DeepCool PF750, 750W, 80PLUS

Picture may differ from actual product, there can be accessories and parts not supplied with the actual product.
ID: 835477 Product code: R-PF750D-HA0B-EU
In stock 50 units
Warranty: 3 years
50.09 €
40.39 € w/o VAT
Ready for dispatch
on Wednesday, 23.09.2026
starting from 1.99 € with VAT
Delivery options
  • Omniva parcel machine
    Within 1-2 working days
    1.99 €
  • SmartPosti parcel terminal
    Within 1-2 working days
    1.99 €
  • Unisend parcel terminal
    Within 1-2 working days
    1.99 €
  • Delivery by courier to the address
    Within 1-2 working days
    5.99 €
Main product parameters All parameters
  • Producer: Deepcool
  • Power output: 750W
  • 80 PLUS certification: 80 PLUS (White)
  • Fan size: 120 mm
  • Modular cables: None
  • Processor plug-in: 2 x 8-pin(4+4) EPS
  • PCI-E: 4 X 6+2pin
Description

We offer to purchase a Deepcool power supply unit with a power capacity of 750W, which has received the 80 PLUS (White) energy efficiency certification.

For polite mid-range computer game playing, a power supply with a 750W capacity will be suitable. This unit can power a computer with a powerful mid-range graphics card (for example, RTX 4070), multiple SSDs and hard drives, and a high-end processor.

This power supply unit is equipped with a 120 mm fan, which is the industry standard for ensuring quiet operation in average computers. If you want an especially quiet unit, look for one with a fan diameter of 135 mm or 140 mm.

The power supply has been awarded the 80 PLUS (White) energy efficiency certificate, which ensures at least 80% efficiency. This indicates that at least 80 W out of 100 W of power received from the mains by the power supply is delivered to the computer components, with the remaining 20 W being lost as heat.

The color of the block is Melna. The block has flat cables, whose color is Melna.

This is a power supply that complies with ATX 2.0 requirements. The power supply has only 6-pin and 8-pin connectors, which can handle only 75 W and 150 W of power, respectively. Modern graphics cards' high power needs exceed the capabilities of ATX 2.0 connectors. When building a system with a very powerful GPU, such as an RTX 4070, you will need an ATX 3.* standard power supply.

This power supply unit does not have modular cables – all its cables are attached to the unit and are not detachable. Despite the simple design, it will fulfill its functions just as well as a power supply unit with modular cables.

This power supply unit was produced by Deepcool. You can view all Deepcool power supply units here.

Basic information
Cybenetics Efficiency certification : There isn't
Cybenetics Noise level certification : There isn't
Power supply type : ATX
Power output 750W
The capacity of the power supply unit in watts. A higher capacity means higher stability of the computer operation. The recommended capacity of the power supply unit of a modern average computer is 500 W and above. If you use several HDDs, a powerful video card and processor it is recommended to buy a power supply unit with the capacity 600 W or above.
80 PLUS certification : 80 PLUS (White)
Total amperage (+12V) : 62A
Fan size : 120 mm
Functionality
Cable colour : Black
Lighting : None
Color : Black
Modular cables : None
Ports and equipment
PCI-E 5.0/5.1 : There is no
Processor plug-in : 2 x 8-pin(4+4) EPS
Motherboard power : 20+4-pin
PCI-E : 4 X 6+2pin
SATA cconnectors : 6
4pin Molex : 2
Case
More detailed specification
Additional information in manufacturers website DeepCool PF750, 750W, 80PLUS
Category - Datoru komponentes :: Barošanas bloki (PSU)
Category - Root/Electronics/PC parts/PC power supply units
Category_1 - Power
Category_2 - Computer Power Supplies
category_en - Computers & Components > Computer components > Universal power supplies PSU
category_lv - Datortehnika > Datoru komponentes > Barošanas bloki PSU
category_ru - Datortehnika > Datoru komponentes > Barošanas bloki PSU
Certificates > Certification - 80 PLUS Standard Certified
Code - R-PF750D-HA0B-EU
Dane techniczne: Certyfikat sprawności - 80 Plus
Dane techniczne: Funkcja PFC - tak
Dane techniczne: Gwarancja - 3 lata w serwisie sprzedawcy
Dane techniczne: Głębokość - 140 mm
Dane techniczne: Ilość wentylatorów chłodzących - 1
Dane techniczne: Moc - 750 W
Dane techniczne: Model - DeepCool PF
Dane techniczne: Modularne okablowanie - brak
Dane techniczne: MTBF - 100000 godz.
Dane techniczne: Producent - Deepcool
Dane techniczne: Rodzaj chłodzenia - wentylator
Dane techniczne: Standard - ATX
Dane techniczne: Szerokość - 150 mm
Dane techniczne: Układ PFC - aktywny
Dane techniczne: Wersja standardu ATX - ATX 2.4x
Dane techniczne: Wtyczka zasilania [pin] - 1 x 4/8 EPS 12V
Dane techniczne: Wtyczka zasilania [pin] - 2 x 4-pin Molex
Dane techniczne: Wtyczka zasilania [pin] - 4 x 6/8-pin PEG
Dane techniczne: Wtyczka zasilania [pin] - 6 x SATA
Dane techniczne: Wtyczka zasilania [pin] - ATX 24pin
Dane techniczne: Wysokość - 86 mm
Dane techniczne: Zabezpieczenia - OPP
Dane techniczne: Zabezpieczenia - OVP
Dane techniczne: Zabezpieczenia - SCP
Dane techniczne: Zabezpieczenia - UVP
Dane techniczne: Średnica wentylatorów - 120 mm
Desc - Jauda: 750W, Energoefektivitāte: 80 Plus, PFC: Aktīvs, Ventilators: 120mm, Modulārs:: Nav, SATA pieslēgumi: 6, MOLEX PATA pieslēgumi: 2, PCI-E: 4 x 6 + 2 PIN, Garantija: 2 gadi
description_en - Power: 750W
Energy Efficiency: 80 Plus
PFC: active
Fan: 120mm
SATA connections: 6
MOLEX PATA connections: 2
PCI-E: 4 x 6 + 2 PIN
description_lv - Jauda: 750W
Energoefektivitāte: 80 Plus
PFC: Aktīvs
Ventilators: 120mm
SATA pieslēgumi: 6
MOLEX PATA pieslēgumi: 2
PCI-E: 4 x 6 + 2 PIN
description_ru - Мощность: 750 Вт
Энергоэффективность: 80 Плюс
PFC: активный
Вентилятор: 120 мм
Подключения SATA: 6
MOLEX PATA подключения: 2
PCI-E: 4 x 6 + 2 контакта
Design > Colour of product - Black
EAN - 6933412711605
Eans - 6933412711605
EAN_code - 6933412711605
gross_weight - 0.35 kg
LargeDescHTML -
Link - https://global.deepcool.com/products/PowerSupplyUnits/powersupplyunits/PF750D-230V-Power-Supply-Unit/2021/15134.shtml?status=authorization
Manufacturer - Deepcool
Manufacturer_code - R-PF750D-HA0B-EU
Model - R-PF750D-HA0B-EU
Name - Barošanas bloks Deepcool PF750 750W
Name - DeepCool PF750
Name - Deepcool PF750 750W (black, 2x PCIe, 750 Watt)
Name - Deepcool | PF750 | 750 W | 80 PLUS Standard Certified | Black
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 260 mm
Package features > Gross height (mm) - 180 mm
Package features > Gross width (mm) - 115 mm
Package features > Packing quantity - 1.00 pc(s)
Package features > Palette Qty - 161 pc(s)
Package features > Paper/Pasteboard - 700.00 g
Package features > Plastic (No PET) - 300.00 g
Package features > Tare weight (kg) - 1.00 kg
Package features > Volume (m3) - 0.005382 m³
Package features > WEE classification - CL109:6:2017-04-01
Package features > WEEE tax - No
Performance > Form factor - ATX12V V2.4
Ports & interfaces > ATX power connector (20+4 pin) - 1
Ports & interfaces > EPS power connector (8-pin) - 1
Ports & interfaces > Number of SATA power connectors - 2
Ports & interfaces > PCI Express power connectors (6+2 pin) - 2
Power > Nominal power - 750 W
Producer - DeepCool
Producer - Deepcool
ProducerCode - R-PF750D-HA0B-EU
ShortDescription -
Technical details > Gross weight - 1.822 kg
Technical details > Net weight - 0.822 kg
Technical details > Other features - 120mm Hypro Bearing Fan; OVP (Over Voltage), SCP (Short Circuit), OPP (Over Power) Protections
Technical details > Producer - Deepcool
Technical details > Producer product name - PF750
title_en - Deepcool PF750 Power supply unit 750W
title_lv - Deepcool PF750 Barošanas bloks 750W
title_ru - Deepcool PF750 Блок питания 750W
Warranty - 36
Warranty - 36 month(s)
weight - 0.3 kg
Weight - 1,93
