Incase 2-Port USB DisplayPort/Audio KVM Switch (4K UHD Supported) | Aten | 2-Port USB DisplayPort/Audio KVM Switch (4K Supported and Cables included)

Brand - ATEN
BrandPartCode - CS782DP-AT
Category - KVM Switches
Code - CS782DP-AT
Design - Hot keys - Yes
Design - Housing material - Plastic
Design - LED indicators - Yes
Design - Product colour - Black
Design - Rack mounting - No
Display - Built-in display - No
EAN - 4719264643644
GTIN - 0672792006722
GTIN - 672792006722
GTIN - 4719264643644
GTIN - 5055309625565
Logistics data - Harmonized System (HS) code - 85176200
Logistics data - Master (outer) case gross weight - 7.71 kg
Logistics data - Master (outer) case height - 196 mm
Logistics data - Master (outer) case length - 497 mm
Logistics data - Master (outer) case net weight - 5.43 kg
Logistics data - Master (outer) case width - 328 mm
Logistics data - Products per master (outer) case - 10 pc(s)
LongDesc - With the ever-growing demand for higher video quality and the evolution of DisplayPort technology, 4K-enabled computers and displays are now widely adopted in visually-intensive and commercial applications. Offering up to 4K resolution, the ATEN CS782DP is at home amongst these demanding scenarios and technological advancements.1x CS782DP 2-Port USB DisplayPort KVM Switch2x LIN5-20K1-K12G DisplayPort Cables2x LIN6-04U1-V1BG USB Cables2x LIN5-0205-21CG Audio Cables1x Remote Port Selector1x User Instructions
LongProductName - 2-Port USB 4K DisplayPort 1.2 KVM Switch (KVM cables included)
LongSummaryDescription - ATEN 2-Port USB 4K DisplayPort 1.2 KVM Switch (KVM cables included). Keyboard port type: USB, Mouse port type: USB, Video port type: DisplayPort. HD type: 4K Ultra HD, Maximum resolution: 4096 x 2160 pixels, Video bandwidth: 60 Hz. Product colour: Black, Housing material: Plastic. Power source: DC, Input voltage: 5 V, Power consumption (typical): 2.18 W. Width: 93 mm, Depth: 93.7 mm, Height: 26.8 mm
Name - Aten 2-Port USB DisplayPort/Audio KVM Switch (4K UHD Supported) | Aten | 2-Port USB DisplayPort/Audio KVM Switch (4K Supported and Cables included)
Operational conditions - Operating relative humidity (H-H) - 0 - 80%
Operational conditions - Operating temperature (T-T) - 0 - 50 °C
Operational conditions - Storage relative humidity (H-H) - 0 - 80%
Operational conditions - Storage temperature (T-T) - -20 - 60 °C
Operational conditions > Temperature range (T-T) - 0 – 50°C °C
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 93.7 mm
Package features > Gross height (mm) - 26.8 mm
Package features > Gross weight - 0.348 kg
Package features > Gross width (mm) - 93 mm
Package features > Packing quantity - 1 pc(s)
Package features > Palette Qty - 54 pc(s)
Package features > Paper/Pasteboard - 182.4 g
Package features > Plastic (No PET) - 45.6 g
Package features > Tare weight (kg) - 0.228 kg
Package features > Volume (m3) - 0.00023353788 m³
Package features > WEE classification - CL109:6:2017-04-01
Package features > WEEE tax - No
Packaging content - Manual - Yes
Packaging content - Quick installation guide - Yes
Packaging data - Package depth - 239 mm
Packaging data - Package height - 175 mm
Packaging data - Package weight - 687 g
Packaging data - Package width - 59 mm
Performance - HD type - 4K Ultra HD
Performance - Maximum resolution - 4096 x 2160 pixels
Performance - Scan interval - 3,5,10,20 s
Performance - Video bandwidth - 60 Hz
Ports & interfaces - Audio connections - Yes
Ports & interfaces - Console ports - 3.5mm headphone, DisplayPort, USB A
Ports & interfaces - DisplayPorts quantity - 2
Ports & interfaces - Headphone outputs - 1
Ports & interfaces - Keyboard port type - USB
Ports & interfaces - Mouse port type - USB
Ports & interfaces - Number of computers controlled - 2
Ports & interfaces - Number of microphone inputs - 1
Ports & interfaces - USB 2.0 Type-B ports quantity - 2
Ports & interfaces - USB connector type - USB Type-A, USB Type-B
Ports & interfaces - Video port type - DisplayPort
Power - Input voltage - 5 V
Power - Power consumption (typical) - 2.18 W
Power - Power source - DC
Producer product name - 2-Port USB DisplayPort/Audio KVM Switch (4K Supported and Cables included)
ProductName - 2-Port USB 4K DisplayPort 1.2 KVM Switch (KVM cables included)
ShortSummaryDescription - ATEN 2-Port USB 4K DisplayPort 1.2 KVM Switch (KVM cables included), 4096 x 2160 pixels, 4K Ultra HD, 2.18 W, Black
Technical details > Net weight - 0.12 kg
Technical details > Other features - Superior video quality – 4K UHD (3840 × 2160 @ 60 Hz) and 4K DCI (4096 x 2160 @ 60 Hz). Computer selection via remote port selector, hotkeys, and USB mouse; bus-powered design. Supports MST (Multi-Stream Transport), enabling multiple monitors to be used via a single DisplayPort connector. Supports DisplayPort Dual - Mode (DP++) for directly outputting single-link HDMI and / or DVI signals via an externally powered DisplayPort-to-HDMI/DVI DP++ adapter. Console Ports - 2 x USB Type A Female, 1 x DisplayPort Female (Black),1 x 3.5mm Audio Jack Female (Green). KVM (Computer) Ports- 2 x USB Type B Female, 2 x DisplayPort Female (Black), 2 x 3.5mm Audio Jack Female (Green). Remote Port Selector 1 x 2.5mm Audio Jack Female.
Technical details > Producer - Aten
Title - ATEN 2-Port USB 4K DisplayPort 1.2 KVM Switch (KVM cables included)
URL - https://www.aten.com/eu/en/products/kvm/desktop-kvm-switches/cs782dp/
Warranty - 24
Warranty - 24 month(s)
WarrantyInfo -
Weight & dimensions - Depth - 93.7 mm
Weight & dimensions - Height - 26.8 mm
Weight & dimensions - Weight - 543 g
Weight & dimensions - Width - 93 mm
