Brand - FSP
BrandPartCode - PPA13F0101
Category - Power Supply Units
Category 1 - Netzteile
Design - Cooling type - Semi-passive
Design - Fan diameter - 13.5 cm
Design - Number of fans - 1 fan(s)
Design - On/off switch - Yes
Design - Product colour - Black
EAN - 4713224529047
GTIN - 4713224529047
LongDesc - New ATX PSU SpecificationsUpdated ATX 3.0 specifications for the next-generation hardware power demands and ensure users get the most stable and cost-optimized performance possible with the highest power efficiency.High Compatibility for High PowerThe series comes with native PCIe Gen 5 connector and also supports 3 slots of PCIe 6+2Pin for graphic card, besides, 2 slots of CPU connector for higher performance.Conformal Coating ApplicationOff-Wet, Off-Dust and Off-StainThe conformal coating which protects the power supply and its internal components from dust, humidity, stains. The Hydro PTM PRO series are covered with conformal coating to guarantee reliable performance in a harsh environment and tested to work perfectly even in 95% relative humidity.LLC Full-Bridge Topology with DC-DC Module DesignHydro PTM PRO series features extremely tight voltage regulation to make the output voltage regulation under +/- 1% above 10% load change and offer you supreme efficiency and voltage stability.Fully Modular Design for Quick and Easy InstallationFully modular design simplifies installation and allows you to use only the cables you need, for a neater, cleaner build.ECO Switch, Quieter and Longer Lasting FanWhen Eco Button is switched on, the PSU runs with lower power consumption and is whisper silent. The fan in the power supply will not operate when the power supply is under 30% loading for silent state.80 Plus® Platinum CertificationHydro PTM PRO series come with 80 Plus Platinum Certification which means your power supplies consume less heat and have a lower operating cost. The power supplies are guaranteed to operate at a minimum of 92% efficiency at 50% load of PSU rated power.Compliance with IEC 62368FSP Group features the latest in green power technology and provides additional safety approvals to keep its power supplies ahead of regulation changes. FSP has upgraded the majority of its power supplies to the newer IEC 62368 standards.Supports Latest CPU SystemsHydro PTM PRO fully supports high performance systems, complies with the most recent Intel, ATX12V V3.0 & EPS12V V2.92 standards.Safety ProtectionOVP (Over Voltage Protection), UVP (Under Voltage Protection), OCP (Over Current Protection), OPP (Over Power Protection), SCP (Short Circuit Protection), and OTP (Over Temperature Protection), a full guardian circuit protections to keep your hardware safe.
LongProductName - Hydro PTM PRO 1350W ATX3.0(12V-2x6)
LongSummaryDescription - FSP Hydro PTM PRO 1350W ATX3.0(12V-2x6). Total power: 1350 W, AC input voltage: 110 - 240 V, AC input frequency: 50/60 Hz. Motherboard power connector: 20+4 pin ATX, Cabling type: Fully-Modular. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Platinum. Product colour: Black, Cooling type: Semi-passive, Fan diameter: 13.5 cm. Width: 150 mm, Depth: 180 mm, Height: 86 mm
Manufacturer - FSP
MPN - PPA13F0101
Name - 1350W FSP HPT2-1350M ATX 3.1 80+ Platinum
Performance - 80 PLUS certification - 80 PLUS Platinum
Performance - ATX version - 3.0
Performance - Bearing technology - FDB
Performance - EPS version - 2.92
Performance - Power supply unit (PSU) form factor - ATX
Performance - Purpose - PC
Ports & interfaces - Cabling type - Fully-Modular
Ports & interfaces - CPU power connector (4+4 pin) - Yes
Ports & interfaces - Motherboard power connector - 20+4 pin ATX
Ports & interfaces - Number of SATA power connectors - 12
Ports & interfaces - PCI Express power connectors (6+2 pin) - 4
Ports & interfaces - Peripheral (Molex) power connectors (4-pin) - 4
Power - AC input frequency - 50/60 Hz
Power - AC input voltage - 110 - 240 V
Power - Combined power (+3.3V) - 20 W
Power - Combined power (+5V) - 20 W
Power - Combined power (+5Vsb) - 5 W
Power - Combined power (+12V) - 1350 W
Power - Combined power (-12V) - 3.6 W
Power - Efficiency - 92%
Power - Max output current (+3.3V) - 20 A
Power - Max output current (+5V) - 20 A
Power - Max output current (+5Vsb) - 3 A
Power - Max output current (+12V) - 112.5 A
Power - Max output current (-12V) - 0.3 A
Power - Number of +12V rail(s) - 1
Power - Power Factor Correction (PFC) type - Active
Power - Power protection features - Over current, Over power, Over voltage, Short circuit, Under voltage
Power - Total power - 1350 W
ProductName - Hydro PTM PRO 1350W ATX3.0(12V-2x6)
ShortSummaryDescription - FSP Hydro PTM PRO 1350W ATX3.0(12V-2x6), 1350 W, 110 - 240 V, 50/60 Hz, Active, 20 W, 1350 W
Title - FSP Hydro PTM PRO 1350W ATX3.0(12V-2x6) power supply unit 20+4 pin ATX ATX Black
URL - https://www.fsplifestyle.com/en/product/HydroPTMPRO1350W_12V2X6.html
WarrantyInfo -
Weight - 4.24
Weight & dimensions - Depth - 180 mm
Weight & dimensions - Height - 86 mm
Weight & dimensions - Width - 150 mm
