Endorfy Supremo FM6, 1000W, 80PLUS Gold, ATX 3.1, PCIe 5.1

80 PLUS certification Performance - 80 PLUS Gold
Accessories included - Supremo FM6 1000W Power Supply Modular Cabling Power Cable Mounting Kit User Manual
AC input frequency Power - 50/60 Hz
AC input voltage Power - 100 - 240 V
ATX version - 3.1
ATX version Performance - 3.1
Bearing technology Performance - FDB
Cables included Packaging content - AC
Cabling type Ports & interfaces - Fully-Modular
Category - Root/Electronics/PC parts/PC power supply units
Category Code - PSU
Category_1 - Power
Category_2 - Computer Power Supplies
Certificates 80+ - 80 PLUS Gold
Combined power (+3.3V) Power - 100 W
Combined power (+5V) Power - 100 W
Combined power (+5Vsb) Power - 15 W
Combined power (+12V) Power - 996 W
Combined power (-12V) Power - 3.6 W
Compliance certificates Certificates - CB, CCC, CE, Federal Communications Commission (FCC), RoHS, UKCA
Cooling type Design - Active
Cybenetics certification Performance - Platinum
Cybenetics Efficiency (ETA) - Platinum
Cybenetics Noise (LAMBDA) - A
Dane techniczne: Certyfikat sprawności - 80 Plus Gold
Dane techniczne: Dodatkowe informacje - Zgodność z wytycznymi ATX 3.1 Certyfikat 80 PLUS® Gold Cicha praca 100% japońskie kondensatory W pełni modularne okablowanie 10 lat gwarancji Kabel zasilający 12V-2x6
Dane techniczne: Grupa produktowa - Zasilacze do komputera Endorfy
Dane techniczne: Gwarancja - 10 lat w serwisie zewnętrznym
Dane techniczne: Głębokość - 150 mm
Dane techniczne: Ilość wentylatorów chłodzących - 1
Dane techniczne: Moc - 1000 W
Dane techniczne: Modularne okablowanie - w pełni modularne
Dane techniczne: MTBF - 100000 godz.
Dane techniczne: Odłączane przewody - tak
Dane techniczne: Producent - Endorfy
Dane techniczne: Rodzaj chłodzenia - wentylator
Dane techniczne: Standard - ATX
Dane techniczne: Szerokość - 140 mm
Dane techniczne: Waga - 1.54 kg
Dane techniczne: Wersja standardu ATX - ATX 3.1
Dane techniczne: Wtyczka zasilania [pin] - 1 x 16-pin PCIe (12VHPWR)
Dane techniczne: Wtyczka zasilania [pin] - 2 x 4/8 EPS 12V
Dane techniczne: Wtyczka zasilania [pin] - 3 x 8-pin PEG
Dane techniczne: Wtyczka zasilania [pin] - 8 x SATA
Dane techniczne: Wtyczka zasilania [pin] - ATX 24pin
Dane techniczne: Wysokość - 87 mm
Dane techniczne: Zabezpieczenia - OCP
Dane techniczne: Zabezpieczenia - OPP
Dane techniczne: Zabezpieczenia - OTP
Dane techniczne: Zabezpieczenia - OVP
Dane techniczne: Zabezpieczenia - SCP
Dane techniczne: Zabezpieczenia - SIP
Dane techniczne: Zabezpieczenia - UVP
Dane techniczne: Średnica wentylatorów - 120 mm
Depth Weight & dimensions - 150 mm
Description - ENDORFY Supremo FM6 1000W
The Supremo FM6 1000W is a modern, fully modular ATX 3.1 power supply, ensuring stable operation and supporting the latest PCIe 5.1 graphics cards. 80 PLUS Gold certification confirms its high energy efficiency, and a 120mm Fluctus fan ensures quiet operation. Thanks to premium Japanese capacitors and a 10-year warranty, it's a reliable solution for gamers and professionals.
Ready for the latest ATX 3.1 standards
The Supremo FM6 1000W is a power supply compliant with the ATX 3.1 standard. It boasts even better efficiency, stability, and resistance to transient power surges than previous ATX standards. A 12V-2x6 cable is included, ensuring full compatibility with PCIe 5.1 cards. Traditional PCI-E 6+2 PIN power connectors have also been incorporated, providing power to traditionally powered GPUs.
The Supremo FM6 1000W will ensure years of trouble-free operation in the most powerful gaming and work setups, ready for future component upgrades, even with upcoming technologies.
80 PLUS Gold - High Efficiency and Reliability
The high energy efficiency of the Supremo FM6 1000W power supply has been certified with 80 PLUS Gold certification. Thanks to its excellent quality and refined design, the unit boasts quiet operation and low heat generation, resulting in a longer lifespan.
Quiet Above All
The Supremo FM6 1000W is designed with maximum user comfort in mind. Thanks to an optimized component layout that improves airflow and an efficient cooling system, the power supply operates exceptionally quietly and maintains a low temperature even under full load.
Premium Japanese Capacitors
All capacitors used in the Supremo FM6 1000W power supply are reliable premium Japanese components. They maintain their performance even at high temperatures (105°C), ensuring trouble-free and stable operation even in extremely demanding conditions.
Reliable 120mm Fluctus Fan
Designed in partnership with Synergy Cooling, the award-winning Fluctus series fan, equipped with a fluid-dynamic bearing, keeps the power supply cool. Psychoacoustic optimization reduces fan noise, ensuring comfortable use even in non-insulated cases.
Fully Modular Cabling
You don't have to worry about cluttering up unused cables. Fully modular cabling allows you to connect only the cables you need. Besides making cable management more convenient, it also allows for more organized space within the case, improving airflow and temperature.
10-Year Warranty
We are confident in the quality and reliability of equipment with the ENDORFY logo. That's why the Supremo FM6 1000W power supply comes with a 10-year warranty, confirming long-lasting and trouble-free operation.
Protection Package
The Supremo FM6 1000W features a full suite of electrical and thermal protections. This means your computer is protected against overloads, voltage spikes, short circuits, and power supply overheating, ensuring stability and safety even in the harshest conditions.
ENDORFY Supremo FM6 1000W - Special Features: Compliant with ATX 3.1 guidelines 80 PLUS Gold certification Quiet operation 100% Japanese capacitors Fully modular cabling 10-year warranty 12V-2x6 power cable
Description - Supremo FM6 1000 W is a fully modular modern ATX 3.1-compliant power supply unit, providing stable operation and supporting PCIe 5.1 GPUs. 80 PLUS® Gold certificate confirms its high efficiency, while a Fluctus fan guarantees quiet work. Thanks to the Japanese capacitors and a 10-year warranty, it’s a reliable solution for avid gamers and professionals alike. Supremo FM6 1000 W
Supremo FM6 1000 W is a modular ATX 3.1 PSU for demanding users that supports PCIe 5.1 graphics cards. It boasts high power efficiency confirmed by an 80 PLUS® Gold certificate. The power supply’s design utilizes only the Japanese capacitors that guarantee its long service life. The quiet Fluctus 120 mm fan and optimized component placement ensure low temperatures with almost noiseless operation. Additionally, the modular cables make it easier to keep the surrounding space in order. The PSU also has a security package that protects it from overloading and power surges. Its quality is additionally confirmed by a 10-year warranty. Ready for latest ATX 3.1 standards
Supremo FM6 1000 W is a power supply unit compliant with the ATX 3.1 standard. Its major advantages include even better performance, stability, and resistance to momentary power spikes than previous ATX standards. The set includes the 12V-2x6 cable fully compatible with PCIe 5.1 cards. A traditional PCI-E 6+2 PIN splitter is also included to handle GPUs with classic power supply systems. 80 PLUS® Gold – supreme performance and reliability
The 80 PLUS® Gold certificate confirms the high efficiency of the Supremo FM6 1000 W power supply unit. Thanks to its excellent quality and refined design, the unit is characterized by low-noise and low-temperature operation, resulting in its extended service life.  Silence first
Supremo FM6 1000 W has been designed with maximum user comfort in mind. Thanks to the optimized component setup streamlining the air flow and a high-performance cooling system, the PSU runs exceptionally quietly and retains low temperature even under full load. Premium class capacitors made in Japan
All capacitors installed in the Supremo FM6 1000 W power supply unit are reliable, premium-class components made in Japan. They retain their operating parameters even at high temperatures (105 °C), enabling them to perform faultlessly and stably for years to come, even under extremely demanding operating conditions. 
Design - Cooling type - Active
Design - Fan diameter - 12 cm
Design - Fan location - Top
Design - Number of fans - 1 fan(s)
Design - On/off switch - Yes
Design - Product colour - Black
Designation - CE+WEEE
dimensionalWeight - 1166
dimension depth - 100 mm
dimension height - 225 mm
Dimensions - 87 x 140 x 150 mm
dimension weight - 2803 g
dimension width - 270 mm
Doesn't contain Technical details - Cadmium, Lead, Mercury
ean - 5903018667942
Eans - 5903018667942
EAN_code - 5903018667942
EPS power connector (4+4 pin) Ports & interfaces - Yes
EPS power connector (8-pin) Ports & interfaces - Yes
Fan - 12 cm
Fan diameter Design - 12 cm
Fan location Design - Top
Fan speed (max) - 1400 rpm
Filters / protection - Circuit
Filters / protection - Current too high
Filters / protection - Overload
Filters / protection - Protection against surges and surges
Filters / protection - Surge
Filters / protection - Thermal
Filters / protection - Voltage drop
guarantee - 120
guarantee_type - normal
Height Weight & dimensions - 87 mm
Illumination Design - No
Input current Power - 13 - 6.5 A
LED indicators Design - No
Manual Packaging data - Yes
Manufacturer - ENDORFY
Manufacturer_code - EY7A011
Max output current (+3.3V) Power - 20 A
Max output current (+5V) Power - 20 A
Max output current (+5Vsb) Power - 3 A
Max output current (+12V) Power - 83 A
Max output current (-12V) Power - 0.3 A
MB power connector - 24 pin
Mean time between failures (MTBF) Performance - 100000 h
Model name - Supremo FM6 1000 W
Modular power supply - Yes
MOLEX power connectors - 1
Motherboard power cable length Ports & interfaces - 60 cm
Motherboard power connector Ports & interfaces - 24-pin ATX
Name - ENDORFY Supremo FM6 1000 W (black, cable management, 1000 watts)
Name - ENDORFY Supremo FM6 Gold 1000 W
name - Power supply Supremo FM6 Gold 1000W EY7A011
Number of fans Design - 1 fan(s)
Number of power connectors 12VHPWR - 1
Number of power supply connector 4+4-pin 12V - 2
Number of SATA power cables Ports & interfaces - 3
Number of SATA power connectors Ports & interfaces - 8
On/off fan switch Design - No
On/off switch Design - Yes
Other features - Fan Bearing: FDB Input Voltage: 100 V / 240 V Lifespan: 100,000 h
Package depth Packaging data - 270 mm
Package height Packaging data - 95 mm
Package type Packaging data - Box
Package weight Packaging data - 2.74 kg
Package width Packaging data - 220 mm
Packaging data - Package depth - 270 mm
Packaging data - Package height - 95 mm
Packaging data - Package weight - 2.42 kg
Packaging data - Package width - 220 mm
PCI-E 8-pin power connectors - 3
PCI Express power cable length Ports & interfaces - 56 cm
PCI Express power connectors (6+2 pin) Ports & interfaces - 3
PCI Express power connectors (12+4 pin) Ports & interfaces - 1
Performance - 80 PLUS certification - 80 PLUS Gold
Performance - ATX version - 3.1
Performance - Power supply unit (PSU) form factor - ATX
Peripheral (Molex) power cable length Ports & interfaces - 880 mm
Peripheral (Molex) power connectors (4-pin) Ports & interfaces - 1
PFC - Yes
Ports & interfaces - Modular cabling - Y
Ports & interfaces - Motherboard power connector - ATX 3.1
Power - AC input frequency - 50 - 60 Hz
Power - AC input voltage - 100 - 240 V
Power - Max output current (+3.3V) - 20 A
Power - Max output current (+5V) - 20 A
Power - Max output current (+5Vsb) - 3 A
Power - Max output current (+12V) - 83 A
Power - Max output current (-12V) - 0.3 A
Power - Power protection features - OCP (overcurrent protection)
Power - Power protection features - OPP (overload protection)
Power - Power protection features - OTP (overheat protection)
Power - Power protection features - OVP (overvoltage protection)
Power - Power protection features - SCP (short circuit protection)
Power - Power protection features - SIP (surge and shock protection)
Power - Power protection features - UVP (undervoltage protection)
Power - Total power - 1000 W
Power Factor Correction (PFC) type Power - Active
Power protection features Power - Over current, Over power, Over voltage, Short circuit, Surge & inrush protection (SIP), Under temperature, Under voltage
Power supply - 1000 W
Power supply unit (PSU) form factor Performance - ATX
Producent: Nazwa producenta / importera - Endorfy
COOLING sp. z o.o
Sokołowska 24
05-806 Sokołów

producer - Endorfy
Producer - Endorfy
producerCode - EY7A011
ProducerCode - EY7A011
Product colour Design - Black
productName - Endorfy Supremo FM6 1000W (EY7A011) Black
productSize - Normal
Purpose Performance - PC
Safety warning - Warnings - Do not open the case - risk of electric shock.
Safety warning - Warnings - The product is not suitable for disposal with municipal waste - dispose of in accordance with local regulations.
SATA power cable length Ports & interfaces - 560,720,880 mm
SATA power connectors - 8
ShortDescription - 1000 | ATX | 120 mm | 87 mm 140mm 150 mm | 80PLUS GOLD | modularny | 3.1 |
sizeX - 96
sizeY - 225
sizeZ - 270
Summary - ENDORFY Supremo FM6 1000 W. Total power: 1000 W, AC input voltage: 100 - 240 V, AC input frequency: 50/60 Hz. Motherboard power connector: 24-pin ATX, Motherboard power cable length: 60 cm, SATA power cable length: 560,720,880 mm. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Gold. Product colour: Black, Cooling type: Active, Fan diameter: 12 cm. Cables included: AC
Sustainability certificates Technical details - ErP
Total power Power - 1000 W
Unit Box Height - 0.22
Unit Box Length - 0.1
Unit Box Width - 0.27
Unit Calculated Volume - 0.00594 cubm
Unit Calculated Weight - 2.8 kg
Units per Shipping Box - 1
Vendor Homepage - https://endorfy.com/en/product/supremo-fm6-850-w/
vendpn - EY7A011
Warranty - 24 months
warrantyLength - 120
Warranty period Logistics data - 10 year(s)
warrantyType - F
Weight - 1.54 kg
Weight - 2,80
weight - 2820
Weight & dimensions - Depth - 150 mm
Weight & dimensions - Height - 87 mm
Weight & dimensions - Weight - 1.46 kg
Weight & dimensions - Width - 140 mm
Width Weight & dimensions - 140 mm
