Angle of rotation Camera - 190°
ARTIKEL1 - AXIS M3216-LVE FIXED DOME
ARTIKEL2 - CAMERA WITH DLPU FORENSIC WDR LI
Breite - 0.2
Built-in HDD Storage - No
Camera shutter speed Camera - 1/50000 - 1/5 s
Card reader integrated Storage - Yes
Category Code - FNC
Closest focusing distance Lens system - 1 m
CnCode - 85258900
Compatible memory cards Storage - MicroSD (TransFlash), MicroSDHC, MicroSDXC
Connectivity technology Performance - Wired
Day/night mode Performance - Yes
Description - This cost-effective fixed focal dome offers Lightfinder, Forensic WDR, and OptimizedIR, and ensures excellent image quality under any light conditions. Built on ARTPEC-8, it includes a deep learning processing unit enabling powerful analytics based on deep learning on the edge. Plus, it delivers valuable metadata facilitating fast, easy, and efficient forensic search capabilities. And AXIS Object Analytics offers detection and classification of humans, vehicles, and types of vehicles—all tailored to your specific needs. Featuring audio and I/O connectivity, you can integrate for instance a microphone to extend the value of your system. Furthermore, built-in cybersecurity features safeguard your system.Analytics with deep learning; Audio and I/O connectivity; Built-in cybersecurity features; Excellent image quality in 4 MP; Lightfinder, Forensic WDR, OptimizedIR
Diameter Weight & dimensions - 14.9 cm
EANCode - 7331021076556
Ethernet interface type Network - Fast Ethernet
Ethernet LAN (RJ-45) ports Ports & interfaces - 1
Ethernet LAN Network - Yes
Fixed focal length Lens system - 2.9 mm
Flash memory Storage - 8192 MB
Fog proof Design - Yes
Form factor Design - Dome
Frame rate Video - 30 fps
Gewicht - 1.09
GRUPPE1 - Security
GRUPPE2 - Network Cameras
Height Weight & dimensions - 102 mm
HERSTELLER - AXIS
Hoehe - 0.15
Housing material Design - Plastic, Polycarbonate (PC)
HSTNUMMER - 02372-001
HTTPS encryption Security - Yes
IK code Design - IK10
Internal memory Storage - 1024 MB
International Protection (IP) code Design - IP66
Laenge - 0.21
LED type Night vision - IR
Lens viewing angle, horizontal Camera - 102°
Lens viewing angle, vertical Camera - 73°
Maximum resolution Video - 2688 x 1512 pixels
Microphone in Ports & interfaces - Yes
Minimum aperture number Lens system - 2
Minimum illumination Camera - 0.16 lx
Model - M3216-LVE
Mounting type Design - Ceiling/wall
Networking standards Network - IEEE 802.1x
Night vision Night vision - Yes
Number of cameras Packaging content - 1
Operating relative humidity (H-H) Operational conditions - 10 - 100%
Operating temperature (T-T) Operational conditions - -40 - 50 °C
Optical sensor size Image sensor - 25.4 / 2.7 mm (1 / 2.7")
Pan range Camera - 0 - 190°
Placement supported Performance - Indoor & outdoor
Power consumption (Power over Ethernet (PoE)) Power - 4.8 W
Power source type Power - PoE
Privacy masking Video - Yes
Product colour Design - White
Progressive scan Image sensor - Yes
PTZ control Performance - Yes
PTZ modes Performance - Digital PTZ
Security algorithms Security - EAP-TLS, HTTPS
Sensor type Image sensor - CMOS
Stck_Kart - 0
Stck_Pal - 0
Storage relative humidity (H-H) Operational conditions - 5 - 95%
Storage temperature (T-T) Operational conditions - -40 - 65 °C
Storno - Y
Summary - Axis M3216-LVE. Type: IP security camera, Placement supported: Indoor & outdoor, Connectivity technology: Wired. Mounting type: Ceiling/wall, Product colour: White, Form factor: Dome. Minimum illumination: 0.16 lx, Angle of rotation: 190°, Lens viewing angle, horizontal: 102°. Sensor type: CMOS, Optical sensor size: 25.4 / 2.7 mm (1 / 2.7"). Fixed focal length: 2.9 mm, Closest focusing distance: 1 m
Supported network protocols Network - IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPSa, HTTP/2, TLSa, QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP®, SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS, NTP, RTSP, RTCP, RTP, SRTP/RTSPS, TCP, UDP, IGMPv1/v2/v3, DHCPv4/v6, ARP, SOCKS,
Tilt angle range Camera - -10 - 80°
Type Performance - IP security camera
Unit Box Height - 0.14
Unit Box Length - 0.215
Unit Box Width - 0.2
Unit Calculated Volume - 0.00602 cubm
Unit Calculated Weight - 1.09 kg
Units per Shipping Box - 1
Vendor Homepage - https://www.axis.com/products/axis-m3216-lve
Video compression formats Video - H.264, H.265
Video streaming Video - Yes
Warranty - 60 months
Weight Weight & dimensions - 791 g
Wide Dynamic Range (WDR) Performance - Yes
Zoom capability Lens system - Yes
