projector - Keystone correction, vertical - -40 - 40°
Projector - Matrix size - 1.65 cm (0.65")
Projector - Number of colours - 1.07 billion colours
Projector - Projection distance - 1 - 10.98 m
Projector - Projection technology - DMD
Projector - Projector brightness - 3800 ANSI lumens
Projector - Projector native resolution - WXGA (1280x800)
Projector - Screen size compatibility - 762 - 7620 mm (30 - 300")
Projector - Vertical scan range - 23 - 120 Hz
ShortSummaryDescription - Viewsonic PA503W, 3800 ANSI lumens, DMD, WXGA (1280x800), 22000:1, 762 - 7620 mm (30 - 300"), 1 - 10.98 m
Storage - Card reader integrated - No
Title - Viewsonic PA503W data projector Standard throw projector 3800 ANSI lumens DMD WXGA (1280x800) White
URL - https://www.viewsonic.com/us/pa503w.html
Video - Analog signal format system - NTSC, PAL, SECAM
Video - Supported graphics resolutions - 640 x 480 (VGA), 1920 x 1080 (HD 1080)
Video - Supported video modes - 480i, 480p, 576i, 576p, 720p, 1080i, 1080p
WarrantyInfo - 3 years
Weight & dimensions - Depth - 218 mm
Weight & dimensions - Height - 110 mm
Weight & dimensions - Package depth - 300 mm
Weight & dimensions - Package height - 188 mm
Weight & dimensions - Package weight - 3.24 kg
Weight & dimensions - Package width - 365 mm
Weight & dimensions - Weight - 2.2 kg
Weight & dimensions - Width - 294 mm
