TP-LINK VIGI C340S(4mm), 1520p, 4MP, White

Accessories included - Quick installation guide Cable sealing elements Mounting accessories
ARTIKEL1 - VIGI 4MP OUTDOOR BULLET CAMERA
ARTIKEL2 - COLORPRO NIGHT VISION
Audio - Bit rate range - 64 - 64 Kbit/s
Audio - Built-in microphone - Yes
Audio - Built-in speaker(s) - Yes
Audio - Sample rate - 8 kHz
Audio - Signal-to-Noise Ratio (SNR) - 52 dB
Bit rate range Audio - 64 - 64 Kbit/s
Bit rate Video - 4 Mbps
Brand - TP-Link
BrandPartCode - VIGI-C340S-4MM
Built-in microphone Audio - Yes
Built-in speaker(s) Audio - Yes
Camera - Camera shutter speed - 1/10000 s
Camera - Lens viewing angle, diagonal - 114.7°
Camera - Lens viewing angle, horizontal - 95.2°
Camera - Lens viewing angle, vertical - 50.6°
Camera - Minimum illumination - 0.0005 lx
Camera - Number of Privacy masking areas - 4
Camera - Pan range - -90 - 90°
Camera - Tilt angle range - -90 - 90°
Camera shutter speed Camera - 1/10000 s
Category - Security Cameras
Category Code - FNC
Certificates - CE, NTRA, VCCI, KC, BSMI, FCC, IC
Color - White
Connectivity technology Performance - Wired
Connectors - microSD
Connectors - RJ-45
Day/night mode Performance - Yes
DC output voltage Power - 12
Depth Weight & dimensions - 236 mm
Description - VIGI 4MP Bullet Outdoor Network Camera with ColorPro Night Vision Color Night Vision in Low Light Conditions: Capture 24/7 images in 4MP resolution and full color, even in very low light conditions, without the use of additional lighting. Facial Recognition: Effectively improves access management and attendance control while protecting privacy.§. People and Vehicles Analysis: Quickly find the people and vehicles you are interested in using numerous attribute filters to increase search efficiency. People and Vehicle Classification: Distinguishing people and vehicles from other objects allows you to receive more accurate event notifications. Smart Detection: Actively detects unexpected events, such as intrusion and crossing lines, and sends instant notifications. True WDR: Crystal clear image in high contrast scenes. Active Protection: Instantly warn potential intruders with sound and light when detecting unexpected events. Two-way audio transmission: Voice intercom support enables two-way communication while viewing the camera stream. H.265+: Compresses video size without loss of quality, reduces network load and saves disk space. IP67 tightness class: Reliable operation in outdoor conditions thanks to the tight housing. Flexible management and storage: Take full control of your security with four management methods: Web interface, NVR interface, VIGI application and VIGI Security Manager. Local storage is available for each of these methods, as well as on the microSD card inserted into the camera (up to 256GB). VIGI ColorPro night vision VIGI ColorPro's industry-leading Night Vision technology enables cameras to overcome the darkness at night and see everything in precise detail. Thanks to this solution, the VIGI C340S camera can offer high-resolution 4MP images and vivid colors, even in very low light conditions. Better than human vision Thanks to its high light sensitivity, VIGI ColorPro Night Vision captures unparalleled colors, along with extremely sharp details, even in low light conditions, which is unattainable for natural human vision. Over Infrared and Full Color Images recorded by infrared (IR) cameras and regular full-color cameras will lose quality due to noise and fewer details. VIGI cameras with ColorPro Night Vision are able to capture excellent image details, even in conditions of extreme darkness. Less light pollution Bright lighting is required for regular full color cameras to be able to capture images when it is dark. VIGI cameras with ColorPro Night Vision deliver true colors and bright images, even in very low light conditions. By eliminating the need to use floodlights, VIGI ColorPro cameras significantly reduce light pollution in the environment. Classification of people and vehicles Integrated AI systems support advanced algorithms that distinguish people and vehicles from other objects. You can flexibly adapt alarm rules to suit your monitoring needs and receive more accurate event notifications. Smart AI detection is the basis for efficient monitoring By setting detection rules in advanced AI-powered VIGI cameras, you can accurately detect many unexpected events. This helps significantly reduce false alarms and meet your monitoring needs in a variety of applications. Face recognition Built-in facial recognition algorithms enable the VIGI camera to intelligently capture faces, extract facial features and create unique facial data. Comparing face data with the face library and quickly matching it significantly reduces the risk of unauthorized access. Run your business with peace of mind The professional VIGI monitoring system from TP-Link will enable you to protect your company regardless of the place and time. Unique functions, trustworthy quality, simple installation and convenient management are a combination that will ensure the security of your company.
Description - VIGI ColorPro Night Vision
VIGI’s industry-leading ColorPro Night Vision technology enables its cameras to pierce the night and see everything in fine detail.
By adopting this best-in-class technology, VIGI C340S can provide 4MP high resolution and capture more vivid full-color images
in extreme low-light conditions. Better than the Naked Eye
Featuring high low-light sensitivity, VIGI’s ColorPro Night Vision produces unparalleled colors along with amazingly crisp images in
ultra-low light conditions, which can’t be achieved with natural eyesight. Beyond IR, Beyond Full-Color
Images captured by IR cameras or traditional full-color cameras will suffer from digital noise and the loss of detail. VIGI’s ColorPro Night
Vision cameras reveal excellent image details even in extreme darkness. Less Light Pollution
Bright illumination is required by conventional full-color cameras to capture images at pitch-dark hours. But VIGI's ColorPro Night Vision cameras
delivers true color and bright imaging even in extremely low light with no spotlights needed, greatly reducing environmental light pollution. Human & Vehicle Classification
Integrated AI chips support advanced algorithms to distinguish humans and vehicles from other objects. You can flexibly customize alarm rules to match your monitoring needs and receive more accurate event notifications. Comprehensive AI Detection with Pre-Set Rules Supported
By setting the detection rules in advance, VIGI AI-powered cameras can accurately capture various abnormal events. This will greatly reduce false alarms and cover your specified monitoring needs in different scenarios. Face Recognition
VIGI’s advanced built-in face recognition algorithm enables cameras to intelligently capture faces, extract facial features, and form unique facial data. By comparing the facial data with a face library, quickly match a human face, efficiently reducing the risk of unauthorized access. People & Vehicle Analytics
Quickly find people and vehicles of interest using a series of attributes. People Analytics
Filter people of interest by various attributes, such as gender, hair length, and clothing, allowing you to improve search efficiency. Vehicle Analytics
Identify and search for vehicles of interest based on vehicle color and type for targeting meaningful events in a short time. Active Defense
Warn potential intruders instantly with sound and light when abnormal events are detected. Two-Way Audio
With voice intercom support, carry two-way conversations while watching your feed from anywhere. PoE & IP67
Outdoor PoE connection makes your wiring remarkably easy. Reliable IP67 enables stable outdoor performance. One system. Full security.
Run your business with peace of mind.
The VIGI professional surveillance system by TP-Link is dedicated to protecting the business you’ve worked hard to build — whenever, wherever. Our outstanding functions, reliable quality guarantees, and simplified installation work together to ensure your business stays safe and sound.Ultra-Low Light Color Night Vision: Capture 24-hour 4MP high-quality and colorful video even in ultra low-light conditions without any supplemental lightsFace Recognition: Efficiently enhances access management and attendance control while better protecting privacy§People & Vehicle Analytics: Quickly find people and vehicles of interest using a series of attributes, allowing you to improve search efficiency§Human & Vehicle Classification: Distinguishes humans and vehicles from other objects, so you receive more accurate event notificationsSmart Detection: Actively detects abnormal events like area intrusion and line-crossing, sending notifications to you instantly120dB WDR Technology: Enable crystal-clear images in high contrast scenesActive Defense: Warn potential intruders instantly with sound and light when abnormal eventsTwo-Way Audio: With voice intercom support, carry two-way conversations while watching your feed from anywhereH.265+: Compresses the video size without sacrificing video quality, easing the network load and saving disk spaceIP67 Waterproof: Reliable IP67 for stable outdoor performanceFlexible Management and Storage: Take full control over your security via four management methods: the web UI, NVR UI, VIGI app, and VIGI Security Manager. Local storage is available for each method, as well as onboard storage with SD card slot (up to 256GB)
Design - Form factor - Bullet
Design - Housing material - Metal, Plastic
Design - International Protection (IP) code - IP67
Design - Mounting type - Wall
Design - Product colour - White
Designation - CE+WEEE
Detect distance Lens system - 70 m
Digest authentication Security - Yes
dimension depth - 145 mm
dimension height - 135 mm
Dimensions - 102 × 236 × 99 mm
dimension weight - 957 g
dimension width - 290 mm
Dynamic range Performance - 120 dB
ean - 4895252500790
EANCode - 4895252500790
Environment requirements - Permissible operating temperature: -30-60 degrees Celsius Permissible storage temperature: -40-60 degrees Celsius Permissible air humidity: 95% or less (non-condensing) Allowable storage humidity: 95% or less (non-condensing)
Ethernet interface type Network - Fast Ethernet
Ethernet LAN (RJ-45) ports Ports & interfaces - 1
Ethernet LAN Network - Yes
Fixed focal length Lens system - 4 mm
Focal length range Lens system - 4 mm
Form factor Design - Bullet
Frame rate Video - 60 fps
Frames per second - 30
GRUPPE1 - Network
GRUPPE2 - Network Camera
GTIN - 4895252500790
guarantee - 36
guarantee_type - normal
Height Weight & dimensions - 99 mm
HERSTELLER - TP-LINK
Housing material Design - Metal/Plastic
HSTNUMMER - VIGI C340S(4MM)
Identify distance Lens system - 7 m
Image sensor - Optical sensor size - 25.4 / 1.8 mm (1 / 1.8")
Image sensor - Progressive scan - Yes
Image sensor - Sensor type - CMOS
Internal memory - 0 KB
International Protection (IP) code Design - IP67
IP address filtering Security - Yes
LED type Night vision - White
Lens - Type: Fixed focal length lens Focal length: 4 mm Aperture: F1.0
Lens system - Detect distance - 70 m
Lens system - Fixed focal length - 4 mm
Lens system - Focal length range - 4 mm
Lens system - Identify distance - 7 m
Lens system - Maximum aperture number - 1
Lens system - Minimum aperture number - 1
Lens system - Number of lenses - 1
Lens system - Observe distance - 29 m
Lens system - Recognize distance - 14 m
Lens viewing angle, diagonal Camera - 114.7 °
Lens viewing angle, horizontal Camera - 95.2 °
Lens viewing angle, vertical Camera - 50.6 °
LongDesc - VIGI ColorPro Night VisionVIGI’s industry-leading ColorPro Night Vision technology enables its cameras to pierce the night and see everything in fine detail.By adopting this best-in-class technology, VIGI C340S can provide 4MP high resolution and capture more vivid full-color imagesin extreme low-light conditions.Better than the Naked EyeFeaturing high low-light sensitivity, VIGI’s ColorPro Night Vision produces unparalleled colors along with amazingly crisp images inultra-low light conditions, which can’t be achieved with natural eyesight.Beyond IR, Beyond Full-ColorImages captured by IR cameras or traditional full-color cameras will suffer from digital noise and the loss of detail. VIGI’s ColorPro NightVision cameras reveal excellent image details even in extreme darkness.Less Light PollutionBright illumination is required by conventional full-color cameras to capture images at pitch-dark hours. But VIGI's ColorPro Night Vision camerasdelivers true color and bright imaging even in extremely low light with no spotlights needed, greatly reducing environmental light pollution.Human & Vehicle ClassificationIntegrated AI chips support advanced algorithms to distinguish humans and vehicles from other objects. You can flexibly customize alarm rules to match your monitoring needs and receive more accurate event notifications.Comprehensive AI Detection with Pre-Set Rules SupportedBy setting the detection rules in advance, VIGI AI-powered cameras can accurately capture various abnormal events. This will greatly reduce false alarms and cover your specified monitoring needs in different scenarios.Face RecognitionVIGI’s advanced built-in face recognition algorithm enables cameras to intelligently capture faces, extract facial features, and form unique facial data. By comparing the facial data with a face library, quickly match a human face, efficiently reducing the risk of unauthorized access.People & Vehicle AnalyticsQuickly find people and vehicles of interest using a series of attributes.People AnalyticsFilter people of interest by various attributes, such as gender, hair length, and clothing, allowing you to improve search efficiency.Vehicle AnalyticsIdentify and search for vehicles of interest based on vehicle color and type for targeting meaningful events in a short time.Active DefenseWarn potential intruders instantly with sound and light when abnormal events are detected.Two-Way AudioWith voice intercom support, carry two-way conversations while watching your feed from anywhere.PoE & IP67Outdoor PoE connection makes your wiring remarkably easy. Reliable IP67 enables stable outdoor performance. One system. Full security.Run your business with peace of mind.The VIGI professional surveillance system by TP-Link is dedicated to protecting the business you’ve worked hard to build — whenever, wherever. Our outstanding functions, reliable quality guarantees, and simplified installation work together to ensure your business stays safe and sound.
LongProductName - CMOS, 4mm. M12, 120dB, IP67, 1/1.8"
LongSummaryDescription - TP-Link VIGI C340S. Type: IP security camera, Placement supported: Outdoor, Connectivity technology: Wired. Mounting type: Wall, Product colour: White, Form factor: Bullet. Minimum illumination: 0.0005 lx, Lens viewing angle, horizontal: 95.2°, Lens viewing angle, vertical: 50.6°. Sensor type: CMOS, Optical sensor size: 25.4 / 1.8 mm (1 / 1.8"). Detect distance: 70 m, Observe distance: 29 m, Recognize distance: 14 m
Luminous flux Performance - 0.0005 lm
Management, monitoring, configuration - Smart Events Classification of people and vehicles Intrusion detection Line crossing detection People detection Vehicle detection Zone entry detection Zone exit detection Object abandonment detection Object deletion detection Vagrant detection Scene change detection Basic events Motion detection Video manipulation detection Exception (failed login) Scene change detection Alarm call Video recording to memory card Push notifications Audible warning Flashing white light Outgoing notification Push notification
Maximum aperture number Lens system - 1
Maximum resolution Video - 2688 x 1520 pixels
Memory card reader - No
Memory standard - Not applicable
Microphone - Yes
Minimum aperture number Lens system - 1
Minimum illumination Camera - 0.0005 lx
Motion detection - Yes
Mounting type Design - Wall
name - Camera VIGI C340S(4mm) 4MP Outdoor Night Bullet
Network - Ethernet interface type - Fast Ethernet
Network - Ethernet LAN - Yes
Network - Supported network protocols - TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS
Network protocols -
Night mode - Yes
Night vision - LED type - White
Night vision - Night vision - Yes
Night vision - Night vision distance - 30 m
Night vision - Number of illumination LEDs - 4
Night vision distance Night vision - 30 m
Night vision Night vision - Yes
Noise reduction technology Video - 3D noise reduction
Noise reduction Video - Yes
Number of cameras Packaging content - 1
Number of illumination LEDs Night vision - 4
Number of lenses Lens system - 1
Number of Privacy masking areas Camera - 4
Observe distance Lens system - 29 m
Operating relative humidity (H-H) Operational conditions - 0 - 95 %
Operating temperature (T-T) Operational conditions - -30 - 60 °C
Operational conditions - Operating relative humidity (H-H) - 0 - 95%
Operational conditions - Operating temperature (T-T) - -30 - 60 °C
Operational conditions - Storage relative humidity (H-H) - 0 - 95%
Operational conditions - Storage temperature (T-T) - -40 - 60 °C
Optical sensor size Image sensor - 1/1.8 "
Other features -
Packaging content - Number of cameras - 1
Pan range Camera - -90 - 90 °
Password protection Security - Yes
Performance - Connectivity technology - Wired
Performance - Day/night mode - Yes
Performance - Dynamic range - 120 dB
Performance - Luminous flux - 0.0005 lm
Performance - Placement supported - Outdoor
Performance - Type - IP security camera
Performance - Wide Dynamic Range (WDR) - Yes
Placement supported Performance - Outdoor
Ports & interfaces - Ethernet LAN (RJ-45) ports - 1
Power - DC output voltage - 12
Power - Power consumption (max) - 10.1 W
Power - Power source type - DC
Power consumption (max) Power - 10.1 W
Power source type Power - DC
Power supply - 12V DC +/- 5%, Max 10.1W, 5.5mm Coaxial Power Plug PoE: 802.3af/at, class 0, Max. 11.5 W
Privacy masking Video - Yes
Privacy protection Security - Yes
producer - TP-LINK
Product colour Design - White
ProductName - VIGI C340S
Progressive scan Image sensor - Yes
Protection class - IP67
Recognize distance Lens system - 14 m
Region of Interest (ROI) encoding Video - Yes
Resolution - 2688 x 1520
Sample rate Audio - 8 kHz
Security - Transmission security: Password protection, HTTPS encryption, IP address filter, Digest authentication
Security - Digest authentication - Yes
Security - IP address filtering - Yes
Security - Password protection - Yes
Security - Privacy protection - Yes
Sensor - 1/1.8 Progressive Scan CMOS
Sensor type Image sensor - CMOS
ShortSummaryDescription - TP-Link VIGI C340S, IP security camera, Outdoor, Wired, 0.0005 lm, 120 dB, Wall
Signal-to-Noise Ratio (SNR) Audio - 52 dB
Speakers built-in - Yes
Special functions -
Stck_Kart - 1
Stck_Pal - 0
Storage relative humidity (H-H) Operational conditions - 0 - 95 %
Storage temperature (T-T) Operational conditions - -40 - 60 °C
Storno - N
Summary - TP-Link VIGI C340S. Type: IP security camera, Placement supported: Outdoor, Connectivity technology: Wired. Mounting type: Wall, Product colour: White, Form factor: Bullet. Minimum illumination: 0.0005 lx, Lens viewing angle, horizontal: 95.2°, Lens viewing angle, vertical: 50.6°. Sensor type: CMOS, Optical sensor size: 25.4 / 1.8 mm (1 / 1.8"). Detect distance: 70 m, Observe distance: 29 m, Recognize distance: 14 m
Supported graphics resolutions Video - 1280 x 720 (HD 720)/1920 x 1080 (HD 1080)/2048 x 1280/2304 x 1296/2550 x 1440/2688 x 1520
Supported network protocols Network - TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS
System Requirements -
Tilt angle range Camera - -90 - 90 °
Title - TP-Link VIGI C340S Bullet IP security camera Outdoor 2688 x 1520 pixels Wall
Total megapixels Video - 4 MP
Two-way transmission - Yes
type - Fixed bullet type camera
Type Performance - IP security camera
Unit Box Height - 0.135
Unit Box Length - 0.285
Unit Box Width - 0.147
Unit Calculated Volume - 0.005656 cubm
Unit Calculated Weight - 0.96 kg
Units per Shipping Box - 1
URL - https://www.tp-link.com/us/business-networking/vigi-network-camera/vigi-c340s/#overview
Vendor Homepage - https://www.tp-link.com/us/business-networking/vigi-network-camera/vigi-c340s/#overview
vendpn - VIGI C340S(4mm)
Video - Bit rate - 4 Mbps
Video - Frame rate - 60 fps
Video - Maximum resolution - 2688 x 1520 pixels
Video - Noise reduction - Yes
Video - Noise reduction technology - 3D noise reduction
Video - Privacy masking - Yes
Video - Region of Interest (ROI) encoding - Yes
Video - Supported graphics resolutions - 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2048 x 1280, 2304 x 1296, 2550 x 1440, 2688 x 1520
Video - Total megapixels - 4 MP
Video - Video compression formats - H.264, H.264+, H.265, H.265+
Video compression formats Video - H.264/H.264+/H.265/H.265+
Viewing angle, horizontal - 95 °
Viewing angle, vertical - 50 °
Warranty - 36 months
WarrantyInfo -
Weight & dimensions - Depth - 236 mm
Weight & dimensions - Height - 99 mm
Weight & dimensions - Width - 102 mm
Wide Dynamic Range (WDR) Performance - Yes
Width Weight & dimensions - 102 mm
Wireless communication - No
