Netgear 8-PORT M4350-8M2V MANAGED SWITCH

ARTIKEL1 - 8-PORT M4350-8M2V
ARTIKEL2 - MANAGED SWITCH
Brand - NETGEAR
BrandPartCode - MSM4310-100NES
Breite - 0
Category - Network Switches
Certificates - Compliance certificates - BSMI, CCC, CE, Federal Communications Commission (FCC), Low Voltage Directive (LVD)
Data transmission - Jumbo frames - 12000
Data transmission - Jumbo frames support - Yes
Data transmission - Latency (10 Gbps) - 2.27 µs
Data transmission - MAC address table - 16000 entries
Data transmission - Packet buffer memory - 32 MB
Data transmission - Store-and-forward - Yes
Data transmission - Switching capacity - 140 Gbit/s
Data transmission - Throughput - 372 Mpps
Design - Airflow direction - Front-to-back airflow
Design - Form factor - 1U
Design - LED indicators - Yes
Design - Product colour - Black
Design - Rack mounting - Yes
Design - Stackable - Yes
EANCode - 0606449172911
Gewicht - 7.65
GRUPPE1 - Network
GRUPPE2 - Switches Managed
GTIN - 0606449172911
GTIN - 606449172911
GTIN - 5715328108677
HERSTELLER - NETGEAR
Hoehe - 0
HSTNUMMER - MSM4310-100NES
Laenge - 0
LongDesc - POWER AND THROUGHPUTEdge to core flexible platform, from 1 Gigabit to 100 Gigabit, good for projects of all sizes.Groundbreaking AV GUIA simplified user interface makes it easy to assign configuration profiles to each port.Multicast in an InstantNETGEAR IGMP Plus™ provides multicast functionality right out of the box for most AV over IP applications.Sleek, Quiet DesignLess fan noise, and mounting ears included for rack mounting.Automatic ConfigurationAuto-trunk and auto-LAG functionality auto connects with other M4350 (and M4250) switches.FAST, EASY CONFIGURATION FOR AV PROSA streamlined interface enables factory default AV settings or user-specified AV profiles to be assigned to individual ports with just a few clicks.FOCUS ON THE EVENT NOT FAN NOISEMost models have quiet mode which greatly reduces fan noise.DESIGNED FOR AV OVER IP RIGHT OUT OF THE BOXWith built-in NETGEAR IGMP Plus™, there's little-to-no setup required for flawless audio and video delivery. Enable multicasting right out of the box.MAXIMIZE PERFORMANCE WITH PRO WIFI ACCESS POINTSEnable powerful, reliable WiFi at your location with Pro WiFi access points, powered by PoE or an external power adapter.PRO AV RESOURCESAll the resources you need to learn about NETGEAR AV over IP solutions, including family brochures, product data sheets, tech tips and more.
LongProductName - 8x2.5G PoE++ (119W base, up to 551W) and 2x25G SFP28 Managed Switch
LongSummaryDescription - NETGEAR MSM4310. Switch type: Managed, Switch layer: L3. Basic switching RJ-45 Ethernet ports type: 2.5G Ethernet (100/1000/2500), Basic switching RJ-45 Ethernet ports quantity: 8. Full duplex. MAC address table: 16000 entries, Switching capacity: 140 Gbit/s. Networking standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1Qav, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE.... Power connector: AC-in jack. Power over Ethernet (PoE). Rack mounting, Form factor: 1U
Management features - ARP inspection - Yes
Management features - Quality of Service (QoS) support - Yes
Management features - Switch layer - L3
Management features - Switch type - Managed
Management features - Web-based management - Yes
Multicast features - Multicast Listener Discovery (MLD) snooping - Y
Multicast features - Multicast support - Yes
Network - 6to4 tunnel - Yes
Network - 10G support - No
Network - Broadcast storm control - Yes
Network - Flow control support - Yes
Network - Full duplex - Yes
Network - IPv4 routes - 512
Network - IPv6 routes - 256
Network - Link aggregation - Yes
Network - Networking standards - IEEE 802.1D, IEEE 802.1Q, IEEE 802.1Qav, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ak, IEEE 802.3bz, IEEE 802.3u
Network - Number of VLANs - 4093
Network - Spanning tree protocol - Yes
Network - Virtual LAN features - MAC address-based VLAN, Private VLAN, Voice VLAN
Network - VLAN support - Yes
Operational conditions - Non-operating altitude - 0 - 3000 m
Operational conditions - Operating altitude - 0 - 3000 m
Operational conditions - Operating relative humidity (H-H) - 0 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 45 °C
Operational conditions - Storage relative humidity (H-H) - 0 - 95%
Operational conditions - Storage temperature (T-T) - -20 - 70 °C
Other features - Power supply - 550 W
Packaging content - Cables included - AC, USB Type-C
Packaging content - Quick start guide - Yes
Packaging content - Rack mount kit - Yes
Packaging data - Included power plug types - EU, UK, NA
Performance - Built-in processor - Yes
Performance - Flash memory - 512 MB
Performance - Internal memory - 2048 MB
Performance - Memory type - DDR4-SDRAM
Performance - Processor frequency - 1800 MHz
Performance - Processor model - ARM Cortex-A57
Performance - sFlow - Yes
Ports & interfaces - 2.5G Ethernet (copper) ports quantity - 8
Ports & interfaces - 10G Ethernet (copper) ports quantity - 8
Ports & interfaces - Basic switching RJ-45 Ethernet ports quantity - 8
Ports & interfaces - Basic switching RJ-45 Ethernet ports type - 2.5G Ethernet (100/1000/2500)
Ports & interfaces - Power connector - AC-in jack
Ports & interfaces - SFP28 ports quantity - 2
Power - Power consumption (max) - 351.5 W
Power - Power consumption (typical) - 133.5 W
Power - Power source - AC
Power - Power supply included - Yes
Power over Ethernet (PoE) - Power over Ethernet (PoE) - Yes
Power over Ethernet (PoE) - Power over Ethernet (PoE) power per port - 90 W
Power over Ethernet (PoE) - Power over Ethernet 4PPoE (PoE++) ports quantity - 48
Power over Ethernet (PoE) - Total Power over Ethernet (PoE) budget - 3314 W
ProductName - MSM4310
Protocols - GARP VLAN Registration Protocol (GVRP) - Yes
Protocols - Management protocols - SNMP V1, V2, V3
Protocols - Routing protocols - OSPF, OSPFv2, OSPFv3, RIP, RIP-1, RIP-2
Security - Access Control List (ACL) - Yes
Security - Access Control List (ACL) egress - 1023
Security - Access Control List (ACL) ingress - 511
Security - Authentication - Guest VLAN, MAC-based authentication
Security - Authentication type - RADIUS, TACACS+
Security - BPDU filtering/protection - Yes
Security - DHCP features - DHCP Option 150, DHCP Option 66, DHCP Option 67, DHCP relay, DHCP server, DHCP snooping
Security - DoS attack prevention - Yes
Security - IGMP proxy - Yes
Security - IGMP snooping - Yes
Security - Loop protection - Yes
Security - MAC address filtering - Yes
Security - Password protection - Yes
Security - Queue scheduling algorithms - Strict Priority Queue (SPQ), Weighted random early detection (WRED)
Security - Root protection - Yes
Security - Static port security - Yes
ShortSummaryDescription - NETGEAR MSM4310, Managed, L3, 2.5G Ethernet (100/1000/2500), Power over Ethernet (PoE), Rack mounting, 1U
Stck_Kart - 1
Stck_Pal - 2
Storno - N
Sustainability - Sustainability compliance - Yes
Title - NETGEAR MSM4310 Managed L3 2.5G Ethernet (100/1000/2500) Power over Ethernet (PoE) 1U Black
URL - https://www.netgear.com/business/wired/switches/fully-managed/msm4310/
WarrantyInfo - Lifetime
Weight & dimensions - Depth - 300 mm
Weight & dimensions - Height - 43.2 mm
Weight & dimensions - Weight - 2.9 kg
Weight & dimensions - Width - 220 mm
