TP-LINK Omada ES228GMP, 26x1Gb PoE+ 2SFP

10G support Network - No
Accessories included - ES228GMP Power cable Mounting brackets Rubber feet Screws Installation instructions
AC input frequency Power - 50/60 Hz
AC input voltage Power - 100 - 240 V
Application - Medium and large companies
ARTIKEL1 - 28-PORT 1G POE SWITCH
ARTIKEL2 - EASY MANAGED WITH 24-PORT POE+
Auto MDI/MDI-X Network - Yes
Basic switching RJ-45 Ethernet ports quantity Ports & interfaces - 26
Basic switching RJ-45 Ethernet ports type Ports & interfaces - Gigabit Ethernet (10/100/1000)
Brand - TP-Link
BrandPartCode - ES228GMP
Breite - 0
Broadcast storm control Network - Yes
Cables included Packaging content - AC
Category - Network Switches
Category 1 - Netzwerk
Category 2 - Switching Hubs
Category Code - SWI
Certificates - FCC CE RoHS
Certificates - Certification - FCC, CE, RoHS
Certificates - Compliance certificates - CE
Certificates - Compliance certificates - CE, Federal Communications Commission (FCC), RoHS
Certificates - Compliance certificates - Federal Communications Commission (FCC)
Certificates - Compliance certificates - RoHS
Certification Certificates - FCC, CE, RoHS
Chassis type - Rack
Cloud-managed Management features - Yes
Compliance certificates Certificates - CE, Federal Communications Commission (FCC), RoHS
Console port - No
Copper ethernet cabling technology Network - 10BASE-T, 100BASE-X, 1000BASE-T, 1000BASE-X
Data transmission - Forwarding rate - 41.66 Mpps
Data transmission - Jumbo frames - 15000
Data transmission - Jumbo frames support - Yes
Data transmission - MAC address table - 8000 entries
Data transmission - Packet buffer memory - 4 MB
Data transmission - Store-and-forward - Yes
Data transmission - Switching capacity - 56 Gbit/s
Depth Weight & dimensions - 330 mm
Description - Omada Cloud Essentials — A Free and Easy Cloud-Based Network Management
Omada Cloud Essentials is a free, easy-to-use version of the Omada Cloud-based Controller. It provides cloud-based centralized management and monitoring for the Omada networking system, covering access points, switches, and gateways, ideal for surveillance networks and small businesses.26× 10/100/1000Mbps RJ45 ports (24× 802.3af/at-compliant PoE+)2× Gigabit SFP port384W Power Budget, with up to 30W for each PoE portEasy to Use: Supports plug-and-play for instant connectivity and simple configuration for additional featuresCentralized Cloud Management via the web or the Omada appUp to 250m PoE, QoS△, PoE Auto Recovery, and Port Isolation for reliable surveillance networkingAutomatic Loop Prevention, VLAN, and IGMP SnoopingDurable metal casing and rack-mountable design
Description - Omada Easy Managed Switch, 28 Gigabit ports, including 24 PoE+ ports 26 Gigabit RJ45 ports (including 24 802.3at/af PoE+ compliant ports) 2 Gigabit SFP slots Up to 384W of total PoE power. Up to 30W of power per PoE port Ease of use thanks to plug-and-play operation, enabling instant connection, and simple configuration for access to additional features Centralized cloud management via the website or the Omada app Up to 250m PoE range, QoS, PoE Auto Recovery, and port isolation ensure a reliable surveillance network Automatic loop prevention, VLAN, and IGMP snooping Rugged metal housing with rack-mountability
Design - Housing material - Metal
Design - LED indicators - Yes
Design - Number of fans - 2 fan(s)
Design - Product colour - Black
Design - Rack mounting - Yes
Designation - CE+WEEE
DHCP features Security - DHCP client
dimensionalWeight - 5306
dimension depth - 100 mm
dimension height - 530 mm
Dimensions - 440 × 330 × 44 mm
dimension weight - 4500 g
dimension width - 470 mm
ean - 1210002600989
EAN - 1210002600989
EANCode - 1210002600989
Environment requirements - Permissible operating temperature: -5°C~45°C Permissible storage temperature: -40°C~70°C Permissible air humidity: 10%~90%, non-condensing Permissible storage humidity: 5%~90%, non-condensing
Ethernet LAN data rates Network - 10,100,1000 Mbit/s
Fan - Yes
Fanless Performance - No
Fast leave Network - Yes
Firmware upgradeable Performance - Yes
Flash memory Performance - 64 MB
Flow control support Network - Yes
Forwarding mode - Store-and-forward
Forwarding rate - 41.67 Mpps
Forwarding rate Data transmission - 41.66 Mpps
Gewicht - 6.1
Gigabit Ethernet (copper) ports quantity Ports & interfaces - 26
Gross Weight Kg - 5,32
GRUPPE1 - Network
GRUPPE2 - Switches Managed
GTIN - 0840460600460
GTIN - 840460600460
GTIN - 1210002600989
GTIN - 1210002600996
guarantee - 60
guarantee_type - normal
Heat dissipation Operational conditions - 1546.15 BTU/h
Height Weight & dimensions - 44 mm
HERSTELLER - TP-LINK
Hoehe - 0
Housing material Design - Metal
HSTNUMMER - ES228GMP
IGMP snooping Security - Yes
Jumbo frames Data transmission - 15000
Jumbo frame size - 15 KB
Jumbo frames support Data transmission - Yes
L2 features - IGMP Snooping IGMP v1/v2/v3 Snooping Fast Leave
L3 features -
Laenge - 0
LED indicators Design - Yes
Link aggregation Network - Yes
LongDesc - Omada Cloud Essentials — A Free and Easy Cloud-Based Network ManagementOmada Cloud Essentials is a free, easy-to-use version of the Omada Cloud-based Controller. It provides cloud-based centralized management and monitoring for the Omada networking system, covering access points, switches, and gateways, ideal for surveillance networks and small businesses.
LongProductName - ES228GMP Omada 28-Port Gigabit Easy Managed Switch with 24-Port PoE+
LongSummaryDescription - TP-Link Omada ES228GMP. Switch type: Managed, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 26. MAC address table: 8000 entries, Switching capacity: 56 Gbit/s. Networking standards: IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3i,.... Power over Ethernet (PoE). Rack mounting
MAC address table Data transmission - 8000 entries
MAC address table size - 8000
Management, monitoring, configuration - Web GUI DHCP Client Cable Diagnostics Automatic Device Discovery Group Configuration Group Software Update Unified Configuration
Management features - Cloud-managed - Yes
Management features - Quality of Service (QoS) support - Yes
Management features - Switch layer - L2
Management features - Switch type - Managed
Management features - Unified static configuration - Yes
Management features - Web-based management - Yes
Manual Packaging content - Yes
Manufacturer - TP-Link
Manufacturer Code - ES228GMP
Manufacturer Name - TP-LINK
Mean time between failures (MTBF) Performance - 224143 h
Model name - SG2428P
MPN - ES228GMP
Multicast features - Multicast support - Yes
Multicast support Multicast features - Yes
name - Switch ES228GMP
Name - TP-Link Omada ES228GMP 28-Port Gigabit Easy mgd. Switch 24-Port PoE+
Network - 10G support - No
Network - Auto MDI/MDI-X - Yes
Network - Broadcast storm control - Yes
Network - Copper ethernet cabling technology - 10BASE-T
Network - Copper ethernet cabling technology - 10BASE-T, 100BASE-X, 1000BASE-T, 1000BASE-X
Network - Copper ethernet cabling technology - 100BASE-X
Network - Copper ethernet cabling technology - 1000BASE-T
Network - Copper ethernet cabling technology - 1000BASE-X
Network - Ethernet LAN data rates - 10,100,1000 Mbit/s
Network - Fast leave - Yes
Network - Flow control support - Yes
Network - Link aggregation - Yes
Network - Networking standards - IEEE 802.1ab
Network - Networking standards - IEEE 802.1p
Network - Networking standards - IEEE 802.1Q
Network - Networking standards - IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Network - Networking standards - IEEE 802.3ab
Network - Networking standards - IEEE 802.3af
Network - Networking standards - IEEE 802.3at
Network - Networking standards - IEEE 802.3i
Network - Networking standards - IEEE 802.3u
Network - Networking standards - IEEE 802.3x
Network - Networking standards - IEEE 802.3z
Network - Number of VLANs - 32
Network - Port mirroring - Yes
Network - Virtual LAN features - MTU VLAN
Network - Virtual LAN features - MTU VLAN, Port-based VLAN, Tagged VLAN
Network - Virtual LAN features - Port-based VLAN
Network - Virtual LAN features - Tagged VLAN
Network - VLAN support - Yes
Network architecture - GigabitEthernet
Networking standards Network - IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Noise level Performance - 46.2 dB
Number of 10/100/1000 Mbps ports - 26
Number of fans Design - 2 fan(s)
Number of PoE+ ports - 24
Number of SFP ports - 2
Number of VLANs Network - 32
Operating relative humidity (H-H) Operational conditions - 10 - 90%
Operating temperature (T-T) Operational conditions - -5 - 45 °C
Operational conditions - Heat dissipation - 1546.15 BTU/h
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - -5 - 45 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 90%
Operational conditions - Storage temperature (T-T) - -40 - 70 °C
Other features -
Other functions -
Packaging content - Cables included - AC
Packaging content - Manual - Yes
Packaging content - Quick start guide - Yes
Packaging content - Rack mount kit - Yes
Packet buffer - 4 MB
Packet buffer memory Data transmission - 4 MB
Performance - Fanless - No
Performance - Firmware upgradeable - Yes
Performance - Flash memory - 64 MB
Performance - Mean time between failures (MTBF) - 224143 h
Performance - Noise level - 46.2 dB
Port mirroring Network - Yes
Ports & interfaces - Basic switching RJ-45 Ethernet ports quantity - 26
Ports & interfaces - Basic switching RJ-45 Ethernet ports type - Gigabit Ethernet (10/100/1000)
Ports & interfaces - Gigabit Ethernet (copper) ports quantity - 26
Ports & interfaces - SFP module slots quantity - 2
Power - AC input frequency - 50/60 Hz
Power - AC input voltage - 100 - 240 V
Power - Power consumption (max) - 454.8 W
Power - Power source - AC
Power - Power supply included - Yes
Power - Surge protection - Yes
Power - Surge protection voltage - 6 kV
Power consumption - 384 W
Power consumption (max) Power - 454.8 W
Power over Ethernet (PoE) - Power over Ethernet (PoE) - Yes
Power over Ethernet (PoE) - Power over Ethernet (PoE) power per port - 30 W
Power over Ethernet (PoE) - Power over Ethernet (PoE) type supported - PoE+
Power over Ethernet (PoE) - Power over Ethernet plus (PoE+) ports quantity - 24
Power over Ethernet (PoE) - Total Power over Ethernet (PoE) budget - 384 W
Power over Ethernet (PoE) Power over Ethernet (PoE) - Yes
Power over Ethernet (PoE) power per port Power over Ethernet (PoE) - 30 W
Power over Ethernet (PoE) type supported Power over Ethernet (PoE) - PoE+
Power over Ethernet plus (PoE+) ports quantity Power over Ethernet (PoE) - 24
Power source Power - AC
Power supply - 100240V AC, 50/60Hz
Power supply - External
Power supply included Power - Yes
producer - TP-LINK
producerCode - ES228GMP
Product colour Design - Black
ProductName - ES228GMP
productName - TP-Link Omada ES228GMP network switch Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black
productSize - Normal
QoS - Port-based QoS/802.1p/DSCP 8 priority queues Priority scheduling mode WRR (Weighted Round Robin) Queue weight configuration Bandwidth control Port-based rate limiting Storm control Multiple control modes (kbps / pps) Broadcast/Multicast/Unknown-Unicast transmission control
Quality of Service (QoS) support Management features - Yes
Queue scheduling algorithms Security - Weighted Round Robin (WRR)
Quick start guide Packaging content - Yes
Rack mounting Design - Yes
Rack mount kit Packaging content - Yes
Security -
Security - DHCP features - DHCP client
Security - IGMP snooping - Yes
Security - Queue scheduling algorithms - Weighted Round Robin (WRR)
Series - Omada
SFP module slots quantity Ports & interfaces - 2
Short description - TP-LINK Switch Omada ES228GMP 28xGBit 24xPoE+ Managed
ShortSummaryDescription - TP-Link Omada ES228GMP, Managed, L2, Gigabit Ethernet (10/100/1000), Power over Ethernet (PoE), Rack mounting
sizeX - 536
sizeY - 104
sizeZ - 476
Stck_Kart - 1
Stck_Pal - 3
Storage relative humidity (H-H) Operational conditions - 5 - 90%
Storage temperature (T-T) Operational conditions - -40 - 70 °C
Store-and-forward Data transmission - Yes
Storno - Y
Summary - TP-Link Omada ES228GMP. Switch type: Managed, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 26. MAC address table: 8000 entries, Switching capacity: 56 Gbit/s. Networking standards: IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3i,.... Power over Ethernet (PoE). Rack mounting
Supported protocols and standards -
Support for Jumbo frames - Yes
Surge protection Power - Yes
Surge protection voltage Power - 6 kV
Switch class - Managed
Switching capacity Data transmission - 56 Gbit/s
Switch layer - L2
Switch layer Management features - L2
Switch type Management features - Managed
Throughput - 56 Gb/s
Title - TP-Link Omada ES228GMP network switch Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black
Total Power over Ethernet (PoE) budget Power over Ethernet (PoE) - 384 W
Unified static configuration Management features - Yes
Unit Box Height - 0.47
Unit Box Length - 0.53
Unit Box Width - 0.1
Unit Calculated Volume - 0.02491 cubm
Unit Calculated Weight - 6.125 kg
Units per Shipping Box - 1
URL - https://www.omadanetworks.com/en/business-networking/omada-switch-agile/es228gmp/
Vendor Homepage - https://www.omadanetworks.com/en/business-networking/omada-switch-agile/es228gmp/
vendpn - ES228GMP
Virtual LAN features Network - MTU VLAN, Port-based VLAN, Tagged VLAN
VLAN - MTU VLAN Port-based VLAN 802.1Q Tag VLAN Max. 32 VLAN groups 4K VID
VLAN support Network - Yes
Warranty - 60 months
WarrantyInfo -
warrantyLength - 60
warrantyType - G
Web-based management Management features - Yes
Weight - 6.12
weight - 6160
Weight & dimensions - Depth - 330 mm
Weight & dimensions - Height - 44 mm
Weight & dimensions - Width - 440 mm
Width Weight & dimensions - 440 mm
