2.5G Ethernet (copper) ports quantity Ports & interfaces - 5
10/100/1000/2500 Mbps ports - 5
10G support Network - No
AC adapter included Packaging data - Yes
Accessories included -
Application - Home and small office
Basic switching RJ-45 Ethernet ports quantity Ports & interfaces - 5
Basic switching RJ-45 Ethernet ports type Ports & interfaces - 2.5G Ethernet (100/1000/2500)
brand - Ubiquiti
Broadcast storm control Network - Yes
category - Mājas un biroju tīkli > Komutatori > 1G komutatori
Category 1 - Netzwerk
Category 2 - Switching Hubs
Category Code - SWI
Category_1 - Network and Servers
Category_2 - Network - Routers
Certificates -
Certificates - Certification - CE, FCC, IC
Certificates - Compliance certificates - CE
Certificates - Compliance certificates - Federal Communications Commission (FCC)
Certificates - Compliance certificates - Industry Canada (IC)
Certification Certificates - CE, FCC, IC
Chassis type - Rack
CnCode - 85176200
Compliance certificates Certificates - CE, Federal Communications Commission (FCC), Industry Canada (IC)
Console port - No
Copper ethernet cabling technology Network - 2.5GBASE-T
Data transmission - Forwarding rate - 18.6 Mpps
Data transmission - Jumbo frames support - Yes
Data transmission - Switching capacity - 25 Gbit/s
Data transmission - Throughput - 12.5 Gbit/s
DC input voltage Power - 5 V
Depth Weight & dimensions - 90 mm
Description - Compact, 5-port 2.5G switch that can be powered with PoE or a USB-C adapter.Optional powering with included 5V, 1A USB-C adapterEthernet In-BandCertifications CE, FCC, IC
Description - Kompaktowy, 5-portowy switch 2.5G, zasilany przez PoE lub adapter USB-C.
Design - Form factor - Desktop
Design - Housing material - Polycarbonate (PC)
Design - LED indicators - Activity
Design - LED indicators - Power
Design - LED indicators - Progress
Design - Product colour - White
Design - Reset button - Yes
Designation - CE+WEEE
dimensionalWeight - 221
dimension depth - 80 mm
dimension height - 100 mm
Dimensions - 117.1 x 90 x 21.2 mm
dimension weight - 380 g
dimension width - 130 mm
ean - 810084696040
EAN - 0810084696040
EAN_code - 0810084696040
Environment requirements - Temperatura otoczenia podczas pracy: -20 do 45°C Wilgotność otoczenia podczas pracy: 10% do 90% (bez kondensacji)
Fan - No
Flow control support Network - Yes
Form factor Design - Desktop
Forwarding mode - Store-and-forward
Forwarding rate - 19 Mpps
Forwarding rate Data transmission - 18.6 Mpps
Gross Weight Kg - 0,3
guarantee - 12
guarantee_type - normal
height - 0.1 m
Height Weight & dimensions - 21.2 mm
Housing material Design - Polycarbonate (PC)
Input current Power - 1 A
Jumbo frames support Data transmission - Yes
L2 features -
L3 features -
LED indicators Design - Activity, Power, Progress
length - 0.13 m
MAC address table size - 4000
Management, monitoring, configuration -
Management features - Switch type - Managed
Manufacturer - Ubiquiti
Manufacturer Code - USW-FLEX-2.5G-5
Manufacturer Name - Ubiquiti Networks
Manufacturer_code - USW-Flex-2.5G-5
Minimum system requirements Performance - UniFi Network Version 8.4.62 and later
Model - USW-FLEX-2.5G-5
Model name - Flex Mini 2.5G
mpn - USW-Flex-2.5G-5
MPN - USW-FLEX-2.5G-5
Multicast features - Multicast support - Yes
Multicast support Multicast features - Yes
Name - 5P Ubiquiti USW-Flex-2.5G-5 M
name - Switch 5P PoE In USW-Flex-2.5G-5
Name - Ubiquiti USW FLEX Mini
Network - 10G support - No
Network - Broadcast storm control - Yes
Network - Copper ethernet cabling technology - 2.5GBASE-T
Network - Flow control support - Yes
Network - Port mirroring - Yes
Network - Rate limiting - Yes
Network architecture - GigabitEthernet
Networking features Other features - STP / RSTP with priorities and port-level disable, Egress rate limit
Number of 10/100 Mbps ports - None
Number of 10/100/1000 Mbps ports - None
Number of 10Gb ports - None
Number of COMBO ports - None
Number of PoE+ ports - None
Number of PoE ports (PoE & PoE+) - 1
Number of ports 25Gb - None
Number of QSFP+ ports - None
Number of SFP+ ports - None
Number of SFP56 ports - None
Number of SFP ports - None
Number of VLAN groups - 256
Operating relative humidity (H-H) Operational conditions - 10 - 90%
Operating temperature (T-T) Operational conditions - -20 - 45 °C
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - -20 - 45 °C
Other features -
Other features - Networking features - STP / RSTP with priorities and port-level disable, Egress rate limit
Other functions -
Packaging data - AC adapter included - Yes
Performance - Minimum system requirements - UniFi Network Version 8.4.62 and later
Port mirroring Network - Yes
Ports & interfaces - 2.5G Ethernet (copper) ports quantity - 5
Ports & interfaces - Basic switching RJ-45 Ethernet ports quantity - 5
Ports & interfaces - Basic switching RJ-45 Ethernet ports type - 2.5G Ethernet (100/1000/2500)
Ports & interfaces - Power connector - USB
Ports & interfaces - USB Type-C ports quantity - 1
Power - DC input voltage - 5 V
Power - Input current - 1 A
Power - Power consumption (max) - 5 W
Power - Power plug type - Type A
Power - Power source - AC/DC/PoE
Power - Power supply included - Yes
Power connector Ports & interfaces - USB
Power consumption - 6.4 W
Power consumption (max) Power - 5 W
Power over Ethernet (PoE) - Power over Ethernet (PoE) - Yes
Power over Ethernet (PoE) - Power over Ethernet (PoE) power per port - 6.4 W
Power over Ethernet (PoE) - Power over Ethernet (PoE) voltage - 57 V
Power over Ethernet (PoE) Power over Ethernet (PoE) - Yes
Power over Ethernet (PoE) power per port Power over Ethernet (PoE) - 6.4 W
Power over Ethernet (PoE) voltage Power over Ethernet (PoE) - 57 V
Power plug type Power - Type A
Power source Power - AC/DC/PoE
Power supply - AC/DC 5W 4.85.2V DC/USB 44V57V PoE
Power supply - External
Power supply included Power - Yes
producer - UBIQUITI
producerCode - USW-Flex-2.5G-5
Product colour Design - White
productName - Ubiquiti UniFi Flex Mini 2.5G Managed 2.5G Ethernet (100/1000/2500) Power over Ethernet (PoE) Desktop White
productSize - Normal
QoS -
Rate limiting Network - Yes
Reset button Design - Yes
Safety warning - Warnings - Avoid contact of the device with liquid.
Safety warning - Warnings - Follow the safety guidelines for electrical current.
Safety warning - Warnings - Make sure the ventilation of the equipment is not blocked.
Security -
Short description - Ubiquiti Switch UniFi 5xRJ45 2.5GBit Compact (incl. NT) Powered by 802.3af/at PoE or USB Type C, Fanless
sizeX - 103
sizeY - 84
sizeZ - 128
Stackability - No
Summary - Ubiquiti UniFi Flex Mini 2.5G. Switch type: Managed. Basic switching RJ-45 Ethernet ports type: 2.5G Ethernet (100/1000/2500), Basic switching RJ-45 Ethernet ports quantity: 5. Switching capacity: 25 Gbit/s. DC input voltage: 5 V. Power connector: USB. Power over Ethernet (PoE). Form factor: Desktop
Supported protocols and standards -
Support for Jumbo frames - Yes
Switch class - Unmanaged
Switching capacity Data transmission - 25 Gbit/s
Switch type Management features - Managed
Throughput - 25 Gb/s
Throughput Data transmission - 12.5 Gbit/s
title - Ubiquiti UniFi Switch Flex Mini 2.5G
Unit Box Height - 0.08
Unit Box Length - 0.122
Unit Box Width - 0.101
Unit Calculated Volume - 0.001429 cubm
Unit Calculated Weight - 0.456 kg
Units per Shipping Box - 18
USB Type-C ports quantity Ports & interfaces - 1
Vendor Homepage - https://eu.store.ui.com/eu/en/products/usw-flex-2-5g-5
vendpn - USW-Flex-2.5G-5
VLAN -
Warranty - 12 months
warrantyLength - 24
warrantyType - G
Weight - 0,38
weight - 0.43 kg
Weight - 0.385
Weight - 206 g
weight - 400
Weight & dimensions - Depth - 90 mm
Weight & dimensions - Height - 21.2 mm
Weight & dimensions - Weight - 206 g
Weight & dimensions - Width - 117.1 mm
Weight Weight & dimensions - 206 g
width - 0.11 m
Width Weight & dimensions - 117.1 mm
