Tecnoware UPS/AVR ERA PLUS 1600VA/FGCERAPL1602SCH

AC outlets quantity Ports & interfaces - 2 AC outlet(s)
AC outlet types Ports & interfaces - Type F
Automatic Voltage Regulation (AVR) Features - Yes
Battery technology Battery - Sealed Lead Acid (VRLA)
Category Code - UPW
Certification Certificates - CE
Depth Weight & dimensions - 279 mm
Description - UPS ERA PLUS 1600VA, 12V 11Ah battery, It has 1 fixed SCHUKO input cable and 2 SCHUKO outputs protected against blackout, overvoltages and undervoltages. Line Interactive Plus technology. Dimensions 10x14x28 cm, weight 5.5 kg. Equipped with On-Off button with integrated multifunction LED with audible alarm for signaling the operating status and USB interface for controlling UPS continuity and programming on / off via the free tecnomanager win / mac software. Designed to protect PC Office, DVR for video surveillance, ADSL-Fiber Modem / router, Cash Register. Totally silent.Complete protection against blackout and power surges (overvoltages and undervoltages)Recommended for Personal Computers, DVR / NVR and video surveillance systems, ADSL / fiber modem, switch / router, cash registersNot suitable with power supplies with Active PFC circuit (Server, PC game, video game console, workstation, Mac computer), lamps and electric motorsAVR Automatic Voltage Regulator electronic circuitn 2 Italy / Schuko output sockets and n 1 schuko input cableoutputs socket protected against blackoutoutputs socket protected against overvoltagesmultifunction LED and on-off buttonUSB port for UPS control / monitoring and ignition programming / shutdown via Tecnomanager softwareUPS management software TecnoManager compatible with Windows, Mac OS X, Linux etc
Form factor Design - Compact
Height Weight & dimensions - 142 mm
Input frequency Features - 50/60 Hz
Input operation voltage (max) Features - 276 V
Input operation voltage (min) Features - 172.5 V
International Protection (IP) code Design - IP20
LED indicators Design - Yes
Noise level Features - 40 dB
Number of input phases Features - 1
Number of output phases Features - 1
Operating altitude Operational conditions - 0 - 300 m
Operating relative humidity (H-H) Operational conditions - 0 - 95%
Operating temperature (T-T) Operational conditions - 0 - 55 °C
Output frequency Features - 50/60 Hz
Output operation voltage (max) Features - 230 V
Output operation voltage (min) Features - 230 V
Output power capacity Features - 1.6 kVA
Output power Features - 1120 W
Output voltage regulation Features - 5%
Package depth Packaging data - 340 mm
Package height Packaging data - 220 mm
Package width Packaging data - 180 mm
Power factor Features - 0.7
Product colour Design - Black
Response time Features - 2 ms
Summary - Tecnoware Era Plus 1600. UPS topology: Line-Interactive, Output power capacity: 1.6 kVA, Output power: 1120 W. AC outlet types: Type F, AC outlets quantity: 2 AC outlet(s), USB port type: USB Type-B. Battery technology: Sealed Lead Acid (VRLA), Typical backup time at full load: 10 min. Form factor: Compact, Product colour: Black, International Protection (IP) code: IP20. Certification: CE
Typical backup time at full load Battery - 10 min
Unit Box Height - 0.22
Unit Box Length - 0.34
Unit Box Width - 0.18
Unit Calculated Volume - 0.01346 cubm
Unit Calculated Weight - 5.35 kg
Units per Shipping Box - 1
UPS topology Features - Line-Interactive
USB 2.0 ports quantity Ports & interfaces - 1
USB port Ports & interfaces - Yes
USB port type Ports & interfaces - USB Type-B
Vendor Homepage - https://www.tecnoware.com/en-US/Dettaglio/Articolo/56
Warranty - 24/12L months
Waveform Features - Sine
Weight Weight & dimensions - 5 kg
Width Weight & dimensions - 101 mm
