Deepcool PX1000G, 1000W, 80PLUS Gold, PCI-E 5.0

Picture may differ from actual product, there can be accessories and parts not supplied with the actual product.
ID: 968792 Product code: R-PXA00G-FC0B-EU
Goods are not available at the moment We do not accept orders for the delivery of this product. We do not have information as to when this product will be available. Our suppliers currently do not provide information about possible delivery times of the product and the possible price when it is on sale again.

TopPC.ee website provides information about this product for information only, so that customers can see the product and compare it to the products available for sale now.

Warranty: 3 years
Main product parameters All parameters
  • Producer: Deepcool
  • Power output: 1000W
  • 80 PLUS certification: 80 PLUS Gold
  • Fan size: 135 mm
  • Modular cables: Fully-Modular
  • Processor plug-in: 2 x 8-pin(4+4) EPS
  • PCI-E: 3 x 6+2pin
Similar Products
This product Deepcool PX1000G, 1000W, 80PLUS Gold, PCI-E 5.0
Gigabyte UD1000GM PG5, 1000W, 80PLUS Gold, PCIe 5.0
Recommended Seasonic Focus GX (2024), 1000W, 80PLUS Gold, ATX 3.1, PCIe 5.1
Recommended Gigabyte UD1600PM PG5, 1600W, 80PLUS Platinum, PCIe 5.0
Recommended Lian Li EDGE 1000W, 80PLUS Platinum, PCIe 5.1, ATX 3.1, Black Sleeved Cables
Show similar specs. Hide similar specs.
169.01 €
115.15 €
196.46 €
390.41 €
199.00 €
Basic information
Cybenetics Efficiency certification Cybenetics Platinum Cybenetics Platinum Nav Nav Cybenetics Platinum
Cybenetics Noise level certification Cybenetics Standard ++ Cybenetics Standard + Nav Nav Cybenetics A
Power supply type ATX ATX ATX ATX ATX
Power output 1000W 1000W 1000W 1600W 1000W
80 PLUS certification 80 PLUS Gold 80 PLUS Gold 80 PLUS Gold 80 PLUS Platinum 80 PLUS Platinum
Total amperage (+12V) 83.3A 83.3A 83A 133.3A 83A
Fan size 135 mm 120 mm 120 mm 140 mm 120 mm
Functionality
Cable colour Melna Melna Melna Melna Melna
Lighting Nav Nav Nav Nav Nav
Color Melna Melna Melna Melna Melna
Modular cables Fully-Modular Fully-Modular Fully-Modular Fully-Modular Fully-Modular
Ports and equipment
PCI-E 5.0 1 x 600W 12VHPWR 1 x 600W 12VHPWR 1 x 600W 12V-2X6 2 x 600W 12VHPWR 1 x 12VHPWR
Processor plug-in 2 x 8-pin(4+4) EPS 2 x 8-pin(4+4) EPS 2 x 8-pin(4+4) EPS 2 x 8-pin(4+4) EPS 2 x 8-pin(4+4) EPS
Motherboard power 20+4pin 20+4pin 20+4pin 20+4pin 20+4pin
PCI-E 3 x 6+2pin 4 X 6+2pin 3 x 6+2pin 8 x 6+2pin 4 X 6+2pin
SATA cconnectors Eight Core Eight Core 10 16 12
4pin Molex 4 3 1 6 4
Description

We offer to purchase a Deepcool power supply unit with a power capacity of 1000W, which has received the 80 PLUS Gold energy efficiency certification.

Even the best gaming computer will be able to operate safely with this 1000W power supply unit. The power will be sufficient for both a substantial water cooling system and multiple high-end graphics cards, an overclocked high-end processor, and several hard drives.

Thanks to the large 135 mm cooling fan diameter, this power supply is much quieter than average. The fan has a larger blade area, which provides the necessary airflow at lower fan speeds, thereby reducing the overall noise and vibration levels to a minimum.

80 PLUS Gold energy efficiency certificate received by this power supply guarantees at least 90% efficiency at 50% load. In other words, for every 100 W of energy the power supply receives from the power grid, at least 90 W goes to your computer components, and the remaining 10 W is lost as heat.

1 x 600W 12VHPWR connector, with which this power supply unit is equipped, is intended for use with modern graphics cards such as Nvidia GeForce RTX 4070 and above (RTX 4060 and below use the standard 8-pin connector).

The color of the power supply is Melna. It is equipped with flat cables, whose color is Melna.

This power supply unit conforms to the ATX 3.0 standard. It has a 16-pin (12VHPWR) connector, which can power the latest generation (RTX 30 and 40 series) PCIe 5.0 graphics cards with up to 600 W of power. To provide more stable current to components, ATX 3.0 also allows increasing the current by 200% for one millisecond.

The power supply unit has received the Cybenetics Standard ++ noise level certificate – the noise generated by the unit will be 30-35 decibels.

This power supply unit has fully-modular cables (Fully-modular) – you can connect and disconnect all the included cables as needed, reducing clutter and improving ventilation. This will be useful for those with a partially transparent computer case and for whom the aesthetic factor is particularly important.

The power supply manufacturer is Deepcool. All power supplies produced by Deepcool can be viewed here.

Basic information
Cybenetics Efficiency certification : Cybenetics Platinum
Cybenetics Noise level certification : Cybenetics Standard ++
Power supply type : ATX
Power output 1000W
The capacity of the power supply unit in watts. A higher capacity means higher stability of the computer operation. The recommended capacity of the power supply unit of a modern average computer is 500 W and above. If you use several HDDs, a powerful video card and processor it is recommended to buy a power supply unit with the capacity 600 W or above.
80 PLUS certification : 80 PLUS Gold
Total amperage (+12V) : 83.3A
Fan size : 135 mm
Functionality
Cable colour : Melna
Lighting : Nav
Color : Melna
Modular cables : Fully-Modular
Ports and equipment
PCI-E 5.0 : 1 x 600W 12VHPWR
Processor plug-in : 2 x 8-pin(4+4) EPS
Motherboard power : 20+4pin
PCI-E : 3 x 6+2pin
SATA cconnectors : Eight Core
4pin Molex : 4
More detailed specification
Category_1 - Power
Category_2 - Computer Power Supplies
Certificates > Certification - 80Plus GOLD/Cybenetics_Platinum
Code - R-PXA00G-FC0B-EU
EAN - 6933412716792
EAN_code - 6933412716792
Link - https://www.deepcool.com/products/PowerSupplyUnits/powersupplyunits/PX1000G-ATX-3.0-80-Plus-Gold-Power-Supply/2023/16912.shtml
Manufacturer - Deepcool
Manufacturer_code - R-PXA00G-FC0B-EU
Name - DeepCool PX1000G 1000W, PC power supply (black, cable management, 1000 watts)
Name - Deepcool | PSU | PX1000-G | 1000 W
Other features > Dimensions (WxDxH) - 150 x 160 x 86 mm
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 225.00 mm
Package features > Gross depth master carton - 250 mm
Package features > Gross height (mm) - 125.00 mm
Package features > Gross height master carton - 282 mm
Package features > Gross width (mm) - 305.00 mm
Package features > Gross width master carton - 355 mm
Package features > Net weight master carton - 9.2 kg
Package features > Packing quantity - 1.00 pc(s)
Package features > Palette Qty - 201 pc(s)
Package features > Paper/Pasteboard - 260.00 g
Package features > Plastic (No PET) - 40.00 g
Package features > Tare weight (kg) - 0.30 kg
Package features > Tare weight master carton - 0.425 kg
Package features > Volume (m3) - 0.01 m³
Package features > WEE classification - CL109:5:2017-04-01
Package features > WEEE tax - No
Performance > Bearing technology - FDB
Power > Nominal power - 1000 W
Producer product family - PSU
Producer product name - PX1000-G
Technical details > Gross weight - 1.40 kg
Technical details > Net weight - 1.10 kg
Technical details > Other features - Fan size 135mm
Technical details > Producer - Deepcool
Warranty - 120
Warranty - 120 month(s)
Weight - 3,80
