ID: 1287612
Product code: PS-TTP-0550NNSABE-1
Can be ordered 10 units Availability: 14 days after order approval
Warranty: 3 years
Thermaltake Smart BX1 SE, 550W, 80PLUS Bronze, BULK
Picture may differ from actual product, there can be accessories and parts not supplied with the actual product.
This image was created with the help of AI and is for illustrative purposes. The appearance, colours, dimensions, lighting and arrangement of the components may differ from the actual product. The image may include parts and accessories that are not included with the product.
-
Omniva parcel machineWithin 1-2 working days1.99 € -
SmartPosti parcel terminalWithin 1-2 working days1.99 € -
Unisend parcel terminalWithin 1-2 working days1.99 € -
Courier delivery to your addressWithin 1-2 working days5.99 €
Main product parameters All parameters
- Producer: Thermaltake
- Power output: 550W
- 80 PLUS certification: 80 PLUS Bronze
- Fan size: 120 mm
- Modular cables: None
- Processor plug-in: 1 x 8-pin(4+4) EPS
- PCI-E: 2 X 6+2pin
Description
We offer to purchase a Thermaltake power supply unit with a power capacity of 550W, which has received the 80 PLUS Bronze energy efficiency certification.
With 550W power, it will be enough to run Office programs, browse the internet, and play simple computer games. It will be able to run a computer with a budget-level processor, integrated graphics card, small SSD, or HDD disk. If there is a desire to upgrade computer components in the future, it is definitely worth considering a more powerful power supply unit.
The diameter of this power supply unit's fan is 120 mm, which will ensure quiet operation in mid-range computers. For especially quiet power supply unit operation, we recommend selecting a fan with a 135 mm or 140 mm diameter.
The power supply has been awarded the 80 PLUS Bronze energy efficiency certificate, which ensures at least 85% efficiency at 50% load. This indicates that at least 85 W out of 100 W of power received by the power supply from the electrical grid is delivered to the computer components, with the remaining 15 W being lost as heat.
The color of the block is Melna. The block has flat cables, whose color is Melna.
This is a power supply that complies with ATX 2.0 requirements. The power supply has only 6-pin and 8-pin connectors, which can handle only 75 W and 150 W of power, respectively. Modern graphics cards' high power needs exceed the capabilities of ATX 2.0 connectors. When building a system with a very powerful GPU, such as an RTX 4070, you will need an ATX 3.* standard power supply.
This power supply has no removable cables and all cables are attached to the power supply. It has a simple design, but it works just as well as a power supply with modular cables.
Basic information
Cybenetics Efficiency certification
: There isn't
Cybenetics Noise level certification
: There isn't
Power supply type
: ATX
Power output
550W
The capacity of the power supply unit in watts. A higher capacity means higher stability of the computer operation. The recommended capacity of the power supply unit of a modern average computer is 500 W and above. If you use several HDDs, a powerful video card and processor it is recommended to buy a power supply unit with the capacity 600 W or above.
80 PLUS certification
: 80 PLUS Bronze
Total amperage (+12V)
: 45.8A
Fan size
: 120 mm
Functionality
Cable colour
: Black
Lighting
: None
Color
: Black
Modular cables
: None
Ports and equipment
PCI-E 5.0/5.1
: There is no
Processor plug-in
: 1 x 8-pin(4+4) EPS
Motherboard power
: 20+4-pin
PCI-E
: 2 X 6+2pin
SATA cconnectors
: 6
4pin Molex
: 2
More detailed specification
Certificates 80+ - 80 PLUS Bronze
Design - Cooling type - Active
Design - Fan diameter - 12 cm
Design - Fan location - Top
Design - Illumination - No
Design - Number of fans - 1 fan(s)
Design - On/off switch - Yes
Design - Product colour - Black
Designation - CE+WEEE
dimensionalWeight - 864
dimension depth - 90 mm
dimension height - 270 mm
Dimensions - 150 x 86 x 140 mm
dimension weight - 1330 g
dimension width - 160 mm
ean - 4711475649880
Fan - 12 cm
Filters / protection - Circuit
Filters / protection - Current too high
Filters / protection - Overload
Filters / protection - Surge
Filters / protection - Thermal
Filters / protection - Voltage drop
Form Factor - ATX
guarantee - 60
guarantee_type - statutory
MB power connector - 20 + 4 pin
Modular power supply - No
MOLEX power connectors - 2
name - Smart BX1 S E 550W Bulk
Number of power supply connector 4+4-pin 12V - 1
Number of power supply connectors PCI-E 6 +2 pin - 2
Operational conditions - Operating relative humidity (H-H) - 20 - 85%
Operational conditions - Operating temperature (T-T) - 5 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 10 - 95%
Operational conditions - Storage temperature (T-T) - -40 - 55 °C
Performance - 80 PLUS certification - 80 PLUS Bronze
Performance - ATX version - 2.3
Performance - EPS version - 2.92
Performance - Mean time between failures (MTBF) - 100000 h
Performance - Noise level - 37.6 dB
Performance - Power supply unit (PSU) form factor - ATX
Performance - Purpose - PC
Performance - Safety - CE, CB, TUV, EAC, RCM
PFC - Active
Ports & interfaces - Cabling type - Non-Modular
Ports & interfaces - CPU power cable length - 65 cm
Ports & interfaces - CPU power connector (4+4 pin) - Yes
Ports & interfaces - Floppy disk drive connector - Yes
Ports & interfaces - Floppy drive power connector - 1
Ports & interfaces - Motherboard power cable length - 60 cm
Ports & interfaces - Motherboard power connector - 24-pin ATX
Ports & interfaces - Number of SATA power connectors - 6
Ports & interfaces - PCI Express connector - Yes
Ports & interfaces - PCI Express power connectors (6+2 pin) - 2
Ports & interfaces - Peripheral (Molex) power cable length - 150 mm
Ports & interfaces - Peripheral (Molex) power cable length - 500 mm
Ports & interfaces - Peripheral (Molex) power connectors (4-pin) - 2
Ports & interfaces - SATA power cable length - 150 mm
Ports & interfaces - SATA power cable length - 500 mm
Power - AC input frequency - 50 Hz
Power - AC input voltage - 230 V
Power - Input current - 10 A
Power - Maximum input current (@220V) - 10 A
Power - Power Factor Correction (PFC) type - Active
Power - Power Good signal delay range - 100 - 500 ms
Power - Total power - 550 W
Power supply - 550 W
producer - Thermaltake
producerCode - PS-TTP-0550NNSABE-1
productName - THERMALTAKE SMART BX1 SE 550W 80+ BRONZE EU BULK
productSize - Normal
SATA power connectors - 6
sizeX - 160
sizeY - 90
sizeZ - 300
vendpn - PS-TTP-0550NNSABE-1
warrantyLength - 36
warrantyType - G
weight - 1560
Weight & dimensions - Depth - 140 mm
Weight & dimensions - Height - 86 mm
Weight & dimensions - Width - 150 mm
