Cougar STC650, 650W, 80PLUS

Picture may differ from actual product, there can be accessories and parts not supplied with the actual product.
ID: 1155299 Product code: STC650
In stock 3 units
Warranty: 2 years (Warranty for business entities 1 year)
50.95 €
Ready for dispatch
on Monday, 04.08.2025
starting from 1.99 €
Delivery options
  • Omniva parcel machine
    Within 1-2 working days
    1.99 €
  • SmartPosti parcel terminal
    Within 1-2 working days
    1.99 €
  • Delivery by courier to the address
    Within 1-2 working days
    5.99 €
Main product parameters All parameters
  • Producer: Cougar
  • Power output: 650W
  • 80 PLUS certification: 80 PLUS (White)
  • Fan size: 120 mm
  • Modular cables: Nav
  • Processor plug-in: 1 x 8-pin(4+4) EPS
  • PCI-E: 2 X 6+2pin
Description

We offer to purchase a Cougar power supply unit with a power capacity of 650W, which has received the 80 PLUS (White) energy efficiency certification.

650W power is sufficient for web browsing, Microsoft Office, and playing simple computer games. The power supply can run a computer with one or two hard drives, a mid-range graphics card (such as the GTX 1650), and a mid-range processor. If you are a serious computer games enthusiast, buy a more powerful power supply.

This power supply unit is equipped with a 120 mm fan, which is the industry standard for ensuring quiet operation in average computers. If you want an especially quiet unit, look for one with a fan diameter of 135 mm or 140 mm.

The power supply has been awarded the 80 PLUS (White) energy efficiency certificate, which ensures at least 80% efficiency. This indicates that at least 80 W out of 100 W of power received from the mains by the power supply is delivered to the computer components, with the remaining 20 W being lost as heat.

The color of the power supply is Melna. It is equipped with flat cables, whose color is Raiba.

This power supply unit has been assigned the ATX 2.0 standard. This means that the unit is equipped only with 6-pin and 8-pin connectors, providing 75W and 150W power respectively. It's important to note that this unit will be compatible with RTX 4070 and more powerful cards, but you will need to use the 2x8-pin to 16-pin 12VHPWR adapter included with the graphics card. ATX 2.0 power connectors are not designed to handle the high power fluctuations of modern graphics cards; therefore, if you are building a system with a powerful GPU, such as the RTX 4070, we recommend choosing a power supply unit with the ATX 3.* standard and 12VHPWR (PCIe 5.0) connector.

This power supply unit does not have modular cables – all its cables are attached to the unit and are not detachable. Despite the simple design, it will fulfill its functions just as well as a power supply unit with modular cables.

Basic information
Cybenetics Efficiency certification : Nav
Cybenetics Noise level certification : Nav
Power supply type : ATX
Power output 650W
The capacity of the power supply unit in watts. A higher capacity means higher stability of the computer operation. The recommended capacity of the power supply unit of a modern average computer is 500 W and above. If you use several HDDs, a powerful video card and processor it is recommended to buy a power supply unit with the capacity 600 W or above.
80 PLUS certification : 80 PLUS (White)
Total amperage (+12V) : 52A
Fan size : 120 mm
Functionality
Cable colour : Raiba
Lighting : Nav
Color : Melna
Modular cables : Nav
Ports and equipment
PCI-E 5.0/5.1 : Nav
Processor plug-in : 1 x 8-pin(4+4) EPS
Motherboard power : 20+4pin
PCI-E : 2 X 6+2pin
SATA cconnectors : 6
4pin Molex : 2
Case
  • Alternatives
  • Alternatives
More detailed specification
+3.3V - 18 Ampērs (115 Vats)
+5V - 20 Ampērs (115 Vats)
+5VSB - 3 Ampērs
+12V - 52 Ampērs (624 Vats)
-12V - 0.3 Ampērs
4-pin Peripheral Power Connector - 2
4/8-pin +12V Power Connector - 1
6/8-pin PCI Express Connector - 2
20+4-pin Main Connector - 1
80 Plus Certification - Jā
Aizsardzība pret ķēdēm - Pārspriegums Undervoltage Pārslodzes strāva Short Circuit Protection Over Power
Barošanas adaptera un barošanas avota funkcijas - Active PFC
Barošanas ierīces atrašanās vieta - Plug-in-module
Barošanas ierīces tips - Power Supply
EAN kods - 4710483776458
Economic operator in EU / authorized representative - COMPUCASE Enterprise Co., Ltd.
Efficiency - 86procenti
Electronic address - info@cougargaming.com
Fan Diameter - 120 milimetrs
Fans Installed Quantity - 1
Gabali iepakojumā - 1
Garantija Produkti atgriežami - Jā
Garantijas apstiprināšanas kritēriji - Sērijas numurs
Garantijas termiņš (mēnesis) - 24 mēnesis(-i)
Ieejas spriegums - AC 200-240 volts
Iekļauti aksesuāri - Ātrā lietošanas pamācība
Iepakojuma augstums (mm) - 165 milimetrs
Iepakojuma garums (mm) - 187 milimetrs
Iepakojuma platums (mm) - 158 milimetrs
Iepakojuma svars Brutto (kg) - 2.02 kilograms
Iepakojuma svars Netto (kg) - 0.2 kilograms
Iepakojuma tips - Kaste
Iepakojums kastē - 9
Image - https://content.it4profit.com/pimg/s/resize/900x900x900x900/240207090012079251.jpg
Image - https://content.it4profit.com/pimg/s/resize/900x900x900x900/240207090012142106.jpg
Image - https://content.it4profit.com/pimg/s/resize/900x900x900x900/240207090012178391.jpg
Image - https://content.it4profit.com/pimg/s/resize/900x900x900x900/240207090012230272.jpg
Input Frequency - 50 Hercs
Kastes augstums (mm) - 185 milimetrs
Kastes garums (mm) - 580 milimetrs
Kastes platums (mm) - 495 milimetrs
Kastes svars Brutto (kg) - 19.28 kilograms
Maksimālā izejas jauda - 650 Vats
Mazumtirdzniecības iepakojuma neto svars Plastmasa - 0.03 kilograms
Mazumtirdzniecības iepakojums Neto svars Kartona kārba - 0.17 kilograms
Nominālā ieejas strāva - 5 Ampērs
Postal address - No. 225, Lane 54, An-Ho Rd., Sec.2, Tainan, Taiwan R.O.C.
ProductCard - https://content.it4profit.com/itshop/itemcard_cs.jsp?ITEM=231121110914543915&THEME=asbis&LANG=lv
ProductCategory - Kabeļi
ProductCode - STC650
ProductDescription - COUGAR STC650 PSU, 80 plus White, 650W
ProductType - Power Supply Unit
S-ATA Connector - 6
Vendor - COUGAR GAMING
Ārējā krāsa - Melna
50.95 €
