Cooler Master MasterFrame 360 Stage LCD, Tempered Glass, Black

Category_1 - Obudowy i chłodzenie
Category_2 - Obudowy komputerowe
Chassis type - Midi Tower
Color - Black
Compatible power supply standard - ATX
Computer case backlight - ARGB
Description - MASTERFRAME 360 STAGE LCD MasterFrame 360 STAGE LCD is designed for creators and enthusiasts who demand both performance and aesthetics.
The integrated front-facing LCD screen transforms the chassis into a visual showcase-ideal for displaying your favorite content or media that complements the stage-inspired theme.
Taking cues from concert stages, the LCD acts as a visual centerpiece, perfectly aligned with the chassis design.
Whether you're building for performance or presentation, the STAGE LCD offers the space and flexibility to bring your vision to life. Front Display Panel for Personal Expression
An integrated front-facing LCD screen transforms the build from a static showcase into a visual platform for personal expression.
Designed to complement collectible displays such as figures and themed setups, the screen allows you to curate content that enhances your aesthetic story.
With its open-frame design, the chassis offers complete freedom to position and showcase \ your items without restrictionturning your build into a stage thats uniquely yours. Massive Cooling Compatibility
To ensure exceptional thermal performance, the case supports fan sizes ranging from 120 mm to 200 mm, with space for up to twelve 120 mm fans-six on the top and six on the bottom. It also supports radiators up to 360 mm, meeting the cooling demands of high-end custom liquid cooling setups. At the front, the integrated STAGE LCD offers two distinct modes: Extended Display Mode - Functions as a true secondary monitor to extend your desktop or showcase any live system content. Custom Playback Mode - Includes 2 preloaded animation effects designed to complement figure and collectible displays. Users can also upload personalized content via MicroSD card (JPG and MP4 formats) to create a uniquely immersive visual experience. Compatible with Standard and BTF Motherboards
Compatible with Mini-ITX, Micro-ATX, and ATX motherboards, including BTF (back-connect) layouts within the ATX form factor. Features 110 mm of cable routing clearance for a clean and clutter-free showcase. PCIe 5.0 Riser Cable Included
Includes a premium PCIe 5.0 riser cable that enables vertical GPU mounting providing both next-gen performance and an elevated presentation right out of the box. Wide Component Compatibility
Accommodates up to 430 mm GPUs and 210 mm PSUs built to handle flagship components without compromise. Next-Gen Connectivity at Your Fingertips
Features USB 4.0 Gen 2x2 Type-C (up to 20G) and 2x USB 3.2 Gen 1 Type-A ports (up to 5G), providing ultra-fast data transfer and future-ready accessibility.
Designation - CE+WEEE
dimension depth - mm
dimension height - mm
Dimensions - 549 x 291 x 581 mm
dimension weight - g
dimension width - mm
Drive bays 2.5'' intern. - 1
ean - 4719512163436
EAN_code - 4719512163436
Form-factor - ATX
Form-factor - Micro ATX
Form-factor - Mini ITX
Front panel connectors - 1 x mic/headphone (combo)
Front panel connectors - 1 x UBS 3.2 Gen 2x2 Type-C
Front panel connectors - 2 x USB 3.2 Gen1
guarantee - 24
guarantee_type - normal
Manufacturer - Cooler Master
Manufacturer_code - MF360-KHNN-S02
Maximum CPU cooling height - 145 mm
Maximum length of the graphics card - 430 mm
Maximum length of the power supply - 210 mm
Maximum number of fans - 12
name - Case MasterFrame 360 Stage LCD black
Name - Cooler Master MasterFrame 360 ??Stage LCD (black, tempered glass x 2)
Number of fans installed - 0
Ooptional water cooling - 1 x 120 mm (bottom)
Ooptional water cooling - 1 x 120 mm (top)
Ooptional water cooling - 1 x 140 mm (bottom)
Ooptional water cooling - 1 x 140 mm (top)
Ooptional water cooling - 1 x 240 mm (bottom)
Ooptional water cooling - 1 x 240 mm (góra)
Ooptional water cooling - 1 x 280 mm (bottom)
Ooptional water cooling - 1 x 280 mm (góra)
Ooptional water cooling - 1 x 360 mm (bottom)
Ooptional water cooling - 1 x 360 mm (top)
Optional fans - 6 x 120 mm lub 2 x 140 mm lub 2 x 180 mm lub 2 x 200 mm (bottom)
Optional fans - 6 x 120 mm lub 2 x 140 mm lub 2 x 180 mm lub 2 x 200 mm (top)
Power supply - Failure
producer - Cooler Master
Side panel - Tempered Glass
vendpn - MF360-KHNN-S02
Weight - 17,70
