Netgear GS305P-300EUS, 5X 1G POE

Accessories included -
Application - Home and small office
ARTIKEL1 - 5-PORT POE UM PLUS SWITCH
ARTIKEL2 - 1X 1G 4X 1G POE PORT
Brand - NETGEAR
BrandPartCode - GS305P-300EUS
Breite - 0.17
Category - Network Switches
Category - Root/Electronics/Networks and communication/Switchers
Category_1 - Network and Servers
Category_2 - Network - Switches and Hubs
Certificates -
Chassis type - Rack
Dane techniczne: Akcesoria - zasilacz
Dane techniczne: Bufor pamięci - 128 KB
Dane techniczne: Grupa produktowa - Przełączniki Netgear
Dane techniczne: Gwarancja - 5 lat w serwisie zewnętrznym
Dane techniczne: Głębokość - 101 mm
Dane techniczne: Liczba portów LAN 10/100/1000 - 5 szt.
Dane techniczne: Obsługiwane protokoły - IEEE 802.1p
Dane techniczne: Obsługiwane protokoły - IEEE 802.3
Dane techniczne: Obsługiwane protokoły - IEEE 802.3ab
Dane techniczne: Obsługiwane protokoły - IEEE 802.3az
Dane techniczne: Obsługiwane protokoły - IEEE 802.3i
Dane techniczne: Obsługiwane protokoły - IEEE 802.3u
Dane techniczne: Obsługiwane protokoły - IEEE 802.3x flow control
Dane techniczne: Porty PoE - 4 szt.
Dane techniczne: Producent - Netgear
Dane techniczne: Przeznaczenie - biurkowy
Dane techniczne: Prędkość magistrali wew. - 10 Gb/s
Dane techniczne: Rozmiar tablicy adresów MAC - 2000
Dane techniczne: Szerokość - 158 mm
Dane techniczne: Szybkość przekierowań pakietów - 1448 mpps
Dane techniczne: Typ - niezarządzalny
Dane techniczne: Waga - 0.39 kg
Dane techniczne: Wysokość - 29 mm
Data transmission - Jumbo frames - 9216
Data transmission - Jumbo frames support - Yes
Data transmission - MAC address table - 2000 entries
Data transmission - Packet buffer memory - 0.128 MB
Data transmission - Packet forwarding rate (1 Gbps) - 1448000 pps
Data transmission - Switching capacity - 10 Gbit/s
Description - 5-Port Unmanaged Gigabit Ethernet SOHO Switch with 4-Port PoE+ (63W)
5-port Gigabit unmanaged PoE switch with 4 PoE+ ports and a 63W power budget to power wireless access points, IP cameras, IP phones, and more. Ethernet Port Configuration - 5 Gigabit Ports PLUG-AND-PLAY Simple setup with no software to install or configure, and no maintenance required. Complete Performance Non-blocking switching architecture enables maximum wired network throughput. Power-over-Ethernet: 4 PoE+ ports with a combined 63W power budget to power wireless access points, IP cameras, IP phones, and more. Automatic PoE Power Balancing and Allocation NETGEAR's unique PoE technology automatically balances PoE power at the most granular level on each port, based on the device's needs. Quiet Operation: Fanless operation means no additional noise, ideal for use in environments where silence is essential. Energy-Efficient: Designed to optimize energy consumption and reduce operating costs. Versatile Mounting Options Desktop and wall-mountable. Wall-mounting kit included. Standards-Based Design Interoperability with any standard PDS.
Design - LED indicators - Yes
Design - Product colour - Black
Design - Rack mounting - No
Design - Stackable - No
Design - Wall mountable - Yes
Designation - CE+WEEE
dimensionalWeight - 734
dimension depth - 90 mm
dimension height - 170 mm
Dimensions - 158× 101 × 27 mm
dimension weight - 1271 g
dimension width - 240 mm
ean - 606449164909
EAN - 606449164909
EANCode - 0606449164909
Eans - 606449164909
EAN_code - 0606449164909
Environment requirements - Ambient temperature during operation: 0 - 40°C
Fan - No
Gewicht - 1.27
Gross Weight Kg - 0,75
GRUPPE1 - Network
GRUPPE2 - Lan Switch Unmanaged
GTIN - 0606449164909
GTIN - 606449164909
guarantee - 0
guarantee_type - perpetual
HERSTELLER - NETGEAR
Hoehe - 0.09
HSTNUMMER - GS305P-300EUS
Jumbo frame size - 9216 KB
L2 features -
L3 features -
Laenge - 0.25
LongDesc - 5-Port Switch Gigabit Unmanaged PoE switch with 4 PoE+ ports and 63W power budget to power Wireless AP, IP Cameras, IP Phones and more.
LongProductName - 5-Port Gigabit Ethernet SOHO Unmanaged Switch with 4-Ports PoE+ (63W)
LongSummaryDescription - NETGEAR GS305Pv3. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 5. Full duplex. MAC address table: 2000 entries, Switching capacity: 10 Gbit/s. Networking standards: IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x. DC input voltage: 54 V. Power connector: DC-in jack. Power over Ethernet (PoE). Wall mountable
MAC address table size - 2000
Management, monitoring, configuration -
Management features - Quality of Service (QoS) support - Yes
Management features - Switch type - Unmanaged
Manufacturer - Netgear
Manufacturer Code - GS305P-300EUS
Manufacturer Name - Netgear
Manufacturer_code - GS305P-300EUS
Mean time between failures (MTBF) - 4113947 h
Name - Netgear GS305P, Switch (black)
Name - Netgear GS305P-300EUS
name - Switches Unmanaged GS305P-300EUS 5PT GE
Network - 10G support - No
Network - Auto-sensing - Yes
Network - Auto MDI/MDI-X - Yes
Network - Ethernet LAN data rates - 10,100,1000 Mbit/s
Network - Flow control support - Yes
Network - Full duplex - Yes
Network - Half duplex - Yes
Network - Networking standards - IEEE 802.1p
Network - Networking standards - IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
Network - Networking standards - IEEE 802.3
Network - Networking standards - IEEE 802.3ab
Network - Networking standards - IEEE 802.3i
Network - Networking standards - IEEE 802.3u
Network - Networking standards - IEEE 802.3x
Network architecture - GigabitEthernet
Number of 10/100/1000 Mbps ports - 5
Number of PoE+ ports - 4
Operational conditions - Heat dissipation - 228.38 BTU/h
Operational conditions - Operating altitude - 0 - 3000 m
Operational conditions - Operating relative humidity (H-H) - 0 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Other features - 4 PoE+ @ 30W each to meet budget PoE power budget: Up to 63W total Supports Energy Efficient Ethernet (IEEE 802.3az) FCC Rating: Class B
Other functions -
Packet buffer - 128 KB
Performance - Mean time between failures (MTBF) - 4113947 h
Ports & interfaces - Basic switching RJ-45 Ethernet ports quantity - 5
Ports & interfaces - Basic switching RJ-45 Ethernet ports type - Gigabit Ethernet (10/100/1000)
Ports & interfaces - Power connector - DC-in jack
Power - DC input voltage - 54 V
Power - Input current - 1.25 A
Power - Power consumption (max) - 66.78 W
Power - Power source - DC
Power consumption - 66.78 W
Power over Ethernet (PoE) - Power over Ethernet (PoE) - Yes
Power over Ethernet (PoE) - Power over Ethernet (PoE) power per port - 30 W
Power over Ethernet (PoE) - Total Power over Ethernet (PoE) budget - 63 W
Power supply -
Producent: Nazwa producenta / importera - NetgearNETGEAR6th Floor, Penrose Two, Penrose DockT23 YY09 CorkIrlandiaEmail: emea.orders@netgear.com
producer - Netgear
Producer - Netgear
producerCode - GS305P-300EUS
ProducerCode - GS305P-300EUS
ProductName - GS305Pv3
productName - NETGEAR GS305Pv3 Unmanaged Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black
productSize - Normal
QoS - IEEE 802.1p QoS
Security -
ShortDescription -
Short description - Netgear 5Port Switch 10/100/1000 GS305P
ShortSummaryDescription - NETGEAR GS305Pv3, Unmanaged, Gigabit Ethernet (10/100/1000), Full duplex, Power over Ethernet (PoE), Wall mountable
sizeX - 90
sizeY - 240
sizeZ - 170
Stck_Kart - 10
Stck_Pal - 450
Storno - Y
Supported protocols and standards -
Support for Jumbo frames - Yes
Switch class - Unmanaged
Title - NETGEAR GS305Pv3 Unmanaged Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black
URL - https://www.netgear.com/business/wired/switches/unmanaged/gs305p/
vendpn - GS305P-300EUS
VLAN -
WarrantyInfo -
warrantyLength - 36
warrantyType - F
Weight - 0.4 kg
Weight - 1,25
weight - 1270
Weight & dimensions - Depth - 101 mm
Weight & dimensions - Height - 27 mm
Weight & dimensions - Weight - 400 g
Weight & dimensions - Width - 158 mm
