TP-LINK LS1210GP 10-Port Gigabit Desktop Switch with 8-Port PoE+

10Base-T / 100Base-TX / 1000Base-T Ports - 9
Brand - TP-Link
BrandPartCode - LS1210GP
Category - Network Switches
Category Code - SWI
Certificates - Certification - CE, FCC, RoHS
Code - LS1210GP
Data transmission - Forwarding rate - 14.88 Mpps
Data transmission - Jumbo frames - 16000
Data transmission - MAC address table - 4000 entries
Data transmission - Store-and-forward - Yes
Data transmission - Switching capacity - 20 Gbit/s
Description - LS1210GP 10-Port Gigabit Desktop Switch with 8-Port PoE+ Full Gigabit Ports: 9× gigabit auto-negotiation RJ45 Ethernet ports and 1× gigabit SFP port provide up to 20 Gbps switching capacity. 61 W PoE Budget: Eight gigabit 802.3af/at-compliant PoE+ ports easily connect and power fixed devices like IP cameras, access points, and IP phones via a single cable. Up to 30 W PoE output is supported by each PoE port. Up to 250 m PoE Transmission: With Extend Mode, PoE transmission distance reaches up to 250m, perfect for surveillance camera deployment in large areas. PoE Auto Recovery: Automatically reboots your dropped or unresponsive PoE-powered devices. Traffic Separation for Higher Security: Isolation Mode allows one-click client traffic separation to avoid snooping and tampering, and isolate broadcast storm. Plug and Play: Simply plug and play for instant connectivity with no configuration required. Silent Operation: Fanless design reduces power consumption and ensures silent operation, ideal for noise-sensitive homes or businesses. Reliable Hardware Design: Durable metal casing and desktop/wall-mounting design are well-suited for different environments.
Design - LED indicators - Yes
Design - Product colour - Black
Design > Form factor - Desktop
dimensionalWeight - 1152
Dimensions - 209×126×26 mm
EAN - 4895252504569
Forwarding rate - 15 Mpps
GTIN - 4895252504576
IEEE 802.1p Network standard - Yes
IEEE 802.3af Network standard - Yes
IEEE 802.3at Network standard - Yes
IEEE 802.3x Network standard - Yes
Link - https://www.tp-link.com/ae/business-networking/litewave-switch/ls1210gp/
LongDesc - OverviewThe TP-Link LiteWave Series PoE Switches require no configuration and provide PoE (Power over Ethernet) ports. They can automatically detect and supply power with all IEEE 802.3af/at compliant Powered Devices (PDs). In this situation, the electrical power is transmitted along with data in one single cable allowing you to expand your network to where there are no power lines or outlets, where you wish to fix devices such as APs, IP Cameras or IP Phones, etc.
LongProductName - 9× 10/100/1000 Mbps RJ45, 1× Gigabit SFP Port, PoE+ 61W, 20 Gbps, 14.88 Mpps, 4K MAC, 16 KB Jumbo, 209x126x26 mm
LongSummaryDescription - TP-Link LiteWave 10-Port Gigabit Desktop Switch with 8-Port PoE+. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 9. MAC address table: 4000 entries, Switching capacity: 20 Gbit/s. Networking standards: IEEE 802.1p, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE.... DC input voltage: 53.5 V. Power over Ethernet (PoE)
Management features - Quality of Service (QoS) support - Yes
Management features - Switch type - Unmanaged
Management features > Switch type - Unmanaged
Model name - LS1210GP
Name - TP-LINK | 10-Port Gigabit Desktop Switch with 8-Port PoE+ | LS1210GP | Unmanaged | Desktop
Network - 10G support - No
Network - Auto-negotiation - Yes
Network - Auto MDI/MDI-X - Yes
Network - Cable types supported - Cat3
Network - Cable types supported - Cat3, Cat4, Cat5, Cat5e
Network - Cable types supported - Cat4
Network - Cable types supported - Cat5
Network - Cable types supported - Cat5e
Network - Flow control support - Yes
Network - Networking standards - IEEE 802.1p
Network - Networking standards - IEEE 802.1p, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Network - Networking standards - IEEE 802.3ab
Network - Networking standards - IEEE 802.3af
Network - Networking standards - IEEE 802.3at
Network - Networking standards - IEEE 802.3i
Network - Networking standards - IEEE 802.3u
Network - Networking standards - IEEE 802.3x
Network - Networking standards - IEEE 802.3z
Operational conditions - Heat dissipation - 261.66 BTU/h
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 90%
Operational conditions - Storage temperature (T-T) - -40 - 70 °C
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 315.00 mm
Package features > Gross height (mm) - 70.00 mm
Package features > Gross width (mm) - 240.00 mm
Package features > Packing quantity - 1.00 pc(s)
Package features > Palette Qty - 327 pc(s)
Package features > Paper/Pasteboard - 190.00 g
Package features > Plastic (No PET) - 10.00 g
Package features > Tare weight (kg) - 0.20 kg
Package features > Volume (m3) - 0.01 m³
Package features > WEE classification - CL109:5:2017-04-01
Package features > WEEE tax - Yes
Packaging content - User guide - Yes
Packaging data - Package type - Box
PoE+ ports - 8
Ports & interfaces - Basic switching RJ-45 Ethernet ports quantity - 9
Ports & interfaces - Basic switching RJ-45 Ethernet ports type - Gigabit Ethernet (10/100/1000)
Ports & interfaces - SFP module slots quantity - 1
Ports & interfaces > Predominant port type - 10/100/1000 Mbps (RJ-45)
Power - AC input frequency - 50 Hz
Power - AC input voltage - 220 V
Power - DC input voltage - 53.5 V
Power - Power consumption (max) - 76.96 W
Power - Power source - DC/PoE
Power - Power supply included - Yes
Power over Ethernet (PoE) - Power over Ethernet (PoE) - Yes
Power over Ethernet (PoE) - Power over Ethernet (PoE) ports quantity - 8
Power over Ethernet (PoE) - Power over Ethernet (PoE) power per port - 30 W
Power over Ethernet (PoE) - Total Power over Ethernet (PoE) budget - 61 W
Power over Ethernet (PoE) > Power over Ethernet (PoE) - Yes
Power supply - External
producerCode - LS1210GP
ProductName - 10-Port Gigabit Desktop Switch with 8-Port PoE+
productName - TP-Link LiteWave 10-Port Gigabit Desktop Switch with 8-Port PoE+
Product Net Weight - 1 kg
productSize - Normal
Safety warning - Warnings - Do not open the case or try to repair it yourself.
Safety warning - Warnings - Ensure the unit is adequately ventilated during operation.
Safety warning - Warnings - The product is not suitable for disposal in the regular waste bin. Take your used electronic equipment to a recycling centre in accordance with local regulations.
SFP Ports - 1
ShortSummaryDescription - TP-Link LiteWave 10-Port Gigabit Desktop Switch with 8-Port PoE+, Unmanaged, Gigabit Ethernet (10/100/1000), Power over Ethernet (PoE)
sizeX - 75
sizeY - 240
sizeZ - 320
Switching capacity - 20 Gbps
Technical details > Gross weight - 1.31 kg
Technical details > Net weight - 1.11 kg
Technical details > Producer - TP-LINK
Technical details > Producer product family - 10-Port Gigabit Desktop Switch with 8-Port PoE+
Technical details > Producer product name - LS1210GP
Title - TP-Link LiteWave 10-Port Gigabit Desktop Switch with 8-Port PoE+
Unit Box Height - 0.24
Unit Box Length - 0.32
Unit Box Width - 0.07
Unit Calculated Volume - 0 cubm
Unit Calculated Weight - 1 kg
Units per Shipping Box - 1
URL - https://www.tp-link.com/uk/business-networking/soho-switch-poe/ls1210gp/
Vendor Homepage - www.tp-link.com/ae/business-networking/litewave-switch/ls1210gp/
Warranty - 60
Warranty - 60 month(s)
Warranty - 60 months
WarrantyInfo -
warrantyLength - 60
warrantyType - G
weight - 1200
Weight & dimensions - Depth - 126 mm
Weight & dimensions - Height - 26 mm
Weight & dimensions - Width - 209 mm
