APC Back-UPS BX2200MI 2200VA, 1200W, IEC

Accessories included -
ACoutletsquantity - 6 AC outlet(s)
ACoutlettypes - C13 coupler
Active power - 1200 W
Apparent power - 2200 VA
ARTIKEL1 - APC BACK-UPS 2200VA 230V AVR
ARTIKEL2 - IEC SOCKETS
AutomaticVoltageRegulationAVR - Yes
Backup time (100% load) - 1 min
Battery -
Battery - Battery life (max) - 2 year(s)
Battery - Battery recharge time - 8 h
Battery - Battery technology - Sealed Lead Acid (VRLA)
Battery - Typical backup time at full load - 1 min
Battery - Typical backup time at half load - 8.5 min
Batterycapacity -
Batterytechnology - Sealed Lead Acid (VRLA)
Batteryvoltage -
Brand - APC
BrandPartCode - BX2200MI
Cablesincluded - Input power cable
Category - Root/Accessories | Exploitation/Power supply/UPSs and power strips/UPSs
Category - Uninterruptible Power Supplies (UPSs)
Category 1 - Energie & USV
Category 2 - USV & Stromversorgung
Category_1 - Power
Category_2 - UPS
Certificates - Certification - CB Meet EN62040-1 / CE / IEC-62040-1 / IEC-62040-2
Certificates - Compliance certificates - RoHS
Charging time - 6 h
Chassis type - Tower
Code - BX2200MI
Color - Black
Depth - 390 mm
Depth, mm - 390
Description - APC BACK-UPS 2200VA, 230V, AVR, IEC SOCKETS
Description - Seria APC Back-UPS BX to ekonomiczne rozwiązanie do ochrony zasilania w domu i biurze domowym. Szeroka gama serii VA z funkcjami premium dodatkowo umożliwia wykorzystanie możliwości pojedynczego zasilacza UPS
Design -
Design - Cable length - 1.2 m
Design - Form factor - Compact
Design - International Protection (IP) code - IP20
Design - LED indicators - Yes
Design - Product colour - Black
Designation - CE+WEEE
dimension depth - 240 mm
dimension height - 490 mm
Dimensions - 190 x 140 x 390 mm
dimension weight - 9000 g
dimension width - 290 mm
Displaytype -
EAN - 731304410836
ean - 731304410836
EAN - 0731304410836
EANCode - 0731304410836
Eans - 0731304410836
EAN_code - 0731304410836
Efficiency -
Environment requirements - Środowisko pracy: 0 - 40 °C Wilgotność względna podczas pracy: 0 - 95% Wysokość robocza: 0-3000 metrów Temperatura przechowywania: 15 - 40 °C Wilgotność względna przechowywania: 0-95%
Features -
Features - Audible alarm(s) - Yes
Features - Audible alarm modes - Low battery alarm
Features - Automatic Voltage Regulation (AVR) - Yes
Features - Input frequency - 50/60 Hz
Features - Input operation voltage (max) - 300 V
Features - Input operation voltage (min) - 140 V
Features - Input power factor - 0.54
Features - Noise level - 40 dB
Features - Output frequency - 50/60 Hz
Features - Output frequency regulation - 0.5 Hz
Features - Output operation voltage (max) - 230 V
Features - Output operation voltage (min) - 230 V
Features - Output power - 1200 W
Features - Output power capacity - 2.2 kVA
Features - Output voltage regulation - 10%
Features - Response time - 6 ms
Features - Surge energy rating - 273 J
Features - Surge protection - Yes
Features - UPS topology - Line-Interactive
Features - Waveform - Sine
Formfactor - Compact
Form factor - Tower
Gross Weight Kg - 13,3
GRUPPE1 - Power Protection
GRUPPE2 - UPS (Uninterruptable Power Supply)
GTIN - 731304410836
GTIN - 0731304410836
guarantee - 24
guarantee_type - external
Heatdissipation -
Height - 190 mm
Height - 290.000000
Height, mm - 190
HERSTELLER - APC
HighLights -
Hotswapbattery -
HSTNUMMER - BX2200MI
I/O connectors - 1 x USB (Type B)
I/O connectors - 2 x RJ-45 (iLO Remote Management Network)
Inputfrequency - 50/60 Hz
Inputoperationvoltagemax - 300 V
Inputoperationvoltagemin - 140 V
Input power ports - IEC-C19
Length - 495.000000
Link - https://www.se.com/lt/lt/product/BX2200MI/apc-backups-2200va-bok%C5%A1tas-230v-6x-iec-c13-lizdai-avr/
Logistics data - Harmonized System (HS) code - 85078000
LongDesc -
LongDesc - This APC Back-UPS offers power and surge protection for wireless networks, computers, gaming consoles and other electronics in your home or business. The 2200VA tower UPS has 6 total outlets, 4 of which are battery back up and surge protection, and 2 that are surge protection only. It has a surge energy rating of 273 Joules. It features Automatic Voltage Regulation to correct voltage dips and surges to proper levels. This UPS has a 2-year warranty and CE product certification.
LongProductName - Back-UPS, 2200VA, Tower, 230V, 6x IEC C13 outlets, AVR
LongSummaryDescription - APC Back-UPS, 2200VA, Tower, 230V, 6x IEC C13 outlets, AVR. UPS topology: Line-Interactive, Output power capacity: 2.2 kVA, Output power: 1200 W. AC outlet types: C13 coupler, Power plug: C19 coupler, AC outlets quantity: 6 AC outlet(s). Battery technology: Sealed Lead Acid (VRLA), Typical backup time at full load: 1 min, Typical backup time at half load: 8.5 min. Form factor: Compact, Product colour: Black, Cable length: 1.2 m. Compliance certificates: RoHS, Certification: CB Meet EN62040-1 / CE / IEC-62040-1 / IEC-62040-2
Manufacturer - APC
Manufacturer Code - BX2200MI
Manufacturer Name - APC by Schneider Electric
ManufacturerPartNumber - BX2200MI
Manufacturer_code - BX2200MI
ManufDatasheet - https://www.tdbaltic.ee/leaflets/APC/BX2200MI.pdf
MPN - BX2200MI
Name - APC Back-UPS 2200 Tower BX2200MI 2200VA 1200W
Name - APC Back-UPS BX MI 2200VA / 230V IEC
Name - APC Back BX2200MI
name - BX2200MI Back-UPS 2200VA, 230V, AVR, 6 IEC
Name - Schneider Electric APC Back-UPS | BX2200MI | 2200 VA | 1200 W
Networkcardslot -
No. of batteries - 1
Noiselevel - 40 dB
Nominal input voltage, V - 230
Nominal output voltage, V - 230
Numberofbatterycells -
Numberofinputphases -
Numberofoutputphases -
Number of phases input - 1 (230V)
Operatingaltitude - 0 - 3000 m
OperatingrelativehumidityHH - 0 - 95%
OperatingtemperatureTT - 0 - 40 °C
Operationalconditions -
Operational conditions - Operating altitude - 0 - 3000 m
Operational conditions - Operating relative humidity (H-H) - 0 - 95%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage temperature (T-T) - -15 - 40 °C
Other features -
Other features > Special features - Compact size allows installation in a variety of environments; AVR corrects voltage fluctuations to ensure reliable power supply; LED display allows easy reading of device status and power conditions
Outputfrequency - 50/60 Hz
Outputoperationvoltagemax - 230 V
Outputoperationvoltagemin - 230 V
Outputpower - 1200 W
Outputpowercapacity - 2.2 kVA
Output power capacity (VA) - 2200
Output power ports - 6 x IEC-C13
Package features > Classification of battery - CL126:NE:2016-12-09
Package features > Composition of battery - CL127:KT:2016-12-09
Package features > Embeeded battery - Yes
Package features > Gross depth (mm) - 297.00 mm
Package features > Gross height (mm) - 495.00 mm
Package features > Gross width (mm) - 235.00 mm
Package features > Packing quantity - 1.00 pc(s)
Package features > Palette Qty - 50 pc(s)
Package features > Paper/Pasteboard - 800.00 g
Package features > Plastic (No PET) - 200.00 g
Package features > Tare weight (kg) - 1.00 kg
Package features > TI weight (kg) - 5.32 kg
Package features > Type of battery - Accumulator
Package features > Volume (m3) - 0.03 m³
Package features > WEE classification - CL109:5:2017-04-01
Package features > WEEE tax - Yes
Packagingcontent -
Packaging content - Cables included - Input power cable
Packaging content - Manual - Yes
Packaging data - Package depth - 495 mm
Packaging data - Package height - 297 mm
Packaging data - Package weight - 13.3 kg
Packaging data - Package width - 235 mm
Performance > Capacity - 2200 VA
Performance > UPS topology - Line-Interactive
PeriodofWarranty - 2 Y
Ports & interfaces - AC outlets quantity - 6 AC outlet(s)
Ports & interfaces - AC outlet types - C13 coupler
Ports & interfaces - Power plug - C19 coupler
Ports & interfaces - USB 2.0 ports quantity - 1
Ports & interfaces - USB port - Yes
Ports & interfaces - USB port type - USB Type-B
Portsinterfaces -
Powerfactor -
Powerplug - C19 coupler
ProdDesc - APC Back-UPS 2200VA, 230V, AVR, IEC Sockets
producer - APC
Producer - APC
ProducerCode - BX2200MI
Productcolour - Black
Productcondition - Original
ProductHighLights -

• Line-Interactive
• 2.2 kVA 1200 W
• Waveform: Sine
• 6 AC outlet(s)
• Sealed Lead Acid (VRLA)
• Compact Black

ProductName - Back-UPS, 2200VA, Tower, 230V, 6x IEC C13 outlets, AVR
ProductPicture - https://www.tdbaltic.ee/images/products/APC/BX2200MI_1.jpg
ProductPicture1 - https://www.tdbaltic.ee/images/products/APC/BX2200MI_2.jpg
ProductPicture2 - https://www.tdbaltic.ee/images/products/APC/BX2200MI_3.jpg
ProductPicture3 - https://www.tdbaltic.ee/images/products/APC/BX2200MI_4.jpg
ProductPicture4 - https://www.tdbaltic.ee/images/products/APC/BX2200MI_5.jpg
ProductPicture5 - https://www.tdbaltic.ee/images/products/APC/BX2200MI_6.jpg
Quickinstallationguide -
Rackmountkit -
RS232ports -
Serialinterface -
Serialinterfacetype -
Serialportsquantity -
ShortDescription -
Short description - APC Back-UPS BX 2200 VA BX2200MI
ShortSummaryDescription - APC Back-UPS, 2200VA, Tower, 230V, 6x IEC C13 outlets, AVR, Line-Interactive, 2.2 kVA, 1200 W, Sine, 140 V, 300 V
Software -
Special functions - AVR
Stck_Kart - 1
Stck_Pal - 18
Storno - Y
Technical details > Capacity - 1200 W
Technical details > Gross weight - 13.30 kg
Technical details > Net weight - 12.30 kg
Technical details > Producer - Schneider Electric
Technical details > Producer product family - APC Back-UPS
Technical details > Producer product name - BX2200MI
Title - APC Back-UPS, 2200VA, Tower, 230V, 6x IEC C13 outlets, AVR
Typicalbackuptimeathalfload - 8.5 min
UPS Architecture - line-interactive
UPS devices and accessories - Yes
UPStopology - Line-Interactive
URL - https://www.apc.com/
USBport - Yes
USBporttype - USB Type-B
vendpn - BX2200MI
Warranty - 24
Warranty - 24 month(s)
Warranty - 24 months
Warrantyandmisc -
WarrantyInfo - 2 years
Waveform - Sine
Weight - 12.3 kg
Weight - 12.3 kg
Weight - 13,95
Weight - 14.6
Weight - 14.130000
Weight & dimensions - Depth - 390 mm
Weight & dimensions - Height - 190 mm
Weight & dimensions - Weight - 12.3 kg
Weight & dimensions - Width - 140 mm
Weight, kg - 12.3
Weightdimensions -
Width - 140 mm
Width - 230.000000
Width, mm - 140
