10G support Network - No
AC input voltage Power - 100 - 240 V
Auto MDI/MDI-X Network - Yes
Bandwidth > Data transfer rate (max) - 10 Gbps Mbit/s
Basic switching RJ-45 Ethernet ports quantity Ports & interfaces - 5
Basic switching RJ-45 Ethernet ports type Ports & interfaces - Gigabit Ethernet (10/100/1000)
Category - Root/Electronics/Networks and communication/Switchers
Category Code - SWI
Code - TSW110000000
Dane techniczne: Akcesoria - Zasilacz 9 W, skrócona instrukcja obsługi
Dane techniczne: Algorytm przełączania - store-and-forward
Dane techniczne: Bufor pamięci - 128 KB
Dane techniczne: Dodatkowe informacje - aluminiowa obudowa, możliwe zasilanie przez POE do portu LAN nr 1 - bez zgodności ze standardami IEEE802.3af, 802.3at i 802.3bt
Dane techniczne: Gwarancja - 2 lata w serwisie zewnętrznym
Dane techniczne: Głębokość - 85 mm
Dane techniczne: Liczba portów LAN 10/100/1000 - 5 szt.
Dane techniczne: Możliwość instalacji w szafach 19' - nie
Dane techniczne: Obsługiwane protokoły - IEEE 802.3
Dane techniczne: Obsługiwane protokoły - IEEE 802.3az
Dane techniczne: Obsługiwane protokoły - IEEE 802.3u
Dane techniczne: Porty PoE - 1 szt.
Dane techniczne: Producent - Teltonika
Dane techniczne: Przeznaczenie - biurkowy
Dane techniczne: Prędkość magistrali wew. - 10 Gb/s
Dane techniczne: Rozmiar tablicy adresów MAC - 2000
Dane techniczne: Szerokość - 110 mm
Dane techniczne: Typ - niezarządzalny
Dane techniczne: Waga - 0.227 kg
Dane techniczne: Warstwa przełączania - 2
Dane techniczne: Wysokość - 30 mm
Data transmission > Jumbo frames - 9216 bytes
DC input voltage Power - 30 V
Depth Weight & dimensions - 85 mm
Description - PLUG-N-PLAY No additional configuration needed DURABILITY Rugged aluminium housing MOUNTING DIN rail and surface mounting options STATUS LEDS 1 x Power, 10 x Ethernet 9-30 V Wide range of supported power supply voltages GIGABIT ETH 5 x Gigabit Ethernet with speeds up to 1000 MbpsTSW110 is a layer 2 unmanaged switch, which is a simplified version of our earlier product – TSW100Possible to power up through the first LAN portIt has five 10/100/1000 Mbps Ethernet ports for an economical high-bandwidth solutionIt offers a wide range of supported power supply voltages (9-30 V)Ideal for professional high bandwidth applications to provide reliable data connection
Design > Housing material - Aluminium
Design > LED indicators - Yes
DIN rail mounting Design - Yes
EAN - 4779027312958
Eans - 4779027312958
Ethernet LAN data rates Network - 10,100,1000 Mbit/s
Height Weight & dimensions - 30 mm
Housing material Design - Aluminium
International Protection (IP) code Design - IP30
Jumbo frames Data transmission - 9216
Jumbo frames support Data transmission - Yes
LED indicators Design - Yes
Link - https://teltonika-networks.com/lt/product/tsw110/
Link - https://wiki.teltonika-networks.com/view/TSW110
MAC address table Data transmission - 2000 entries
Management features > Switch type - Unmanaged
Model - TSW110
Model name - TSW110000000
Name - Teltonika TSW110
Name - Teltonika | Switch | TSW110 | Unmanaged | Gigabit Ethernet (copper) ports quantity 5 | 10 Gbps (RJ-45) ports quantity 0 | SFP ports quantity 0 | SFP+ ports quantity 0 | Combo ports quantity 0 | PoE+ ports quantity 0 | Passive PoE ports quantity Possibility to power up through LAN port, not compatible with IEEE802.3af, 802.3at and 802.3bt standards | 24 month(s)
Networking standards Network - IEEE 802.3, IEEE 802.3az, IEEE 802.3u
Operating relative humidity (H-H) Operational conditions - 10 - 90%
Operating temperature (T-T) Operational conditions - -40 - 75 °C
Operational conditions > Operating relative humidity (H-H) - 10 % to 90 % non-condensing %
Operational conditions > Operating temperature (T-T) - -40 C to 75 C °C
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 175 mm
Package features > Gross height (mm) - 150.00 mm
Package features > Gross width (mm) - 70 mm
Package features > Packing quantity - 1.00 pc(s)
Package features > Palette Qty - 470 pc(s)
Package features > Paper/Pasteboard - 82 g
Package features > Tare weight (kg) - 0.082 kg
Package features > Volume (m3) - 0.0018375 m³
Package features > WEE classification - CL109:6:2017-04-01
Package features > WEEE tax - Yes
Package type Packaging data - Box
Packet buffer memory Data transmission - 0.128 MB
Performance > Buffer size - 128 KB
Ports & interfaces > 10 Gbps (RJ-45) ports quantity - 0
Ports & interfaces > Combo ports quantity - 0
Ports & interfaces > Combo SFP ports quantity - 0
Ports & interfaces > Gigabit Ethernet (copper) ports quantity - 5
Ports & interfaces > Passive PoE ports quantity - Possibility to power up through LAN port, not compatible with IEEE802.3af, 802.3at and 802.3bt standards
Ports & interfaces > POE - PoE passive
Ports & interfaces > PoE+ ports quantity - 0
Ports & interfaces > Predominant port type - 1 Gbps (RJ-45)
Ports & interfaces > SFP+ ports quantity - 0
Ports & interfaces > SFP ports quantity - 0
Power > Input voltage - 9-30 VDC (reverse polarity protection, voltage surge/transient protection) V
Power consumption (typical) Power - 1.8 W
Power over Ethernet (PoE) Power over Ethernet (PoE) - Yes
Power supply included Power - Yes
Producent: Nazwa producenta / importera - Teltonika
Teltonika Networks
K. Baršausko st. 66
LT-51436 Kaunas
Producer - Teltonika
ProducerCode - TSW110
Producer product family - Switch
Producer product name - TSW110
Product colour Design - Blue, Grey
Quick start guide Packaging content - Yes
ShortDescription - Teltonika TSW110 Switch 5p Gigabit, aluminiowa obudowa
Summary - Teltonika TSW110. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 5. MAC address table: 2000 entries, Switching capacity: 10 Gbit/s. Networking standards: IEEE 802.3, IEEE 802.3az, IEEE 802.3u. DC input voltage: 30 V. Power over Ethernet (PoE)
Switching capacity Data transmission - 10 Gbit/s
Switch type Management features - Unmanaged
Technical details > Gross weight - 0.287 kg
Technical details > Net weight - 0.205 kg
Technical details > Producer - Teltonika
Technical details > Warranty - 12 month(s)
Unit Box Height - 0.07
Unit Box Length - 0.175
Unit Box Width - 0.15
Unit Calculated Volume - 0.001837 cubm
Unit Calculated Weight - 0.393 kg
Units per Shipping Box - 1
Vendor Homepage - https://teltonika-networks.com/product/tsw110/
Warranty - 12
Warranty - 24 months
Weight Weight & dimensions - 227 g
Width Weight & dimensions - 100 mm
