Cudy Router CUDY WR1300S

Accessories included - WR1300S Power Adapter Ethernet Cable Installation Guide
Antenna - Fixed external
Antenna - Antenna design - External
Antenna - Antenna gain level (max) - 5 dBi
Antenna - Antennas quantity - 4
Antenna gain - 5 dBi
Brand - Cudy
BrandPartCode - WR1300S
Category - Wireless Routers
Certificates - FCC CE
Certificates - Certificates - CE
Certificates - Certificates - FCC
Color - White
Data Act - Link
Description - AC1200 Gigabit Wi-Fi Mesh Router with USB Dual-band AC1200 Wi-Fi router with a USB port, ideal for hosting an SMB server, 4K streaming, and Internet speeds up to 1000 Mb/s. Specifications: Dual-band Wi-Fi 5 Wi-Fi speeds: 867 Mbps + 300 Mbps 5 × Gigabit Ethernet ports 4 high-power antennas Supports up to 50 connected devices 1 × USB 3.0 port Coverage: up to 100 m2 (1,100 ft2) Cudy Mesh, VPN Server and Client Cudy App, Cloud Control
Design - LED indicators - LAN, Power, Status, WPS
Design - LED indicators - LAN, Power, WAN
Design - Product colour - White
Design - Product type - Tabletop router
Designation - CE+WEEE
dimensionalWeight - 1100
dimension depth - 255 mm
dimension height - 60 mm
Dimensions - Router: 183.3 x 109 x 38 mm Antenna: 175 mm
dimension weight - 800 g
dimension width - 330 mm
ean - 6971690793753
Environment requirements - Operating temperature: 0°C ~ 40°C (32°F ~ 104°F) Storage temperature: -40°C ~ 70°C (-40°F ~ 158°F) Operating humidity: 10% ~ 90% non-condensing Storage humidity: 5% ~ 95% non-condensing
Features - Flash memory - 16 MB
Features - Internal memory - 128 MB
GTIN - 6971690793753
guarantee - 24
guarantee_type - normal
I/O ports - 1 x USB 3.0 Type A
I/O ports - 1 x WAN (RJ-45)
I/O ports - 4 x 10/100/1000 Mbit/s
LongDesc - Direction Detected, Signal BoostedBeamforming detects the direction of connected devices and forms a focused signal towards them to improve coverage.More Devices. Lower Latency.MU-MIMO technology transmits data for multiple devices at the same time, reducing latency when give you smoother streaming experience.Fast Roaming Thoughout Your PlaceCreate same-name Wi-Fi coverage throughout your home and enjoy fast roaming between Wi-Fi zones. Compatible with other Cudy Mesh routers and repeaters.Super-Fast Wired SpeedFive Gigabit Ethernet ports enable Internet speed up to 1000 Mbps and offer speedy and stable wired connectivity for TV, consoles, and desktop computers.Parental ControlSet Wi-Fi time schedules and block inappropriate websites to protect your loved ones. You can create custom profiles to easily manage multiple devices.Cudy AppManage your network from your phone. This model supports cloud remote control and local control via the Cudy App.
LongProductName - 2.4-5 GHz, 880 MHz Dual-Core, MIPS1004Kc, Wi-Fi, 12V 1.5A DC, 100 ~ 240 V, 50/60 Hz AC, 183.3×109×38 mm, 284 g
LongSummaryDescription - Cudy WR1300S. WAN connection type: RJ-45. Wi-Fi band: Dual-band (2.4 GHz / 5 GHz), Top Wi-Fi standard: Wi-Fi 5 (802.11ac), WLAN data transfer rate (max): 867 Mbit/s. Ethernet LAN interface type: Gigabit Ethernet, Ethernet LAN data rates: 10,100,1000 Mbit/s, VPN support: PPTP/L2TP/OpenVPN/WireGuard. Security algorithms: WPA, WPA2, WPA3. Product type: Tabletop router, Product colour: White, LED indicators: LAN, Power, Status, WPS
Management, monitoring, configuration - All Devices Management: Wi-Fi Time Schedule MAC Filter IP/MAC Binding   Per-Devices Management: Internet On/Off VPN On/Off Online Time Schedule Device Rename   Content Management: Domain Filter IP Filter Local Control Method: Config Web Page App Control     Remote Control Method: Config Page via HTTPS App Control TR069/TR098/TR111/TR143/TR181   QoS: Per-User Rate Limiting   DHCP: Address Reservation DHCP Client List Server   IPv6 Protocols: Relay Dynamic (SLAAC/DHCPv6) Static (Fixed IP) Passthrough 464XLAT MAP-E DS-Lite   IPTV/VLAN: Bridge Tag VLAN VoIP VLAN IPTV VLAN   TTL Customization: Extend Spoof Custom   IGMP: IGMP Proxy IGMP Snooping   Forwarding: Port Forwarding Port Triggering UPnP DMZ
Management features - MIMO - Yes
Management features - MU-MIMO technology - Yes
Management features - Reset button - Yes
Management features - Web-based management - Yes
Management features - Wi-Fi Multimedia (WMM)/(WME) - Yes
Management features - WPS push button - Yes
Model - WR1300S
name - Router WR1300S Mesh Gigabit WiFi AC1200 with USB, 5 × 10/100/1000Mbps RJ45 Ports, 4 x 5dB
Network - Dynamic DNS (DDNS) - Yes
Network - Ethernet LAN - Yes
Network - Ethernet LAN data rates - 10
Network - Ethernet LAN data rates - 10,100,1000 Mbit/s
Network - Ethernet LAN data rates - 100
Network - Ethernet LAN data rates - 1000
Network - Ethernet LAN interface type - Gigabit Ethernet
Network - Number of guest networks (2.4 GHz) - 1
Network - Number of guest networks (5 GHz) - 1
Network - Port forwarding - Yes
Network - Port triggering - Yes
Network - USB sharing - Yes
Network - VPN support - PPTP/L2TP/OpenVPN/WireGuard
Network - Wireless radio - Yes
Network architecture - GigabitEthernet
Number of antennas - 4
Operating frequency - 2,4 GHz
Operating frequency - 5 GHz
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 95%
Operational conditions - Storage temperature (T-T) - -40 - 70 °C
Other features - CPU: 880 MHz Dual-Core, MIPS1004Kc Flash/ROM: 16 MB (128 Mbit) NOR DDR/RAM: 128 MB (1 Gbit) DDR3 5 GHz Wi-Fi Speed: 867 Mbps 2.4 GHz Wi-Fi Speed: 300 Mbps
Other features - Supported WAN type - Dynamic IP/Static IP/PPPoE
Packaging content - AC adapter included - Yes
Packaging content - Cables included - LAN (RJ-45)
Packaging content - Quick installation guide - Yes
Packaging data - Number of products included - 1 pc(s)
Packaging data - Package depth - 256 mm
Packaging data - Package height - 60 mm
Packaging data - Package type - Box
Packaging data - Package weight - 729,4 g
Packaging data - Package weight - 729.4 g
Packaging data - Package width - 330 mm
Ports & interfaces - DC-in jack - Yes
Ports & interfaces - Ethernet LAN (RJ-45) ports - 4
Ports & interfaces - Number of USB 3.0 Type-A ports - 1
Ports & interfaces - RJ-45 ports quantity - 5
Ports & interfaces - USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity - 1
Ports & interfaces - USB port - Yes
Power - Output current - 1 A
Power - Output current - 1.5 A
Power - Output voltage - 12 V
Power - Power source type - DC
Power supply - Input: 100 ~ 240 V, 50/60 Hz AC Output: 12V 1.5A DC
producer - Cudy
producerCode - WR1300S
productName - CUDY WR1300S Router
ProductName - WR1300S
productSize - Normal
Protocols - DHCP client - Yes
Protocols - DHCP server - Yes
Protocols - Universal Plug and Play (UPnP) - Yes
Security - Wi-Fi Security: WPA/WPA2/WPA3   Parental Controls: Profiles Settings Offline Time Online Time Pause the Internet Web Filter   Firewall: SPI Firewall DoS Protection Block PING
Security - DMZ support - Yes
Security - Filtering - Yes
Security - Firewall - Yes
Security - Guest access - Yes
Security - IGMP snooping - Yes
Security - IP address filtering - Yes
Security - MAC address filtering - Yes
Security - Parental control - Yes
Security - Security algorithms - WPA, WPA2, WPA3
Security - URL filtering - Yes
ShortSummaryDescription - Cudy WR1300S, Wi-Fi 5 (802.11ac), Dual-band (2.4 GHz / 5 GHz), Ethernet LAN, White, Tabletop router
sizeX - 259
sizeY - 64
sizeZ - 332
Standards - 802.11a
Standards - 802.11ac
Standards - 802.11b
Standards - 802.11g
Standards - 802.11n
Standards - IPv4
Standards - IPv6
System requirements - Browser supported - Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0
System requirements - Mac compatibility - Yes
System requirements - Mac operating systems supported - MacOS
System requirements - Windows operating systems supported - Windows 10, Windows 2000, Windows 7, Windows 8, Windows 8.1, Windows 98SE, Windows NT, Windows Vista, Windows XP
Title - Cudy WR1300S wireless router Gigabit Ethernet Dual-band (2.4 GHz / 5 GHz) White
Type - xDSL
URL - https://www.cudy.com/products/wr1300s-1-0?_pos=1&_psq=WR1300S+AC1200+Mesh+Wi-Fi+USB&_ss=e&_v=1.0
vendpn - WR1300S
WAN connection - 3G/4G USB modem compatibility - No
WAN connection - DSL WAN - No
WAN connection - Ethernet WAN - Yes
WAN connection - SIM card slot - No
WAN connection - WAN connection type - RJ-45
WarrantyInfo -
warrantyLength - 24
warrantyType - G
Weight - 284 g
weight - 722
Weight & dimensions - Depth - 109 mm
Weight & dimensions - Height - 38 mm
Weight & dimensions - Weight - 284 g
Weight & dimensions - Width - 183.3 mm
Wireless LAN features - Top Wi-Fi standard - Wi-Fi 5 (802.11ac)
Wireless LAN features - Wi-Fi band - Dual-band (2.4 GHz / 5 GHz)
Wireless LAN features - Wi-Fi standards - 802.11a, 802.11b, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Wireless LAN features - WLAN data transfer rate (first band) - 300 Mbit/s
Wireless LAN features - WLAN data transfer rate (max) - 867 Mbit/s
Wireless LAN features - WLAN data transfer rate (second band) - 867 Mbit/s
