Ubiquiti NanoStation 5AC

Picture may differ from actual product, there can be accessories and parts not supplied with the actual product.
ID: 933673 Product code: NS-5AC
In stock 1 units
Warranty: 2 years (Warranty for business entities 1 year)
121.37 €
Ready for dispatch
on Monday, 22.12.2025
starting from 1.99 €
Delivery options
  • Omniva parcel machine
    Within 1-2 working days
    1.99 €
  • SmartPosti parcel terminal
    Within 1-2 working days
    1.99 €
  • Delivery by courier to the address
    Within 1-2 working days
    5.99 €
Main product parameters All parameters
  • Speed index: 450
  • Type of device: Antenna
  • Wi-Fi standard: N/A
Basic information
Speed index : 450
Type of device Antenna

Access Point - bezvadu piekļuves punkts, kas nodrošina kabeļu tīkla paplašināšanas pārraidi bezvadu tīklā izmantojot vienu LAN pieslēgvietu. Access point nav rūteris, un nespēj sadalīt vienu interneta pieslēguma adresi vairākiem datoriem, tamdēļ šo iekārtu slēdziet tikai aiz esoša kabeļu rūtera.

Router, jeb maršrutētājs - bezvadu piekļuves punkts, kas nodrošina viena interneta pieslēguma sadalīšanu vairākiem datoriem, gan caur tīkla vadiem, gan bezvadu tīklā. Parasti bezvadu maršrutētājam ir viena kabeļu interneta pieslēgvieta, četras datoru pieslēgvietas (kuras var papildināt, izmantojot switch komutatoru) un antenas, kas nodrošina apraidi datoriem un citām WiFi iekārtām.

Range Extender - bezvadu tīkla apraides attāluma pastiprinātājs. Paredzēts esoša signāla pastiprināšanai, lai palielinātu uzveršanas un pārraides attālumu.

Wifi adapter - Bezvadu tīkla karte, paredzēta datora pieslēgšanai pie bezvadu WiFi rūtera vai piekļuves punkta. PCI, PCI-E ir paredzēti galddatoriem, savukārt PCMCIA un USB - portatīvajiem datoriem. Jāpiebilst, ka lielākā daļa portatīvo datoru jau rūpnīcā tiek komplektēti ar bezvadu tīkla kartēm.

USB tīkla karte ir pēdējā izvēle, jo USB2.0 caurlaidības ātrums ir samērā zems ~22MB/s, kas nozīmē to, ka netiks izmantots bezvadu tīkla maksimālais iespējamais ātrums. Ja ir iespēja, labāk izvēlēties kādu citu pieslēguma veidu.

Wi-Fi standard : N/A
Functionality
3G/4G support Nav

A possibility to put the SIM card of mobile operators or the USB Dongle adapter in the router providing access to the 3G mobile Internet.

Prior to buying a router with the 3G support you should verify whether the device supports the 3G USB Dongle receiver of the particular mobile communications operator at the manufacturer's website.

Band mode N/A

SingleBand is a standard wireless technology characteristic of all the modern wireless devices.

DualBand is 2.4GHz with an additional 5.0GHz channel providing better receiving of the signal and more stable high-speed operation. For using this function both devices, i.e. the router and the wireless network card, have to support the DualBand mode.

Ethernet 100/1000

LAN or ethernet cables connection slots operational mode.

10/100 MB.s is the standard speed characteristic of almost all the routers.

10/100/1000 MB.s, or GigaBit is tens of times faster standard which, in combination of GigaBit LAN network cards, provides great data transmission speed advantages between computers connected within the internal network. This solution is usually required in offices where large data volumes are copied between computers or fast Internet connection is used (no ~30 MB/s) simultaneously in several computers.



Ports and equipment
LAN ports : 2
More detailed specification
Additional information in manufacturers website Ubiquiti NanoStation 5AC
10/100/1000M LAN Ports - 2
Amplification - 16 decibeli (izotropiski)
Antenna - Internal
Antenna - Antenna gain level (max) - 16 dBi
Antenna Gain - 16 dB
Augstums (mm) - 257 milimetrs
brand - Ubiquiti
category - Ubiquiti > Āra Wi-Fi > airMAX 5 GHz
Category 1 - Netzwerk
Category 2 - Netzwerkartikel
Category Code - WOD
Certificates - Certification - CE, FCC, IC
CPU - Atheros MIPS 74KC
Data transmission speed - 450 Mbps
Description - The indoor/outdoor NanoStation® AC and NanoStation AC loco are compact, high-performance CPEs featuring airMAX® AC technology and a dedicated Wi-Fi radio for management.
Design - Internal - No
Design - LED indicators - Network
Design - LED indicators - Power
Design - LED indicators - Signal strength
Design - Placement - Ceiling
Design - Product colour - White
dimensionalWeight - 613
Dimensions - 257 x 84 x 41mm
Dziļums (mm) - 30 milimetrs
EAN - 0817882021371
EAN - 8178820213718
EAN kods - 817882021371
Features - 5 GHz - Yes
Features - Channel bandwidth - 80 MHz
Features - Ethernet LAN data rates - 10
Features - Ethernet LAN data rates - 100
Features - Ethernet LAN data rates - 1000 Mbit/s
Features - Maximum data transfer rate - 1000 Mbit/s
Features - Maximum outdoor range - 15000 m
Features - Modulation - 16-QAM
Features - Modulation - 64-QAM
Features - Modulation - 256-QAM
Features - Modulation - BPSK
Features - Modulation - QPSK
Features - Throughput data rate - 450 Mbit/s
Gabali iepakojumā - 1
Garantija Produkti atgriežami - Jā
Garantijas apstiprināšanas kritēriji - Sērijas numurs
Garantijas termiņš (mēnesis) - 24
height - 0.11 m
Iepakojuma augstums (mm) - 89 milimetrs
Iepakojuma garums (mm) - 312 milimetrs
Iepakojuma platums (mm) - 113 milimetrs
Iepakojuma svars Brutto (kg) - 0.7995 kilograms
Iepakojuma svars Netto (kg) - 0.2 kilograms
Iepakojuma tips - Cits
Iepakojums kastē - 10
Ierīces atrašanās vieta - Ārējais
Image - https://content.it4profit.com/pimg/s/resize/500x500x500x500/180712100008743887.jpg
Interfeiss - Ethernet/Wi-Fi
Internal Clock Rate - 560 megahercs
Kastes augstums (mm) - 345 milimetrs
Kastes garums (mm) - 468.5 milimetrs
Kastes platums (mm) - 240 milimetrs
Kastes svars Brutto (kg) - 8.81 kilograms
LAN - 2 (RJ-45)
length - 0.31 m
Line Modulation Type - 16QAM 64QAM BPSK QPSK 256QAM
Local Area Network Architecture - 10Base-T/100Base-TX/1000Base-T
Logistics data - Harmonized System (HS) code - 85176990
Maks. Diapazons Atvērtā telpa - 15 kilometrs
Maksimālais darba mitrums - 95 procenti
Maksimālā darba vides temperatūra - 70 Celsija grāds
Manufacturer - Ubiquiti
Mazumtirdzniecības iepakojuma neto svars Plastmasa - 0.23 kilograms
Mazumtirdzniecības iepakojums Neto svars Kartona kārba - 0.23 kilograms
Minimālais darba gaisa mitrums - 5 procenti
Minimālā darba vides temperatūra - -40 Celsija grāds
mpn - NS-5AC
MPN - NS-5AC
Name - Z Ubiquiti NS-5AC
Network Device Type - Wireless CPE
Networking Features - Power over Ethernet (PoE)
Nominālais svars - 0.233 kilograms
Number of Ports - 1
Operational conditions - Operating relative humidity (H-H) - 5 - 95%
Operational conditions - Operating temperature (T-T) - -40 - 70 °C
Packaging content - PoE adapter included - Yes
Performance - Built-in processor - Yes
Performance - Internal memory - 64 MB
Performance - Operating system installed - AirOS
Platums (mm) - 84 milimetrs
PoE Adapter - ĀrējaisOutput: DC 24 volts
Ports & interfaces - Ethernet LAN (RJ-45) ports - 2
Power - AC input voltage - 24 V
Power - Input current - 0.5 A
Power - Power over Ethernet (PoE) - Yes
Power consumption - 8.5 Watts
Power Consumption Operational - 9 Vats
Power supply requirements - 24V, 0.5A Gigabit PoE Supply (Included)
producerCode - NS-5AC
ProductCard - https://content.it4profit.com/itshop/itemcard_cs.jsp?ITEM=180611065905364050&THEME=asbis&LANG=lv
ProductCategory - Tīkla produkti
ProductCode - NS-5AC-EU
ProductDescription - Ubiquiti airMAX NanoStation 5AC, UISP-supported WiFi radio designed for point-to-point and customer premises applications, 5 GHz, 15+ km link range, 450+ Mbps throughput, Secondary LAN with PoE out support, PoE adapter included,Pole and wall mounting
productName - Ubiquiti NanoStation AC 1000 Mbit/s White Power over Ethernet (PoE)
Product Net Weight - 0.233 kg
productSize - Normal
ProductType - Networking - Wireless Outdoor Access Point
RAM - 64 MB
RAM - 64 megabaits DDR2 SDRAM
Safety warning - Warnings - Do not open the appliance, it does not contain serviceable parts.
Safety warning - Warnings - Keep the unit away from moisture and high temperatures.
Safety warning - Warnings - Use the appliance in accordance with its intended use to avoid risk of injury.
Sertifikācija - CE, FCC, IC
sizeX - 310
sizeY - 90
sizeZ - 110
title - Ubiquiti airMAX NanoStation 5AC
Unit Box Height - 0.09
Unit Box Length - 0.315
Unit Box Width - 0.115
Unit Calculated Volume - 0.00326 cubm
Unit Calculated Weight - 0.77 kg
Units per Shipping Box - 1
Vendor - UBIQUITI
Vendor Homepage - www.ubnt.com/airmax/nanostation-ac/
Warranty - 12 months
warrantyLength - 24
Warranty Term Notes - 24 months - for EU
warrantyType - G
Weight - 0.76
weight - 0.89 kg
weight - 780
Weight & dimensions - Depth - 84 mm
Weight & dimensions - Height - 41 mm
Weight & dimensions - Weight - 233 g
Weight & dimensions - Width - 257 mm
width - 0.12 m
Wireless Frequency Range - 5 GHz
Ārējā krāsa - Balts
