Digitus UPS External Battery Pack for 1.5kVA UPS Model (Extended Pack) | DN-170121

Accessories included - External Battery for 1.5 kVA Models (Expansion Module) User Manual AC Connecting Cable Battery Connecting Cable
Battery capacity - 9 Ah
Category1 - Adapter
Code - DN-170121
Color - Black
Description - DIGITUS battery modules for uninterruptible power supplies enable UPS solutions used in highly demanding environments to reliably continue powering connected devices even during power outages. Up to four battery modules can be connected to extend the runtime of connected IT devices. This solution ensures that systems are protected by uninterrupted power during battery replacement. External battery modules can provide a quick extension of runtime when power demand increases. Compatible with the OnLine UPS: DN-170094 Rack/Tower conversion option Hot-swappable - battery can be replaced during operation Supports rapid extension of runtime with increasing capacity demand Easy installation - user-replaceable batteries Supports cold start
Description1 - DIGITUS external battery pack for UPS system DN-170094 - 9 Ah
Description2 - The DIGITUS external battery pack is a comprehensive power solution designed to keep your devices running during power outages. With a 9 Ah lead acid battery at its core, this pack offers a reliable, maintenance-free power backup that is both hot-swappable and sealed for maximum convenience. It comes equipped with essential cables and a circuit breaker for protection, ensuring your setup is both safe and efficient. The cold start function allows for activation without AC power, providing flexibility in emergency situations. Designed to fit standard 19" racks, it integrates seamlessly into your existing setup, making it an ideal choice for businesses and individuals seeking a dependable power management solution.
Designation - CE+WEEE
dimension depth - 210 mm
dimension height - 563 mm
Dimensions - (L x W x D): 86.5 x 440 x 430 mm
dimension weight - 25000 g
dimension width - 565 mm
EAN - 4016032487449
ean - 4016032487449
Environment requirements -
guarantee - 24
guarantee_type - external
Link - https://de.assmann.shop/en/IT-Infrastructure/Uninterruptible-Power-Supply-UPS/Server-and-Network/UPS-External-Battery-Pack-for-1-5kVA-UPS-Model-Extended-Pack.html?listtype=search
Manufacturer - Digitus
ManufacturerID - DN-170121
Name - Digitus UPS External Battery Pack for 1.5kVA UPS Model (Extended Pack) | DN-170121
name - UPS Battery Pack DN-170121
No. of batteries - 6
Other features - Gross Weight: 25.1 kg Weight of Individual Lead-Acid Batteries: 2.7 kg Weight of Individual Battery Modules: 22.5 kg Total Lead-Acid Battery Weight: 16.2 kg Battery module can be installed in a 19-inch rack or as a tower with a rack Hot-Swap Battery Battery Voltage: 41 VDC Capacity (Standard Unit): 12 V / 9 Ah Number of Internal Batteries: 6 Batteries in Series: 3 (per battery module) Battery Type: Lead-Acid Typical Charge Time: 12 hours to restore 90% of full capacity Operating Temperature: 20°C to 25°C Operating Humidity: 0 - 90% Rear Terminal Connectors
Package features > Classification of battery - CL126:NE:2016-12-09
Package features > Composition of battery - CL127:KT:2016-12-09
Package features > Embeeded battery - Yes
Package features > Gross depth (mm) - 562.00 mm
Package features > Gross height (mm) - 202.00 mm
Package features > Gross width (mm) - 555.00 mm
Package features > Packing quantity - 1.00 pc(s)
Package features > Palette Qty - 14 pc(s)
Package features > Paper/Pasteboard - 2080.00 g
Package features > Plastic (No PET) - 520.00 g
Package features > Tare weight (kg) - 2.60 kg
Package features > Type of battery - Accumulator
Package features > Volume (m3) - 0.06 m³
Package features > WEE classification - CL109:6:2017-04-01
Package features > WEEE tax - Yes
PackageHeight - 209
PackageLength - 571
PackageWeight - 25000
PackageWidth - 559
producer - Digitus
Technical details > Gross weight - 25.10 kg
Technical details > Net weight - 22.50 kg
Technical details > Producer - Digitus
Technical details > Producer product family - UPS External Battery Pack for 1.5kVA UPS Model (Extended Pack)
Technical details > Producer product name - DN-170121
Type - Battery module
vendpn - DN-170121
Voltage - 12 V
Warranty - 24
Warranty - 24 month(s)
WEEE - DE83654239
Weight - 22.5 kg
