Accessories included - 1x IB-DK4080AC 1x USB Type-C to Type-A adapter 1x Manual
Brand - ICY BOX
BrandPartCode - 60980
Category - Laptop Docks & Port Replicators
Category_1 - Hard Drives and Pendrives
Category_2 - Docking stations for HDD
Code - IB-DK4080AC
Color - Black
Compatible with -
Description - 9-in-1
USB Type-C & Type-A dock with dual video output IB-DK4080AC MOBILE DOCK WITH DUAL 4K: Provided the latest DisplayLink driver software is installed, up to two 4K@60 Hz monitors can be connected either via DisplayPort or HDMI QUICKLY ON THE MOVE: Via a host PC with USB 3.1 Gen 2 or Thunderbolt 3/4 technology, data transfer rates of up to 5 Gbit/s are available at the additional USB Type-A ports. A headset jack is mandatory STABLE ON THE WEB: If you want to exploit maximum data transfer rates with maximum security, then a LAN cable connection is preferable to WLAN, in the home office as well as in the office AVAILABLE IF NEEDED: Supports PD up to 100 watts via a supported PD Type-C host connection once an appropriate power supply is connected (power supply not included) OPTIMISED HEAT DISSIPATION: The enclosure in cooling fin design is made of heat-conductive aluminium. This keeps the temperature inside constant during more intensive demands by dissipating the heat that forms
Design > Cable length - 0.18 m
Designation - CE+WEEE
dimension depth - 25 mm
dimension height - 200 mm
Dimensions - 66x154x18 mm
dimension weight - 260 g
dimension width - 100 mm
Docking connector - No
EAN - 4250078173144
ean - 4250078173144
EAN_code - 4250078173144
GTIN - 4250078173144
guarantee - 24
guarantee_type - normal
I/O ports - 1 x 3,5 mm minijack (Combo)
I/O ports - 1 x RJ-45 (LAN)
I/O ports - 1 x USB power
I/O ports - 2 x DisplayPort
I/O ports - 2 x HDMI Type A
I/O ports - 3 x USB 3.1 Type A
Logistics data - Master (outer) case gross weight - 11.1 kg
Logistics data - Master (outer) case height - 205 mm
Logistics data - Master (outer) case length - 440 mm
Logistics data - Master (outer) case width - 345 mm
Logistics data - Products per master (outer) case - 42 pc(s)
LongDesc - Performance and handling in symbiosisOur new DockingStation IBDK4080AC features the best possible performance in the smallest possible size. We have developed a mobile dock that is an essential accessory for every PC and MacBook owner, whether you work on the road, at home or in the officeC becomes A It doesn't matter whether the host computer is equipped with a USB Type-C or Type-A interface, the 4K monitor support remains the same. The only requirement is that the minimum USB standard USB 3.2 Gen 1 is supported. The matching adapter is included in the scope of delivery. Power Delivery works too The possibility of connecting a headset is just as obligatory as the support of Power Delivery up to 100 watts via a supported PD Type-C® host connection as soon as a corresponding power supply unit is connected. Note: Power supply unit is not included in the scope of delivery.
LongProductName - 9-in-1 USB Type-C & Type-A dock with dual video output
LongSummaryDescription - ICY BOX IB-DK4080AC. Connectivity technology: Wired, Host interface: USB 3.2 Gen 1 (3.1 Gen 1) Type-C, USB Power Delivery up to: 100 W. Ethernet LAN data rates: 10,100,1000 Mbit/s. Product colour: Black, Data transfer rate: 5 Gbit/s, Maximum digital resolution: 3840 x 2160 pixels. USB cable length: 0.18 m. Other operating systems supported: ChromeOS
Manufacturer - Icy Box
Manufacturer_code - 60980
Name - ICY BOX IB-DK4080AC, docking station (HDMI, USB-C, USB-A, DisplayPort, RJ-45)
name - ICY BOX IB-DK4080AC 9in1, Dual Video
Name - Raidsonic | Icy Box 9-in-1 USB Type-C and Type-A dock with dual video output | IB-DK4080AC | Dock | Ethernet LAN (RJ-45) ports 1 | USB 2.0 ports quantity 3 | HDMI ports quantity 2 | Ethernet LAN
Network - Ethernet LAN - Yes
Network - Ethernet LAN data rates - 10,100,1000 Mbit/s
Networking > Ethernet LAN - Yes
Other features -
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 25.00 mm
Package features > Gross height (mm) - 200.00 mm
Package features > Gross width (mm) - 100.00 mm
Package features > Packing quantity - 1.00 pc(s)
Package features > Palette Qty - 3456 pc(s)
Package features > Paper/Pasteboard - 180.00 g
Package features > Plastic (No PET) - 70.00 g
Package features > Tare weight (kg) - 0.07 kg
Package features > Volume (m3) - 0.00 m³
Package features > WEE classification - CL109:6:2017-04-01
Package features > WEEE tax - Yes
Packaging content - Manual - Yes
Packaging data - Package depth - 100 mm
Packaging data - Package height - 200 mm
Packaging data - Package weight - 239 g
Packaging data - Package width - 25 mm
Packaging data - Quantity per pack - 1 pc(s)
Performance - Country of origin - China
Performance - Data transfer rate - 5 Gbit/s
Performance - Housing material - Aluminium, Plastic
Performance - LED indicators - Power
Performance - Maximum digital resolution - 3840 x 2160 pixels
Performance - Maximum refresh rate - 60 Hz
Performance - Product colour - Black
Performance - UASP support - Yes
Ports & interfaces - Combo headphone/mic port - Yes
Ports & interfaces - Connectivity technology - Wired
Ports & interfaces - DisplayPorts quantity - 2
Ports & interfaces - HDMI ports quantity - 2
Ports & interfaces - Headphone outputs - 1
Ports & interfaces - Host interface - USB 3.2 Gen 1 (3.1 Gen 1) Type-C
Ports & interfaces - Microphone in - Yes
Ports & interfaces - USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity - 3
Ports & interfaces - USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity - 1
Ports & interfaces - USB Power Delivery (USB PD) - Yes
Ports & interfaces - USB Power Delivery up to - 100 W
Ports & interfaces > Ethernet LAN (RJ-45) ports - 1
Ports & interfaces > HDMI ports quantity - 2
Ports & interfaces > Host interface - 1x USB 3.2 Gen 1 Type-C to USB Type-C
Ports & interfaces > USB 2.0 ports quantity - 3
Ports & interfaces > USB 3.0 (3.1 Gen 1) Type-A ports quantity - 3
Power - USB cable length - 0.18 m
producer - IcyBox
Producer product family - Icy Box 9-in-1 USB Type-C and Type-A dock with dual video output
Producer product name - IB-DK4080AC
ProductName - IB-DK4080AC
ShortSummaryDescription - ICY BOX IB-DK4080AC, Wired, USB 3.2 Gen 1 (3.1 Gen 1) Type-C, 100 W, 10,100,1000 Mbit/s, Black, 5 Gbit/s
Software - Mac operating systems supported - Yes
Software - Other operating systems supported - ChromeOS
Software - Windows operating systems supported - Yes
System Requirements -
Technical details > Gross weight - 0.23 kg
Technical details > Net weight - 0.16 kg
Technical details > Producer - Raidsonic
Technical details > Type - Dock
Title - ICY BOX IB-DK4080AC Wired USB 3.2 Gen 1 (3.1 Gen 1) Type-C Black
URL - https://icybox.de/en/product.php?id=577
vendpn - IB-DK4080AC
Warranty - 12
Warranty - 12 month(s)
WarrantyInfo -
Weight - 0,24
Weight - 0.163 kg
Weight & dimensions - Depth - 154 mm
Weight & dimensions - Height - 1 mm
Weight & dimensions - Weight - 163 g
Weight & dimensions - Width - 66 mm
