Onkron Tilting TV bracket, 32-70"

Category Code - TMS
Description - For TVs 32''–70''Max load: 60 kgVESA: 75x75, 100x100, 100x200, 200x100, 200x200, 200x300, 200x400, 300x100, 300x200, 300x300, 300x400, 400x200, 400x300, 400x400 mmTilt: 0° ~ +12°Wall distance: 35–145 mmBubble levelClick’n’Pull systemSoft spacersMaterial: cold-rolled steel
Distance to the wall (max) Ergonomics - 14.5 cm
Distance to the wall (min) Ergonomics - 3.5 cm
Housing material Design - Steel
Maximum screen size Mounting - 177.8 cm (70")
Maximum VESA mount Mounting - 400 x 400 mm
Maximum weight capacity (per display) Mounting - 60 kg
Maximum weight capacity Mounting - 60 kg
Minimum screen size Mounting - 81.3 cm (32")
Minimum VESA mount Mounting - 75 x 75 mm
Model - TM5
Mounting type Mounting - Wall
Number of displays supported Mounting - 1
Package depth Packaging data - 113 mm
Package height Packaging data - 55 mm
Package weight Packaging data - 2.3 kg
Package width Packaging data - 505 mm
Panel mounting interface Mounting - 75 x 75,100 x 100,100 x 200,200 x 100,200 x 200,200 x 300,200 x 400,300 x 100,300 x 200,300 x 300,300 x 400,400 x 200,400 x 300,400 x 400
Product colour Design - Black
Summary - ONKRON TM5-B. Maximum weight capacity: 60 kg, Minimum screen size: 81.3 cm (32"), Maximum screen size: 177.8 cm (70"), Minimum VESA mount: 75 x 75 mm, Maximum VESA mount: 400 x 400 mm. Tilt angle range: 0 - 12°, Distance to the wall (min): 3.5 cm, Distance to the wall (max): 14.5 cm. Product colour: Black
Tilt adjustment Ergonomics - Yes
Tilt angle range Ergonomics - 0 - 12°
Unit Box Height - 0.05
Unit Box Length - 0.5
Unit Box Width - 0.11
Unit Calculated Volume - 0.003519 cubm
Unit Calculated Weight - 2.33 kg
Units per Pallet - 0
Units per Shipping Box - 10
Vendor Homepage - https://onkron-uk.co.uk/products/onkron-tilting-tv-wall-mount-for-35-to-65-inch-flat-panel-tvs-digital-panels-60-kg-tm5-black?_pos=1&_psq=TM5-B&_ss=e&_v=1.0
Warranty - 60 months
