Dahua LM25-B221B, 24.5"

Name: Dahua LM25-B221B, 24.5"
Brand: Dahua
SKU: 1258547
Price: 90.12 EUR
Availability: InStock

Picture may differ from actual product, there can be accessories and parts not supplied with the actual product.

ID: 1258547 Product code: DHI-LM25-B221B

In stock 4 units

Warranty: 3 years

Compare

Ready for dispatch

tomorrow, 03.09.2025

starting from 5.99 €

Delivery options

Delivery by courier to the address

Within 1-2 working days

5.99 €

Main product parameters All parameters

Curved: Nav
Panel Type: IPS
Refresh rate: 144 Hz
Response time: 1ms
Contrast ratio: 1500:1
Brightness: 300cd/m2
Size: 24.5"
Resolution: FHD 1920x1080

Description

We offer to buy Dahua 24.5" a monitor with FHD 1920x1080 resolution.

IPS matrix for this monitor provides high colour correspondence parameters, superior picture contrast and good visibility from eventually all viewing angles.
The compatibility with the modern graphics cards and video players will be ensured by HDMI input.
DisplayPort port ensures the receipt of a higher quality picture from the computer graphics card supporting this technology.
1ms fast response time makes this monitor perfectly suitable for enjoying computer games and dynamic films.

Display characteristics

AMD FreeSync : Nav

Curved : Nav

NVIDIA G-SYNC : Nav

Panel Type IPS

Teh monitor panel is the main feature of the visible part of the screen or the technology where the display of the colour dots (pixels) is implemented.

TN is the standard technology with average contract, brightness and colour compliance indices.

IPS is the matrix with high colour compliance and good response speed, therefore it is well suited for graphics tasks and photo editing. IPS matrix provide an excellent viewing angle maintaining the colours and contrast from almost any angle.

VA matrix ensures superior colour compliance, however, the response time of this matrix is lagging behind that of the IPS and TN; the viewing angle is somewhere between both these technologies.

The TN type monitor is fully sufficient for an average user. If you have more money available the VA or IPS can be chosen.

Refresh rate : 144 Hz

Touchscreen : NO

VESA DisplayHDR : Nav

Response time 1ms

The response time of the monitor screen determines how fast the monitor will display moving images (films, games, animations, etc.). The response time is measured in miliseconds. The less the response time the better the ability of the monitor to display moving images.
www.toppc.ee recommends to buy monitors with 5ms response time or lower.

Contrast ratio 1500:1

Ekrāna kontrasts nosaka attēla asumu. Tā ir atšķirība starp vistumšāko (pilnīgi melnu) un visgaišāko (pilnīgi baltu) pikseli. Jo lielāks kontrasts, jo skaidrāk salasāms teksts uz ekrāna, kontrasts arī nosaka, cik izteiksmīgas līnijas būs redzamas monitora attēlā.

Augsts kontrasts ir nozīmīgs faktors izvēloties monitoru biroja, vai mācību vajadzībām, kad lielākoties tiek strādāts ar tekstuālu informāciju.

Mājas vajadzībām svarīgāks izvēles rādītājs ir gaišums un attēla reakcijas laiks. Kontrastu labāk novērtēt tumšā istabā.
Lielākais LCD monitoru trūkums ir tas, ka samazinot attēla spilgtumu, kontrasts var pazust.

Brightness 300cd/m2

Monitora gaišums ir attēla redzamības rādītājs, kas nosaka, cik labi saskatāms ir attēls pie spēcīga ārējā apgaismojuma (saules gaisma, gaiša telpa, utt.). LCD monitoru gaišums tiek mērīts kandelās uz kvadrātmetru (Cd/m2).
Izvēloties monitoru jāņem vērā - jo lielāks gaišuma rādītājs, jo labāka attēla redzamība.

Ikdienas vajadzībām TopPC.ee iesaka iegādāties monitoru ar gaišumu, ne mazāku par 250 cd/m2.

Basic information

Application : Home & Office

Aspect ratio : 16:9

Color : Black

Size 24.5"

The size of the monitor screen is measured in inches across the diagonal. The screen size must be proportionate to the resolution of the screen for achieving the maximum utilisation of the desktop and details of the image.

Mainly two forms of LCD monitors are available: with standard width and height proportion 4:3 or the widescreen proportion 16:9 or 16:10. A widescreen monitor is wider and its resolution is higher than that of the monitors with standard proportion.

The bigger the monitor size the higher resolution usually is supported. Possibilities to increase the resolution of the screen usually depend on the size and possibilities of the monitor and the type of the video card.

Resolution FHD 1920x1080

The resolution of the monitor screen determines the number of colour dots (pixels) a monitor can display. It refers to the clarity of the text and images displayed on the screen. The higher the resolution the sharper the items look.

The applied resolution depends on the resolution supported by the monitor. LCD monitors, including the screens of laptop computers usually work best if their local resolution has been set. The setting of this resolution for the monitor is not mandatory, but usually it is recommended to set it for ensuring the highest possible sharpness of texts and images. The bigger the monitor size the higher resolution usually is supported.

Possibilities to increase the resolution of the screen usually depend on the size and possibilities of the monitor and the type of the video card.
• 19 inches screen (standard proportions): 1280x1024 pixels
• 20 inches screen (standard proportions): 1600x1200 pixels
• 22 inches screen (widescreen): 1680x1050 pixels
• 24 inches screen (widescreen): 1900x1200 pixels

Functionality

Flicker-free : Ir

Height adjustment : Nav

Pivot : Nav

Swivel : None

Tilt : YES

VESA wall mount : 100x100 mm

Ports and equipment

D-SUB Nav

D-SUB is the classic (analogous) monitor connection plug. This standard is gradually disappearing from the market giving the place to the higher quality HDMI or DisplayPort (digital) plugs.

If the resolution of the monitor is FullHD or below the average user will experience no problems with this connection. Those who want to achieve higher image quality and resolution should look for the monitor with the DisplayPort or HDMI connection slot.

DisplayPort 1

DisplayPort is the digital connection for transmitting the image via a single wire at a high quality level. Contrary to the HDMI, this connection allows to connect several external monitors to the computer via a single connector.

Prior to buying the monitor with the DisplayPort you should verify whether your computer has the DisplayPort plug available!

DVI Nav

DVI is a digital standard and ensures high image quality, however, thanks to the big size of the plug and the inability of the standard to develop further due to a few technical restrictions this type of connection is gradually losing its popularity to modern HDMI and DisplayPort standards.

DVI is compatible with HDMI and transitions of both directions are available.

DVI is not compatible with DisplayPort, however, there are DualMode DisplayPort connectors which contains the HDMI/DVI signal, and in the relevant direction DisplayPort -> DVI can transmit an image.

If the monitor resolution exceeds 1920px in any direction a graphics card with the DVI-D Dual Link support and the relevant quality cable will be required.

Before buying a monitor you should verify whether your graphics card has the corresponding connection slot!

HDMI port 1

HDMI is the digital high quality image transmission standard that allows to connect the monitor to the computer via a thin cable by using an elegant small-size connector. HDMI is compatible with DVI if the relevant transition or cable is used.

Speakers Nav

Some monitors may have built-in speakers that quite often allow to give up external speakers thus freeing a space on the desk and saving money. The sound quality of built-in speakers is quite moderate and therefore we recommend to use this possibility just for infrequent needs.

For enjoying music, movies and games we recommend buying the corresponding quality and capacity speakers.

USB Hub : NO

USB-C Power Delivery : Nav

USB-C video input : 0

More detailed specification

Additional information in manufacturers website Dahua LM25-B221B, 24.5"

Audio-Out Input/Output connectors - 1
Brand - Dahua Technology
BrandPartCode - DHI-LM25-B221B
Brightness - 300
Category - Computer Monitors
Category Code - LC3
CnCode - 85285210
Colour - Black
Contrast - 1500:1
Data Sheet (Link) Energy Efficiency - https://eprel.ec.europa.eu/api/product/1538753/fiches?language=EN
Depth Product Dimensions - 58.1 mm
Description - LM25-B221B Dahua 24.5" FHD Commercial Monitor > The 144Hz refresh rate provides an instant, tangible improvement in image smoothness; > The IPS panel technology offers accurate and consistent colour reproduction with wide viewing angles; > Wide color gamut, 85% NTSC, It meets the designer's demand of image texture; > 1ms fast response time with no image blurring or ghosting; > Low blue light technology can support a comfortable viewing experience.
Design - Detachable stand - Yes
Design - Feet colour - Black
Design - Frameless design - Yes
Design - Front bezel colour - Black
Design - Product colour - Black
Display - Backlight type - Edge LED
Display - Colour gamut standard - NTSC
Display - Contrast ratio (typical) - 1500:1
Display - Display brightness (typical) - 300 cd/m²
Display - Display diagonal - 62.2 cm (24.5")
Display - Display diagonal (metric) - 62 cm
Display - Display number of colours - 16.7 million colours
Display - Display resolution - 1920 x 1080 pixels
Display - Display technology - LED
Display - Haze rate - 25%
Display - HD type - Full HD
Display - LED backlight - Yes
Display - Maximum refresh rate - 144 Hz
Display - Native aspect ratio - 16:9
Display - NTSC coverage (typical) - 85%
Display - Panel type - IPS
Display - Pixel density - 89.91 ppi
Display - Pixel pitch - 0.2832 x 0.2802 mm
Display - Response time (MPRT) - 1 ms
Display - Screen shape - Flat
Display - Surface hardness - 3H
Display - Touchscreen - No
Display - Viewable size, horizontal - 47.6 cm
Display - Viewable size, vertical - 26.8 cm
Display - Viewing angle, horizontal - 178°
Display - Viewing angle, vertical - 178°
Displayable colours - 16.7 million
DisplayPort Input/Output connectors - 1
Energy consumption, standard - 17 kWh/1000h
Energy efficiency class Energy Efficiency - E
EPREL Registration Number Energy Efficiency - 1538753
EPREL Version Number Energy Efficiency - 1
Ergonomics - Height adjustment - No
Ergonomics - LED indicators - Yes
Ergonomics - Panel mounting interface - 100 x 100 mm
Ergonomics - Plug and Play - Yes
Ergonomics - Tilt adjustment - Yes
Ergonomics - Tilt angle range - -5 - 20°
Ergonomics - VESA mounting - Yes
Ergonomics - Wall mountable - Yes
HDMI Input/Output connectors - 1
Height Product Dimensions - 330.6 mm
LongDesc -
LongProductName - 24.5" FHD ELED, IPS, 16:9, 144 Hz, 1 ms, 300 cd/m², 1500:1, DP, HDMI, 3.5 mm, 12 VDC, 2.5 A, 2.9 kg
LongSummaryDescription - Dahua Technology LM25-B221B. Display diagonal: 62.2 cm (24.5"), Display resolution: 1920 x 1080 pixels, HD type: Full HD, Display technology: LED, Native aspect ratio: 16:9, Viewing angle, horizontal: 178°, Viewing angle, vertical: 178°. VESA mounting. Product colour: Black
Model name - LM25-B221B
Monitor features - Business
Multimedia - Built-in camera - No
Multimedia - Built-in speaker(s) - No
Native resolution - 1920x1080
Operational conditions - Operating relative humidity (H-H) - 10 - 85%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 90%
Operational conditions - Storage temperature (T-T) - -20 - 60 °C
Other features - Compliance certificates - CE, Electromagnetic Compatibility (EMC), Low Voltage Directive (LVD)
Other features - Mean time between failures (MTBF) - 30000 h
Packaging content - Cables included - HDMI
Packaging content - Manual - Yes
Packaging content - Power adapter included - Yes
Packaging content - Quick start guide - Yes
Packaging content - Stand included - Yes
Packaging data - Package depth - 134 mm
Packaging data - Package height - 431 mm
Packaging data - Package type - Box
Packaging data - Package weight - 3.9 kg
Packaging data - Package width - 620 mm
Panel type - IPS
Performance - Low Blue Light technology - Yes
Ports & interfaces - Audio output - Yes
Ports & interfaces - Built-in USB hub - No
Ports & interfaces - DisplayPorts quantity - 1
Ports & interfaces - HDMI - Yes
Power - AC adapter output voltage - 12 V
Power - Current rating - 2.5 A
Power - Energy consumption (SDR) per 1000 hours - 15 kWh
Power - Energy efficiency class (SDR) - D
Power - Power consumption (max) - 23.8 W
Power - Power consumption (standby) - 0.5 W
Power - Power consumption (typical) - 19 W
Power - Power supply type - External
ProductName - LM25-B221B
Product Net Weight - 2.9 kg
Refresh rate - 144Hz
Response time - 1 ms
Screen form factor - 16:9
Screen size - 24.5"
ShortSummaryDescription - Dahua Technology LM25-B221B, 62.2 cm (24.5"), 1920 x 1080 pixels, Full HD, LED, Black
Standby consumption - 0.5 Watts
Title - Dahua Technology LM25-B221B LED display 62.2 cm (24.5") 1920 x 1080 pixels Full HD Black
Unit Box Height - 0.425
Unit Box Length - 0.62
Unit Box Width - 0.135
Unit Calculated Volume - 0.03557 cubm
Unit Calculated Weight - 4.1 kg
Units per Pallet - 0
URL - https://www.dahuasecurity.com/search/products?keyword=DHI-LM25-B221B-A5-V1
Vendor Homepage - display.dahuasecurity.com/consumer/en/products/productDetail?product_id=152833
Viewing angle horizontal - 178 degrees
Viewing angle vertical - 178 degrees
Warranty - 36 months
WarrantyInfo -
Weight & dimensions - Bezel width (bottom) - 1.96 cm
Weight & dimensions - Bezel width (side) - 2.1 mm
Weight & dimensions - Bezel width (top) - 2.1 mm
Weight & dimensions - Depth (without stand) - 58.1 mm
Weight & dimensions - Height (without stand) - 330.6 mm
Weight & dimensions - Weight (without stand) - 2.9 kg
Weight & dimensions - Width (without stand) - 557.7 mm
Width Product Dimensions - 557.7 mm
