TP-LINK C230, 1620p, 5MP, White

AC input frequency Power - 50/60 Hz
AC input voltage Power - 100-240 V
Audio - Audio formats supported - RTSP
Audio - Audio system - 2-way
Audio - Built-in microphone - Yes
Audio - Built-in speaker(s) - Yes
Audio formats supported Audio - RTSP
Audio system Audio - 2-way
Back Light Compensation (BLC) Video - Yes
Brand - TP-Link
BrandPartCode - TAPO C230
Built-in microphone Audio - Yes
Built-in siren Security - Yes
Built-in speaker(s) Audio - Yes
Cable length Weight & dimensions - 3 m
Camera - Camera pan control - Yes
Camera - Camera tilt control - Yes
Camera - Field of view (FOV) angle - 88°
Camera - Lens viewing angle, diagonal - 88°
Camera - Lens viewing angle, horizontal - 75°
Camera - Lens viewing angle, vertical - 41°
Camera - Pan range - 0 - 340°
Camera - Tilt angle range - 0 - 69°
Camera pan control Camera - Yes
Camera tilt control Camera - Yes
Card reader integrated Storage - Yes
Category - Security Cameras
Category Code - NCI
Cloud-managed Management features - Yes
Compatible memory cards Storage - MicroSD (TransFlash)
Connectivity technology Performance - Wireless
DC output current Power - 0.6 A
DC output voltage Power - 9
Depth Weight & dimensions - 86.8 mm
Description - Smart. Secure. Easy.
Always Know What Matters Most to You.
Pan/Tilt AI Home Security Wi-Fi Camera Razor-Sharp 3K 5MP View
Record all of life's wonderful moments with the realistic 3K 5MP. Zoom to see the sharp views. Smart AI Detection and Notification
Smart AI identifies people, pets, and vehicles while recognizing a baby crying and other sounds, notifying users as needed. Motion Detection and Notifications
Customizable Your Activity Zones to Know What Matters Control what alerts you receive by creating multiple custom activity zones around areas that matter. Pan/Tilt View
Get detailed look at your room
A wide range of coverage to capture every moment. Precise Smart Motion Tracking
Always Know What Matters Most to You
When motion activity is detected, tracks and follows the subject to keep it within view. Flexible Storage Choices
Save recorded videos on the microSD Card†(up to 512 GB) or by using Tapo Care‡ cloud storage services. Two-Way Audio
Use crisp two-way audio to communicate with nosy roommates, family, or even mischievous pets. Protect Your Privacy from the Very Beginning
Set customizable block zones to keep certain spaces from being recorded so you never need to worry about personal moments being leaked. Filter out any personal spaces, like your bed, and only record areas that require monitoring such as doorways and windows to ensure your privacy remains just that—private. Tapo Sharing
Funny Clips
To share funny records with your families or guests.High-Quality Video Recording: Capture every detail with exceptional clarity in 3K 5MP resolutionWide Range of Movement: Enjoy a full 360º horizontal and 114º vertical range for pan and tilt, allowing you to cover more areaEnhanced Night Vision: See clearly even in low-light conditions with advanced night vision that provides visibility up to 40 ftSmart AI Detection and Notifications: Benefit from smart AI technology that detects relevant events and sends you instant notificationsSound and Light Alarm: Scare away unwanted visitors using a sound and light alarm that triggers attention-grabbing effectsTwo-Way Audio: Enables communication through a built-in microphone and speakerSafe Storage: Store footage directly on a microSD card with a capacity of up to 512 GB, ensuring safe and convenient storage.(microSD card purchased separately.)Hands-Free Operation: Control the device using your voice with compatibility for Google Assistant and Amazon Alexa, freeing up your hands for other tasks. (Availability of Google Assistant and Amazon Alexa may vary based on language and country)
Design - Form factor - Bulb
Design - Mounting type - Ceiling/Desk
Design - Product colour - White
dimensionalWeight - 668
Field of view (FOV) angle Camera - 88°
Focal length range Lens system - 4 mm
Form factor Design - Bulb
Frame rate Video - 30 fps
GTIN - 1210002606509
GTIN - 8885021371658
Height Weight & dimensions - 117.7 mm
Image quality adjustment Video - DNR
Image sensor - Number of sensors - 1
Image sensor - Optical sensor size - 25.4 / 3 mm (1 / 3")
Image sensor - Progressive scan - Yes
Image sensor - Sensor type - CMOS
Infra-red wavelength Night vision - 850 nm
Intelligent Video Surveillance (IVS) system features Security - Human detection, Line crossing detection, Pet detection, Vehicle detection
LED type Night vision - IR
Lens system - Focal length range - 4 mm
Lens system - Maximum aperture number - 2
Lens system - Minimum aperture number - 2
Lens system - Number of lenses - 1
Lens system - Zoom capability - No
Lens viewing angle, diagonal Camera - 88°
Lens viewing angle, horizontal Camera - 75°
Lens viewing angle, vertical Camera - 41°
Live view Network - Yes
LongDesc - Smart. Secure. Easy.Always Know What Matters Most to You.Pan/Tilt AI Home Security Wi-Fi CameraRazor-Sharp 3K 5MP ViewRecord all of life's wonderful moments with the realistic 3K 5MP. Zoom to see the sharp views.Smart AI Detection and NotificationSmart AI identifies people, pets, and vehicles while recognizing a baby crying and other sounds, notifying users as needed.Motion Detection and NotificationsCustomizable Your Activity Zones to Know What MattersControl what alerts you receive by creating multiple custom activity zones around areas that matter. Pan/Tilt ViewGet detailed look at your roomA wide range of coverage to capture every moment.Precise Smart Motion TrackingAlways Know What Matters Most to YouWhen motion activity is detected, tracks and follows the subject to keep it within view. Flexible Storage ChoicesSave recorded videos on the microSD Card†(up to 512 GB) or by using Tapo Care‡ cloud storage services. Two-Way AudioUse crisp two-way audio to communicate with nosy roommates, family, or even mischievous pets.Protect Your Privacy from the Very BeginningSet customizable block zones to keep certain spaces from being recorded so you never need to worry about personal moments being leaked.Filter out any personal spaces, like your bed, and only record areas that require monitoring such as doorways and windows to ensure your privacy remains just that—private. Tapo SharingFunny ClipsTo share funny records with your families or guests.
LongProductName - Pan/Tilt AI Home Security Wi-Fi Camera SPEC: 3K 5MP (2880×1620), 2.4 GHz, Horizontal 360º
LongSummaryDescription - TP-Link Tapo Pan/Tilt AI Home Security Wi-Fi Camera SPEC: 3K 5MP (2880×1620), 2.4 GHz, Horizontal 360º. Type: IP security camera, Placement supported: Indoor, Connectivity technology: Wireless. Mounting type: Ceiling/Desk, Product colour: White, Form factor: Bulb. Field of view (FOV) angle: 88°, Lens viewing angle, horizontal: 75°, Lens viewing angle, vertical: 41°. Sensor type: CMOS, Optical sensor size: 25.4 / 3 mm (1 / 3"). Focal length range: 4 mm
Management features - Cloud-managed - Yes
Management features - Reset button - Yes
Maximum aperture number Lens system - 2
Maximum memory card size Storage - 512 GB
Maximum resolution Video - 2880 x 1620 pixels
Minimum aperture number Lens system - 2
Model name - Tapo C230
Mounting type Design - Ceiling/Desk
Network - Live view - Yes
Network - Networking standards - IEEE 802.11b
Network - Networking standards - IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Network - Networking standards - IEEE 802.11g
Network - Networking standards - IEEE 802.11n
Network - Supported network protocols - TCP/IP, DHCP, ICMP, DNS, NTP, HTTPS, TCP, UDP
Network - Wi-Fi - Yes
Network - Wi-Fi standards - 802.11b
Network - Wi-Fi standards - 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Network - Wi-Fi standards - 802.11g
Network - Wi-Fi standards - Wi-Fi 4 (802.11n)
Networking standards Network - IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Night vision - Infra-red wavelength - 850 nm
Night vision - LED type - IR
Night vision - Night vision - Yes
Night vision - Night vision distance - 12 m
Night vision distance Night vision - 12 m
Night vision Night vision - Yes
Noise reduction Video - Yes
Number of cameras Packaging content - 1
Number of lenses Lens system - 1
Number of sensors Image sensor - 1
Operating relative humidity (H-H) Operational conditions - 5 - 90%
Operating temperature (T-T) Operational conditions - 0 - 40 °C
Operational conditions - Operating relative humidity (H-H) - 5 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 10 - 90%
Operational conditions - Storage temperature (T-T) - -20 - 60 °C
Optical sensor size Image sensor - 25.4 / 3 mm (1 / 3")
Package depth Packaging data - 190 mm
Package height Packaging data - 110 mm
Package type Packaging data - Box
Package weight Packaging data - 430 g
Package width Packaging data - 160 mm
Packaging content - Number of cameras - 1
Packaging content - Packaging content - Tapo C230 Camera
Power Adapter
Quick Start Guide
Mounting Anchors
Mounting Screws
Mounting Template
Camera Base
Packaging content Packaging content - Tapo C230 Camera
Power Adapter
Quick Start Guide
Mounting Anchors
Mounting Screws
Mounting Template
Camera Base
Packaging data - Package depth - 190 mm
Packaging data - Package height - 110 mm
Packaging data - Package type - Box
Packaging data - Package weight - 430 g
Packaging data - Package width - 160 mm
Pan range Camera - 0 - 340°
Performance - Connectivity technology - Wireless
Performance - Placement supported - Indoor
Performance - Type - IP security camera
Performance - Virtual assistant - Amazon Alexa & Google Assistant
Placement supported Performance - Indoor
Power - AC input frequency - 50/60 Hz
Power - AC input voltage - 100-240 V
Power - DC output current - 0.6 A
Power - DC output voltage - 9
Power - Power consumption (max) - 5.7 W
Power - Power consumption (typical) - 3 W
Power - Power source type - AC, DC
Power consumption (max) Power - 5.7 W
Power consumption (typical) Power - 3 W
Power source type Power - AC, DC
producerCode - Tapo C230
Product colour Design - White
ProductName - Pan/Tilt AI Home Security Wi-Fi Camera SPEC: 3K 5MP (2880×1620), 2.4 GHz, Horizontal 360º
productName - TP-Link Tapo Pan/Tilt AI Home Security Wi-Fi Camera SPEC: 3K 5MP (2880×1620), 2.4 GHz, Horizontal 360º
productSize - Normal
Progressive scan Image sensor - Yes
Reset button Management features - Yes
Security - Built-in siren - Yes
Security - Intelligent Video Surveillance (IVS) system features - Human detection
Security - Intelligent Video Surveillance (IVS) system features - Human detection, Line crossing detection, Pet detection, Vehicle detection
Security - Intelligent Video Surveillance (IVS) system features - Line crossing detection
Security - Intelligent Video Surveillance (IVS) system features - Pet detection
Security - Intelligent Video Surveillance (IVS) system features - Vehicle detection
Security - Security algorithms - 128-bit AES
Security - Security algorithms - 128-bit AES, SSL/TLS, WPA, WPA2-PSK
Security - Security algorithms - SSL/TLS
Security - Security algorithms - WPA
Security - Security algorithms - WPA2-PSK
Security - Siren noise level - 99 dB
Security - Video motion detection - Yes
Security algorithms Security - 128-bit AES, SSL/TLS, WPA, WPA2-PSK
Sensor type Image sensor - CMOS
ShortSummaryDescription - TP-Link Tapo Pan/Tilt AI Home Security Wi-Fi Camera SPEC: 3K 5MP (2880×1620), 2.4 GHz, Horizontal 360º, IP security camera, Indoor, Wireless, Amazon Alexa & Google Assistant, Ceiling/Desk, White
Siren noise level Security - 99 dB
sizeX - 190
sizeY - 160
sizeZ - 110
Storage - Card reader integrated - Yes
Storage - Compatible memory cards - MicroSD (TransFlash)
Storage - Maximum memory card size - 512 GB
Storage relative humidity (H-H) Operational conditions - 10 - 90%
Storage temperature (T-T) Operational conditions - -20 - 60 °C
Summary - TP-Link Tapo Pan/Tilt AI Home Security Wi-Fi Camera SPEC: 3K 5MP (2880×1620), 2.4 GHz, Horizontal 360º. Type: IP security camera, Placement supported: Indoor, Connectivity technology: Wireless. Mounting type: Ceiling/Desk, Product colour: White, Form factor: Bulb. Field of view (FOV) angle: 88°, Lens viewing angle, horizontal: 75°, Lens viewing angle, vertical: 41°. Sensor type: CMOS, Optical sensor size: 25.4 / 3 mm (1 / 3"). Focal length range: 4 mm
Supported graphics resolutions Video - 2880 x 1620
Supported network protocols Network - TCP/IP, DHCP, ICMP, DNS, NTP, HTTPS, TCP, UDP
Supported video modes Video - 1620p
Tilt angle range Camera - 0 - 69°
Title - TP-Link Tapo Pan/Tilt AI Home Security Wi-Fi Camera SPEC: 3K 5MP (2880×1620), 2.4 GHz, Horizontal 360º
Total megapixels Video - 5 MP
Type Performance - IP security camera
Unit Box Height - 0.11
Unit Box Length - 0.185
Unit Box Width - 0.16
Unit Calculated Volume - 0.003256 cubm
Unit Calculated Weight - 0.458 kg
Units per Shipping Box - 1
URL - https://www.tp-link.com/us/home-networking/cloud-camera/tapo-c230/#overview
Vendor Homepage - https://www.tp-link.com/us/home-networking/cloud-camera/tapo-c230/#overview
Video - Back Light Compensation (BLC) - Yes
Video - Frame rate - 30 fps
Video - Image quality adjustment - DNR
Video - Maximum resolution - 2880 x 1620 pixels
Video - Noise reduction - Yes
Video - Supported graphics resolutions - 2880 x 1620
Video - Supported video modes - 1620p
Video - Total megapixels - 5 MP
Video - Video formats supported - H.264
Video formats supported Video - H.264
Video motion detection Security - Yes
Virtual assistant Performance - Amazon Alexa & Google Assistant
Warranty - 24 months
WarrantyInfo - 2 Years
warrantyLength - 24
warrantyType - G
weight - 460
Weight & dimensions - Cable length - 3 m
Weight & dimensions - Depth - 86.8 mm
Weight & dimensions - Height - 117.7 mm
Weight & dimensions - Weight - 190 g
Weight & dimensions - Width - 85.4 mm
Weight Weight & dimensions - 190 g
Wi-Fi Network - Yes
Wi-Fi standards Network - 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Width Weight & dimensions - 85.4 mm
Zoom capability Lens system - No
