Antenna - Antenna design - Internal
Antenna - Antenna gain level (max) - 15 dBi
ARTIKEL1 - LONG RANGE WIRELESS AC BRIDGE
ARTIKEL2 - BRIDGE
Brand - D-Link
BrandPartCode - DAP-3711
Breite - 0
Category - Bridges & Repeaters
Category 1 - Netzwerk
Category 2 - Accesspoints
Category_1 - Network and Servers
Category_2 - Network - WiFi Access Points
Certificates - Certification - CE, FCC
Data transmission - Maximum data transfer rate - 867 Mbit/s
Data transmission - Maximum transfer distance - 5000 m
EAN - 0790069457272
EANCode - 0790069457272
EAN_code - 0790069457272
Features - International Protection (IP) code - IP66
Features - LED indicators - LAN, Power, Signal strength, WLAN
Features - Material - Acrylonitrile butadiene styrene (ABS)
Features - Mounting type - Pole
Features - Product colour - White
Features - Product type - Network bridge
Features - Reset button - Yes
Features - Surge protection - Yes
GRUPPE1 - Network
GRUPPE2 - Wireless Lan Ap
GTIN - 0790069457272
GTIN - 790069457272
HERSTELLER - D-LINK
Hoehe - 0
HSTNUMMER - DAP-3711
Laenge - 0
Logistics data - Harmonized System (HS) code - 85176990
LongDesc - HighlightsThe DAP-3711 is the essential solution in providing connectivity to previously believed impossible-to-reach areas. Industry leading core technologies, especially designed for long distance coverage, bring high-speed connectivity to rural areas and challenging terrain equivalent to that of a wired connection.TDMA Technology Cuts Through the Chatter, Creating Even Stabler CoverageThe DAP-3711 transmission capability is augmented thanks to its integrated Time Division Multiple Access (TDMA). Everything works more efficiently on a schedule, and the DAP-3711 is no different: TDMA creates a schedule for multiple connected clients to work to. Senders and receivers get their own time slot for transmissions. This eliminates hidden node data collisions, in turn maximizing airtime efficiency, significantly cutting down interference and making for a highly scalable solution.Form Without Sacrificing FunctionIt can be hard to look good while still being functional. Yet the DAP-3711 strikes the balance just right. The smooth case in crisp white makes for a low-key form that can effortlessly fit any outdoor setting without drawing attention.Being as functional as it is well-formed, it champions an IP66 rating, fighting dust and repelling water, all while maintaining its unassuming looks.Cutting Edge Hardware Makes the Previously Impossible, PossibleThe DAP-3711 features state-of-the-art hardware, including a high-gain 15 dBi directional antennas. This powerful antenna effortlessly extends high-speed coverage to distances of up to 5 km away.Discreet Deployment that’s Hassle-Free with Power Over Ethernet (PoE)Power sockets can be tricky to come by, especially in outdoor deployments. But PoE makes for easy installation and a simple, clean setup. No need to run extra power lines, no added hassle when configuring your hardwiring, and no more cable clutter.
LongProductName - 5 km Long Range Wireless AC Bridges DAP-3711
LongSummaryDescription - D-Link 5 km Long Range Wireless AC Bridges DAP-3711. Maximum data transfer rate: 867 Mbit/s, Maximum transfer distance: 5000 m. Antenna design: Internal, Antenna gain level (max): 15 dBi. Wi-Fi band: Single-band (5 GHz), WLAN data transfer rate (max): 867 Mbit/s, Frequency band: 5.180 - 5.825 GHz. Ethernet LAN interface type: Gigabit Ethernet, Ethernet LAN data rates: 100,1000 Mbit/s, Networking standards: IEEE 802.11a, IEEE 802.11ac, IEEE 802.11n. Connectivity technology: Wired & Wireless
Management features - Web-based management - Yes
Manufacturer - D-Link
Manufacturer_code - DAP-3711
MPN - DAP-3711
Name - D-Link DAP-3711
Name - D-Link DAP-3711 Long Range Wireless AC Bridge
Network - Cabling technology - 10/100/1000Base-T(X)
Network - Ethernet LAN - Yes
Network - Ethernet LAN data rates - 100,1000 Mbit/s
Network - Ethernet LAN interface type - Gigabit Ethernet
Network - Networking standards - IEEE 802.11a, IEEE 802.11ac, IEEE 802.11n
Network - Wireless Distribution System (WDS) bridge - Yes
Operational conditions - Operating relative humidity (H-H) - 0 - 90%
Operational conditions - Operating temperature (T-T) - -40 - 65 °C
Operational conditions - Storage relative humidity (H-H) - 0 - 90%
Operational conditions - Storage temperature (T-T) - -40 - 85 °C
Packaging data - Quantity per pack - 1 pc(s)
Ports & interfaces - Connectivity technology - Wired & Wireless
Ports & interfaces - Ethernet LAN (RJ-45) ports - 2
Power - Power consumption (typical) - 15 W
Power - Power over Ethernet (PoE) - Yes
Power - Power over Ethernet (PoE) voltage - 24 V
Power - Power source type - PoE
ProductName - 5 km Long Range Wireless AC Bridges DAP-3711
Security - MAC address filtering - Yes
Security - Security algorithms - 128-bit AES
ShortSummaryDescription - D-Link 5 km Long Range Wireless AC Bridges DAP-3711, Network bridge, 867 Mbit/s, Wi-Fi, Ethernet LAN, White
Stck_Kart - 9998
Stck_Pal - 0
Storno - N
Title - D-Link 5 km Long Range Wireless AC Bridges DAP-3711
URL - https://www.dlink.com/en/products/dap-3711-5-km-long-range-80211ac-wireless-bridge
WarrantyInfo -
Weight - 0,88
Weight & dimensions - Depth - 45 mm
Weight & dimensions - Height - 88 mm
Weight & dimensions - Weight - 600 g
Weight & dimensions - Width - 288 mm
Wireless LAN features - Channels quantity - 2 channels
Wireless LAN features - Frequency band - 5.180 - 5.825 GHz
Wireless LAN features - Signal strength - 27 dBm
Wireless LAN features - Wi-Fi - Yes
Wireless LAN features - Wi-Fi band - Single-band (5 GHz)
Wireless LAN features - WLAN data transfer rate (max) - 867 Mbit/s
