Eaton UPS 9PX 5000i RT3U HotSwap Netpack G2

Accessories included - UPS power supply 2 × cable glands 2 × IEC-to-IEC output cables (1.2 m) USB cable (1.8 m) Network card Maintenance bypass Tower mounting brackets Rack mounting kit with brackets and UPS rails Maintenance bypass installation kit Safety instructions Quick start guide
Active power - 5000 W
Apparent power - 5 kVA
ARTIKEL1 - EATON 9PX 5000I RT3U HOTSWAP
ARTIKEL2 - NETPACK G2
Battery - Automatic battery test - Yes
Battery - Battery capacity - 5 Ah
Battery - Battery technology - Sealed Lead Acid (VRLA)
Battery - Battery voltage - 12 V
Battery - Typical backup time at half load - 9.4 min
Battery capacity - 5 Ah
Brand - Eaton
BrandPartCode - 9PX5KIRTNBPG2
Breite - 0.8
Category - Uninterruptible Power Supplies (UPSs)
Certificates - Certification - IEC/EN 62040-1
IEC/EN 62040-2
IEC/EN 62040-3
Certificates - Compliance certificates - BSMI, CE, Electromagnetic Compatibility (EMC), KCC, Low Voltage Directive (LVD), RCM, REACH, RoHS, UKCA, WEEE, cULus
Chassis type - Rack
Chassis type - Tower
Color - Black
Color - Silver
Data Act - Link
Design - Cable length - 1.8 m
Design - Display type - LCD
Design - Form factor - Rackmount/Tower
Design - LED indicators - Yes
Design - Product colour - Black, Silver
Design - Rack capacity - 4U
Designation - CE+WEEE
dimension depth - 630 mm
dimension height - 650 mm
Dimensions - 130 x 440 x 684 mm
dimension weight - 62000 g
dimension width - 980 mm
ean - 3553340710568
EANCode - 3553340710568
Environment requirements - Altitude: 3,000 m Noise level: below 40 dB at a distance of 1 m Relative humidity: 0-95%, non-condensing Operating temperature range: 0°C to 40°C (32°F to 104°F)
Features - Efficiency - 96.7%
Features - Efficiency (ECO mode) - 99%
Features - Heat dissipation - 563 BTU/h
Features - Input frequency - 40/70 Hz
Features - Input operation voltage (max) - 276 V
Features - Input operation voltage (min) - 100 V
Features - Input power factor - 0.99
Features - Noise level - 37 dB
Features - Number of input phases - 1
Features - Number of output phases - 1
Features - Output frequency - 50/60 Hz
Features - Output operation voltage (max) - 240 V
Features - Output operation voltage (min) - 200 V
Features - Output power - 5000 W
Features - Output power capacity - 5 kVA
Features - Power consumption (average operating) - 214 W
Features - UPS topology - Double-conversion (Online)
Features - Waveform - Sine
Filters / protection - Overdischarge
Gewicht - 73.5
GRUPPE1 - Power Protection
GRUPPE2 - UPS (Uninterruptable Power Supply)
GTIN - 3553340710568
GTIN - 8592978730536
guarantee - 36
guarantee_type - external
HERSTELLER - EATON
Hoehe - 0.73
HSTNUMMER - 9PX5KIRTNBPG2
I/O connectors - 1 x RS-232 (COM)
I/O connectors - 1 x USB (Type B)
Input power ports - Input terminal
Laenge - 1.2
LongDesc - Eaton 9PX Gen2 UPS HotSwap Netpack, 5000 VA, 5000 W, Input: Hardwired, Outputs: (2) C13, (3) C39, Hardwired, Rack/tower, 3U, Gigabit Network card included, Rack-mounting kit included, Maintenance bypass included
LongProductName - 9PX Gen2 UPS, Rack/tower, 4U, 5000VA, 5000W, 230V, LCD, 200-240V, Black/silver, 45.1 kg
LongSummaryDescription - Eaton 9PX 5000i RT3U. UPS topology: Double-conversion (Online), Output power capacity: 5 kVA, Output power: 5000 W. AC outlet types: C13 coupler, C19 coupler. Battery technology: Sealed Lead Acid (VRLA), Battery capacity: 5 Ah, Battery voltage: 12 V. Form factor: Rackmount/Tower, Product colour: Black, Silver, Rack capacity: 4U. Compliance certificates: BSMI, CE, Electromagnetic Compatibility (EMC), KCC, Low Voltage Directive (LVD), RCM, REACH, RoHS,..., Certification: IEC/EN 62040-1 IEC/EN 62040-2 IEC/EN 62040-3
name - UPS 9PX 5000i RT3U HotSwap Netpack G2
No. of batteries - 15
Number of phases input - 1 (230V)
Operational conditions - Operating altitude - 0 - 3000 m
Operational conditions - Operating relative humidity (H-H) - 0 - 95%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Output power ports - 3 x IEC-C13
Output power ports - 3 x IEC-C39
Output power ports - Output terminals
Packaging content - Cables included - Output power cable, USB cable
Packaging content - Quick installation guide - Yes
Packaging content - Rack mount kit - Yes
Ports & interfaces - AC outlet types - C13 coupler, C19 coupler
Ports & interfaces - RS-232 ports - 1
Ports & interfaces - USB port - Yes
producer - Eaton
ProductName - 9PX 5000i RT3U
ShortSummaryDescription - Eaton 9PX 5000i RT3U, Double-conversion (Online), 5 kVA, 5000 W, Sine, 100 V, 276 V
Software - Eaton Brightlayer Software suite
Special functions - ABM+ (predictive battery life monitoring) and temperature-compensated charging (user selectable) Automatic battery test Automatic detection of external battery modules
Stck_Kart - 1
Stck_Pal - 1
Storno - Y
Sustainability - Sustainability certificates - ENERGY STAR
The shape of the output voltage - Full sine wave
Title - Eaton 9PX 5000i RT3U uninterruptible power supply (UPS) Double-conversion (Online) 5 kVA 5000 W
UPS Architecture - on-line double conversion
URL - https://www.eaton.com/de/en-gb/skuPage.9PX5KIRTNBPG2.html
vendpn - 9PX5KIRTNBPG2
Voltage - 12 V
Warranty - 3-year warranty on electronics and 2-year warranty on batteries; after registration, a full 3-year warranty applies.
WarrantyInfo -
Weight - 45.1 kg
Weight & dimensions - Depth - 684 mm
Weight & dimensions - Height - 130 mm
Weight & dimensions - Weight - 45.1 kg
Weight & dimensions - Width - 440 mm
