ID: 1188933
Product code: TACMARS-MPB550SI
In office 1 units
Warranty: 2 years
Mars Gaming MPB550SI, 550W, 80PLUS Bronze
Picture may differ from actual product, there can be accessories and parts not supplied with the actual product.
-
Omniva parcel machineWithin 1-2 working days1.99 € -
Itella parcel machineWithin 1-2 working days1.99 € -
Delivery by courier to the addressWithin 1-2 working days5.99 €
Main product parameters All parameters
- Producer: Mars Gaming
- Power output: 550W
- 80 PLUS certification: 80 PLUS Bronze
- Fan size: 120 mm
- Modular cables: Nav
- Processor plug-in: 1 x 8-pin(4+4) EPS
- PCI-E: 1 X 6+2pin
Description
We offer to purchase a Tacens power supply unit with a power capacity of 550W, which has received the 80 PLUS Bronze energy efficiency certification.
The power of 550W is more than sufficient for office programs, web browsing, and light computer games. It will be able to run a basic computer with an integrated graphics card, budget-level processor, small SSD or hard drive. If you plan to upgrade your computer in the future, you should definitely consider a more powerful power supply.
The diameter of this power supply unit's fan is 120 mm, which will ensure quiet operation in mid-range computers. For especially quiet power supply unit operation, we recommend selecting a fan with a 135 mm or 140 mm diameter.
The power supply has received the 80 PLUS Bronze energy efficiency certificate, which guarantees at least 85% efficiency at 50% load. This means that for every 100W of power the power supply draws from the electrical grid, at least 85W is delivered to your computer components, while the remaining 15W is lost as heat.
The color of the power supply is Melna. It is equipped with flat cables, whose color is Melna.
ATX 2.0 standard, which is assigned to this power supply unit, ensures that the unit is equipped only with 6-pin and 8-pin connectors (with respective power of 75W and 150W). For a system with a very powerful graphics card (such as RTX 4070), an ATX 3.* standard unit will be required, and ATX 2.0 will not be sufficient.
This power supply has no removable cables and all cables are attached to the power supply. It has a simple design, but it works just as well as a power supply with modular cables.
Basic information
Cybenetics Efficiency certification
: Nav
Cybenetics Noise level certification
: Nav
Power supply type
: ATX
Power output
550W
The capacity of the power supply unit in watts. A higher capacity means higher stability of the computer operation. The recommended capacity of the power supply unit of a modern average computer is 500 W and above. If you use several HDDs, a powerful video card and processor it is recommended to buy a power supply unit with the capacity 600 W or above.
80 PLUS certification
: 80 PLUS Bronze
Total amperage (+12V)
: 45A
Fan size
: 120 mm
Functionality
Cable colour
: Melna
Lighting
: Nav
Color
: Melna
Modular cables
: Nav
Ports and equipment
PCI-E 5.0
: Nav
Processor plug-in
: 1 x 8-pin(4+4) EPS
Motherboard power
: 24-pin
PCI-E
: 1 X 6+2pin
SATA cconnectors
: 4
4pin Molex
: 2
More detailed specification
8-pin 12V power connectors - 0
Accessories included -
Brand - Mars Gaming
BrandPartCode - MPB550SI
Category - Power Supply Units
Certificates - Certification - CE, RoHS, TUV
Certificates 80+ - 80 PLUS Bronze
Description - Tacens Mars MPB550SI 550W The MPB550SI 550W ATX power supply redefines performance and efficiency with its Extreme Silence design and integrated advanced technology. Equipped with a copper and aluminium core SI fan and FDB bearings with intelligent AI2-RPM control, it automatically adjusts fan speed using artificial intelligence and machine learning to achieve the ideal balance between silence and cooling. Backed by a 7-year warranty and multiple protection systems, the MPB550SI offers total security and maximum reliability. With 80 Plus Bronze 230V EU certification and DC-DC and SMD technologies, it guarantees superior energy efficiency and exceptional durability.
Design - Cooling type - Active
Design - Fan diameter - 12 cm
Design - Fan location - Top
Design - Number of fans - 1 fan(s)
Design - Product colour - Black
Designation - CE+WEEE
dimensionalWeight - 1230
dimension depth - 125 mm
dimension height - 205 mm
Dimensions - 85 x 145 x 150 mm
dimension weight - 1585 g
dimension width - 240 mm
ean - 8435693108504
Fan - 12 cm
Filters / protection - Circuit
Filters / protection - Overload
Filters / protection - Surge
Filters / protection - Voltage drop
Floppy power connectors - 0
GTIN - 8435693108504
guarantee - 24
guarantee_type - normal
LongDesc - Power Supply Extreme Silence MPB550SIThe MPB550SI 550W ATX power supply redefines performance and efficiency with its Extreme Silence design and integrated advanced technology. Equipped with a copper and aluminium core SI fan and FDB bearings with intelligent AI2-RPM control, it automatically adjusts fan speed using artificial intelligence and machine learning to achieve the ideal balance between silence and cooling. Backed by a 7-year warranty and multiple protection systems, the MPB550SI offers total security and maximum reliability. With 80 Plus Bronze 230V EU certification and DC-DC and SMD technologies, it guarantees superior energy efficiency and exceptional durability.Extreme Silence with Advanced TechnologyExperience absolute silence with the MPB550SI power supply, designed to deliver exceptional performance without distractions. The advanced copper-core SI fan with next-generation FDB bearings minimizes friction and prolongs the lifespan, ensuring ultra-quiet and stable operation even under demanding conditions. The fan’s advanced frame structure and airflow acceleration channels guarantee optimal heat dissipation and continuous airflow to keep temperatures in check, maximizing efficiency at all times.Available in two versionsWhite and blackChoose the one that best suits your setupTotal Protection. 7-Year WarrantyBacked by a 7-year warranty, the MPB550SI safeguards your setup against overloads, short circuits, and other electrical irregularities with the best protection system for your components: OVP, UVP, OCP, OPP, and SCP. Developed in Europe and certified by TÜV Rheinland, a leading German quality and safety laboratory, the MPB550SI meets the highest standards of quality and reliability.Smart Control AI2- RPM. Complete SilenceThe AI2-RPM technology employs machine learning and artificial intelligence to adapt the fan speed in real-time based on system load. This ensures not only exceptional silence but also maximum efficiency. This intelligent adjustment enables the MPB550SI to deliver optimal performance without unnecessary noise, adapting seamlessly to each moment and maintaining the perfect balance between power and silence.80 Plus Bronze CertificationWith 80 Plus Bronze 230V EU certification, the MPB550SI ensures over 90% efficiency, allowing you to save energy and reduce your environmental footprint. This high efficiency helps keep your system cool while maintaining quiet operation, achieving the perfect balance of power, sustainability, and performance.Advanced Technologies: DC-DC and SMDThe MPB550SI integrates advanced DC-DC conversion technology, delivering unparalleled stability and energy efficiency. With a powerful 12V rail, it supports high-power graphics cards, making it ideal for high-performance platforms. The SMD technology enhances the power supply’s durability, ensuring reliable long-term operation. Additionally, it contributes to sustainability by reducing energy consumption by up to 20%, guaranteeing precise voltage regulation to protect even the most sensitive components under any load conditions.Premium CablingExtra-long, flat black cables provide a clean and professional aesthetic, making cable management easy and enhancing airflow within your case.
LongProductName - 550W, 200-240V 47/63Hz, ATX, 80PLUS Bronze 230V EU, 150x145x85mm
LongSummaryDescription - Mars Gaming MPB550SI. Total power: 550 W, AC input voltage: 220 - 240 V, AC input frequency: 47 - 63 Hz. Motherboard power connector: 24-pin ATX, Cabling type: Non-Modular. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Bronze. Product colour: Black, Cooling type: Active, Fan diameter: 12 cm. Certification: CE, RoHS, TUV
MB power connector - 24 pin
Modular power supply - No
MOLEX power connectors - 2
name - Power supply Tacens Mars MPB550SI 550W 80Plus Bronze
Number of connectors PATA - 0
Number of power connectors 12VHPWR - 0
Number of power connectors PCI-E 16-pin Gen 5 - 0
Number of power supply connector 4+4-pin 12V - 1
Number of power supply connector 4-pin 12V - 0
Number of power supply connectors PCI-E 6 +2 pin - 1
Number of USB 10p connectors - 0
Other features -
Packaging data - Package depth - 240 mm
Packaging data - Package height - 125 mm
Packaging data - Package weight - 1.6 kg
Packaging data - Package width - 205 mm
PCI-E 6-pin power connectors - 0
PCI-E 8-pin power connectors - 0
Performance - 80 PLUS certification - 80 PLUS Bronze
Performance - Noise level - 12 dB
Performance - Power supply unit (PSU) form factor - ATX
Performance - Purpose - PC
PFC - Active
Ports & interfaces - Cabling type - Non-Modular
Ports & interfaces - CPU power connector (4+4 pin) - Yes
Ports & interfaces - Motherboard power connector - 24-pin ATX
Ports & interfaces - Number of SATA power connectors - 4
Ports & interfaces - PCI Express power connectors (6+2 pin) - 1
Ports & interfaces - Peripheral (Molex) power connectors (4-pin) - 2
Power - AC input frequency - 47 - 63 Hz
Power - AC input voltage - 220 - 240 V
Power - Combined power (+3.3V) - 100 W
Power - Combined power (+5V) - 100 W
Power - Combined power (+5Vsb) - 12.5 W
Power - Combined power (+12V) - 546 W
Power - Combined power (-12V) - 3.6 W
Power - Efficiency - 90%
Power - Input current - 5 A
Power - Max output current (+3.3V) - 18 A
Power - Max output current (+5V) - 18 A
Power - Max output current (+5Vsb) - 2.5 A
Power - Max output current (+12V) - 45.5 A
Power - Max output current (-12V) - 0.3 A
Power - Power Factor Correction (PFC) type - Active
Power - Power protection features - Over current
Power - Power protection features - Over current, Over power, Over voltage, Short circuit, Under voltage
Power - Power protection features - Over power
Power - Power protection features - Over voltage
Power - Power protection features - Short circuit
Power - Power protection features - Under voltage
Power - Total power - 550 W
Power supply - 550 W
producer - AeroCool
producerCode - TACMARS-MPB550SI
productName - Mars Gaming MPB550SI power supply unit 550 W 24-pin ATX ATX Black
ProductName - MPB550SI
productSize - Normal
SATA power connectors - 4
ShortSummaryDescription - Mars Gaming MPB550SI, 550 W, 220 - 240 V, 47 - 63 Hz, 5 A, Active, 100 W
sizeX - 240
sizeY - 205
sizeZ - 125
Title - Mars Gaming MPB550SI power supply unit 550 W 24-pin ATX ATX Black
URL - https://www.marsgaming.eu/en/power-supplies/power-supply-extreme-silence-mpb550si_mpb550si
vendpn - TACMARS-MPB550SI
WarrantyInfo - 7 years
warrantyLength - 24
warrantyType - G
Weight - 1.45 kg
weight - 1595
Weight & dimensions - Depth - 145 mm
Weight & dimensions - Height - 85 mm
Weight & dimensions - Weight - 1.4 kg
Weight & dimensions - Width - 150 mm
