Accessories included - 2 IEC10A output wires (1.8 m), 1 European 16A power cord (1.8 m), Rack mounting kit, 1 USB cable (1.8 m), 1 serial cable (1.8 m), Short instruction manual, Safety instructions.
ACoutletsquantity - 9 AC outlet(s)
AC outlets quantity Ports & interfaces - 9 AC outlet(s)
ACoutlettypes - C13 coupler, C19 coupler
AC outlet types Ports & interfaces - C13 coupler, C19 coupler
Active power - 2700 W
Apparent power - 3000 VA
ARTIKEL1 - EATON 9SX 3000I RACK2U
ARTIKEL2 - .
AutomaticVoltageRegulationAVR -
Battery -
Batterycapacity -
Batterytechnology -
Batteryvoltage -
Breite - 0.59
Cablesincluded -
Category - Root/Accessories | Exploitation/Power supply/UPSs and power strips/UPSs
Category Code - UPW
Certificates > Certification - IEC/EN 62040-1, UL 1778, IEC/EN 62040-2, CE, cULus Listed, EAC
Certification Certificates - IEC/EN 62040 -2 , FCC B, CISPR22 B, CE /CB (TUV) / cULus / EAC / RCM
Charging time - 22 min
Chassis type - Rack
Code - 9SX3000IR
Color - Black
Depth - 608 mm
Depth Weight & dimensions - 608 mm
Description - UPS with double conversion online, 2U Rackmount, 3000 VA / 2700 W, multilingual LCD display, energy meter, 6 IEC 10 A + IEC 16 A (2 manageable groups), slot for optional management board, USB and serial ports, contacts potential free, RPO connector, power management software compatible with the virtual environment, batteries replaceable during operation, long emergency operation time with four optional EBM modules, all accessories for mounting in a rack in the set.
Design -
Design > Form factor - Rack
Designation - CE+WEEE
dimension depth - 245 mm
dimension height - 780 mm
Dimensions - 86,5 x 438 x 608 mm
dimension weight - 33200 g
dimension width - 578 mm
Displaytype - LCD
Display type Design - LCD
EAN - 743172091147
ean - 743172091147
EANCode - 0743172091147
Eans - 743172091147
Efficiency -
Environment requirements - Temperature during operation: 0-40°C Noise level: 45 dB
Features -
Features > Colour of product - Black
Filters / protection - Overdischarge
Formfactor - Rackmount
Form factor Design - Rackmount
Gewicht - 35.5
GRUPPE1 - Power Protection
GRUPPE2 - UPS (Uninterruptable Power Supply)
guarantee - 24
guarantee_type - external
Heatdissipation -
Height - 86.5 mm
Height Weight & dimensions - 86.5 mm
HERSTELLER - EATON
HighLights -
Hoehe - 0.26
Hotswapbattery -
HSTNUMMER - 9SX3000IR
I/O connectors - 1 x RS-232 (COM)
I/O connectors - 1 x USB 2.0
Inputfrequency - 40 - 70 Hz
Input frequency Features - 40 - 70 Hz
Input operation voltage (max) Features - 276 V
Input operation voltage (min) Features - 200 V
Inputoperationvoltagemax - 276 V
Inputoperationvoltagemin - 200 V
Input power ports - IEC-C20
Laenge - 0.79
Link - https://www.eaton.com/gb/en-gb/skuPage.9SX3000IR.html
LongDesc -
ManufDatasheet -
Maximum current Features - 16 A
Name - Eaton 9SX3000IR
Name - Eaton | UPS | 9SX 3000i Rack2U | 3000 VA | 2700 W
name - UPS 9SX 1000i Rack2U LCD/USB/RS232
Networkcardslot -
Noiselevel - 45 dB
Noise level Features - 45 dB
Numberofbatterycells -
Numberofinputphases -
Numberofoutputphases -
Number of phases input - 1 (230V)
Operatingaltitude -
OperatingrelativehumidityHH -
Operating temperature (T-T) Operational conditions - 0 - 40 °C
OperatingtemperatureTT - 0 - 40 °C
Operationalconditions -
Other features - 1 mini-terminal block for remote power off (configurable) 1 block of mini-terminals to the output relay 1 socket for the optional communication module
Outputfrequency - 50/60 Hz
Output frequency Features - 50/60 Hz
Outputoperationvoltagemax -
Outputoperationvoltagemin -
Outputpower - 2700 W
Outputpowercapacity - 3 kVA
Output power capacity Features - 3 kVA
Output power Features - 2700 W
Output power ports - 1 x IEC-C19
Output power ports - 8 x IEC-C13
Package features > Classification of battery - CL126:NE:2016-12-09
Package features > Composition of battery - CL127:KT:2016-12-09
Package features > Embeeded battery - Yes
Package features > Gross depth (mm) - 580.00 mm
Package features > Gross height (mm) - 240.00 mm
Package features > Gross width (mm) - 780.00 mm
Package features > Packing quantity - 1.00 pc(s)
Package features > Palette Qty - 10 pc(s)
Package features > Paper/Pasteboard - 1800.00 g
Package features > Plastic (No PET) - 200.00 g
Package features > Tare weight (kg) - 0.20 kg
Package features > TI weight (kg) - 20.00 kg
Package features > Type of battery - Accumulator
Package features > Volume (m3) - 0.11 m³
Package features > WEE classification - CL109:5:2017-04-01
Package features > WEEE tax - Yes
Packagingcontent -
PDF - https://www.blobs.lt/products/0/4/6/0/9/3/1f4ce16351ec9315b9cbd957ccea063e/original.pdf
Performance > Capacity - 3000 VA
Performance > UPS topology - On line
Portsinterfaces -
Powerfactor -
Powerplug - C20 coupler
Power plug Ports & interfaces - C20 coupler
ProdDesc - Eaton 9SX 3000i Rack2U
producer - Eaton
Producer - Eaton
ProducerCode - 9SX3000IR
Producer product family - UPS
Producer product name - 9SX 3000i Rack2U
Productcolour - Black
Product colour Design - Black
Productcondition - Original
ProductHighLights -
- Double-conversion (Online)
- 3 kVA 2700 W
- 9 AC outlet(s)
- Rackmount Black
ProductPicture - https://www.tdbaltic.ee/images/products/EATON/9SX3000IR_1.jpg
ProductPicture1 -
ProductPicture2 -
ProductPicture3 -
ProductPicture4 -
ProductPicture5 -
Quickinstallationguide -
Rack capacity Design - 2U
Rackmountkit -
RS-232 ports Ports & interfaces - 1
RS232ports - 1
Safety Safety regulation & standards - IEC/EN 62040-1, UL 1778, CSA 22.2
Serialinterface - Yes
Serial interface Ports & interfaces - Yes
Serialinterfacetype - RS-232
Serial interface type Ports & interfaces - RS-232
Serialportsquantity -
ShortDescription -
Software -
Special functions -
Stck_Kart - 1
Stck_Pal - 5
Storno - Y
Summary - Eaton 9SX. UPS topology: Double-conversion (Online), Output power capacity: 3 kVA, Output power: 2700 W. AC outlet types: C13 coupler, C19 coupler, Power plug: C20 coupler, AC outlets quantity: 9 AC outlet(s). Form factor: Rackmount, Product colour: Black, Rack capacity: 2U. Certification: IEC/EN 62040 -2 , FCC B, CISPR22 B, CE /CB (TUV) / cULus / EAC / RCM. Safety: IEC/EN 62040-1, UL 1778, CSA 22.2
Technical details > Capacity - 2700 W
Technical details > Gross weight - 26.70 kg
Technical details > Net weight - 26.50 kg
Technical details > Producer - Eaton
Typicalbackuptimeathalfload -
Unit Box Height - 0.235
Unit Box Length - 0.78
Unit Box Width - 0.58
Unit Calculated Volume - 0.1063 cubm
Unit Calculated Weight - 35.6 kg
Units per Shipping Box - 1
UPS Architecture - on-line double conversion
UPStopology - Double-conversion (Online)
UPS topology Features - Double-conversion (Online)
USBport - Yes
USB port Ports & interfaces - Yes
USBporttype -
Vendor Homepage - https://www.eaton.com/gb/en-gb/skuPage.9SX3000IR.html
vendpn - 9SX3000IR
Video -
Voltage - 230 V
Warranty - 12 months
Warranty - 24
Warranty - 24 month(s)
Warranty - 24 months
Warrantyandmisc -
Waveform -
Weight - 26.5 kg
Weight - 26.5 kg
Weightdimensions -
Weight Weight & dimensions - 26.5 kg
Width - 438 mm
Width Weight & dimensions - 438 mm
