ID: 1441484
Product code: 306-7ZPNX11-CE0
In stock 9 units
Warranty: 2 years
MSI MAG A1200PLS PCIE5, 1000W, 80PLUS Platinum, ATX 3.1, PCIe 5.1
Picture may differ from actual product, there can be accessories and parts not supplied with the actual product.
-
Omniva parcel machineWithin 1-2 working days1.60 € -
SmartPosti parcel terminalWithin 1-2 working days1.60 € -
Unisend parcel terminalWithin 1-2 working days1.60 € -
Delivery by courier to the addressWithin 1-2 working days4.83 €
Main product parameters All parameters
- Producer: MSI
- Power output: 1200W
- 80 PLUS certification: 80 PLUS Platinum
- Fan size: 135 mm
- Modular cables: Fully-Modular
- Processor plug-in: 2 x 8-pin(4+4) EPS
- PCI-E: 4 X 6+2pin
Description
We offer to purchase a MSI power supply unit with a power capacity of 1200W, which has received the 80 PLUS Platinum energy efficiency certification.
120 mm fans, with which this power supply unit is equipped, will ensure industry standard quiet operation. For especially quiet power supply unit operation, we recommend purchasing a 135 mm or 145 mm diameter fan.
The power supply unit has received the 80 PLUS Platinum energy efficiency certificate, which guarantees at least 92% efficiency at 50% load. This means that for every 100W of power the power supply unit receives from the electrical grid, at least 92W are delivered to your computer components, while the remaining 8W are lost as heat.
The color of the power supply is Melna. It is equipped with flat cables, whose color is Melna.
This power supply unit has fully-modular cables (Fully-modular) – you can connect and disconnect all the included cables as needed, reducing clutter and improving ventilation. This will be useful for those with a partially transparent computer case and for whom the aesthetic factor is particularly important.
The manufacturer of this power supply unit is MSI. Check out all MSI power supply units here.
Basic information
Cybenetics Efficiency certification
: Cybenetics Platinum
Cybenetics Noise level certification
: There isn't
Power supply type
: ATX
Power output
1200W
The capacity of the power supply unit in watts. A higher capacity means higher stability of the computer operation. The recommended capacity of the power supply unit of a modern average computer is 500 W and above. If you use several HDDs, a powerful video card and processor it is recommended to buy a power supply unit with the capacity 600 W or above.
80 PLUS certification
: 80 PLUS Platinum
Total amperage (+12V)
: 100A
Fan size
: 135 mm
Functionality
Cable colour
: Black
Lighting
: None
Color
: Black
Modular cables
: Fully-Modular
Ports and equipment
PCI-E 5.0/5.1
: 1 x 600W 12V-2X6 (5.1)
Processor plug-in
: 2 x 8-pin(4+4) EPS
Motherboard power
: 24-pin
PCI-E
: 4 X 6+2pin
SATA cconnectors
: 6
4pin Molex
: 3
More detailed specification
80 PLUS certification Performance - 80 PLUS Platinum
AC input frequency Power - 50/60 Hz
AC input voltage Power - 100 - 240 V
ATX power connector (20+4 pin) Ports & interfaces - Yes
ATX Power connector (24-pin) Ports & interfaces - No
Cabling type Ports & interfaces - Fully-Modular
Category Code - PSU
Category_1 - Power
Category_2 - Computer Power Supplies
Combined power (+3.3V) Power - 100 W
Combined power (+5V) Power - 100 W
Combined power (+5Vsb) Power - 15 W
Combined power (+12V) Power - 1200 W
Cooling type Design - Active
CPU power connector (4+4 pin) Ports & interfaces - Yes
Depth Weight & dimensions - 150 mm
Description - Featuring ATX 3.1 and PCIe 5.1 support with native 12V-2x6 connectors, these PSUs are built to handle NVIDIA’s 50 series graphics cards and AI PCs with ease. Advanced thermal solutions ensure cool, stable, and efficient operation, even under heavy loads, giving you the reliability and durability you need for gaming, streaming, or AI-powered tasks. MSI's mainstream MAG series epitomizes stability and durability and is built to withstand the most intense gaming sessions. The entire lineup features robust construction with metallic-like hardness and excellent heat dissipation, ensuring stability for all critical gaming components. OPTIMIZED SOUND LEVEL
This power supply is designed for quiet operation, delivering low noise levels like in the night, ensuring a serene computing experience free from disturbances.Premium protection, GPU Safeguard and Fan SafeguardSupports Nvidia® GeForce RTXTM 50 series graphics cardsNative 12V-2x6 connectorDual-color 12V-2x6 cable80 PLUS Platinum certifiedOptimized the sound levelMain 105oC capacitorEmbossed Jacket Cables, the cables are more bending and routingIndustrial level protection with OCP/ OTP/ OPP/ SCP/ OVP/ UVP/ SIP/ NLO
EAN_code - 4711377397919
EPS power connector (4+4 pin) Ports & interfaces - Yes
Fan diameter Design - 13.5 cm
Floppy disk drive connector Ports & interfaces - No
Height Weight & dimensions - 86 mm
Illumination Design - No
Manufacturer - MSI
Manufacturer_code - 306-7ZPNX11-CE0
Max output current (+3.3V) Power - 20 A
Max output current (+5Vsb) Power - 3 A
Max output current (+12V) Power - 100 A
Model name - MAG A1200PLS PCIE5
Motherboard power cable length Ports & interfaces - 60 cm
Motherboard power connector Ports & interfaces - 20+4 pin ATX
Name - MSI MAG A1200PLS PCIE5 1200W (black, 1200 watts)
Number of fans Design - 1 fan(s)
Number of SATA power connectors Ports & interfaces - 6
On/off switch Design - Yes
PCI Express power connectors (6+2 pin) Ports & interfaces - 3
Peripheral (Molex) power connectors (4-pin) Ports & interfaces - 2
Power Factor Correction (PFC) type Power - Active
Power supply unit (PSU) form factor Performance - ATX
Product colour Design - Black
Purpose Performance - PC
Summary - MSI MAG A1200PLS PCIE5. Total power: 1200 W, AC input voltage: 100 - 240 V, AC input frequency: 50/60 Hz. Motherboard power connector: 20+4 pin ATX, Motherboard power cable length: 60 cm, Cabling type: Fully-Modular. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Platinum. Product colour: Black, Cooling type: Active, Fan diameter: 13.5 cm. Width: 150 mm, Depth: 150 mm, Height: 86 mm
Total power Power - 1200 W
Unit Box Height - 0.13
Unit Box Length - 0.3
Unit Box Width - 0.23
Unit Calculated Volume - 0.01117 cubm
Unit Calculated Weight - 3.55 kg
Units per Pallet - 0
Units per Shipping Box - 4
Vendor Homepage - https://www.msi.com/Power-Supply/MAG-A1200PLS-PCIE5
Warranty - 24 months
Weight - 0,00
Width Weight & dimensions - 150 mm
