Brand - WESTERN DIGITAL
Category - PC COMPON
Category Code - HDS
Certification Other features - BSMI, ICES-003/NMB-003, CE, FCC, KC, Maghreb, RCM, UKCA, VCCI, CB-Scheme, TUV, UL
Code - WD100EFGX
Component for Features - NAS
Country of origin - TH
Depth Weight & dimensions - 147 mm
Description - Powerful internal HDDs designed for performance, reliability and power efficiency in small to medium NAS environments.
WD Red Plus internal HDDs are designed to handle workloads for power users and small to medium business NAS environments. WD Red Plus drives deliver the speed and capacity required to store, protect and share growing amounts of data in mid-sized RAID-optimized NAS systems with increased power efficiency.
Description - Western Digital 10TB, 7200rpm, 512MB, S, Red
dimensionalWeight - 94
EAN -
EAN - 0718037906201
Features - Certification - BSMI, ICES-003/NMB-003, CE, FCC, KC, Maghreb, RCM, UKCA, VCCI, CB-Scheme, TUV, UL
Features - Component for - NAS
Features - HDD average transfer rate - 260 MB/s
Features - HDD capacity - 10 TB
Features - HDD size - 3.5"
Features - HDD speed - 7200 RPM
Features - Hot-swap - No
Features - Interface - Serial ATA III
Features - Mean time between failures (MTBF) - 2500000 h
Features - Storage drive buffer size - 512 MB
Features - Type - HDD
Features - Workload rate limit - 180 TB/year
Gross weight - 0.5
Gross Weight Kg - 0,83
HDD average transfer rate Features - 215 MB/s
HDD capacity Features - 10 TB
HDD Family name - Red Plus
HDD interface transfer rate Features - 6 Gbit/s
HDD size Features - 3.5"
HDD speed Features - 7200 RPM
height - 0.04
Height Weight & dimensions - 26.1 mm
Interface Features - Serial ATA III
length - 0.16
Manufacturer Code - WD100EFGX
Manufacturer Name - Western Digital
Mean time between failures (MTBF) Features - 1000000 h
Model - WD100EFGX
Non-operating shock Operational conditions - 250 G
Operating shock Operational conditions - 30 G
Operating temperature (T-T) Operational conditions - 0 - 65 °C
Operating voltage Power - 12 V
Operational conditions - Operating temperature (T-T) - 0 - 65 °C
Operational conditions - Storage temperature (T-T) - -40 - 70 °C
Power consumption (idle) Power - 6.1 W
Power consumption (read) Power - 8.8 W
Power consumption (standby) Power - 0.3 W
Power consumption (write) Power - 8.8 W
producerCode - WD100EFGX
productName - Western Digital Red WD100EFGX internal hard drive 3.5" 10 TB Serial ATA III
productSize - Normal
Quantity per pack Packaging data - 1 pc(s)
Safety warning - Warnings - Do not drop and avoid strong impacts.
Safety warning - Warnings - Do not expose to high temperatures or moisture.
Safety warning - Warnings - Do not open or disassemble.
Short description - WD HD3.5" SATA3 10TB WD100EFGX / 24x7 / NAS (Di) 512MB / 7200rpm / CMR
sizeX - 150
sizeY - 30
sizeZ - 105
Start/stop cycles Features - 600000
Storage drive buffer size Features - 256 MB
Storage temperature (T-T) Operational conditions - -40 - 70 °C
Subcategory - HDD
Summary - Western Digital Red Plus WD100EFGX. HDD capacity: 10 TB, HDD speed: 7200 RPM, Storage drive buffer size: 256 MB, HDD size: 3.5", Interface: Serial ATA III
Tariff No. - 84717050
Type Features - HDD
Unit Box Height - 0.105
Unit Box Length - 0.15
Unit Box Width - 0.03
Unit Calculated Volume - 0.0004725 cubm
Unit Calculated Weight - 0.4 kg
Units per Shipping Box - 1
Vendor Homepage - https://www.westerndigital.com/products/internal-drives/wd-red-plus-sata-3-5-hdd?sku=WD101EFBX
Warranty -
Warranty - 36L months
warrantyLength - 36
Warranty period Other features - 3 year(s)
warrantyType - G
weight - 715
Weight & dimensions - Depth - 26.1 mm
Weight & dimensions - Height - 147 mm
Weight & dimensions - Weight - 750 g
Weight & dimensions - Width - 101.6 mm
Weight Weight & dimensions - 750 g
width - 0.12
Width Weight & dimensions - 101.6 mm
Workload rate limit Features - 180 TB/year
