Zebra DS3608 RUGG GR VIBR MOTOR USB CBA-U46-S07ZAR SHIELD USB CABLE

ARTIKEL1 - DS3608 RUGG GR VIBR MOTOR USB
ARTIKEL2 - CBA-U46-S07ZAR SHIELD USB CABLE
Brand - Zebra
BrandPartCode - DS3608-SR3U4600VZW
Category - Barcode Readers
EANCode -
Gewicht - 0.62
GRUPPE1 - POS
GRUPPE2 - Handheld Barcode
GTIN - 4016139084619
GTIN - 5711783197584
GTIN - 8596375044807
HERSTELLER - ZEBRA
HSTNUMMER - DS3608-SR3U4600VZW
Logistics data - Harmonized System (HS) code - 84716070
LongDesc - UNSTOPPABLE PERFORMANCE FOR STANDARD RANGE 1D/2D BARCODE CAPTUREAs a member of the Zebra 3600 Ultra-Rugged Series of scanners, the practically indestructible 1D/2D DS3608-SR corded and DS3678-SR cordless scanners are ready for the world’s toughest environments — the warehouse and manufacturing floor. Designed to capture virtually any barcode from near contact to as far as 5 ft./1.5 m away, these scanners are loaded with features that deliver truly unstoppable performance, redefining reliability and management simplicity. The result? The dependable, fast and accurate scanning you need to take the quality of your products and your customer service to the next level.SUPERIOR PERFORMANCEYou get the ultimate in scanning performance — period. Your workers can scan virtually any 1D or 2D electronic or printed barcode in any condition, as fast as they can pull the trigger. With 30 percent more working range, it’s easy to capture barcodes that are farther away. Even if barcodes are under shrinkwrap or damaged, dirty or poorly printed, no problem — this intelligent scanner can handle it all.ULTRA-RUGGED DESIGNThe manufacturing plant floor is as tough as its gets — and the cost of unplanned downtime on the production line is astronomical. That’s why we created a new product category — the ultra-rugged scanner. The corded and cordless models are the only scanners in this class that are dust-tight, sprayproof and waterproofed to IP67, with an IP65-sealed cradle for a complete rugged cordless solution. UNRIVALED MANAGEABILITYWith our complimentary industry-best tools, managing these scanners couldn’t be easier. You can remotely configure and upgrade your scanners, format data properly for instant transmission into your business applications, monitor battery statistics for your cordless models and more.
LongProductName - DS3608-SR, 1D/2D Imager, 610nm Led, 1280 x 800, One 660nm LED
LongSummaryDescription - Zebra DS3608-SR. Type: Handheld bar code reader, Scanner type: 1D/2D, Sensor type: LED. Connectivity technology: Wired, Standard interfaces: RS-232, USB, Keyboard wedge. Product colour: Black, Green, International Protection (IP) code: IP67, Protection features: Dust resistant, Shock resistant, Water resistant. Power source type: Battery, Battery technology: Lithium-Ion (Li-Ion), Battery capacity: 3100 mAh. Weight: 305 g, Width: 132 mm, Depth: 76 mm
Operational conditions - Operating relative humidity (H-H) - 5 - 95%
Operational conditions - Operating temperature (T-T) - -30 - 50 °C
Operational conditions - Storage temperature (T-T) - -40 - 70 °C
Performance - International Protection (IP) code - IP67
Performance - LED indicators - Yes
Performance - Product colour - Black, Green
Performance - Programming function - Yes
Performance - Protection features - Dust resistant, Shock resistant, Water resistant
Ports & interfaces - Connectivity technology - Wired
Ports & interfaces - Ethernet LAN - Yes
Ports & interfaces - Standard interfaces - RS-232, USB, Keyboard wedge
Power - Battery capacity - 3100 mAh
Power - Battery technology - Lithium-Ion (Li-Ion)
Power - Number of reads per charge - 100000
Power - Power source type - Battery
ProductName - DS3608-SR
Scanning - 2D (matrix & stacked) barcodes supported - Aztec Code, Composite Codes, Data Matrix, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code, TLC-39
Scanning - Linear (1D) barcodes supported - Codabar, Code 11, Code 128, Code 39, Code 93, GS1-128 (UCC/EAN-128), MSI, Plessey, U.P.C.
Scanning - Optical sensor resolution - 1280 pixels
Scanning - Pitch reading angle - -65 - 65°
Scanning - Scanner type - 1D/2D
Scanning - Sensor type - LED
Scanning - Tilt reading angle - -65 - 65°
Scanning - Type - Handheld bar code reader
Scanning - Wavelength - 610 nm
Scanning - Yaw reading angle - -45 - 45°
ShortSummaryDescription - Zebra DS3608-SR, Handheld bar code reader, 1D/2D, LED, Codabar, Code 11, Code 128, Code 39, Code 93, GS1-128 (UCC/EAN-128), MSI, Plessey, U.P.C., Aztec Code, Composite Codes, Data Matrix, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, PDF417,..., 610 nm
Stck_Kart - 8
Stck_Pal - 80
Storno - Y
Technical details - Compliance certificates - RoHS
Title - Zebra DS3608-SR Handheld bar code reader 1D/2D LED Black, Green
URL - https://www.zebra.com/us/en/products/scanners/ultra-rugged-scanners/3600-series/ds36x8-sr.html
WarrantyInfo - 3 year
Weight & dimensions - Depth - 76 mm
Weight & dimensions - Height - 185 mm
Weight & dimensions - Weight - 305 g
Weight & dimensions - Width - 132 mm
