Corsair WS3000, 3000W, 80PLUS Platinum, ATX 3.1, PCIe 5.1

Picture may differ from actual product, there can be accessories and parts not supplied with the actual product.
ID: 1301449 Product code: CP-9020312-EU
Goods are not available at the moment We do not accept orders for the delivery of this product. We do not have information as to when this product will be available. Our suppliers currently do not provide information about possible delivery times of the product and the possible price when it is on sale again.

TopPC.ee website provides information about this product for information only, so that customers can see the product and compare it to the products available for sale now.

Warranty: 2 years
Main product parameters All parameters
  • Producer: Corsair
  • Power output: 3000W
  • 80 PLUS certification: 80 PLUS Platinum
  • Fan size: 140 mm
  • Modular cables: Fully-Modular
  • Processor plug-in: 2 x 8-pin(4+4) EPS
  • PCI-E: 8 x 6+2pin
Similar Products
This product Corsair WS3000, 3000W, 80PLUS Platinum, ATX 3.1, PCIe 5.1
Corsair SF750 (2024), 750W, 80PLUS Platinum, ATX 3.1, PCIe 5.1
Corsair HX1500i SHIFT, 1500W, Cybenetics Platinum, ATX 3.1, PCIe 5.1
NZXT C1000 Core, 80PLUS Gold, ATX 3.1, PCIe 5.1
AeroCool Premier G1, 750W, 80PLUS Gold, ATX 3.1, PCIe 5.1
Show similar specs. Hide similar specs.
533.31 €
193.61 €
309.85 €
160.48 €
105.63 €
Basic information
Cybenetics Efficiency certification There isn't Cybenetics Platinum Cybenetics Platinum Cybenetics Platinum Cybenetics Platinum
Cybenetics Noise level certification There isn't Cybenetics A - Cybenetics A Cybenetics A + There isn't
Power supply type ATX SFX ATX ATX ATX
Power output 3000W 750W 1500W 1000W 750W
80 PLUS certification 80 PLUS Platinum 80 PLUS Platinum 80 PLUS Platinum 80 PLUS Gold 80 PLUS Gold
Total amperage (+12V) 250A 62.5A 125A 83.3A 62.5A
Fan size 140 mm 92 mm 140 mm 135 mm 135 mm
Functionality
Cable colour Black Black Black Black Black
Lighting None None None None None
Color Black Black Black Black Black
Modular cables Fully-Modular Fully-Modular Fully-Modular Fully-Modular Fully-Modular
Ports and equipment
PCI-E 5.0/5.1 4 x 600W 12V-2X6 (5.1) 1 x 450W 12V-2X6 (5.1) 2 x 600W 12V-2X6 (5.1) 1 x 600W 12V-2X6 (5.1) 1 x 450W 12V-2X6 (5.1)
Processor plug-in 2 x 8-pin(4+4) EPS 2 x 8-pin(4+4) EPS 2 x 8-pin(4+4) EPS 2 x 8-pin(4+4) EPS 2 x 8-pin(4+4) EPS
Motherboard power 24-pin 24-pin 20+4-pin 24-pin 24-pin
PCI-E 8 x 6+2pin 2 X 6+2pin 4 X 6+2pin 3 x 6+2pin 2 X 6+2pin
SATA cconnectors 9 8 12 8 8
4pin Molex 6 4 8 3 2
Description

Available for purchase is a power supply produced by Corsair with a power output of 3000W. The product has been awarded an 80 PLUS Platinum energy efficiency certificate.

This power supply unit is equipped with a 140 mm fan. Thanks to its massive size, it will provide excellent airflow, better cooling even at lower speeds, and will be noticeably quieter than a standard 120 mm fan.

The power supply has been awarded the 80 PLUS Platinum energy efficiency certificate, which ensures at least 92% efficiency at 50% load. This indicates that at least 92 W out of 100 W of power that the power supply receives from the power grid is delivered to the computer components, while the remaining 8 W is lost as heat.

The color of the block is Melna. The block has flat cables, whose color is Melna.

This power supply unit has fully-modular cables (Fully-modular) – you can connect and disconnect all the included cables as needed, reducing clutter and improving ventilation. This will be useful for those with a partially transparent computer case and for whom the aesthetic factor is particularly important.

Basic information
Cybenetics Efficiency certification : There isn't
Cybenetics Noise level certification : There isn't
Power supply type : ATX
Power output 3000W
The capacity of the power supply unit in watts. A higher capacity means higher stability of the computer operation. The recommended capacity of the power supply unit of a modern average computer is 500 W and above. If you use several HDDs, a powerful video card and processor it is recommended to buy a power supply unit with the capacity 600 W or above.
80 PLUS certification : 80 PLUS Platinum
Total amperage (+12V) : 250A
Fan size : 140 mm
Functionality
Cable colour : Black
Lighting : None
Color : Black
Modular cables : Fully-Modular
Ports and equipment
PCI-E 5.0/5.1 : 4 x 600W 12V-2X6 (5.1)
Processor plug-in : 2 x 8-pin(4+4) EPS
Motherboard power : 24-pin
PCI-E : 8 x 6+2pin
SATA cconnectors : 9
4pin Molex : 6
More detailed specification
Design - Cooling type - Active
Design - Fan diameter - 14 cm
Design - Number of fans - 1 fan(s)
Design - Product colour - Black
dimensionalWeight - 2425
Packaging content - Cables included - AC, CPU, PATA, PCIe, SATA
Packaging data - Package type - Box
Performance - 80 PLUS certification - 80 PLUS Platinum
Performance - ATX version - 3.1
Performance - Mean time between failures (MTBF) - 100000 h
Performance - Power supply unit (PSU) form factor - ATX
Performance - Purpose - PC
Ports & interfaces - Cabling type - Fully-Modular
Ports & interfaces - EPS power connector (4+4 pin) - Yes
Ports & interfaces - Motherboard power connector - 24-pin ATX
Ports & interfaces - Number of PATA power connectors - 3
Ports & interfaces - Number of SATA power connectors - 3
Ports & interfaces - PCI Express power connectors (6+2 pin) - 2
Power - AC input frequency - 47 - 63 Hz
Power - AC input voltage - 220 - 240 V
Power - Combined power (+3.3V) - 130 W
Power - Combined power (+5V) - 130 W
Power - Combined power (+5Vsb) - 15 W
Power - Combined power (+12V) - 3000 W
Power - Input current - 16 A
Power - Max output current (+3.3V) - 25 A
Power - Max output current (+5V) - 25 A
Power - Max output current (+5Vsb) - 3.5 A
Power - Max output current (+12V) - 250 A
Power - Total power - 3000 W
producerCode - CP-9020312-EU
productName - Corsair WS3000 3000W 80+ Pla ATX 3.1 F.Mod power supply
productSize - Normal
sizeX - 285
sizeY - 230
sizeZ - 185
warrantyLength - 24
warrantyType - G
weight - 4545
Weight & dimensions - Weight - 4.47 kg
