LG 86UH5N-M

AC input frequency Power - 50-60 Hz
AC input voltage Power - 100-240 V
Aspect ratio - 16:9
Audio - Built-in speaker(s) - Yes
Audio - RMS rated power - 20 W
Audio output Other features - 1
Automatic brightness control Performance - Yes
Batteries included Packaging content - Yes
Bezel width (bottom) Design - 1.34 cm
Bluetooth - Yes
Brand - LG
BrandPartCode - 86UH5N-M
Built-in speaker(s) Audio - Yes
Built-in speakers - Yes
Cables included Packaging content - AC, Phone
Category - Signage Displays
Category Code - LCD
Colour depth Display - 8 bit
Colour gamut Display - 95%
Computer system - Computer system - Yes
Computer system - Computer system type - System on Chip (SoC)
Computer system - Internal memory - 16 GB
Computer system - Operating system installed - WebOS
Computer system - Operating system version - 6.0
Computer system Computer system - Yes
Computer system type Computer system - System on Chip (SoC)
Connections - Digital Audio Out (Optical)
Connections - Ethernet (RJ-45)
Connections - HDMI
Connections - IR
Connections - RS-232C
Connections - USB-A (USB 2.0)
Contrast ratio (dynamic) Display - 1000000:1
Contrast ratio (typical) - 1200:1
Contrast ratio (typical) Display - 1200:1
Description - Large UHD Signage Display with Slim Design
Eye-catching Large Screen
A large screen effectively captures people's attention. Especially, 75-inch model supports 60Hz, enabling smooth content operation. Sturdy Design with Fire Flame Resistance
The outer cover of the product is designed to effectively resist fire flame spread, making the product a great fit for installation in public spaces. * Based on third party testing, the case top and back cover of the product are classified Class A1 (case top) and A2 (back cover) under EN13501-1, Class 1 under BS476 Part 7. Slim Depth with Even Bezel
Despite its large screen, UH5N-M boasts a slim depth, which is advantageous for interior design. To avoid visual issues when adjusting to portrait mode, the bezel maintains uniform thickness on all four sides, providing even symmetry on the top, bottom, left, and right. Therefore, it is a model suitable for various styling options. Versatile Operation with Multi-USB
With support for two USB ports, UH5N-M offers versatile usage options. For example, operating content on the screen while simultaneously using other connected devices is possible. This includes convenient tasks like downloading PPT files from external storage devices while using a mouse or keyboard during a meeting. High Resolution Display
It offers a resolution that is four times higher than FHD, satisfying customers visually. Additionally, the anti-glare coating on the screen reduces screen reflection in bright lighting environments, increasing visibility and legibility, providing customers with a comfortable screen. Convenient webOS Platform
The UH5N-M is equipped with a high-performance SoC that allows for multiple tasks to be performed without a separate media player. The webOS platform provides app development tools with an intuitive UI that enhances user convenience, enabling easy connection with external sensors and webOS partner apps to create an SI-friendly environment. Durability that Provides Reliability
Optimized for business environments, the UH5N-M is protected against rust and dust with conformal coating and IP5x certification, allowing for stable operation. Enhanced Security Features
The UH5N-M provides advanced security features, including LG's Enhanced Kernel Protection (EKP) technology, protecting important data from external access or attacks. LG UHD Signage also holds reliable certifications in the field of information security, maintaining customers' data and businesses securely. For example, this model is ISO/IEC 15408 Common Criteria EAL2 Certified. SuperSign Solutions
SuperSign is an integrated and intuitive content management solution for creative and organized digital signage content in your space, connecting customers to a range of services with convenient user experiences. There are a variety of versions such as SuperSign Cloud, so discover and enjoy the version that best fits you.Resolution : 3,840 × 2,160 (UHD)Brightness : 500 nits (Typ.)Surface Treatment (Haze) : 25%Bezel Width : 13.4 mm
Description - LG 86UH5N-M 86" UHD IPS 500 NITS 24/7 SOC WIFI HAZE
Design - Bezel width (bottom) - 1.34 cm
Design - Orientation - Horizontal
Design - Panel mounting interface - 600 x 400 mm
Design - Placement supported - Indoor
Design - Product colour - Black
Design - Product design - Digital signage flat panel
Design - VESA mounting - Yes
Dimensions W x D x H, mm - 1928.8 x 29.7 x 1099.8
Display - Colour depth - 8 bit
Display - Colour gamut - 95%
Display - Contrast ratio (dynamic) - 1000000:1
Display - Contrast ratio (typical) - 1200:1
Display - Display brightness - 500 cd/m²
Display - Display diagonal - 2.18 m (86")
Display - Display number of colours - 1.07 billion colours
Display - Display resolution - 3840 x 2160 pixels
Display - Display technology - LED
Display - Haze rate - 25%
Display - HD type - 4K Ultra HD
Display - LED backlight - Yes
Display - LED backlighting type - Edge-LED
Display - Native aspect ratio - 16:9
Display - Native refresh rate - 120 Hz
Display - Panel life - 50000 h
Display - Panel type - IPS
Display - Response time - 8 ms
Display - Touchscreen - No
Display - Viewing angle, horizontal - 178°
Display - Viewing angle, vertical - 178°
Display brightness, cd/m² - 500
Display brightness Display - 500 cd/m²
Display depth Weight & dimensions - 29.7 mm
Display diagonal, " - 86
Display diagonal Display - 2.18 m (86")
Display height Weight & dimensions - 1099.8 mm
Display number of colours Display - 1.07 billion colours
DisplayPorts quantity Ports & interfaces - 1
Display resolution, pixels - 3840 x 2160
Display resolution Display - 3840 x 2160 pixels
Display technology Display - LED
Display weight Weight & dimensions - 52.7 kg
Display width Weight & dimensions - 1928.8 mm
DVI port Ports & interfaces - No
Energy efficiency class - B
Ethernet LAN (RJ-45) ports Ports & interfaces - 1
Ethernet LAN Network - Yes
Features - Heat dissipation (max) - 1013 BTU/h
Green certifications - Energy Star
GTIN - 0195174097427
GTIN - 195174097427
GTIN - 8806096233740
Haze rate Display - 25%
HDCP Performance - Yes
HDCP version Performance - 1.4/2.2/2.3
HDMI input ports quantity Ports & interfaces - 3
HDMI ports quantity Ports & interfaces - 3
HD type Display - 4K Ultra HD
Heat dissipation (max) Features - 1013 BTU/h
Heat dissipation Power - 672 BTU/h
Height - 1240.000000
Internal memory Computer system - 16 GB
Internal player - Yes
International Protection (IP) code Performance - IP5X
IP classification - IP5X
LED backlight Display - Yes
LED backlighting type Display - Edge-LED
Length - 2100.000000
LongDesc - Large UHD Signage Display with Slim DesignEye-catching Large ScreenA large screen effectively captures people's attention. Especially, 75-inch model supports 60Hz, enabling smooth content operation.Sturdy Design with Fire Flame ResistanceThe outer cover of the product is designed to effectively resist fire flame spread, making the product a great fit for installation in public spaces.* Based on third party testing, the case top and back cover of the product are classified Class A1 (case top) and A2 (back cover) under EN13501-1, Class 1 under BS476 Part 7.Slim Depth with Even BezelDespite its large screen, UH5N-M boasts a slim depth, which is advantageous for interior design. To avoid visual issues when adjusting to portrait mode, the bezel maintains uniform thickness on all four sides, providing even symmetry on the top, bottom, left, and right. Therefore, it is a model suitable for various styling options.Versatile Operation with Multi-USBWith support for two USB ports, UH5N-M offers versatile usage options. For example, operating content on the screen while simultaneously using other connected devices is possible. This includes convenient tasks like downloading PPT files from external storage devices while using a mouse or keyboard during a meeting.High Resolution DisplayIt offers a resolution that is four times higher than FHD, satisfying customers visually. Additionally, the anti-glare coating on the screen reduces screen reflection in bright lighting environments, increasing visibility and legibility, providing customers with a comfortable screen.Convenient webOS PlatformThe UH5N-M is equipped with a high-performance SoC that allows for multiple tasks to be performed without a separate media player. The webOS platform provides app development tools with an intuitive UI that enhances user convenience, enabling easy connection with external sensors and webOS partner apps to create an SI-friendly environment.Durability that Provides ReliabilityOptimized for business environments, the UH5N-M is protected against rust and dust with conformal coating and IP5x certification, allowing for stable operation.Enhanced Security FeaturesThe UH5N-M provides advanced security features, including LG's Enhanced Kernel Protection (EKP) technology, protecting important data from external access or attacks. LG UHD Signage also holds reliable certifications in the field of information security, maintaining customers' data and businesses securely. For example, this model is ISO/IEC 15408 Common Criteria EAL2 Certified.SuperSign SolutionsSuperSign is an integrated and intuitive content management solution for creative and organized digital signage content in your space, connecting customers to a range of services with convenient user experiences. There are a variety of versions such as SuperSign Cloud, so discover and enjoy the version that best fits you.
LongProductName - 86", 4K UHD (3840 x 2160), IPS 500 nit, 8 ms, IP5X, Wi-Fi, webOS 6.0
LongSummaryDescription - LG 86UH5N-M. Product design: Digital signage flat panel. Display diagonal: 2.18 m (86"), Display technology: LED, Display resolution: 3840 x 2160 pixels, Display brightness: 500 cd/m², HD type: 4K Ultra HD. Wi-Fi. Operating hours (hours/days): 24/7. Operating system installed: WebOS. Product colour: Black
Manufacturer - LG Electronics
ManufacturerPartNumber - 86UH5N-M
Model name - 86UH5N-M
Native aspect ratio Display - 16:9
Native refresh rate Display - 120 Hz
Network - Ethernet LAN - Yes
Network - Wi-Fi - Yes
On Screen Display (OSD) Performance - Yes
Operating hours (hours/days) Performance - 24/7
Operating relative humidity (H-H) Operational conditions - 10 - 80%
Operating system installed Computer system - WebOS
Operating system provided - webOS 6.0
Operating system version Computer system - 6.0
Operating temperature (T-T) Operational conditions - 0 - 40 °C
Operating temperature range (T-T), °C - 0 - 40
Operational conditions - Operating relative humidity (H-H) - 10 - 80%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operation time - 24/7
Orientation Design - Horizontal
Other features - Audio output - 1
Other features - Plug and Play - Yes
Package depth Packaging data - 253 mm
Package height Packaging data - 1250 mm
Package weight Packaging data - 65.5 kg
Package width Packaging data - 2100 mm
Packaging content - Batteries included - Yes
Packaging content - Cables included - AC, Phone
Packaging content - Remote control included - Yes
Packaging data - Package depth - 253 mm
Packaging data - Package height - 1250 mm
Packaging data - Package weight - 65.5 kg
Packaging data - Package width - 2100 mm
Panel life Display - 50000 h
Panel mounting interface Design - 600 x 400 mm
Panel type - ADS
Panel type Display - IPS
Performance - Automatic brightness control - Yes
Performance - HDCP - Yes
Performance - HDCP version - 1.4/2.2/2.3
Performance - International Protection (IP) code - IP5X
Performance - On Screen Display (OSD) - Yes
Performance - Operating hours (hours/days) - 24/7
Performance - Purpose - Universal
PeriodofWarranty -
Pivot - Yes
Placement supported Design - Indoor
Plug and Play Other features - Yes
Ports & interfaces - DisplayPorts quantity - 1
Ports & interfaces - DVI port - No
Ports & interfaces - Ethernet LAN (RJ-45) ports - 1
Ports & interfaces - HDMI input ports quantity - 3
Ports & interfaces - HDMI ports quantity - 3
Ports & interfaces - Remote (IR) input - 1
Ports & interfaces - RS-232C - Yes
Ports & interfaces - USB connector type - USB Type-A
Ports & interfaces - USB port - Yes
Ports & interfaces - USB ports quantity - 2
Ports & interfaces - USB version - 2.0
Power - AC input frequency - 50-60 Hz
Power - AC input voltage - 100-240 V
Power - Heat dissipation - 672 BTU/h
Power - Power consumption (max) - 297 W
Power - Power consumption (standby) - 0.5 W
Power - Power consumption (typical) - 197 W
Power consumption (max) Power - 297 W
Power consumption (max.), W - 297
Power consumption (standby), W - 0.5
Power consumption (standby) Power - 0.5 W
Power consumption (typical) Power - 197 W
Power consumption, W - 205
Product colour Design - Black
Product design Design - Digital signage flat panel
ProductName - 86UH5N-M
Product name - Digital signage LFD
Purpose Performance - Universal
Real Time Clock (RTC) Technical details - Yes
Refresh rate, Hz - 120
Remote (IR) input Ports & interfaces - 1
Remote control included Packaging content - Yes
Response time, ms - 8
Response time Display - 8 ms
RMS rated power Audio - 20 W
RS-232C Ports & interfaces - Yes
ShortSummaryDescription - LG 86UH5N-M, Digital signage flat panel, 2.18 m (86"), LED, 3840 x 2160 pixels, Wi-Fi, 24/7
Speaker power, W - 2 x 10
Summary - LG 86UH5N-M. Product design: Digital signage flat panel. Display diagonal: 2.18 m (86"), Display technology: LED, Display resolution: 3840 x 2160 pixels, Display brightness: 500 cd/m², HD type: 4K Ultra HD. Wi-Fi. Operating hours (hours/days): 24/7. Operating system installed: WebOS. Product colour: Black
Technical details - Real Time Clock (RTC) - Yes
Title - LG 86UH5N-M Signage Display Digital signage flat panel 2.18 m (86") LED Wi-Fi 500 cd/m² 4K Ultra HD Black WebOS 24/7
Touchscreen Display - No
Touch sensitive screen - No
Unit Box Height - 0.245
Unit Box Length - 2.09
Unit Box Width - 2.15
Unit Calculated Volume - 1.1009075 cubm
Unit Calculated Weight - 72 kg
URL - https://www.lg.com/global/business/digital-signage/lg-86uh5n-m
USB connector type Ports & interfaces - USB Type-A
USB port Ports & interfaces - Yes
USB ports quantity Ports & interfaces - 2
USB version Ports & interfaces - 2.0
Vendor Homepage - https://www.lg.com/global/business/digital-signage/lg-86uh5n-m
VESA-standard, mm - 600 x 400
VESA mounting Design - Yes
Viewing angle, horizontal, ° - 178
Viewing angle, horizontal Display - 178°
Viewing angle, vertical, ° - 178
Viewing angle, vertical Display - 178°
Warranty - 36 months
WarrantyInfo -
Weight - 66.700000
Weight & dimensions - Display depth - 29.7 mm
Weight & dimensions - Display height - 1099.8 mm
Weight & dimensions - Display weight - 52.7 kg
Weight & dimensions - Display width - 1928.8 mm
Weight, kg - 53
Wi-Fi - Yes
Wi-Fi Network - Yes
Width - 250.000000
