Aten 4-Port USB HDMI/Audio KVMP Switch CS1794-AT-G

Accessories included -
Brand - ATEN
BrandPartCode - CS1794-AT-G
Category - KVM Switches
Category_1 - Network and Servers
Category_2 - Network - KVM Switches
Console Ports - 1x HDMI Female
Console Ports - 2x USB Type A Żeński
Console Ports - 4x Audio 3,5mm minijack Female
Description - 4-portowy przełącznik HDMI USB 2.0 KVMP Jedna konsola USB steruje czterema komputerami z interfejsem HDMI i dwoma dodatkowymi urządzeniami USB Wbudowany 2-portowy hub USB 2.0; w pełni zgodny ze specyfikacją USB 2.0 Niezależne przełączanie KVM, urządzeń peryferyjnych USB i fokusu audio za pomocą przycisków na panelu przednim i skrótów klawiszowych Obsługa cyfrowego monitora HDMI - w pełni zgodny z HDMI; również zgodny z HDCP Obsługa Dolby True HD i DTS HD Master Audio Najwyższa jakość wideo - obsługuje 480i, 480p, 720p, 1080i i 1080p (HDTV ) / 1920 x 1200 (DVI) Wykrywanie włączenia - jeśli jeden z komputerów zostanie wyłączony, CS1794 automatycznie przełączy się na następny włączany komputer Obsługuje rozdzielczości szerokoekranowe Obsługa wielu platform - Windows, Linux i Mac Emulacja / pomijanie portów myszy w konsoli obsługuje większość sterowników myszy i myszy wielofunkcyjnych Wideo DynaSync - przechowuje EDID monitora konsoli (rozszerzone dane identyfikacyjne wyświetlacza) w celu zoptymalizowania rozdzielczości ekranu Pełna emulacja klawiatury dla bezbłędnego rozruchu Obsługa i emulacja klawiatury Mac Tryb automatycznego skanowania do monitorowania wszystkich komputerów i urządzeń HDMI Aktualizacja oprogramowania układowego
Design - Hot keys - Yes
Design - Housing material - Metal, Plastic
Design - LED indicators - Yes
Design - Product colour - Black
Design - Push button - Yes
Designation - CE+WEEE
dimension depth - 110 mm
dimension height - 220 mm
Dimensions - 26.23 x 7.68 x 4.40 cm
dimension weight - 1890 g
dimension width - 320 mm
Display - Built-in display - No
ean - 4710423775718
EAN_code - 4710423775718
GTIN - 4710423775718
guarantee - 24
guarantee_type - external
Logistics data - Harmonized System (HS) code - 85176200
Logistics data - Master (outer) case gross weight - 10.7 kg
Logistics data - Master (outer) case height - 232 mm
Logistics data - Master (outer) case length - 512 mm
Logistics data - Master (outer) case net weight - 8.8 kg
Logistics data - Master (outer) case width - 342 mm
Logistics data - Products per master (outer) case - 5 pc(s)
LongDesc - With its unique design and innovative features, the CubiQ™ CS1794 USB 2.0 HDMI KVMP™ Switch provides both style and functionality for today's multimedia SOHO environment. Combining a 4-port switch with a 2-port USB 2.0 hub, the CS1794 provides seamless HDMI signal switching between 4 PCs or other HDMI-enabled devices, such as gaming consoles, and allows users to share USB peripherals from a single console.1x CS1794 USB 2.0 HDMI KVMP™ Switch4x 2L-7D02UH HDMI KVM Cable Sets1x LIN5-04A2-J13G Firmware Upgrade Cable1x 0AD8-1605-24M1 Power Adapter1x User Instructions
LongProductName - 4-Port USB HDMI KVM Switch with Audio & USB 2.0 Hub (KVM cables included)
LongSummaryDescription - ATEN 4-Port USB HDMI KVM Switch with Audio & USB 2.0 Hub (KVM cables included). Keyboard port type: USB, Mouse port type: USB, Video port type: HDMI. HD type: WUXGA, Maximum resolution: 1920 x 1200 pixels, Video bandwidth: 60 Hz. Product colour: Black, Housing material: Metal, Plastic. Power source: DC, Input voltage: 5.3 V, Power consumption (typical): 3.62 W. Width: 262.3 mm, Depth: 76.8 mm, Height: 44 mm
Manufacturer - Aten
Manufacturer_code - CS1794-AT-G
name - 4-Port USB HDMI/Audio KVMP Switch CS1794-AT-G
Name - ATEN 4-Port USB HDMI KVM + Cables
No. of devices (max) - 4
Operational conditions - Operating relative humidity (H-H) - 0 - 80%
Operational conditions - Operating temperature (T-T) - 0 - 50 °C
Operational conditions - Storage relative humidity (H-H) - 0 - 80%
Operational conditions - Storage temperature (T-T) - -20 - 60 °C
Other features -
Packaging content - Manual - Yes
Packaging content - Quick installation guide - Yes
Packaging data - Package depth - 325 mm
Packaging data - Package height - 210 mm
Packaging data - Package weight - 2 kg
Packaging data - Package width - 98 mm
PC connectors - 4 x HDMI Female
PC connectors - 4x USB Type B Female
PC connectors - 8x Audio 3,5mm minijack Female
Performance - HD type - WUXGA
Performance - Maximum resolution - 1920 x 1200 pixels
Performance - Scan interval - 1,5,99 s
Performance - Video bandwidth - 60 Hz
Ports & interfaces - Audio connections - Yes
Ports & interfaces - Console ports - 3.5mm headphone, HDMI, USB A
Ports & interfaces - Console USB ports quantity - 2
Ports & interfaces - DC-in jack - Yes
Ports & interfaces - HDMI ports quantity - 4
Ports & interfaces - Headphone outputs - 6
Ports & interfaces - Keyboard port type - USB
Ports & interfaces - Mouse port type - USB
Ports & interfaces - Number of computers controlled - 4
Ports & interfaces - Number of microphone inputs - 6
Ports & interfaces - USB 2.0 Type-A hub ports quantity - 2
Ports & interfaces - USB 2.0 Type-B ports quantity - 4
Ports & interfaces - USB connector type - USB Type-A, USB Type-B
Ports & interfaces - USB hub - Yes
Ports & interfaces - Video port type - HDMI
Power - Input voltage - 5.3 V
Power - Power consumption (typical) - 3.62 W
Power - Power source - DC
producer - ATEN
ProductName - 4-Port USB HDMI KVM Switch with Audio & USB 2.0 Hub (KVM cables included)
Resolution - 1920 x 1080 (FHD 1080)
ShortSummaryDescription - ATEN 4-Port USB HDMI KVM Switch with Audio & USB 2.0 Hub (KVM cables included), 1920 x 1200 pixels, WUXGA, 3.62 W, Black
Supported operating systems - Linux
Supported operating systems - Mac OS
Supported operating systems - Windows
System requirements - Linux operating systems supported - Yes
System requirements - Mac operating systems supported - Yes
System requirements - Windows operating systems supported - Yes
Title - ATEN 4-Port USB HDMI KVM Switch with Audio & USB 2.0 Hub (KVM cables included)
URL - https://www.aten.com/eu/en/products/kvm/desktop-kvm-switches/cs1794/
vendpn - CS1794-AT-G
WarrantyInfo -
Weight - 0.53 kg
Weight - 2,13
Weight & dimensions - Depth - 76.8 mm
Weight & dimensions - Height - 44 mm
Weight & dimensions - Weight - 1.76 kg
Weight & dimensions - Width - 262.3 mm
