Asus Prime 750W Bronze White Edition, 80PLUS Bronze

Picture may differ from actual product, there can be accessories and parts not supplied with the actual product.
News
ID: 1432029 Product code: 90YE00Y3-B0NA00
Can be ordered 6 units Availability: 14 days after order approval
Warranty: 2 years (Warranty for business entities 1 year)
111.33 €
Ready for dispatch
13.07.2026
starting from 1.99 € with VAT
Delivery options
  • Omniva parcel machine
    Within 1-2 working days
    1.99 €
  • SmartPosti parcel terminal
    Within 1-2 working days
    1.99 €
  • Unisend parcel terminal
    Within 1-2 working days
    1.99 €
  • Delivery by courier to the address
    Within 1-2 working days
    5.99 €
Main product parameters All parameters
  • Producer: Asus
  • Power output: 750W
  • 80 PLUS certification: 80 PLUS Bronze
  • Fan size: 135 mm
  • Modular cables: None
  • Processor plug-in: 2 x 8-pin(4+4) EPS
  • PCI-E: 4 X 6+2pin
Description

Available for purchase is a power supply produced by Asus with a power output of 750W. The product has been awarded an 80 PLUS Bronze energy efficiency certificate.

With 750W power, it will be sufficient for a good mid-level gaming experience. The power supply unit will be able to run a computer with a high-class processor, a powerful mid-range graphics card (for example, RTX 4070), and several drives (SSD/HDD).

The large 135 mm cooling fan diameter makes this power supply significantly quieter than average. Since the fan blade area is larger, the fan provides the necessary airflow at lower fan speeds, overall reducing the noise and vibration levels.

The power supply has been awarded the 80 PLUS Bronze energy efficiency certificate, which ensures at least 85% efficiency at 50% load. This indicates that at least 85 W out of 100 W of power received by the power supply from the electrical grid is delivered to the computer components, with the remaining 15 W being lost as heat.

The color of the block is Balta. The block has flat cables, whose color is Balta.

This is a power supply that complies with ATX 2.0 requirements. The power supply has only 6-pin and 8-pin connectors, which can handle only 75 W and 150 W of power, respectively. Modern graphics cards' high power needs exceed the capabilities of ATX 2.0 connectors. When building a system with a very powerful GPU, such as an RTX 4070, you will need an ATX 3.* standard power supply.

The power supply unit does not have modular cables; all cables are attached to the power supply unit and are not removable. Despite this, it will work just as well as a power supply unit with modular cables.

The manufacturer of this power supply unit is Asus. Check out all Asus power supply units here.

Basic information
Cybenetics Efficiency certification : There isn't
Cybenetics Noise level certification : There isn't
Power supply type : ATX
Power output 750W
The capacity of the power supply unit in watts. A higher capacity means higher stability of the computer operation. The recommended capacity of the power supply unit of a modern average computer is 500 W and above. If you use several HDDs, a powerful video card and processor it is recommended to buy a power supply unit with the capacity 600 W or above.
80 PLUS certification : 80 PLUS Bronze
Total amperage (+12V) : 62.5A
Fan size : 135 mm
Functionality
Cable colour : White
Lighting : None
Color : White
Modular cables : None
Ports and equipment
PCI-E 5.0/5.1 : There is no
Processor plug-in : 2 x 8-pin(4+4) EPS
Motherboard power : 20+4-pin
PCI-E : 4 X 6+2pin
SATA cconnectors : 6
4pin Molex : 3
Case
More detailed specification
Brand - ASUS
BrandPartCode - 90YE00Y3-B0NA00
Category - Power Supply Units
Category_1 - Power
Category_2 - Computer Power Supplies
Design - Cooling type - Active
Design - Fan diameter - 13.5 cm
Design - Fan location - Top
Design - Illumination - No
Design - Number of fans - 1 fan(s)
Design - On/off switch - Yes
Design - Product colour - White
EAN_code - 4711636055147
GTIN - 4711636055147
LongDesc - ASUS Prime 750W Bronze White Edition PSU brings efficient and durable power delivery to all-round PCs, and gaming rigs.Prime PerformanceWith 80+ Bronze certification, dual ball fan bearings, etched cables and an 6-year warranty, the ASUS Prime series PSU brings efficient and durable power delivery to reliable performance for the system build.
LongProductName - 750W, Active PFC, ATX12V, 80Plus Bronze, 100-240Vac, 2.2 kg, white
LongSummaryDescription - ASUS Prime 750W Bronze White Edition. Total power: 750 W, AC input voltage: 100 - 240 V, Power Factor Correction (PFC) type: Active. Motherboard power connector: 20+4 pin ATX, Motherboard power cable length: 60 cm, SATA power cable length: 120,400 mm. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Bronze. Product colour: White, Cooling type: Active, Fan diameter: 13.5 cm. Width: 150 mm, Depth: 150 mm, Height: 86 mm
Manufacturer - Asus
Manufacturer_code - 90YE00Y3-B0NA00
Name - Asus PRIME-750B-WHITE (white, 4x PCIe, 750 watts)
Packaging data - Package depth - 196 mm
Packaging data - Package height - 115 mm
Packaging data - Package type - Box
Packaging data - Package weight - 3 kg
Packaging data - Package width - 340 mm
Performance - 80 PLUS certification - 80 PLUS Bronze
Performance - Mean time between failures (MTBF) - 120000 h
Performance - Power supply unit (PSU) form factor - ATX
Performance - Purpose - PC
Ports & interfaces - Cabling type - Non-Modular
Ports & interfaces - CPU power cable length - 80 cm
Ports & interfaces - CPU power connector (4+4 pin) - Yes
Ports & interfaces - Motherboard power cable length - 60 cm
Ports & interfaces - Motherboard power connector - 20+4 pin ATX
Ports & interfaces - Number of SATA power connectors - 6
Ports & interfaces - PCI Express connector - Yes
Ports & interfaces - PCI Express power cable length - 60 cm
Ports & interfaces - PCI Express power connectors (8-pin) - 3
Ports & interfaces - Peripheral (Molex) power cable length - 120,400 mm
Ports & interfaces - Peripheral (Molex) power connectors (4-pin) - 3
Ports & interfaces - SATA power cable length - 120,400 mm
Power - AC input voltage - 100 - 240 V
Power - Combined power (+3.3V) - 120 W
Power - Combined power (+5V) - 120 W
Power - Combined power (+5Vsb) - 12.5 W
Power - Combined power (+12V) - 750 W
Power - Combined power (-12V) - 3.6 W
Power - Max output current (+3.3V) - 20 A
Power - Max output current (+5V) - 20 A
Power - Max output current (+5Vsb) - 2.5 A
Power - Max output current (+12V) - 62.5 A
Power - Max output current (-12V) - 0.3 A
Power - Power Factor Correction (PFC) type - Active
Power - Power protection features - Over current, Over power, Over voltage, Short circuit, Under voltage
Power - Total power - 750 W
ProductName - Prime 750W Bronze White Edition
ShortSummaryDescription - ASUS Prime 750W Bronze White Edition, 750 W, 100 - 240 V, Active, 120 W, 750 W, 120 W
Title - ASUS Prime 750W Bronze White Edition power supply unit 20+4 pin ATX ATX
URL - https://www.asus.com/motherboards-components/power-supply-units/prime/prime-750b-white/
WarrantyInfo -
Weight - 0,00
Weight & dimensions - Depth - 150 mm
Weight & dimensions - Height - 86 mm
Weight & dimensions - Weight - 2.2 kg
Weight & dimensions - Width - 150 mm
