Eaton 5P650IRG2, 650VA 520W, IEC 1U

Accessories included - Zestaw do montażu w szafie rack System blokady przewodów Kabel USB 2 x Przewód IEC-IEC Szybki start Instrukcje dotyczące bezpieczeństwa
ACoutletsquantity - 4 AC outlet(s)
AC outlets quantity Ports & interfaces - 4 AC outlet(s)
ACoutlettypes - C13 coupler
AC outlet types Ports & interfaces - C13 coupler
Active power - 520 W
Apparent power - 650 VA
ARTIKEL1 - EATON 5P 650I RACK 1U G2
ARTIKEL2 - EQUIPMENT (NETWORK SERVER STORAG
Automatic battery test Battery - Yes
AutomaticVoltageRegulationAVR -
Backup time (100% load) - 1 min
Battery -
Batterycapacity -
Battery capacity - 9 Ah
Batterytechnology - Sealed Lead Acid (VRLA)
Battery technology Battery - Sealed Lead Acid (VRLA)
Batteryvoltage -
Breite - 0
Bundled software Packaging data - Intelligent Power Software suite
Cablesincluded -
Category Code - UPW
Certification Certificates - IEC/EN 62040-1, UL 1778, IEC/EN 62040 -2 , IEC/EN 62040-3 (Performance), CE, CB report (TUV)
Chassis type - Rack
Code - 5P650IRG2
Color - Black
Color - Silver
Depth - 361 mm
Depth Weight & dimensions - 361 mm
Description - 5P650IRG2 UPS Eaton 5P, 650 VA, 520 W, wejście: C14, wyjścia: (4) C13, rack, 1U System automatycznej regulacji napięcia (AVR) Ochrona zasilania dla zastosowań o wysokiej gęstości: tylko 1U Energooszczędność, redukcja kosztów energii i chłodzenia Czysta sinusoida na wyjściu 1 slot na opcjonalną kartę komunikacyjną (karta sieciowa, karta przekaźnikowa lub karta sieciowa obsługująca protokoły przemysłowe) Kompatybilność ze środowiskami wirtualnymi (VMware, Hyper-V, Citrix Xen, Redhat) Pełna integracja z oprogramowaniem Eaton Brightlayer Software suite 1 port USB + 1 port szeregowy Technologia zaawansowanego zarządzania bateriami (ABM+) zwiększająca żywotność baterii oraz poprawiająca dokładność przewidywania żywotności Wyświetlacz graficzny LCD nowej generacji Baterie wymienialne podczas pracy urządzenia Zdalny restart i optymalizacja czasu podtrzymania dzięki 2 zarządzanym grupom gniazd
Design -
Designation - CE+WEEE
dimension depth - 590 mm
dimension height - 185 mm
Dimensions - 361 x 43.2 x 438 mm
dimension weight - 11000 g
dimension width - 445 mm
Displaytype - LCD
Display type Design - LCD
EAN - 3553340710292
ean - 3553340710292
EANCode - 3553340710292
ECO mode Features - No
Efficiency - 98%
Efficiency Features - 98%
Environment requirements - Wilgotność względna: 0-90%, bez kondensacji
Features -
Filters / protection - Automatic Voltage Regulation (AVR)
Filters / protection - Overdischarge
Formfactor - Rackmount
Form factor Design - Rackmount
Gewicht - 11.4
GRUPPE1 - Power Protection
GRUPPE2 - UPS (Uninterruptable Power Supply)
guarantee - 24
guarantee_type - external
Heatdissipation -
Height - 43.2 mm
Height Weight & dimensions - 43.2 mm
HERSTELLER - EATON
HighLights -
Hoehe - 0
Hot-swap battery Battery - Yes
Hotswapbattery - Yes
HSTNUMMER - 5P650IRG2
I/O connectors - 1 x RS-232 (COM)
I/O connectors - 1 x Terminal
I/O connectors - 1 x USB (Type B)
Input connection type Other features - IEC C14
Inputfrequency - 40/70 Hz
Input frequency Features - 40/70 Hz
Input operation voltage (max) Features - 294 V
Input operation voltage (min) Features - 160 V
Inputoperationvoltagemax - 294 V
Inputoperationvoltagemin - 160 V
Input power ports - IEC-C14
Laenge - 0
Link - https://www.eaton.com/lt/lt-lt/skuPage.5P650IRG2.html
LongDesc -
Mac compatibility Other features - No
Management card included Packaging data - No
ManufDatasheet -
Model - 5P Gen2
Name - Eaton 5P Gen2 UPS | 5P650IRG2 | 650 VA | 520 W
name - UPS 5P 650i Rack 1U G2 650VA / 520W ABM+
Networkcardslot -
No. of batteries - 2
Noiselevel - 40 dB
Noise level Features - 40 dB
Nominal input voltage Other features - 230 V
Nominal output voltage Other features - 230 V
Numberofbatterycells -
Numberofinputphases - 1
Number of input phases Features - 1
Numberofoutputphases - 1
Number of output phases Features - 1
Number of phases input - 1 (230V)
Operatingaltitude -
OperatingrelativehumidityHH -
Operating temperature (T-T) Operational conditions - 0 - 35 °C
OperatingtemperatureTT - 0 - 35 °C
Operationalconditions -
Other features -
Other features > Special features - Input: C14, Outputs: (4) C13
Outputfrequency - 50/60 Hz
Output frequency Features - 50/60 Hz
Output operation voltage (max) Features - 240 V
Output operation voltage (min) Features - 200 V
Outputoperationvoltagemax - 240 V
Outputoperationvoltagemin - 200 V
Outputpower - 520 W
Outputpowercapacity - 0.65 kVA
Output power capacity Features - 0.65 kVA
Output power Features - 520 W
Output power ports - 4 x IEC-C13
Package features > Classification of battery - CL126:NE:2016-12-09
Package features > Composition of battery - CL127:KT:2016-12-09
Package features > Embeeded battery - Yes
Package features > Gross depth (mm) - 580.00 mm
Package features > Gross height (mm) - 228.00 mm
Package features > Gross width (mm) - 500.00 mm
Package features > Packing quantity - 1.00 pc(s)
Package features > Palette Qty - 13 pc(s)
Package features > Paper/Pasteboard - 3000.00 g
Package features > Plastic (No PET) - 960.00 g
Package features > Tare weight (kg) - 3.96 kg
Package features > TI weight (kg) - 0.5 kg
Package features > Type of battery - Accumulator
Package features > Volume (m3) - 0.07 m³
Package features > WEE classification - CL109:4:2017-04-01
Package features > WEEE tax - Yes
Packagingcontent -
Performance > Capacity - 650 VA
Performance > UPS topology - Line-Interactive
Portsinterfaces -
Powerfactor -
Powerplug - C14 coupler
Power plug Ports & interfaces - C14 coupler
ProdDesc - Eaton 5P 650i Rack 1U G2
producer - Eaton
Productcolour - Black
Product colour Design - Black
Productcondition - Original
ProductHighLights -

• Line-Interactive
• 0.65 kVA 520 W
• Waveform: Pure sine
• 4 AC outlet(s)
• Sealed Lead Acid (VRLA)
• Rackmount Black

ProductPicture - https://www.tdbaltic.ee/images/products/EATON/5P650IRG2_1.jpg
ProductPicture1 - https://www.tdbaltic.ee/images/products/EATON/5P650IRG2_2.jpg
ProductPicture2 - https://www.tdbaltic.ee/images/products/EATON/5P650IRG2_3.jpg
ProductPicture3 - https://www.tdbaltic.ee/images/products/EATON/5P650IRG2_4.jpg
ProductPicture4 -
ProductPicture5 -
Quickinstallationguide -
Rack capacity Design - 1U
Rackmountkit - Yes
Rack mount kit Packaging content - Yes
RS-232 ports Ports & interfaces - 1
RS232ports - 1
Safety Safety regulation & standards - IEC/EN 62040-1, UL 1778
Serialinterface -
Serialinterfacetype -
Serialportsquantity -
Software - Eaton Brightlayer Software suite
Special functions - Automatyczny test baterii
Stck_Kart - 1
Stck_Pal - 5
Storno - Y
Summary - Eaton 5P650IRG2. UPS topology: Line-Interactive, Output power capacity: 0.65 kVA, Output power: 520 W. AC outlet types: C13 coupler, Power plug: C14 coupler, AC outlets quantity: 4 AC outlet(s). Battery technology: Sealed Lead Acid (VRLA), Typical backup time at full load: 2 min, Typical backup time at half load: 9 min. Form factor: Rackmount, Product colour: Black, Rack capacity: 1U. Certification: IEC/EN 62040-1, UL 1778, IEC/EN 62040 -2 , IEC/EN 62040-3 (Performance), CE, CB report (TUV)
Technical details > Capacity - 520 W
Technical details > Gross weight - 12.56 kg
Technical details > Net weight - 8.60 kg
Technical details > Producer - Eaton
Technical details > Producer product family - 5P Gen2 UPS
Technical details > Producer product name - 5P650IRG2
The shape of the output voltage - Full sine wave
Typical backup time at full load Battery - 2 min
Typicalbackuptimeathalfload - 9 min
Typical backup time at half load Battery - 9 min
Unit Box Height - 0.175
Unit Box Length - 0.59
Unit Box Width - 0.445
Unit Calculated Volume - 0.04595 cubm
Unit Calculated Weight - 11.2 kg
Units per Shipping Box - 1
UPS Architecture - line-interactive
UPStopology - Line-Interactive
UPS topology Features - Line-Interactive
USB 2.0 ports quantity Ports & interfaces - 1
USBport - Yes
USB port Ports & interfaces - Yes
USBporttype -
Vendor Homepage - https://www.eaton.com/gb/en-gb/skuPage.5P650IRG2.html
vendpn - 5P650IRG2
Voltage - 6 V
Warranty - 24 months
Warranty - 36
Warranty - 36 month(s)
Warrantyandmisc -
Waveform - Pure sine
Waveform Features - Pure sine
Weight - 8.6 kg
Weight - 8.6 kg
Weightdimensions -
Weight Weight & dimensions - 8.6 kg
Width - 438 mm
Width Weight & dimensions - 438 mm
